Enertrak AMF-9920 Series User manual

USER MANUAL
FOR
AMF CONTROLLER
MODEL –AMF-9920
Version –3.10
Release of Date- 22/01/2021
AMF V3.10
SRN 000001

Table of Content
Sr.No.
Description
Page No.
1
Introduction
1
2
Features
1
3
Front Panel Configuration
1
4
Push Button
2
5
Display Parameter
2-3
6
Specification- LED
4
7
Action on Faults
4
8
Description of Programming Parameter
5-6
9
Operation
6-7
10
Programming Parameters
A) Configuration Parameters –Timer (Page-1)
7
B) Configuration Parameters –Generator (Page-2)
8-9
C) Configuration Parameters –Mains (Page-3)
10
D) Configuration Parameters –Engine (Page-4)
10-11
E) Configuration Parameters –Digital Inputs (Page-5)
11-12
F) Configuration Parameters –Analogue Inputs (Page-6)
12-13
G) Configuration Parameters –Output (Page-7)
13-14
H) Configuration Parameters –(Page-8)
14
I) Configuration Parameters –Maintenance (Page-9)
14
J) Configuration Parameters –Scheduler (Page-10)
14-15
K) Configuration Parameters –Sensor(Page-11)
16
11
Sensor Type
17
12
AC System
17
13
Digital Input Polarity
17
14
Digital Output Polarity
17

15
Action
17
16
Activation
17
17
Input Sources
18
18
Output Sources
18
19
Instrumentation Icons
19
20
MODE ICON
19
21
LOAD SWITCHING ICON
19
22
WARNING ALARM ICONS
20
23
ELECTRICAL TRIP ALARM ICONS
20
24
SHUTDOWN ALARM ICONS
21
25
Communication Port
A)Can Interface
B)USB Connection
22-23
26
DO’S AND DON’T
23
27
General characteristics
24
28
Terminal description
25
29
Display Monitoring
26-30

1
INTRODUCTION
Smart DG Controller is an advanced Micro controller based DG Protection unit and has been
specially designed to meet the harsh requirement of Indian conditions.
The AMF-9920 series module has been designed to allow the operator to start and stop the
generator, and if required, transfer the load to the generator either manually or automatically.
Additionally, the AMF-9920 automatically starts and stops the generator set depending upon the
status of the mains (utility) supply.
The AMF-9920 module monitors the engine, indicating the operational status and fault conditions,
automatically shutting down the engine and giving a true first up fault condition of an engine
failure by the LCD display.
FEATURES
• Micro Controller Based Design
• Compact Size , Elegant Design & Easy Install
• Icon based LCD display
• True RMS Voltage
• Current and Power monitoring
• USB Communications
• Engine parameter monitoring.
• Remote Start/Stop
FRONT PANEL CONFIGURATION
MCB/GCB
Contactor
ON/OFF
LED blinking in
Manual Mode
(Manual/Start
Mode)
Manual/ Start
Mode Key
Auto Mode
Key
Gen. Set
Contactor LED
LED will glow
continuously
when in Auto
Mode
Stop/ Reset
Mode Key
Mains Contactor
LED
LED will glow
continuously in stop
mode and blinking in
Fault upon Electrical
Trip & Shutdown Fault
Menu Navigation
Module Display
AMF V3.10
SRN 000001

2
PUSH BUTTON-
ICON
DESCRIPTION
STOP/RESET MODE
This key is used to Stop DG Set in Manual Mode & Reset if any fault
Condition Present.
AUTO MODE
This key is used to set in Auto Mode and for event log exit.
MANUAL/START MODE
This key is used to start the DG Manually.
MENU NAVIGATION
Both key is used to shift from one Page to another Page in
Programming mode and used to enter in Event Log History Mode.
MCB/GCB MODE
By Pressing both key and key simultaneously to ON/OFF MCB
Contactor & by Pressing both and key simultaneously to
ON/OFF GCB Contactor.
DISPLAY PARAMETER
Sr.No.
DISPLAY
PARAMETER
DESCRIPTION
Display
DISPLAY
SCREEN
1
AMF V3.10
SRN 000001
Display Version
Graphical
Display
Screen-1
2
000VL1N 000V
000VL2N 000V
000V L3N 000V
Generator & Mains Voltage
(L-N)
Graphical
Display
Screen-2
3
O00V L1L2 000V
O00V L2L3 000V
O00V L3L1 000V
Generator & Mains Voltage
(L-L)
Graphical
Display
Screen-3
4
L1N 000V
L2N 000V
L3N 000V
Generator Voltage (L-N)
Graphical
Display
Screen-4
5
L1L2 000V
L2L3 000V
L3L4 000V
Generator Voltage (L-L)
Graphical
Display
Screen-5
6
00.00 Hz
Generator Frequency
Graphical
Display
Screen-6
7
L1N 000V
L2N 000V
L3N 000V
Mains Voltage(L-N)
Graphical
Display
Screen-7
8
L1L2 000V
Graphical

3
L2L3 000V
L3L1 000V
Mains Voltage(L-L)
Display
Screen-8
9
00.00Hz
Mains Frequency
Graphical
Display
Screen-9
10
L1 00.00A
L2 00.00A
L3 00.00A
Load Current (A)
Graphical
Display
Screen-10
11
00.0% L1 00.00 KW
00.0% L2 00.00 KW
00.0% L3 00.00 KW
Active Power % &
Active Power Per Phase (kW)
Graphical
Display
Screen-11
12
L1 00.0 KVA
L2 00.0 KVA
L3 00.0 KVA
Apparent Power (KVA)
Graphical
Display
Screen-12
13
L1 0.00 PF
L2 0.00 PF
L3 0.00 PF
Power Factor
Graphical
Display
Screen-13
14
00.00 KW
00.00 KVA
0.00 PF
Combined Active Power
Combined Apparent Power
Avg. Power Factor
Graphical
Display
Screen-14
15
0000.0 kWh 0000.0
kWh
DG kWh
Mains kWh
Graphical
Display
Screen-15
16
00.00 V
Battery Voltage
Graphical
Display
Screen-16
17
00.00 V
Charging Alternator
Graphical
Display
Screen-17
18
00.0 Bar
Oil Pressure
Graphical
Display
Screen-18
19
000⁰C
Temperature
Graphical
Display
Screen-19
20
000%
Fuel Level
Graphical
Display
Screen-20
21
000000:00
00000
Run Hours
No of Start
Graphical
Display
Screen-21
22
0000:00 R
0000:00 S
Service Hour
Graphical
Display
Screen-22
23
0000
Engine Speed
Graphical
Display
Screen-23
24
METER SRN
000001
ID 001
Meter Serial No.
Communication ID
Graphical
Display
Screen-24
25
ALARMS
Fault Alarm
Graphical
Display
Screen-25
26
Status
Fault Status
Graphical
Display
Screen-26
27
XX:XX:XX
XX XX/XX/XX
RTC (Real time Clock)
Graphical
Display
Screen-27

4
SPECIFICATION –LED
LED will glow, whenever the corresponding condition is sensed by the controller.
Tag
LED Status
NORMAL
Active
START
OFF
ON
STOP
OFF
ON
AUTO
OFF
ON
GCB
OFF
ON
MCB
OFF
ON
ACTION ON FAULTS
Sr.No.
Name of Faults
Description of Indication
1
FAIL TO START
When after no. of Set attempt , DG not start then
FAIL TO START fault occur & Graphical Display
2
LLOP
DG Stop and GCB Contactor OFF & Graphical
Display
3
HCT / HWT
DG Stop and GCB Contactor OFF & Graphical
Display
4
RWL
DG Stop and GCB Contactor OFF & Graphical
Display
5
LOW FUEL
DG Stop and GCB Contactor OFF & Graphical
Display
6
EMERGENCY / CANOPY
DG Stop and GCB Contactor OFF & Graphical
Display
7
UNDER/OVER VOLTAGE
DG Stop and GCB Contactor OFF & Graphical
Display
8
UNDER / OVER SPEED
DG Stop and GCB Contactor OFF & Graphical
Display
9
UNDER /OVER
FREQUENCY
DG Stop and GCB Contactor OFF & Graphical
Display
10
OVER CURRENT
DG Stop and GCB Contactor OFF & Graphical
Display
11
UNBALANCE CURRENT
DG Stop and GCB Contactor OFF & Graphical
Display
12
CHARGING ALTERNATOR
DG Stop and GCB Contactor OFF & Graphical
Display
13
UNDER / OVER BATTERY
DG Stop and GCB Contactor OFF & Graphical
Display
14
OVER ACTIVE
POWER(KW)
DG Stop and GCB Contactor OFF & Graphical
Display
15
SERVICE DUE
ALARM & Graphical Display

5
Description of Programming Parameter
Step
Process
1
Press and hold the and buttons together to enter the editor mode. Display
shows
PROGRAMMING MODE
PASSWORD
0000
2
Press button 1 appear on right side on LCD means first digit from MSB can change
from 0-9 by using button .For Password Enter “1” at first digit.
PROGRAMMING MODE
PASSWORD
1000 1
3
Use button to shift to next digit , now can change value of second digit from 0 to 9
by using button and enter “0”and so on.
PROGRAMMING MODE
PASSWORD
1000 4
4
After entering ‘1000’ Press button again. If the entered Password is correct then
controller shifts to programming page otherwise the controller shows’0000’ and
again prompts for entry of password.
5
Press the or navigation buttons to cycle through the front panel editor to
select the required page in the configuration tables.
6
Press the to select the next parameter or to select the previous parameter
within the current page.
7
When viewing the parameter to be edited, press the button, the value begins to
flash.

6
8
.
Press the or buttons to adjust the value to the required setting
9
Press the button to save the current value, the value ceases flashing.
10
Press and hold the button to save and exit the editor, the configuration
icon is removed from the display.
11
If User wants to see Event log Fault History then Press & button
simultaneously (Long Press) to enter in Event Log History Mode, then can see
100 faults history by & button. To exit from Event Log History,
Long Press button.
Operation –
Auto Mode - To Enter into Auto mode press key. When the mains unhealthy condition
occurs, first Mains Restoration Delay timer is initiated and genset will be cranked at the end of
this delay. Controller will latch the genset contactor when genset loading voltage and frequency
are above the Minimum Healthy thresholds after the warm-up time is over. Engine run hours will
start incrementing when the genset voltage becomes greater than Minimum Healthy Voltage.
During genset running, if the mains voltage returns, return to Mains Delay timer starts. If the
mains voltage is healthy over the entire return delay duration, genset contactor gets opened and
controller will initiate the stopping sequence and latch the mains contactor after transfer delay.
During start sequence, if the mains voltage recovers or any stop command or shutdown / warning
alarm occurs controller will not issue start command. To start the genset it is necessary to clear
all the alarms manually and put the controller in Auto mode.
Manual Mode –In this mode start and stop key use for starting and stopping DG set.
Remote Mode-
To use Remote mode, follow below points
1) Configure one one digital input as "Remote Start”
2) Configure “Remote Mode ” in Parameter 909.
3) Put controller in Auto mode
In that case if negative present at configurable digital input, controller activate crank relay for
"crank time". DG continue run till Negative present at input and Latch Genset contactor. If mains
become healthy contactor shift to mains and stop dg set.

7
Current Unbalance Detection:-
A) Controller doesn’t take any action till the current is below 25% of the Over current Set Limit
in three Phase.
B) Controller Monitors the Current and upon any phase current exceeding 25% compares it with
other phase currents and if the difference between max current and other phase current
exceed set value in % defined then controller consider it as a current unbalance condition.
C) In case the current unbalance persists for a period greater than the limit specified by with
default setting of programmable parameters and between 1-9999 Sec., then controller issues
STOP Command.
D) The Default setting for this feature is “DISABLE”.
Charging Alternator Type:
If Chg. Alternator Type (Parameter no. 422) = 0 , Sense Signal from W Point.
If Chg. Alternator Type (Parameter no. 422) = 1, Controller Provide Excitation from terminal no. 5
(Chg. Alt/Excite) for 10 sec. when DG Start.
If Chg. Alternator Type (Parameter no. 422) = 2, Controller Provide Excitation from terminal no.
5 (Chg. Alt/Excite) Continuously, when DG Start.
Auto Load Transfer: This function only applicable in Manual Mode.
1) If “Auto Load Transfer” (Parameter -1162) is 1 (ENABLE-1) than shifting of contactors
method change in Manual mode. In this Mode DG Contactor on high priority. If someone
start the DG manually, than DG Contactor Latch either Mains Healthy or Fail.
2) Enable-2 :- Semi Auto
CT On Load: - Measure energy of Mains & DG both depends on Contactor.
CT On DG: - Only Measure DG Energy.
PROGRAMMING PARAMETERS
Configuration Parameters –TIMERS (Page 1)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
101
MAINS RESTORATION TIME
0-999 s
010 s
102
ENGINE START TIME
0-99 s
01 s
103
PREHEAT TIME
0-99 s
05 s
104
CRANK TIME
0-99 s
03s
105
CRANK REST TIME
0-99 s
10 s
106
WARM UP TIME
0-999 s
010 s
107
COOLING TIME
0-999 s
020 s
108
STOP TIME
0-99 s
25 s
109
MCB _GCB CHANGEOVER TIME
0-99 s
01 s
110
BUZZER TIME
0-99 s
60 s
111
LLOP BYPASS TIME
0-99 s
10 s
112
POWER SAVER MODE TIME
0-99 s
60 s
113
FUEL LOGGING TIME
0-99 s
99 s

8
Configuration Parameters –Generator (Page 2)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
201
ALTERNATOR POLES
0- 36
04
202
ENGINE UNDER VOLTAGE TRIP ENABLE
On (1), Off (0)
On(1)
203
ENGINE UNDER VOLTAGE TRIP LEVEL
120-250V
160 V
204
ENGINE UNDER VOLTAGE WARNING ENABLE
On (1), Off (0)
On(1)
205
ENGINE UNDER VOLTAGE WARNING LEVEL
120-250V
180 V
206
ENGINE UNDER VOLTAGE ACTION DELAY
0-99s
10s
207
ENGINE OVER VOLTAGE WARNING ENABLE
On (1), Off (0)
On(1)
208
ENGINE OVER VOLTAGE WARNING RETURN
150-350V
250 V
209
ENGINE OVER VOLTAGE WARNING ALARM
150-350V
260 V
210
ENGINE OVER VOLTAGE TRIP LEVEL
150-350V
265 V
211
ENGINE OVER VOLTAGE ACTION DELAY
0-99s
10s
212
ENGINE UNDER FREQUENCY TRIP ENABLE
On (1), Off (0)
On(1)
213
ENGINE UNDER FREQUENCY TRIP LEVEL
45-60 Hz
47.5Hz
214
ENGINE UNDER FREQUENCY WARNING ENABLE
On (1), Off (0)
On(1)
215
ENGINE UNDER FREQUENCY WARNING LEVEL
45-60 Hz
48 Hz
216
ENGINE UNDER FREQUENCY ACTION DELAY
0-99s
10s
217
ENGINE OVER FREQUENCY WARNING ENABLE
On (1), Off (0)
On(1)
218
ENGINE OVER FREQUENCY WARNING RETURN
LEVEL
45-60 Hz
52.5 Hz

9
219
ENGINE OVER FREQUENCY WARNING ALARM
LEVEL
45-60 Hz
52.5 Hz
220
ENGINE OVER FREQUENCY TRIP ENABLE
On (1), Off (0)
On(1)
221
ENGINE OVER FREQUENCY TRIP LEVEL
45-60 Hz
53 Hz
222
ENGINE OVER FREQUENCY ACTION DELAY
0-99s
10s
223
CT PRIMARY
0005-9999
100
224
AMPERE LOAD RATING ( PER PHASE )
0-9999A
80A
225
OVER AMPERE TRIP ENABLE
On (1), Off (0)
On(1)
226
OVER AMPERE ACTION SELECT
0-3
0
227
OVER AMPERE DELAY TIME
0-9999s
10s
228
OVER AMPERE TRIP PERCENTAGE
0-150%
80%
229
UNBALANCE AMPERE TRIP ENABLE
On (1), Off (0)
Off(0)
230
UNBALANCE AMPERE ACTION SELECT
0-3
0
231
UNBALANCE AMPERE DELAY TIME
0-9999s
10s
232
UNBALANCE AMPERE TRIP PERCENTAGE
0-150%
23%
233
KW LOAD RATING (TOTAL)
0-9999 KW
0072
234
OVER KW TRIP ENABLE
On (1), Off (0)
On(1)
235
OVER KW ACTION SELECT
0-3
0
236
OVER KW ACTION LEVEL PERCENTAGE
0-150%
90 %
237
OVER KW DELAY TIME
0 -9999 s
10s

10
Configuration Parameters –Mains (Page 3)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
301
MAINS AC SYSTEM CONFIGURATION
0 (DG 3P EB
3P)
0 (DG 3P EB
3P)
302
MAINS FAILURE DETECTION ENABLE
On (1), Off (0)
On(1)
303
MAINS UNDER VOLTAGE ENABLE
On (1), Off (0)
On(1)
304
MAINS UNDER VOLTAGE TRIP VOLTAGE LEVEL
120-250 V
160 V
305
MAINS UNDER VOLTAGE RETURN VOLTAGE LEVEL
120-250 V
180 V
306
MAINS UNDER VOLTAGE TRIP OCCURRENCE DELAY
0 -99s
10s
307
MAINS OVER VOLTAGE ENABLE
On (1), Off (0)
On(1)
308
MAINS OVER VOLTAGE RETURN VOLTAGE LEVEL
150-350 V
250 V
309
MAINS UNDER VOLTAGE TRIP VOLTAGE LEVEL
150-350 V
260 V
310
MAINS OVER VOLTAGE OCCURRENCE DELAY
0 -99s
10 s
311
MAINS UNDER FREQUENCY ENABLE
On (1), Off (0)
On(1)
312
MAINS UNDER FREQUENCY TRIP LEVEL
45-60 Hz
47 Hz
313
MAINS UNDER FREQUENCY RETURN
LEVEL
45-60 Hz
47.5Hz
314
MAINS UNDER FREQUENCY OCCURRENCE DELAY
0 -99s
10 s
315
MAINS OVER FREQUENCY ENABLE
On (1), Off (0)
On(1)
316
MAINS OVER FREQUENCY RETURN LEVEL
45-60 Hz
52.5 Hz
317
MAINS OVER FREQUENCY TRIP LEVEL
45-60 Hz
53.0 Hz
318
MAINS OVER FREQUENCY OCCURRENCE DELAY
0 -99s
10 s
Configuration Parameters –Engine (Page 4)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
401
ENGINE START ATTEMPTS
0 -9
3
402
CRANK DISCONNECT OIL PRESSURE ENABLE
On (1), Off (0)
Off (0)
403
CRANK DISCONNECT OIL PRESSURE LEVEL
0.0-9.9
01.0
404
CRANK DISCONNECT FREQUENCY LEVEL
45-60Hz
45 Hz
405
CRANK DISCONNECT RPM LEVEL
1350-1800
1200
406
DG UNDER RPM ENABLE
On (1), Off (0)
On (1)
407
DG UNDER RPM TRIP LEVEL
1350
1350
408
DG UNDER RPM TRIP DELAY
0-99s
10s
409
DG OVER RPM TRIP LEVEL
1600
1600
410
DG OVER RPM TRIP DELAY
0 -99s
10s
411
DG LOW BATTERY ACTION
0-3
2
412
DG LOW BATTERY TRIP VOLTAGE LEVEL
8.0-12.0
11.0
413
DG LOW BATTERY RETURN VOLTAGE LEVEL
8.0-12.0
12.0
414
DG LOW BATTERY DELAY
0 -99s
10s

11
415
DG HIGH BATTERY ACTION
0-3
2
416
DG HIGH BATTERY RETURN VOLT LEVEL
12.0-18.0V
15.0V
417
DG HIGH BATTERY TRIP LEVEL
12.0-18.0V
16.0 V
418
DG HIGH BATTERY DELAY
0 -99s
10s
419
DG CHARGING ALTERNATOR ACTION
0-3
1
420
DG CHARGING ALT. TRIP VOLT. LEVEL
0-35.0V
04.0 V
421
DG CHARGING ALTERNATOR DELAY
0 -99s
10s
422
CHG ALT TYPE
0-2
2
423
FAN FAULT ENABLE
On (1), Off (0)
0ff (0)
424
GSM COM
On (1), Off (0)
0ff (0)
Configuration Parameters –Digital Inputs (Page 5)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
501
DIGITAL INPUT A SOURCE
(LLOP/HWT/LFL/RWL/CANOPY/EMG /REMOTE START/
EARTH FAULT/DOOR OPEN/SIMULATE AUTO/SIMULATE
START/SIMULATE STOP/SIMULATE MAINS/MAINS FAIL)
0(Input Source)
Canopy
502
DIGITAL INPUT A POLARITY
On (1), Off (0)
Off (0)
503
DIGITAL INPUT A ACTION
0-3
0
504
DIGITAL INPUT A DELAY
0 -99s
10s
505
DIGITAL INPUT B SOURCE
(LLOP/HWT/LFL/RWL/CANOPY/EMG /REMOTE START/
EARTH FAULT/DOOR OPEN/SIMULATE AUTO/SIMULATE
START/SIMULATE STOP/SIMULATE MAINS/MAINS FAIL)
0(Input Source)
EMERGENCY
506
DIGITAL INPUT B POLARITY
On (1), Off (0)
Off (0)
507
DIGITAL INPUT B ACTION
0-3
0
508
DIGITAL INPUT B DELAY
0 -99s
10s
509
DIGITAL INPUT C SOURCE
(LLOP/HWT/LFL/RWL/CANOPY/EMG /REMOTE START/
EARTH FAULT/DOOR OPEN/SIMULATE AUTO/SIMULATE
START/SIMULATE STOP/SIMULATE MAINS/MAINS FAIL)
0(Input Source)
LLOP
510
DIGITAL INPUT C POLARITY
On (1), Off (0)
Off (0)
511
DIGITAL INPUT C ACTION
0-3
0
512
DIGITAL INPUT C DELAY
0 -99s
10s

12
513
DIGITAL INPUT D SOURCE
(LLOP/HWT/LFL/RWL/CANOPY/EMG /REMOTE START/
EARTH FAULT/DOOR OPEN/SIMULATE AUTO/SIMULATE
START/SIMULATE STOP/SIMULATE MAINS/MAINS FAIL)
0(Input Source)
HWT
514
DIGITAL INPUT D POLARITY
On (1), Off (0)
Off (0)
515
DIGITAL INPUT D ACTION
0-3
0
516
DIGITAL INPUT D DELAY
0 -99s
10s
517
ANALOGUE INPUT A (SET AS DIGITAL) SOURCE
(LLOP/HWT/LFL/RWL/CANOPY/EMG /REMOTE START/
EARTH FAULT/DOOR OPEN/SIMULATE AUTO/SIMULATE
START/SIMULATE STOP/SIMULATE MAINS/MAINS FAIL)
0(Input Source)
LFL
518
ANALOGUE INPUT A (SET AS DIGITAL) SOURCE
POLARITY
On (1), Off (0)
Off (0)
519
ANALOGUE INPUT A (SET AS DIGITAL) SOURCE
ACTION
0 -3
0
520
ANALOGUE INPUT A (SET AS DIGITAL) SOURCE DELAY
0 -99s
10s
521
ANALOGUE INPUT B (SET AS DIGITAL) SOURCE
(LLOP/HWT/LFL/RWL/CANOPY/EMG /REMOTE START/
EARTH FAULT/DOOR OPEN/SIMULATE AUTO/SIMULATE
START/SIMULATE STOP/SIMULATE MAINS/MAINS FAIL)
0(Input Source)
RWL
522
ANALOGUE INPUT B (SET AS DIGITAL) SOURCE
POLARITY
On (1), Off (0)
Off (0)
523
ANALOGUE INPUT B (SET AS DIGITAL) SOURCE
ACTION
0-3
0
524
ANALOGUE INPUT B (SET AS DIGITAL) SOURCE DELAY
0 -99s
10s
525
ANALOGUE INPUT C (SET AS DIGITAL) SOURCE
(LLOP/HWT/LFL/RWL/CANOPY/EMG /REMOTE START/
EARTH FAULT/DOOR OPEN/SIMULATE AUTO/SIMULATE
START/SIMULATE STOP/SIMULATE MAINS/MAINS FAIL)
0(Input Source)
REMOTE
526
ANALOGUE INPUT C (SET AS DIGITAL) SOURCE
POLARITY
On (1), Off (0)
Off (0)
527
ANALOGUE INPUT C (SET AS DIGITAL) SOURCE
ACTION
0-3
0
528
ANALOGUE INPUT C (SET AS DIGITAL) SOURCE DELAY
0 -99s
10s
Configuration Parameters –Analogue Inputs (Page 6)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
601
ANALOGUE INPUT A SENSOR TYPE
Pressure
Pressure
(3)
602
ANALOGUE INPUT A SENSOR SELECTION
Eicher
Eicher
603
ANALOGUE INPUT A LOW OIL PRESSURE ENABLE
0
0
604
ANALOGUE INPUT A LOW OIL PRESSURE TRIP POINT
00.0-9.9
1.0
605
ANALOGUE INPUT A LOW OIL PRESSURE OPEN ENABLE
0
0

13
606
ANALOGUE INPUT A OIL PRESSURE DELAY
0-99s
10s
607
ANALOGUE INPUT B SENSOR TYPE
Temperature
Temperature
(4)
608
ANALOGUE INPUT B SENSOR SELECTION
Eicher
Eicher
609
ANALOGUE INPUT B TEMPERATURE ENABLE
0
0
610
ANALOGUE INPUT B TEMPERATURE TRIP POINT
0-999
120
611
ANALOGUE INPUT B TEMPERATURE OPEN ENABLE
0
0
612
ANALOGUE INPUT B TEMPERATURE DELAY
0-99s
10s
613
ANALOGUE INPUT C SENSOR TYPE
Fuel
Fuel (2)
614
ANALOGUE INPUT C SENSOR SELECTION
Eicher
Eicher
615
ANALOGUE INPUT C SENSOR LFL ENABLE
0
0
616
ANALOGUE INPUT C SENSOR LFL TRIP POINT
0-999
10
617
ANALOGUE INPUT C SENSOR OPEN ENABLE
On (1), Off (0)
Off (0)
618
ANALOGUE INPUT C SENSOR LFL DELAY
0-99s
10s
Configuration Parameters –Output (Page 7)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
701
DIGITAL OUTPUT ASOURCE
(FUEL/ENERGISE TO STOP/MCB OPEN/GCB OPEN/MCB
CLOSE/GCB CLOSE/BUZZER/CHOKE/ALT PULSE/LFL/AS
IDLE RELAY/As Fail to Start/ As Fail to Stop)
OUTPUT
SOURCE
Fuel
702
DIGITAL OUTPUT A POLARITY
On (1), Off (0)
On (1)
703
DIGITAL OUTPUT B SOURCE
(START)
Start
Start
704
DIGITAL OUTPUT B POLARITY
On (1), Off (0)
On (1)
705
DIGITAL OUTPUT C SOURCE
(FUEL/ENERGISE TO STOP/MCB OPEN/GCB OPEN/MCB
CLOSE/GCB CLOSE/BUZZER/CHOKE/ALT PULSE/LFL/AS
IDLE RELAY/As Fail to Start/ As Fail to Stop)
OUTPUT
SOURCE
MCB Close
706
DIGITAL OUTPUT C POLARITY
On (1), Off (0)
On (1)
707
DIGITAL OUTPUT D SOURCE
(FUEL/ENERGISE TO STOP/MCB OPEN/GCB OPEN/MCB
CLOSE/GCB CLOSE/BUZZER/CHOKE/ALT PULSE/LFL/AS
IDLE RELAY/As Fail to Start/ As Fail to Stop)
OUTPUT
SOURCE
GCB Close
708
DIGITAL OUTPUT D POLARITY
On (1), Off (0)
On (1)
709
DIGITAL OUTPUT E SOURCE
(FUEL/ENERGISE TO STOP/MCB OPEN/GCB OPEN/MCB
CLOSE/GCB CLOSE/BUZZER/CHOKE/ALT PULSE/LFL/AS
IDLE RELAY/As Fail to Start/ As Fail to Stop)
OUTPUT
SOURCE
Buzzer

14
710
DIGITAL OUTPUT E POLARITY
On (1), Off (0)
On (1)
711
DIGITAL OUTPUT F SOURCE
(FUEL/ENERGISE TO STOP/MCB OPEN/GCB OPEN/MCB
CLOSE/GCB CLOSE/BUZZER/CHOKE/ALT PULSE/LFL/AS
IDLE RELAY/As Fail to Start/ As Fail to Stop)
OUTPUT
SOURCE
Choke
712
DIGITAL OUTPUT F POLARITY
On (1), Off (0)
On (1)
Configuration Parameters –(Page 8)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
801
LAMP TEST AT START
On(1) ,Off (0)
On(1)
802
POWER SAVER MODE ENABLE
On(1) ,Off (0)
On(1)
Configuration Parameters –Maintenance (Page 9)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
901
OIL MAINTENANCE ENABLE
On(1) ,Off (0)
On (1)
902
OIL_SERVICE DUE ACTION
0-3
2
903
OIL MAINTENANCE HOURS
0-9999h
50h
904
DG START PROTECTION
On(1) ,Off (0)
On(1)
905
POWER ON DG MODE
0-AUTO
1- MANUAL
2- STOP
STOP
906
TEST MODE
0-999
050
907
ENGINE MAX RUN TIME
0-999 min
0
908
ENGINE REST TIME
0-999 min
0
909
SELECT MODE (0- REMOTE MODE ,1- NO REMOTE)
0-1
1
910
CT POSITION
CT ON DG/CT
ON LOAD
CT ON LOAD
Configuration Parameters –SCHEDULER (Page 10)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
1001
Enable Scheduler
On (1), Off (0)
Off (0)
1002
Schedule Run Load
On(1) ,Off (0)
On(1)
1003
Scheduler Period
Week (0) , Month (1)
1004
Scheduler 1 Start Time
0
1005
Scheduler 1 Start Day
1-7
1006
Scheduler 1 Start Week
1-4 , L

15
1007
Scheduler 1 Stop Time
0
1008
Scheduler 2 Start Time
0
1009
Scheduler 2 Start Day
1-7
1010
Scheduler 2 Start Week
1-4 , L
1011
Scheduler 2 Stop Time
0
1012
Scheduler 3 Start Time
0
1013
Scheduler 3 Start Day
1-7
1014
Scheduler 3 Start Week
1-4 , L
1015
Scheduler 3 Stop Time
0
1016
Scheduler 4 Start Time
0
1017
Scheduler 4 Start Day
1-7
1018
Scheduler 4 Start Week
1-4 , L
1019
Scheduler 4 Stop Time
0
1020
Scheduler 5 Start Time
0
1021
Scheduler 5 Start Day
1-7
1022
Scheduler 5 Start Week
1-4 , L
1023
Scheduler 5 Stop Time
0
1024
Scheduler 6 Start Time
0
1025
Scheduler 6 Start Day
1-7
1026
Scheduler 6 Start Week
1-4 , L
1027
Scheduler 6 Stop Time
0
1028
Scheduler 7 Start Time
0
1029
Scheduler 7 Start Day
1-7
1030
Scheduler 7 Start Week
1-4 , L
1031
Scheduler 7 Stop Time
0
1032
Scheduler 8 Start Time
0
1033
Scheduler 8 Start Day
1-7
1034
Scheduler 8 Start Week
1-4 , L
1035
Scheduler 8 Stop Time
0

16
Configuration Parameter –Sensor & Timers (Page -11)
INDEX
SETTABLE PARAMETER
RANGE
DEFAULT
1101 -1120
Resistance R01 TO R10
0-1500 Ω
Pressure P01 TO P10
0-10
1121-1140
Resistance R01 TO R10
0-1500 Ω
Temperature T01 TO T10
0-300
1141-1160
Resistance R01 TO R10
0-1500 Ω
FUEL L01 TO L10
0-100%
1161
Modbus ID
001
001
1162
Auto Load Transfer
0 (Disable)
1(Enable-1)
2(Enable-2)
Off (0)
1163
Engine Selection
CAN/CONVENTIONAL
Conventional
1164
Display Contrast
0-99
85
1165
Ideal Timer
0-999 Sec
000 Sec
1166
Stop Selection
0/1
1
1167
Alternator detect delay
0-99 Sec
05 Sec
1168
DG Stop Switch Cool down
On(1) ,Off (0)
On(1)
1169
Safety Monitoring Delay
0-99 Sec
10 Sec
1170
Return To Mains Delay
0-999 Sec
10 Sec
1171
Additional Stop Timer
0-99 Sec
05 Sec
1172
DG Pickup Voltage
0-240V
80V
1173
Over Speed Threshold %
100-200 %
120%
1174
Monitoring LOP Analog
before Crank
On(1) ,Off (0)
Off (0)
1175
Monitoring LOP Digital before
Crank
On(1) ,Off (0)
Off (0)
1176
Disconnect Crank LLOP
Digital Input
On(1) ,Off (0)
Off (0)
1177
Digital Input A Activation
0-3
3
1178
Digital Input B Activation
0-3
3
1179
Digital Input C Activation
0-3
3
1180
Digital Input D Activation
0-3
3
1181
Analog Input A Activation
0-3
3
1182
Analog Input B Activation
0-3
3
1183
Analog Input C Activation
0-3
3
1184
Service Hour Clear
Yes/No

17
SENSOR TYPE AC SYSTEM
DIGITAL INPUT POLARITY DIGITAL OUTPUT POLARITY
OUTPUT POLARITY
Index
Polarity
0
De-Energies
1
Energies
ACTION
ACTION
Index
Action
0
Electrical Trip
1
Shutdown
2
Warning Alarm
3
NONE
ACTIVATION
ACTION
Index
Activation
0
Never
1
From Engine Start
2
From Monitoring
3
Always
SENSOR TYPE
Index
Type
0
None
1
Digital Input
2
Fuel Sensor
3
Pressure Sensor
4
Temperature Sensor
AC SYSTEM
Index
Type
0
3-Phase DG, 3-Phase Mains
1
1- Phase DG , 1-Phase Mains
2
3-Phase DG, 1-Phase Mains
3
1-Phase DG, 3-Phase Mains
DIGITAL INPUT POLARITY
Index
Polarity
0
Close to Activate
1
Open to Activate
