enraf SmartRadar FlexLine User manual

SmartRadar
FlexLine
©2007
Installation Guide

Table of contents FlexLine
A
Table of contents
1 General........................................................................... 1
1.1 Using this installation guide ......................................... 1
1.2 Related documents...................................................... 1
1.3 Trademarks.................................................................. 1
1.4 Contact ........................................................................ 1
2 Safety ............................................................................. 2
2.1 Correct for use............................................................. 2
2.2 Safety conventions ...................................................... 2
2.3 Safety instructions ....................................................... 2
2.4 Liability......................................................................... 3
2.5 Labels .......................................................................... 4
2.6 Personal safety............................................................ 5
2.7 Warnings and cautions ................................................ 5
2.8 Electrical ...................................................................... 7
2.9 Accordance to regulations ........................................... 7
2.10 Compliance to FCC, R&TTE........................................ 8
3 Product Description .................................................... 10
3.1 SmartRadar components........................................... 10
3.2 SmartRadar FlexLine................................................. 10
3.3 SmartView ................................................................. 12
3.4 SmartConn................................................................. 12
3.5 Configurations............................................................ 13
4 Installation ................................................................... 14
4.1 Safety ........................................................................ 14
4.2 Receipt....................................................................... 14
4.3 Storage ...................................................................... 15
4.4 Before installation ...................................................... 15
4.5 Installation overview .................................................. 16
4.6 Mechanical installation............................................... 17
4.7 Preparations for installation with SmartConn............. 18
4.8 Preparations for installation without SmartConn........ 19
4.9 Installing the cable glands and stopping plugs with
SmartConn................................................................. 21

FlexLine Table of contents
B
4.10 Installing the compound glands, conduits and stopping
plugs without SmartConn........................................... 22
4.11 Electrical connection.................................................. 23
4.12 Finishing installation with SmartConn........................ 34
4.13 Finishing installation without SmartConn................... 35
5 Technical data ............................................................. 36
5.1 Weights and dimensions............................................ 36

General FlexLine
1
1 General
1.1 Using this installation guide
For use in measurement systems for inventory measurement and control. The
SmartRadar Flexline can integrate data from other measurement devices, such as
temperature RTD sensors. Data from Radar and connected sensors can be
communicated to host computer systems via a variety of industry standard protocols.
1.2 Related documents
• SmartRadar FlexLine Safety instructions for installation, commissioning,
operation and maintenance, shipped with the device.
• Installation guide SmartRadar Antennas.
• CE Declaration of Conformity
• EC-Type Examination Certificate
• IECEx Certificate of Conformity
• FCC Authorization
• Control drawings for FM and CSA.
1.3 Trademarks
HART™ is a registered trademark of the HART Communication Foundation.
1.4 Contact
Enraf BV
PO Box 812; 2600AV Delft
Netherlands
E-mail: [email protected]
Website: http://www.enraf.com

FlexLine Safety
2
2 Safety
2.1 Correct for use
The SmartRadar FlexLine is a radar-based level gauge to use in inventory
measurement systems and can be used to interface with other systems and sensors
such as temperature gauges.
2.2 Safety conventions
"Warnings", "Cautions" and "Notes" are used throughout this installation guide to
bring special matters to the immediate attention of the reader.
• A Warning concerns danger to the safety of the technician or user.
• A Caution draws the attention to an action which may damage the equipment.
• A Note points out a statement deserving more emphasis than the general text, but
not requiring a "Warning" or a "Caution".
2.3 Safety instructions
2.3.1 Safety instructions
Refer to the safety instructions shipped with the device for installation,
commissioning, operation and maintenance.
2.3.2 EC declaration of conformity (for E.U.)
Refer to the EC declaration of conformity, shipped with the device.
2.3.3 Control drawings for FM & CSA
Refer to the control drawings shipped with the device.
2.3.4 Users
The mechanical and electrical installation must be carried out only by trained
personnel with knowledge of the requirements for installation of explosion proof
equipment in hazardous areas. The entire installation procedure must be carried out

Safety FlexLine
3
in accordance with national, local and company regulations. The entire electrical
installation shall be carried out in accordance with the national requirements for
electrical equipment to be installed in hazardous areas.
2.3.5 Additional information
If you require additional information, contact Enraf or its representative.
2.3.6 Environmental conditions
Observe the environmental conditions for the temperature and the pressure. Refer to
the chapter “Technical data”.
2.4 Liability
The information in this installation guide is the copyright property of Enraf B.V.,
Netherlands. Enraf B.V. disclaims any responsibility for personal injury or damage to
equipment caused by:
• Deviation from any of the prescribed procedures,
• Execution of activities that are not prescribed,
• Neglect of the safety regulations for handling tools and use of electricity.
The contents, descriptions and specifications in this installation guide are subject to
change without notice. Enraf B.V. accepts no responsibility for any errors that may
appear in this installation guide.
NOTE
Refer to EN IEC 60079-14 or NEC (NFPA70).
Warning!
Only certified technicians are authorized to make changes on the
SmartRadar configuration. All modifications must be in accordance to
the guidelines as set forth by Enraf. Modifications not authorized by
Enraf will invalidate the approval certificates.

FlexLine Safety
4
2.5 Labels
Fig. 2.1 Labels
A Identification label with safety note.
Fig. 2.2 Identification label (Example)
A

Safety FlexLine
5
2.6 Personal safety
2.7 Warnings and cautions
2.7.1 General
When it is required to open the instrument in an explosive hazardous environment.
Warning!
In hazardous areas it is compulsory to use personal protection and
safety gear. This can be:
• Safety helmet, fire-resistive overall, safety shoes, safety glasses,
working gloves, LEL-meter.
Pay attention to the kind of product in the tank. If there is any danger
for your health, wear a gas mask and take all necessary precautions.
Warning!
Take appropriate precautions when chemical or toxic product vapors
are present (compressed air, chemical protection suit, detection
equipment).
NOTE
The emitted microwave energy is far below the accepted limits for
exposure of the human body. The antenna generates a maximum
radiation of 0.1 mW/cm2.
Warning!
Make sure that all power to the device is switched off before you open
the covers of the device. Failure to do so may cause danger to
persons or damage the equipment. All covers of the device must be
closed before switching the power on again.
Warning!
Treat the flange surface of the cover and the housing with care.
Keep the flange surface free of dirt.
The O-ring must be present and undamaged.

FlexLine Safety
6
Too ls
Working environment
Required skills
Warning!
Use non-sparking tools and explosion-proof testers. Use suitable
explosion-proof tools (e.g. testing devices)!
Warning!
Avoid generation of static electricity. Make sure that no explosive gas
mixtures build up in the working area.
Warning!
The technician must have technical skills to be able to safely install the
equipment. The technician also must be trained to work in accordance
with the national requirements for electrical equipment in hazardous
areas.

Safety FlexLine
7
2.8 Electrical
2.8.1 IEC safety standards
• The entire electrical installation must be in accordance with the International
Standard EN IEC 60079-14 for electrical equipment in hazardous areas or with
NEC (NFPA70) requirements.
• The stopping plugs, cable glands and reducers must be installed in accordance
with appropriate IP requirements
• Use explosion proof (Ex-d) compound barrier glands (due >2 litres IIB) in case of
use without SmartConn (Ex-e junction box).
• Use increased safe (Ex-e) cable glands in case a SmartConn box is used.
• Improper installation of cable glands, conduits or stopping plugs will invalidate the
Ex approval of this device.
2.8.2 Grounding
2.9 Accordance to regulations
2.9.1 Device without SmartConn
Type of protection:
ATEX / IEC Ex / CSA
Certificate numbers:
SmartRadar FlexLine: KEMA 07ATEX0010X and IECEX KEM 07.0003 X.
SmartView: KEMA 07ATEX0011X and IECEX KEM 07.0004 X.
SmartConn: KEMA 07ATEX0093 and IECEX KEM 07.0031.
Without SmartView: Ex d [ia] T6 Ta: -40 °C - +65 °C.
With SmartView: Ex d [ia] ia T4 Ta: -25 °C - +65 °C.
Warning!
Make sure the housing of the device is properly connected to the
ground reference! Make sure that the electrical resistance of the
ground connection is below the maximum of prescribed by local
requirements!

FlexLine Safety
8
FM
Without SmartView: Class ,DIV ,group C,D T6 NEMA 4X Ta: -40 °C - +65 °C.
With SmartView: Class ,DIV ,group C,D T4 NEMA 4X Ta: -25 °C - +65 °C.
CSA
Without SmartView: Class ,DIV ,group C,D T6 NEMA 4X Ta: -40 °C - +65 °C.
With SmartView: Class ,DIV ,group C,D T4 NEMA 4X Ta: -25 °C - +65 °C.
2.9.2 Device with SmartConn
Type of protection:
ATEX / IEC Ex / CSA
Without SmartView: Ex de [ia] T6 Ta: -40 °C - +65 °C.
With SmartView: Ex de [ia] ia T4 Ta: -25 °C - +65 °C.
2.10 Compliance to FCC, R&TTE
This device complies with EN 302372 of the R&TTE Directive and Part 15 of the
FCC Rules. The device does not cause harmful interference and accepts any
interference received.
Warning!
Changes or modifications made to this equipment not approved by
Enraf B.V. invalidate the R&TTE/FCC authorization to operate this
equipment.
Caution!
This equipment has been tested. It complies with a Field disturbance
sensor device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation. This device generates, uses
and radiates radio frequency energy. If this device is not installed and
used in accordance with the instructions, it can cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.

Safety FlexLine
9
2.10.1 EN302372-1 ANNEX B
The following installation requirements shall be fulfilled:
1 SmartRadar FlexLine instruments are required to be installed at a permanent
fixed position at a closed (not open) metallic tank or reinforced concrete tank, or
similar enclosure structure made of comparable attenuating material;
2 Flanges and attachments of the radar equipment shall provide the necessary
microwave sealing by design.
3 Sight glasses shall be coated with a microwave proof coating when necessary
(i.e. electrically conductive coating);
4 Manholes or connection flanges at the tank shall be closed to ensure a low-level
leakage of the signal into the air outside the tank.
5 Whenever possible, mounting of the radar equipment shall be on top of the tank
structure with the orientation of the antenna to pointing in a downward direction;
6 Installation and maintenance of the radar equipment shall be performed by
professionally trained individuals only.
NOTE
This device is certified to measure liquid levels in metal, concrete or
similar materials, enclosed tanks.
NOTE
The radiated output power of the device is far below the exposure
limits. Nevertheless, use the device in such a manner that the
potential for human contact during normal operation is minimal.

FlexLine Product Description
10
3 Product Description
3.1 SmartRadar components
Fig. 3.1 System components
The device has following components:
A SmartRadar FlexLine with separator coupling to radar antenna
B SmartView (optional)
C SmartConn (optional)
D Antenna connection (refer to the antenna installation guide)
3.2 SmartRadar FlexLine
3.2.1 Function
The SmartRadar Flexline is the core component. It provides the level measurement,
integrates optional sensor data and communicates via the fieldbus to the host
computer system.
A
B
C
D

Product Description FlexLine
11
3.2.2 Components
Fig. 3.2 General view and main components of the FlexConn box (FCB)
A Top cover
B Display cover
C FlexConn box and FlexConn cover flange
D FlexConn cover
E Bolts with reduced shank (turn into thread when closing the cover)
F Cable entry
G Connection terminals with identification labels
H Separator coupling (connection between antenna and SmartRadar FlexLine)
I FlexConn box
J Inner cover (do not open, do not touch), tampering label
A
C
E
D
F
G
H
B
J
I

FlexLine Product Description
12
3.3 SmartView
3.3.1 Function
The SmartView display can be part of the device. You can install it as stand alone
version as well. In this case it is placed in a larger housing. Refer to the display
installation guide.
3.4 SmartConn
3.4.1 Function
SmartConn is an optional Ex-e junction box and is only certified for ATEX, IEC Ex
and CSA. It simplifies the external connection of the device and provides additional
cable entries.
3.4.2 Components
A Enclosure
B Cover
C Cable entry M20 (4 (6 is optional))
D Connection to FlexConn box
E Terminals for intrinsic safe and non intrinsic safe connections
A
E
B
C
D

Product Description FlexLine
13
3.5 Configurations
Each device has several configurations. They can differ in:
• Accuracy of measurement
• Allowed process temperature ranges
• Chemical compatibility
• Allowed tank pressure
• Weights and Measurements (W&M) approval
• Explosion safety approvals
• Optional features like SmartView (Display) and SmartConn (junction box)
• Allowed process temperature (Gas temperature)

FlexLine Installation
14
4 Installation
4.1 Safety
4.2 Receipt
1.Open the box.
2.Make sure that following items are in the box:
• The device
• Safety instruction
• Declaration of conformity
• Installation guide
3.Inspect the package upon arrival. Make sure that the items are not damaged.
Contact your local representative or Enraf B.V. in the event of damage.
Warning!
Make sure that the power to the device is switched off, before you
open the cover of the device.
Caution!
Do not make any additional holes in the housing. Do not incorporate
rotating machines or other devices, which create turbulence inside
the FlexConn box.
Warning!
Always clean the FlexConn box flange, when you open or before you
close the housing.
NOTE
Do not throw away the packaging. The packaging is necessary for
further transport on site. The packaging is necessary if the device is
returned for service or warranty.

Installation FlexLine
15
4.3 Storage
4.3.1 Storage of uninstalled devices
Keep the device in its original packing during storage. Keep the device indoors
during storage.
/i
4.3.2 Storage of installed devices
If you do not use an installed device for a longer period, we recommend not to
disconnect the mains connection line. If this is not possible, put some moisture-
absorbing material (e.g. silica gel) into the electronic compartment and store the
device in a closed plastic bag.
4.4 Before installation
Make sure that following conditions are obeyed:
• The antenna and the tank separator are already installed on the tank (refer to the
Installation guide SmartRadar Antennas).
• The top cover of the device can open without obstruction. Refer to illustration 4.1
for distances required for installation.
Ambient conditions
Temperature -50 to +85 °C (SmartView -30 to +85 °C)
Humidity 20 to 90 %

FlexLine Installation
16
Fig. 4.1 Distances to installed device
A 550 mm. (21.7“)
B 260 mm. (10.2“)
C 430 mm. (16.9“)
D 300 mm. (11.8“)
Device weight: 16,3 kg. (36 lbs)
4.5 Installation overview
Installation of the SmartRadar requires the following steps:
1. Mechanical installation of the device on the tank separator.
2.Preparations for connection
3.Installing the compound glands and conduits
4.Electrical connection
5.Finishing installation
These steps are further explained in the following sections.
C B
D
A

Installation FlexLine
17
4.6 Mechanical installation
Fig. 4.2 Separator coupling and separator
Connect the SmartRadar to the tank separator.
1.Place the separator coupling (A) of the device on the tank separator (C). Make
sure that the pin of the separator coupling fits into the corresponding opening of
the tank separator.
2.Turn the ring (B) clockwise to fasten the device. Fasten the ring hand tight.
A
B
C
