1 Network Connection 1
2 Login 1
Preparation 1
Logging In to the Web Interface 3
Introduction to the Web Interface 4
Initial Configuration 5
3 Configuring Parameters 6
Local Parameters 6
Network Configuration 7
Ethernet 7
Port 11
FTP 11
E-Mail 12
Port Mapping 13
DNS 14
DDNS 14
EZCloud 15
SNMP 15
802.1x 16
QoS 16
Adaptive Streams 17
Image Configuration 17
Image Adjustment 17
OSD Setting 27
Privacy Mask 29
Audio and Video Configuration 30
Video Configuration 30
Audio Configuration 32
Snapshot 33
ROI 34
Media Stream Configuration 34
Intelligent Alarm Configuration 36
Smart 36
Cross Line Detection 37
Enter Area 38
Leave Area 39
Intrusion Detection 40
Object Moving 41
Object Left 41
Mixed -Traffic Detection 42
Face 43
Face Picture Comparison 45
People Counting 47
Auto Tracking 48
Heat Map 48
Defocus Detection 49
1

Scene Change Detection 50
Advanced Settings 51
Master-Slave Linkage 52
Attribute Collection 55
Master-Slave Linkage 55
Common Alarm Configuration 59
Configuring Motion Detection Alarm 60
Configuring Tampering Alarm 62
Configuring Audio Detection Alarm 63
Configuring Alarm Input 65
Configuring Alarm Output 66
Memory Card Storage 67
Setting Edge Storage 67
Setting Cache Post Recording 69
System Maintenance 70
Security 70
Setting the System Time 73
SettingServers 74
Serial Port Mode Configuration 74
Wiper Control 77
Viewing Device Status 78
Photo Storage Status 78
Upgrading the Device 79
Restarting the System 80
Importing and Exporting System Configuration File 80
Collecting Diagnosis Information 81
Focus Configuration 81
Device Mounting Height 81
Fisheye Camera Parameter 82
4 Live View 83
Live View Toolbar 84
Viewing Certain Area of Images 85
Using Digital Zoom 85
Using Area Focus 86
Using 3D Positioning 87
Face Snapshot 87
Deep Perimeter Snapshot 90
Mixed-Traffic Detection Snapshot 91
Live View of Fisheye Cameras 92
5ePTZ of Panoramic Cameras 93
5 Video Playback and Download with Edge Storage 95
Video Playback 95
Download 95
6 PTZ Control 96
PTZ Control Toolbar 96
Setting Patrol by Presets 97
Setting Presets 97
Setting Patrol 98
Setting Home Position 102
Remote Control PTZ 103
PTZ Limit 103
Resume Patrol 104
2

7 LPR 105
LPR Live View 105
LPR Configuration 105
Appendix A Glossary 108
Appendix B FAQ 109
3

1Network Connection
Before accessing a network camera (also known as IP Camera or IPC) from a PC, you need to connect the network
camera to the PC directly with a network cable or via a switch or router.
Use a Shielded Twisted Pair (STP) cable to connect the network interfaces of the network camera and the PC.
Use Shielded Twisted Pair (STP) cables to connect the network interfaces of the camera and the switch or router.
2Login
Preparation
After you have completed the installation in accordance with the quick guide, connect the camera to power to
start it. After the camera is started, you can access the camera from a PC client installed with a web
browser or the client software EZStation. Internet Explorer(IE) is a recommended web browser. For more
information about EZStation, refer to the EZStation User Manual.
The following takes IE on a Microsoft Windows7 operating system as an example.
Check before login
●The camera is operating correctly.
●The network connection between the PC and the camera is normal.
●The PC is installed with Internet Explorer 10.0 or higher.
●(Optional) The resolution is set to 1440 x 900.
1

Add the IP address as a trusted site
2

NOTE!
The IP address 192.168.1.13in this example is the default IP address. Please replace it with the actual
address of your camera if it has been changed.
(Optional) Modifyuser access control settings
Before you access the camera, follow the steps to set User Account Control Settings to Never notify.
Logging In to the Web Interface
The default static IP address of the camera is 192.168.1.13, and the default subnet mask is 255.255.255.0.
DHCP is turned on by default. If a DHCP server is used in the network, the IP address of your camera may be
assigned dynamically, and you need to use the correct IP address to log in. Use the EZStationclient to view
the dynamic IP address of your camera.
The following takes IE as an example to describe the login procedure.
1. Browse to the login page by entering the correct IP address of your camera in the address bar.
2. If you log in for the first time, follow system prompts and install the ActiveX. You need to close your
browser to complete the installation.
NOTE!
●To manuallyload the ActiveX,typehttp://IP address/ActiveX/Setup.exein the address bar and press
Enter.
●The default password is intended for your first login. For security, please set a strong password
after your first login. A strong password shall include at least nine characters comprising digits,
letters, and special characters.
●The camera protects itself from illegal access by limiting the number of failed login attempts. If
login fails six times consecutively, the camera locks automatically for ten minutes.
3

3. Privacy policy is displayed on the screen when the user logs in for the first time. After reading the
privacy policy, you need to check in the'I have read and agree to the above policy'box, then click the'OK'
button to proceed to the next step.
4. Enter the username and password, and then click Login. For the first login, use the default username
“admin” and password “123456”.
●If you log in with Save Password selected, you do not need to enter the password each time when you
log in.To ensure security, you are not advised to select Save Password.
●To clear the Username and Password text boxes and the Save Password checkbox, click Reset.
Introduction to the Web Interface
By default the live view window is displayed when you are logged in to the Web interface. The following shows an
example.
No.
Description
1
Menu
4

No.
Description
2
PTZ control area
Note:
This area is available for PTZ dome cameras and PTZ cameras.
3
Live view window
4
Live view toolbar
Initial Configuration
After you log in to the device, please perform the following initial configuration.
Item
Description
1. Ethernet.
Reconfigure the device IP and network parameters based on the
actual networking.
2. Log out and log in again to the Web
using the new IP address.
-
3. Set the system time.
Set the system time based on the actual situation.
4. (Optional) Set the management server.
Set the management server based on the actual networking.
5. (Optional) Set the server for storing
photos.
Set the server for storing photos based on the actual networking.
6. Set OSD.
Set the information displayed on the screen as needed, for
example, time.
7. (Optional) Manage users.
Change the default password and add common users as needed.
You can watch the live videoafter finishing the initial configuration. Please configure other parameters as needed.
NOTE!
●The displayed live view interface, parameters displayed and value ranges may vary with models.
Please see the actual Web interface for details.
●The parameters that are grayed out cannot be modified. For the actual settings, see the Web
interface.
●It is recommended that you change the password when you are logged in the first time. For
detailsabout how to change a password, seeSecurity.
3Configuring Parameters
Local Parameters
Set local parameters for your PC.
5

NOTE!
The local parameters may vary with models. Please see the actual Web interface for details.
1. Select Setup>Common>Local Parameters
2. Modify the settings as required. The following table describes some major parameters.
Parameter
Description
Smart
Untriggered Target
When enabled, the camera will display an on-screen mark on the target (e.g.,
face when face detection is enabled) and track it.
Intelligent Mark
This function should be used with“Cross Line Detection、Enter Area、Leave
Area、Intrusion Detection、Mixed -Traffic Detection”
6

Parameter
Description
Display Attributes
When enabled, the attributes collected will be displayed in live view page.
This function should be used with Intelligent > Smart > Attribute Collection.
Video
Processing Mode
●Real-Time Priority: Recommended if the network is in good condition.
●Fluency Priority: Recommended if you want short time lag for live video.
●Ultra-Low Delay: Recommended if you want the minimum time lag for live
video.
Protocol
Set the protocol used to transmit media streams to be decoded by the PC.
Record and
Snapshot
Recording
●Subsection By Time: Duration of recorded video for each recording file on
the computer. For example, 2 minutes.
●Subsection By Size: Size of each recording file stored on the computer. For
example, 5M.
Record Overwrite
●Overwrite: When the assigned storage space on the computer is used up,
the camera deletes the existing recording files to make room for the new
recording file.
●Full Stop: When the assigned storage space on the computer is full,
recording stops automatically.
Files Folder
●The save path of snapshots and recordings. The max. path length is 260
bytes. If the limit is exceeded, recording or snapshot during live view will
fail, and messages will appear on the screen.
3. Click Save.
Network Configuration
Ethernet
Modify communication settings such as the IP address for the camera so that the camera can communicate with
other devices.
NOTE!
●After you have changed the IP address, you need to use the new IP address to log in.
●The configurations of DNS (Domain Name System) server are applicable when the device is
accessed by domain name.
Static Address
1. Click Setup>Network>Network.
7

2. Select Static from the Obtain IP Address drop-down list.
3. Enter the IP address, subnet mask, and default gateway address. Make sure that the IP address of the
camera is unique in the network.
4. Click Save.
PPPoE
NOTE!
This function is not supported by some models. Please see the actual model for details.
If the camera is connected to the network through Point to Point over Ethernet (PPPoE), you need to select PPPoE
as the IP obtainment mode.
1. Click Setup>Network>Network.
2. Select PPPoEfrom theObtain IP Address drop-down list.
3. Enter the username and password provided by your internet Service Provider (ISP).
4. Click Save.
DHCP
The Dynamic Host Configuration Protocol (DHCP) is enabled by default when the camera is delivered. If a DHCP
server is deployed in the network, the camera can automatically obtain an IP address from the DHCP
server.
8

To manually configure DHCP, follow the steps below:
1. Click Setup>Network>Network.
2. Select DHCP from theObtain IP Address drop-down list.
3. Click Save.
IPv6
1. Click Setup>Network>Network.
2. By defaultthe IPv6 mode is set toManual.
3. Enter the IPv6 address, set the prefix length and default gateway. The IP address must be unique on
the network.
4. Click Save.
Wi-Fi
NOTE!
This function is not supported by some models, please see the actual model for details.
1. Click Setup>Network>Network. Click the Wi-Fi tab.
2. Select Sniffer.
3. Click Save.
Some devices can search for Wi-Fi networks and connect.
1. Select Setup>Network>Network. Select Wi-Fi for Wi-Fi Mode.
9

2. Signal strength is displayed. Turn on Adaptive Streams. The page shows that there are other Wi-Fi
networks. To search for Wi-Fi networks again, click Search.
3. Click an SSID in the Wi-Fi Network list. Information about the corresponding network is displayed.
4. Click Save.
5. When Wi-Fi Mode is set to Wi-Fi Hotspot, the camera can function as a Wi-Fi hotspot for other
devices.
6. Click Save.
Port
NOTE!
This function is not supported by some models. Please see the actual model for details.
10

4. Click Setup>Network>Port.
5. Configure relevant port numbers.
6. Click Save.
FTP
All snapshots (except face detection) are saved through the general FTP service.After the configuration of FTP, you
will be able to upload snapshots from network cameras to the specified FTP server.
General
1. Click Setup>Storage>FTP. Go to General tab.
2. Set the IP address and port for the FTP server, username and passwordused to upload images to the
FTP server, select Upload Images,Overwrite Storage and set Overwrite At (threshold for overwriting
images).Some camera models support FTP test. You may test FTP after completing FTP settings
correctly.
3. Set the path for saving snapshots on the FTP server and the file name format. For example, set path as
Preset No.\\IP Address\\Date\\Hour(s), and set file name as Preset No.-PTZ Zoom-PTZ Latitude-PTZ
Longitude.jpg.
4. Click Save.
Smart
This function is used to store snapshotstaken for smart functions such as face recognition.To use smart FTP, click
Setup > System > Server > Intelligent Server and set Platform Communication Type to FTP.
1. Click Setup>Storage>FTP. Go to Smart tab.
11

2. Set the IP address and port of the FTP server, username and password used to upload images to the
FTP server.
3. Set the path for saving snapshots on the FTP server and the file name format.For example, set path as
Preset No.\\IP Address\\Date,and set file name as Preset No.-PTZ Latitude-PTZ Longitude-PTZ
Zoom.jpg.
4. Click Save.
E-Mail
After the configuration of E-mail, when alarms are triggered, you will be able to send messages to the specified
E-mail address.
1. Click Setup>Network>E-mail.
12

2. Configure relevant parameters of the sender and the recipient. Some camera models support Email
test. You may test email after setting the recipient address.The following table describes some major
parameters.
Parameter
Description
TLS/SSL
When enabled, the e-mail will be encrypted using TLS (Transport Layer Security) or
Secure Socket Layer (SSL) to protect privacy.
First it tries to send through an SSL connection.If the SMTP server supports SSL, the
e-mail will be sent through the SSL connection; otherwise, it tries to send using
STARTTLS.
Attach Image
When enabled, the e-mail will contain 3 instant snapshots as attachment according to
the Capture Interval.
Username/Password
Username and password of the registration email address. The password allows the
following special characters \ / : * ? ’ ” <> | % &
3. Click Save.
Port Mapping
1. Click Setup>Network>Port. Go to Port Mappingtab.
13

2. Enable Port Mapping and select mapping type. If Manual is selected, then external ports must be
configured (external IP is obtained automatically by the camera). If the configured port is occupied,
then the Status will show Inactive.
3. Click Save.
DNS
1. Click Setup>Network>DNS.
2. Set DNS server addresses.
3. Click Save.
DDNS
NOTE!
This function is not supported by some models. Please see the actual model for details.
1. Click Setup>Network>DDNS.
2. Enable DDNS Service.
3. Select a DDNS type: DynDNS, NO-IP, or EZDDNS.
4. Complete other settings including server address, domain name, username and password.
5. Click Save.
14
