Entec Wearable Air Purifier Mask User manual

DAEHYUNENTEC
Wearable Air Purifier Mask
User Manual
Korean
English

CONTENTS
Ⅰ. Usage and Features of the Product································ 1
Ⅱ. Cautions················································································ 2
Ⅲ. Method for Usage ······························································ 3
Ⅳ. Storage and Maintenance ················································· 6
Ⅴ. Product Configurations ····················································· 8
Ⅵ. Product Specifications ······················································· 9
Product Warranty
A/S Application

Ⅰ. Usage and features of the product
Use
Use it outdoor when the air quality is bad
Use it at dusty workplace

Product explanation
This product uses a filter to purify fine dust and other contaminants,
supplying fresh air thereafter to the user's face.
Features
The product is equipped with a filter and air flow control for proper air supply
to the user.
It prevents the inflow of harmful substance by generating a positive pressure so
that outside air does not enter the mask.
It protects the user from the harmful substances in the air and ensures a softer
breath than the yellowdust mask. It also eliminates the discomfort caused by
the moisture from when you breathe, allowing for pleasant use.
The mask is ultra-light and can reduce weight and fatigue of throat when used.
–1 –

Ⅱ. Cautions
Warning
Do not use without filter. Fine dust is not blocked.
Do not use if the oxygen concentration in the room is less than 18%.
Be sure to use the parts included in the product diagram and not to use the product
for anything other than its purpose.
Do not modify or change the device, and make sure to replace parts with the filter
with those provided by us.
Do not use in a confined space.
Do not use in places where there is a risk of fire or explosion.
Turn off the controller's power and charge it.
Do not connect the mask body and the charging terminal directly. This may cause a
malfunction of device.

!
Checklist
Check the cleaning status of the filter frequently.
Check that the filter is fitted correctly.
Check that the mask and controller are connected correctly.
Check for any abnormalities such as deformation, tearing, etc. of the silicone part in
contact with the face part of the mask.
Check that air is supplied to the face when the power is turned on and operated.
Remove the product and check it immediately, under the following condition.
①When deformation or abnormality is found in each part of the product due to an
accident / collision, etc.
②When the supplied air flow decreases or stops.
③When breathing becomes difficult.
④When you have a headache or dizziness.
⑤
–2 –

Ⅲ. Method of Usage
Filter Installation
Replace the filter with the power turned off.
Lift the cover under the mask and insert the filter
Close the cover and press it to make a click sound.

Controller Using Method
①When turning the power on
Press the power button on the controller for 3 seconds.
②Flow rate control
When the power is turned on, the flow starts at ‘weak’
Each time the power button pressed, the flow increased by one step from ‘weak’
to ‘middle’and ‘strong’.
If you pressed power button again in the flow of ‘strong’, it returns to ‘weak’.
③When turning the power off
Press the power button on the controller for 3 seconds.

–3 –

Ⅲ. Method of Usage
Wear Mask
Buckle-type head strap
–4 –
①Unhook the head strap, place the entire mask face in front of your face, and
fill the buckle of the head strap behind your head.
②Adjust the length of hair strap to fit your face.
③Check that the mask is in close contact with your face and adjust the head
strap.
①Remove the Velcro on the head strap, place the entire face of the mask in front
of your face, and stick it behind your head to fit the face.
②Adjust the length of hair strap to fit your face.
③Make sure the mask is in close contact with your face, hang it on your ears to
prevent the mask from dripping and adjust the head strap.
Velcro-type head strap
※Wear it so that the smooth side of the head strap touches your face.
※If the left or right side of the head strap is attached in reverse, the mask may not
be attached properly. Please wear after confirmation.

Ⅲ. Method of Usage
Use/Charge
The charging controller turns on a red light, and currently used one illuminates
a blue light. The light is removed after it is fully charged.
When the controller is off, the remaining of battery can be determined by the
green light on when the button is pressed. If there is not remaining of battery, it
lights on red.
The fully charged controller can be used for 3 to 5 hours depending on the
mask flow rate.
If you are using it for the first time or have not used it for more than 5 days,
please recharge it before reuse.
After removing the mask and controller, charge the controller.
The controller takes about 3 hours to fully charged, but the charging time
depends on the battery remaining on the controller.
Check the charger voltage (220V).
–5 –

Ⅳ. Storage and Maintenance
Storage
Store the product in a dry, clean place when it will not be used for a long time.
Keep the product out of direct sunlight and store away from heat, oil, organic
vapor and moisture.
Pre-operation is required to obtain the battery capacity of the controller when
stored below 0℃.
The storage temperature is suitable between -5℃and+55℃, relative, and please
stored at relative humidity below 90%.
Keep the mask, controller and charger away from moisture.

Maintenance
Check the product before using.
Check the filter regularly, replace it with a new one if the filter is damaged or
contaminated by foreign objects.
If there is not enough air supply, check and replace the filter.
The product is not warranted if problems arise from cleaning the used filter or
removing contaminants through compressed air.
If you need to wash the face part of the mask, gently wipe the household
detergent with water and a clean patch.
Silicon of face part of the mask can be detached or attached, and can be used
after cleaning and drying.
Do not use petroleum, organic solvents and abrasive cleaners.
!
Used filters cannot be cleaned or reused.
Be careful not to let water get into the body when cleaning.
–6 –

Ⅳ. Storage and Maintenance
Troubleshooting
If the product does not operate smoothly, follow the Troubleshooting Guide.
If the problem is not solved after checking, please contact us or apply for A/S.

Problems
Cause
Solution
When air is not
supplied
The power was not turned on
Press and hold the power button on
the controller for 3 seconds
The controller was not charged
properly
Please use after recharging
Mask and controller not connected
Check the connector and plug it in
properly
The filter is clogged by foreign matter
Check the filter and cover and replace
the filter if there is a problem
When operation
does not stop
The power was not turned off.
Press and hold the power button on
the controller for 3 seconds
When the operation
time is short even
when the controller
is fully charged
The controller battery has reached the
end of its life.
Contact A/S center
The charger is defective
Check for damage and contact A/S
center
When inflow air is
uncomfortable
Severe filter contamination
Check for filter contamination and
replace the filter
The filter is damaged.
Check for filter damage and replace
the filter
The filter cover or mask is damaged
Check for damage and contact A/S
center
–7 –

Ⅴ. Product Configuration
Product name
Quantity
Product name
Quantity
Front body
1
Silicon holder
1
Rear body
1
Controller
1
Filter
1
Battery
1
Filter cover
1
Motor
1
Filter body
1
Charger
1
Filter inner cover
1
5 pin cable
1
Face silicon
1
Head strap (Velcro type)
1
Pass silicon
1
Head strap (Buckle type)
1
–8 –
* Filter and Face silicone can be purchased separately.

Ⅵ. Product Specifications
Category
Specification
Size
Mask : 120mm x 110mm x 120mm
Controller : 10mm x 3mm x 3mm
Air flow rate
Weak : 100 L/min
Middle : 120 L/min
Strong : 140 L/min
Operational time
Weak : 5hr
Middle : 4hr
Strong : 3hr
Operational temperature
-5℃~ +55℃
Storage temperature
-5℃~ 55℃
Weight
Mask : 178g
Controller : 95g
Filter : 10g
Charger
Cable
Micro USB 5pin 220V
C type cable
Battery
Li-ion 12V 2600mA
Filter
HEPA filter (H12)
–9 –

DAEHYUNENTEC
Product warranty
Product Name
Wearable Air Purifier Mask
Model Name
DH-WAPM1
Warranty Period
12month for free, 10 years for paid
This product has been completed through strict quality test.
Free repair is possible within the warranty period if a failure occurs during the
normal use of the consumer.
If the warranty period has passed or even if is within the warranty period, repairs
may be charged and charges may be incurred if breakdown or damage occurs due
to careless handling of the consumer.
Repairs due to natural disasters, accidents, and disasters should be paid for.
The fault of A/S will be decided by technician after determine the cause.
Please submit this warranty when repairing.
Manufacturer : DAEHYUNENTEC Co., Ltd.
Address : 1-714, 98, Gasan digital 2-ro, Geumcheon-gu, Seoul, Republic of Korea
Tel : [phone]
Fax : [phone]

