Entel EA12 Setup guide
EA12
Quick Start User Guide
EARPIECE MICROPHONE WITH IN-LINE PTT
Designed in the United Kingdom
V1.1
EA12
Thank you for purchasing the Entel ear-
piece microphone. With care, this product
should provide years of trouble free use.
FITTING
Place the D-shaped shell comfortably and
securely over your left ear. The combination
microphone/PTT button should be attached
around the lapel area about 10cm from
your mouth.
OPERATING INSTRUCTIONS
• Press the PTT button to transmit and
release to receive.
• Speak normally, do not shout directly into
the microphone.
IMPORTANT
Always switch the radio off before at-
taching an audio accessory. Models that
are certied to ATEX & IECEx have been
clearly labelled. Should, in the course of
use, any labels be removed or become
illegible please return the accessory to
Entel for relabelling.
SPECIFICATIONS
EARPIECE MICROPHONE
Mic. element Electret condenser
Speaker impedance 16 ohm
Output sound pressure level <85 dBA
Weight 60g
Quick Start User Guide V1.1
D-SHAPE EARPIECE
CONNECT
TO RADIO
PTT UNIT
Above approvals apply to specic models only
Model Series Intrinsically safe
cert. no. Approval
EA12/950 HT500,
HT800, HT900
IECEx SIR 10.0097X
Sira 10ATEX2066X
IECEx
ATEX
EA12/750 HT700 None None
EA12/450 HX None None
EA12/DX DX, DN None None
EA12/DT9 DT500
DT800, DT900
IECEx BAS 18.0094X
Baseefa18ATEX0152X
IECEx
ATEX
Contact
For more information about our products please contact us:
All Rights Reserved. Copyright Entel UK Ltd.
