Enttec 79335 User manual

Datasheet (510845)
DALI 8A 12-36V LED DIMMER: 79335
www.enttec.com
1 ID: 2345301 Rev:1
DALI 8A 12-36V LED DIMMER
DALI LED Dimmer
General Information
•DALI single channel PWM dimmer
•Smooth full range logarithmic fade curve tuned
to human vision.
•This device will require an external DC power
supply for normal operation. (not included)
Features
•1 channel ultra-high PWM output
•Screw terminal connections.
•Two holes for wall mounting.
•IP20 moulded shell.
Wiring Schematic
Technical Specifications
Item
Value
Input Voltage
Input voltage 12VDC-36VDC
Maximum Current
8A (96-288W)
Max Output Channels
1
Supported Protocols
DALI (IEC 60929 & IEC 62386)
Control Resolu-
tion
8 bit dimming
(256 graduations)
Connectors
Screw terminals
Environment
Ambient: 20 C to +50 C
Humidity: 0-50% non-con-
densing
IP Rating
IP20
Installation
•This product should be installed and serviced by a
qualified person.
•Do not expose this unit to direct sunlight or wa-
ter. If installed outdoors, ensure it is mounted
within a waterproof enclosure.
•Never connect any cables whilst the power is on and
always assure correct connections before switching
DALI Power Supply

Datasheet (510845)
DALI 8A 12-36V LED DIMMER: 79335
www.enttec.com
2 ID: 2345301 Rev:1
on to avoid short circuits and irreversible
damage.
•Ensure the output voltage of any power supplies
used comply with the working voltage of the unit.
•This product should be installed and serviced by
a qualified person.
•Always be sure to mount this unit in an area with
proper ventilation to avoid overheating.
Note: This product requires a DALI power supply for
proper functioning
Driver Layout
Dimensions
Item
Value
Weight
50 g
Height
20.0 mm
Width
37.0 mm
Length
95.0 mm
Due to continuous improvements and innovations of all
ENTTEC products, specifications and features are subject to
change without notice. For the latest version of this manual
contact your local ENTTEC vendor.
Ordering Information
ENTTEC DALI Dimmer and related products can be ordered
from our website or through your ENTTEC dealer using the
following part numbers.
Item
Value
79335
DALI 8A 12-36V LED DIMMER
