AMX Incandescent Dimmer Module RDM-INC50 Assembly instructions

Installation Sheet
RDM-INC50 Incandescent Dimmer Module
6000 W
The RDM-INC50 Incandescent Dimmer Module is a standard 6000 W
incandescent dimmer. It can dim incandescent lights, cold-cathode, neon
transformers and two-wire dimmable ballasts. It is designed for use with the
RDA series of enclosures, in a AMX Lighting™ modular digital dimming
system. The RDM-INC50 module's 120, 240, and 277 VAC ratings are CE,
UL, and C-UL approved.
RDM-INC50 UL and C-UL Ratings
• 120 VAC, 6000 W
• 240/277 VAC, 6000 W
Suggested Dimmed Loads
• Incandescent
• Low-voltage
• Neon, cold cathode
• Two-wire, phase-controlled ballast
Specifications:
• Dimensions (HW): 10.0" x 5.50" (25.4 cm x 13.97 cm)
• Phase dependant
• Use wires rated at 75°C (167°F)
• Torque terminals to 16 in-lbs. (1.84 N/M)
• Max. wire size: 8 AWG (10 mm²)
• Wire stripping length: 0.28" (7 mm)
• Weight: 7.0 lbs. (3.175 kg)
• BTU/hr: 750
• Control current: 45 mA @ 12 VDC
• Occupies two enclosure spaces
Caution: Pre-Installation Notes
• All Class 1 wiring must be connected to proper terminals.
• All control wiring must be connected to proper terminals.
• Disconnect power while installing or connecting the unit.
• Keep top and bottom air vents clear at all times.
• Test loads for shorts before connecting.
• Run all control and low-voltage wires away from heat producing parts
of the dimmer.
• Each dimming circuit must have a separate neutral connection.
• Use low-voltage wires with a 300 volt rating or greater.
• Use field installed copper conductors.
• All electrical ratings are for continuous duty.
• AC lighting loads only.
• For indoor use only.
• This module may require extra power from the AXlink connection or an
external power supply connected to the control card.
Connecting the RDM-INC50 to the AMX Lighting Master
Lighting Application Drawing
FIG. 1 RDM-INC50
Line in (hot)
Load out
500µS choke
50 A Power
Device
Mounting
points
Low-voltage control
wiring: 4-pin connector
to AMX Lighting
master controller
FIG. 2 RDM-INC50 connections
FIG. 3 RDM-INC50 wiring application
Pin 4 (GND)
Pin 3 (RLY)
Pin 2 (DIM)
Pin 1 (+12 V)
RDM-INC50 4-pin module connector
4-pin plug from a RDM series module
Note: The 4-pin plugs from the module
connector to the 4-pin connector on the
master (black plug cover facing up).
2 (-)
1 (+)
Neutral
Load
Neutral
Load
Neon lights
(cold-cathode, on/off)
Two-wire
dimmable ballast
Neutral
Line in (HOT) Load
All neutrals are common to the
Neutral block in the enclosure.
Provide a separate neutral for
each load.
