enVerid AP-W-120V-14W-2 Owner's manual
enverid.com 1
enVerid Technical Documentation
Air Purifier Installation,
Operation & Maintenance
Guide
AUGUST 2021
V5
MODEL NUMBER:
AP-W-120V-14W-2
enverid.com 2
Important Information
enVerid Air Purifier Installation, Operation & Maintenance Guide
READ AND SAVE THESE INSTRUCTIONS!
Read all instructions before using this Air Purier. When using an electrical appliance, basic precautions should
always be followed, including the following:
•Always turn o the unit before performing any maintenance.
•Do not use attachments, lters or other components not recommended and approved by enVerid (doing so will void warranty).
•Do not use outdoors.
•Do not attempt to remove any part of the unit except the lters or UVC lamp
•Do not operate the Air Purier near an open ame.
•Do not obstruct the air inlet or outlets of the Air Purier.
•Do not expose the Air Purier to water or rain.
•This product employs overload protection (fuse). A blown fuse indicates an overload or short-circuit situation. If the fuse
blows, disconnect the product from the electric supply before inspecting unit. If the replacement fuse blows, a short-circuit
may be present and the product should be discarded or returned to an authorized service facility for examination or repair.
•Use AC 120V only.
WARNING – Important safety instructions to reduce the risk of re or electric shock, or injury to persons,
observe the following:
•High voltage inside – To reduce the risk of injury, disconnect from power supply before servicing.
•CAUTION! To reduce the risk of injury to persons, install purier at least 8 feet (2.5 meters) above the oor. Installed ducting
should be at least 5 feet (1.5 meters).
•Suitable for commercial or industrial use only
•Use this unit only in the manner intended by the manufacturer. If you have questions contact the manufacturer.
•Before servicing or cleaning unit, switch power o at service panel and lock the service disconnecting mains to prevent
power from being switched on accidentally.When the service disconnecting mains cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
•Installation work and electrical wiring must be done by qualied person(s) in accordance with all applicable codes and
standards, including re-rated construction practices.
•When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
•Skin or eye damage may result from directly viewing the light produced by the lamp in this equipment. Always disconnect
power before replacing the lamp or servicing. Replace lamp with model No. GPH287T5 manufactured by ESLight.
WARNING - To reduce the risk of re or electric shock, do not use this fan with any solid-state speed
control device.
AVERTISSEMENT : NE CONVIENT PAS À DES RÉGULATEURS DE VITESSE À SEMI-CONDUCTEURS.
enverid.com 3
enVerid Air Purifier Installation, Operation & Maintenance Guide
TABLE OF CONTENTS
PART ONE: Air Purifier Installation Manual 4
PART TWO: Air Purifier Operations & Maintenance Guide 10
1. enVerid Air Purier Installation View
2. enVerid Air Purier Installation BOM List
3. enVerid Air Purier Installation Method
1. Operation
2. Control Panel
3. Trouble Shooting
4. Routine Maintenance
enverid.com 4
1. enVerid Air Purier Installation View
BELOW THE CEILING (UNCONCEALED INSTALLATION) SIDE VIEW
AIR PURIFIER TOP VIEW
IN THE CEILING (CONCEALED INSTALLATION) SIDE VIEW
Floor Slab
Ceiling
Floor Slab
Air PurifierReturn Grille Supply Grille
3/8” Threaded Rod
Air PurifierDuctworkReturn Grille
Supply Diffuser
Pre Filter
High Efficiency Filter
3/8” Threaded Rod
Blower UVC LampsSilencer
Floor Slab
Ceiling
Ceiling
Air PurifierDuctworkReturn Grille
Duct Clamp
Supply Diffuser
Filter
Access
Door
Control Box
Pre Filter
High Efficiency Filter
Air Muffler Box
3/8” Threaded Rod
Blower UVC LampsSilencer
3/8" Threaded Rod
Floor Slab
Ceiling
Floor Slab
Air PurifierReturn Grille Supply Grille
3/8” Threaded Rod
Air PurifierDuctworkReturn Grille
Supply Diffuser
Pre Filter
High Efficiency Filter
3/8” Threaded Rod
Blower UVC LampsSilencer
ONE: Air Purifier Installation Manual
enverid.com 5
2. enVerid Air Purier Installation BOM List (not included in packaging)
NO.
1
5
11
3
9
7
13
2
6
12
4
10
8
14
IMAGENAME
Isolation Hangers
Suspension Rubber
Washer
Duct Collar
Expansion Bolt
Spiral Duct
Return Air Box
485 Communication
Wires
Hanging Bar
Return Air Grille
Power Line
Washer
Duct Clamp
Duct Silencer
Mccb Circuit Breaker
QTY.
4
4
3
4
2
1
Multiple
Multiple
1
Multiple
4
4
2
1
REMARK
TD-65lbs only for Purier
3/8” Rubber Washer
8” Flexible collar
3/8” Expansion bolt
NOTE: Beam clamps may be used in case where
air purier is supported by building framing.
8” x 60”
NOTE: For use in hard duct applications.
20”x20”x14” – 1” liner for
sound attenuation or conrm on site
18 gauge, 2 wire, stranded and shielded wire
3/8” Threaded Rod
20”x20” minimum or to be conrmed by PM
See power requirements and local code
3/8” Fender Washer
8” Duct Clamp
8” x 40”
NOTE: For use with exible duct for sound attenuation.
MOCP 15 Amp – Do not exceed code requirements
and guidelines for number of units per circuit
enVerid Air Purifier Installation, Operation & Maintenance Guide
enverid.com 6
3. enVerid Air Purier Installation Method
NO.
1
5
3
7
2
6
4
8
IMAGENAME
Equipment Body
Screws
Installation &
Maintenance Guide
Pre-Filter
Controller
Flange
Angle Bracket
HEPA Filter
QTY.
1
Multiple
1
1
1
3
4
1
REMARK
Individually packed
Included in accessories bag
Included in data packet
Included in equipment body
Individually packed
Included in equipment body
NOTE: 2-Supply
1-Return
Included in accessories bag
Included in equipment body
STEP 1
Open package and check parts/documents. Assemble angle bracket (item 4) to unit (item 1) as below.
STEP 2
Install expansion bolts and threaded rod into slab. Use 3/8” expansion bolt drill depth of minimum 2”, as below.
NOTE: Minimum recommended installation height 8ft above the oor.
Maximum recommended installation height 16ft above the oor.
Floor Slab
Air PurifierReturn Grille Arc GrilleAir Muffler Box
Expansion Bolt
2” Min. Into the slab
Nuts
3/8” Threaded Rod
enVerid Air Purifier Installation, Operation & Maintenance Guide
enverid.com 7
STEP 3
Use four threaded rods to hang the unit,
xed with screws, and install appropriate
vibration isolation devices.
The equipment location must allow
access to the lter for replacement and
the control board for service (A).
STEP 5
Install ductwork per local code and
SMACNA guidelines. 40” minimum
of hard duct silencers is suggested
for exible duct installations and 60”
minimum for hard duct installations.
Both supply and return should be
insulated or lined to dampen system
sound.
Floor Slab
Filters Silencing Section
3/8” Threaded Rod
Isolation Hangers
STEP 4
Install the Air Purier box to the slab
with 3/8” standard threaded rod at
the corresponding position.
NOTE: UVC lamps can be removed
prior to installing the Air Purier box if
the UVC lamps will not be used.
A
enVerid Air Purifier Installation, Operation & Maintenance Guide
enverid.com 8
STEP 6
Power supply wiring: cabling should be contained within
conduit, and connected to PCB board as shown.
STEP 7
Control panel wiring: The position of the control switch
panel shall be decided and conrmed with client and/or
main contractor.
Cabling should be contained within conduit and
controller connected to panel board with RVSP line
as shown.
STEP 8
Installation of lter: Please note that the arrow on the
lter is the direction of air ow as below. Filters should be
installed after cleaning work has been completed on-site.
The reset button on the Controller should be pressed
once the lters are installed to reset the maintenance
schedule for the lters. Once reset, the Filter Life counter
in the Notication Center under the speed display will say
365 or 182 days to indicate a 12 or 6 month lter life. The
HEPA lter should be replaced every 6 months when the
UVC lamp is used and every 12 months if the UVC lamp
is not used by removing the UVC lamps from the unit. If
the lter life shows 182 days and you are operating the
system without the UVC lamp, then one maintenance
schedule can be skipped each cycle. The counter is hard-
coded to either 365 or 182 days.
NOTE: Filters should only be installed once the building is
completely clean of construction debris and dust. HEPA lter
must be removed from plastic before operating unit.
enVerid Air Purifier Installation, Operation & Maintenance Guide
enverid.com 9
enVerid Air Purifier Installation, Operation & Maintenance Guide
AIR PURIFIER WIRING DIAGRAM
enverid.com 10
1. Operation
•Do not put your nger or other material into the air suction port or the exhaust port.
•Do not use near ammable materials, water, in places of extreme temperature, or very high humidity.
•Stop use immediately if the machine starts to vibrate excessively, make unusual noises, overheats or starts to smell.
2. Control Panel
• The system is in operation when the light is on.
• Displays the current speed of air volume.
• MAINTENANCE: Appears rst when the lter life is less than 30
days, and starts ickering when the lter life is less than 10 days.
• FILTER LIFE: Check remaining days of the lter.
On/O.
+Increase air volume.
–Decrease air volume.
Reset: Short press to check the remaining days of the lter, and long
press for 10 seconds to reset counter.
Mode: If the ECS control system is used, hold for more than 3 seconds
to turn o the ECS operating mode.
STATUS
SPEED DISPLAY AREA
CONTROL PANEL INTERFACE
NOTIFICATION CENTER
KEY PAD
3. Trouble Shooting
ISSUE ACTION
Does not turn on
Display shows “MAINTENANCE”
Loud noise during operation
Check power source.
Check whether lter replacement is required.
If lter has been replaced, long press the “Reset” button to reset the timer.
Check whether lter replacement is required.
If lter replacement is not required, stop using the Air Purier immediately and contact a licensed contractor.
TWO: Air Purifier Operations & Maintenance Guide
enverid.com 11
enVerid Technical Specifications
4. Routine Maintenance
Make sure the power is turned o before performing maintenance.
All maintenance should be performed by a licensed contractor.
Only enVerid supplied lters should be used to ensure performance.
Maintenance Requirements
The HEPA lter should be replaced every 6 months when the UVC lamp is used and every 12 months if the UVC lamp is not used
by removing the UVC lamps from the unit.
The washable pre-lter should be washed whenever the HEPA lter is replaced and replaced every 2 years.
The UVC lamp should be replaced every 9,000 hours and cleaned whenever the HEPA lter is replaced.
The Maintenance light on the Control Panel lights up when the HEPA lter life is less than 30 days and blinks when
the HEPA lter life is less than 10 days. Filter life is determined based on a countdown of the number of days since
the counter was re-set. For most models, the counter is based on 182 days or six months. In some models, the counter is based
on 365 days. The Reset button can be used to re-set the maintenance schedule for the HEPA lter. The days remaining on the
HEPA lter can also be viewed in the notication center under the speed display on the LCD controller.
Used lters should be bagged and disposed of like other HVAC lters.
Contact your trash removal service to determine the appropriate disposal method for used UVC lamps.
Replacement parts can be ordered from the distributor who sold you the enVerid Air Purier or from enVerid directly by calling
+1 617-795-4000 or emailing [email protected].
Floor Slab
Ceiling
Floor Slab
Air PurifierReturn Grille Arc GrilleAir Muffler Box
3/8” Threaded Rod
Air PurifierDuctworkReturn Grille Supply Diffuser
Pre Filter
HEPA Filter
Air Muffler Box
3/8” Threaded Rod
UVC Lamp
Silencer
©2021 enVerid Systems, Inc. All rights reserved. Third-party trademarks mentioned are the property of their respective owners. | 2021-08-26_AP_Install_v5
enVerid helps buildings achieve ESG (Environmental, Social, and Governance), healthy building, and cost saving goals by improving indoor air quality while saving money and reducing energy consumption and
carbon emissions. For new HVAC systems, enVerid’s award-winning HVAC Load Reduction (HLR) Modules enable immediate capital cost savings. HLR Modules also deliver up to 30% energy savings and superior
indoor air quality in new and existing buildings. enVerid’s air ltration products remove particulate and microorganism contamination from indoor air without the signicant cost of upgrading mechanical systems and
increasing mechanical ventilation rates. enVerid’s products are deployed in commercial, academic and government buildings globally. enVerid’s HLR Modules are ASHRAE Standard 62.1, LEED, and WELL compliant
and eligible for utility rebates. For more information visit enverid.com.
Table of contents
