Installation and User‘s Guide
P1
Druck Nr. 29340787en -21.08

2GB
English
Table of Contents
General notes .........................................................................................................3
Important notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Oven installation: ....................................................................................................8
Sauna stones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Maintenance and care ............................................................................................9
Service Address:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Guarantee. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Handling procedures for return shipments (RMA) - Details for all returns ! . . . . . . . . . . 12

3
GB
Dear Customer,
You have purchased a high quality technical
system which will provide you with many ye-
ars of enjoyable sauna bathing. This sauna
heating system was constructed in accor-
dance with state-of-the-art European safety
standards, inspected and manufactured in
accordance with the Quality Standard EN
DIN ISO 9001.
This detailed installation and user‘s guide was
created for your information. Please note
especially the important information and the
data dealing with the electrical connection.
We wish you a richly invigorating and resto-
rative sauna bathing experience.
First of all, check whether the sauna system
has arrived at your site undamaged. Register
transport damage claims immediately with
the delivering transport company or please
consult the supplier who provided the equip-
ment to you.
General notes
Please note that an optimal sauna climate
can be reached only when the cabin, with
its air intake and exhaust, the sauna heating
unit and the control unit have been tuned for
compatibility with one another.
Please note all data and information provided
by your sauna supplier.
The sauna heating units warm your sauna
cabin through means of heated convection
currents. To this end, fresh air from the air
intake vent is drawn in, rises upon warming
(convection) and is then circulated through
the cabin. A part of the used air is pushed out
through the exhaust vent in the cabin. This is
the means by which the typical sauna climate
develops, reaching characteristic temperatu-
res of about 110° C directly under the ceiling
of your sauna, which fall off to about 30-40°C
in the floor area due to the temperature gra-
dient in the sauna cabin. Therefore, it is not
unusual when, for example, temperatures of
110°C prevail in the area of the temperature
sensor over the oven, while the thermometer,
which is installed 20-25 cm under the cabin
ceiling on the sauna wall, registers only 85°
C. With a temperature setting at maximum,
the mean bathing temperature lies between
80°C and 90°C in the area of the upper rec-
liner bench.
Please note that the highest temperature va-
lues in the cabin always develop in the area
above the sauna heating unit and that the
temperature sensor and safety limiter must
be installed in this area in accordance with
the control unit installation guide.
At the initial heating, you may notice a slight
odor arising from evaporation of substances
from the manufacturing process. Air out your
cabin after this cycle before you begin with
the sauna bath
Intended use
This sauna heater is exclusively designed
for the heating of sauna cabins, in connec-
tion with an appropriate control unit.
Any use apart from the defined application
shall be regarded as non-intended use. Ad-
herence to the conventional operating, main-
tenance and servicing conditions is also part
of the intended use.
The manufacturer cannot be made respon-
sible for deviating alterations undertaken on
the authority of the user and any consequen-
tial damage. The risk for such measures
shall be borne solely by the person carrying
out the alterations and causing the damage.

4GB
air intake and exhaust vents must not be
closed. Please observe the information
provided by your sauna cabin supplier.
•For the adjustment and control of the sau-
na heating unit, one of the control units
mentioned later must be used. This con-
trol unit must be attached to a suitable lo-
cation on the outer wall of the cabin, the
associated sensor housings in the interior
of the sauna cabin in accordance with the
installation guide which accompanies the
control units.
•Caution: Covering and improperly
filled stone receptacles present a fire
hazard.
•Make certain that no objects have
been placed on the sauna heating
unit before each start-up.
•Caution: High temperatures on the
heating unit during operation can
cause burns on contact.
•The sauna heating unit is not intended for
installation or placement in a niche under
the bench or under a roof slope.
•Donot start up operation of the sauna he-
ating unit with air intake vents closed.
•The cabin lighting with corresponding
mounting must be of a type that it is splash-
proof and able to withstand a surrounding
temperature of 140°C. Therefore, only
a VDE-certified sauna lamp of 40 W ma-
ximum may be installed for use with the
sauna oven.
•The sauna system (sauna hea-
ting unit, control unit and lighting etc.)
may be hard-wired to the power source
only by a locally certified electrician. All
connecting lines laid on the inside of the
cabin must be able to withstand a surroun-
ding temperature of at least 140°C. For
practical purposes, a silicone line should
be used. If singlewired cables are used
as connecting lines, they must be protec-
ted by flexible metal tubing. The minimum
diameter of the connecting line and the
suitable cabin size in proportion to the po-
Important notes
If assembled incorrectly, the system
will present a fire hazard. Please read
this installation guide thoroughly. It is
especially important to consider appli-
cable dimensions and observe the follo-
wing instructions:
•This device has not been designed for
being used by persons (including children)
that are physically or mentally handicap-
ped or have sensory disabilities. Moreover,
it is not allowed to use this device without
sufficient experience and/or knowledge,
unless these persons will be supervised
by persons responsible for their security
or in case they have been instructed how
to use this device.
•Children are to be supervised in order to
make sure that they do not play with this
device.
•The installation and connection of the
sauna heating unit, control unit and
other electrical equipment must be ac-
complished only by an expert. In this re-
gard it is especially important to meet the
required safety precautions in accordance
with VDE 0100 v. §49 DA/6 and VDE 0100
part 703/2006-2.
•The sauna heating and control units may
be installed only in sauna cabins made of
suitable, low resin and untreated material
(for example: Nordic pine)
•Only a sauna oven with the appropriate
heating capacity may be installed in the
sauna cabin (see Table 2).
•There should always be a provision for air
intake and exhaust vents in every sauna
cabin. The air intake vents must always
be aligned behind the sauna heating unit,
ca. 5 to 10 cm above the floor. Please use
the minimum dimensions of the air intake
and exhaust vents listed in Table 1.
•The exhaust vents must always be placed
towards the sauna heating unit diagonally
in the rear sauna wall, lower area. The

5
GB
wer supply capacity are listed in Table 2:
•During the installation of the sauna hea-
ting unit, make certain that the vertical
clearance between the upper edge of the
sauna heating unit and the sauna ceiling
is sufficient . The horizontal (lateral) clea-
rance between the sauna heating unit and
the cabin wall is provided in the dimension
diagram of the respective sauna heating
unit. The required distance between the
lower edge of the sauna heating unit and
the floor is also provided by the dimen-
sion diagram. In case of floor-standing
ovens, the distance is determined by the
base. Fundamentally, it is important to
make sure that the sauna heating unit is
not placed on a floor that consists of an
easily flammable material (wood, synthe-
tic flooring or similar material). Ceramic
tiles or similar materials are practical in the
area of the sauna.
•The distance between the oven safety
grid or recliner bench and other flammable
materials and the sauna heating unit are
provided in the dimensional data of the re-
spective sauna heating unit. The safety
grid height must be approximately equal
to the frontal height of the sauna heating
unit.
Electrical connection
Your electrician will be able to accomplish
this work without further explanation in ac-
cordance with the provided wiring schematic
and with the help of the circuit diagram
mounted inside the respective control unit.
Be sure to note, however, that live wires
should not be visibly laid onto the inner cabin
walls due to safety considerations. For this
reason, the wall element with the air intake
vent is already equipped with cable conduits
in most sauna cabins
Should there be no cable conduits in your
cabin, drill an hole in the cabin wall imme-
diately adjacent to the sauna heating unit
where the cable projects from the sauna he-
ating unit and pull the cable through this hole
towards the exterior and then to the control
unit. The cable as well as all other connec-
ting lines (supply wire to the power source
and to the cabin lighting) on the outside wall
of the cabin should also be protected from
damage, for ex. by installation in cable con-
duits or by covering with wooden skirting
strips.

6GB
N
U
V
W
N
U
V
W
12 kW =6x 2,0 kW
15 kW =6x 2,5 kW
double-tuned connection
single-tuned connection
12 kW =6x 2,0 kW
15 kW =6x 2,5 kW
N
U
V
W
N
U
V
W
Supply line to con-
trol unitt
Supply line to con-
trol unit
Supply line
to LSG
Capacity
acc. DIN
Installation
dimensions
H/W/D cm
For cabin
size
Minimum
dimensions
of air intake
and exhaust
vents
Weight
without
stones
without
package
Stone filling Power switch
gear needed
For operation with control
units
12 kw
72/63/38
14 - 18 m³35 x 7 cm*)
25,5 kg 30 kg ECON L09
EMOTEC L09
ECON A1
ECON A2
ECON H2
EMOTEC B6000
EMOTEC DC9000
EMOTEC DC9000 DB/DL
EMOTEC HCS 9003
EMOTEC HCS 9003 DB/DL
15 kW 18 - 25 m³35 x 9 cm*)
*or in accordance with the instructions of the cabin manufacturer
Capacity
acc. DIN
Electrical.
Connection
Fuse control
unit in A
Fuse LSG
in A
Connecting
cable main
- control unit
in mm²
Connecting
cable main -
LSG in mm²
Connecting
cable control
unit - heater
in mm²
Connecting
cable LSG
- heater in
mm²
Connecting
cable control
unit - LSG in
mm²
12 kw 3N AC
50 Hz
400 V
3 x 163 x 165 x 2,5 5 x 2,5 5 x 1,5 5 x 1,5 4 x 1,5
15 kW
All cross sections of a line are minimum diameters in mm²(Copper line)

7
GB
L1 L2 L3 N
Sensor
Limiter
S1
Saunasteuergerät
control unit
U V W WB WM N
400 V AC 3N
N U V W
max. 9 kW
Sensor
Wiring diagram
Caution! Always make
certain to include neutral
conductor N clamp
L1 L2 L3 N
Sensor
Limiter
S1
Saunasteuergerät
control unit
U V W WB WM N
400 V AC 3N
4 3 2 1
Sensor
4 3 2 1 U V W N L1 L2 L3 N
S1 V N
400 V AC 3N
ECON / EMOTEC
single-tuned connection
double-tuned connection
LSG 09
max. 15kW
Attention!
Dear customer,
accordingto the valid regulations,the
electrical connection ofthe sauna heater
and the control unit has to be carried out
through the specialist ofan authorized
electric shop.
We would like to mention to the fact
that in case of a warrenty claim, you are
kindlyrequested to present a copy ofthe
invoice of the executive electric shop.
15 kW

8GB
Oven installation:
The sauna oven is intended only for a supply
voltage of 400 V3 N AC.
The minimum height of the sauna cabin must
be 1.90m on the inside.
During the installation of the sauna oven,
make certain that the vertical distance bet-
ween the upper edge of the sauna oven and
the sauna ceiling is at least 90 cm, and that
the horizontal (lateral) distance between the
oven and the cabin wall is at least 8 cm.
The distance between the oven safety grid
or recliner bench and other flammable ma-
terials and the oven must be at least 8 cm.
Mounting screw
Angle bracket
Rear wall, sauna oven
Cabin wall
Fig. 1 Fig. 2
Fig. 3 Fig. 4
8 cm
63 cm
30 cm
30 cm
8 cm
72 cm
8 cm
The safety grid height must be equal to the
frontal oven height (fig. 3 and 4).
In accordance with required safety dis-
tances, center the oven in front of the air
intake vents. Insert angle bracket into the
mounting slot on the rear wall in accordance
with the following illustration and swing
into horizontal position. To this end, make
certain the short side of the angle bracket
latches into the upper slot. Tighten the
brackets with the screws for particle board
which are provided.

9
GB
Please be sure to note!
Do not stack the stones in layers;stack them
loosely instead, leaving as many spaces as
possible to allow the rising hot air to circu-
late.
Sauna stones
The sauna stone is a natural product. Check
the sauna stones at regular intervals. Strong
infusion concentrates especially can wea-
ken the sauna stones and cause them to
disintegrate over time. Consult your sauna
supplier if necessary.
Thoroughly clean the sauna stones provided
under running water and then place them in
the stone receptacle so that the convection
air current can circulate easily between the
stones (Illust. 9 +10).
The number of stones is adequate to crea-
te a steam burst, vaporizing about 10 cl of
water per m³cabin volume. Always wait 10
minutes after infusion before repeating the
infusion. Only then are the sauna stones
sufficiently hot.
Never add more infusion agents or volatile
oils than instructed on the packaging. Never
use alcohol or undiluted concentrates. Cau-
tion! Fire hazard!
Maintenance and care
All sauna heating units are made of low-
corrosion material. Still, to enjoy your sau-
na heating unit for a long time, you should
maintain and care for the unit. To this end,
always make sure that the vents and re-
flection plating in the area of air intake are
free of objects. These can easily become
clogged with fuzz and dust when drawing in
fresh air. This reduces the air convection in
the sauna heating unit and can be a cause
of unacceptable temperatures.
Clean or de-scale the units when needed.
Refer to your sauna supplier or directly to
the manufacturing plant in case of defects or
signs of wear and tear.
Only use original manufacturer‘s replace-
ment parts, which can be obtained from your
supplier or directly from the manufacturer.
If you do not use your sauna for a signifi-
cant period of time, always check before
next use that cloths, cleansers or other
objects have not been placed on the sau-
na heating unit or the vaporizer before
turning them on.

10 GB
For the installation of sauna heaters, please
pay attention to the DIN VDE 0100 part 703 !
This standard makes the following statement
valid in your newest expenditure, since Febru-
ary 2006, paragraph 703.412.05;
Quotation:
The additional must be planned for all electric
circuits of the Sauna by one or more fault cur-
rent protection device (RCDs) with a calculati-
on difference stream not more largely than 30
mA, excluded of it is Saunaheating.
The EN 60335-1 DIN VDE 0700 part 1 of Janu-
ary 2001 states the following in paragraph 13;
quote:
The leakage current may not exceed the follo-
wing values during operation:
- for stationary heaters of protection class I
0,75 mA; or 0,75 mA each kW input of the ap-
pliance, depending on the higher value, at a
maximum value of 5 mA.
If the appliance is equipped with a protective
device for leakage current (ELCB), please pay
attention to the fact that no other electrical
units will be protected by this ELCB.
Under current manufacturing methods, it is
not yet possible to produce tubular heating
elements for sauna heaters which do not at-
tract moisture on each end from the surroun-
ding air.
Therefore, should the ELCB be triggered du-
ring start-up, the electrical installation must be
checked.
It is also possible that moisture from the sur-
rounding air has been concentrated in the ma-
gnesium-oxide filling in the heating elements
during transport or storage and is now cau-
sing the ELCB to be triggered.
In this case, the oven must be heated up under
supervision of an expert, during which the PE
conductor is not connected. After about 10
minutes, when moisture has evaporated from
Instructions
Leakage current on sauna heaters

11
GB
Service Address:
EOS-WERKE GÜNTHER GmbH
Adolf-Weiß-Straße 43
35759 Driedorf-Mademühlen, Germany
Fon: +49 (0)2775 82-0
Fax: +49 (0)2775 82-431
servicecenter@eos-werke.de
www.eos-werke.de
Guarantee
The guarantee is taken over according to
the legal regulations at present.
Manufacturer’s warrenty
- The period of warrenty starts from the
date of purchase and lasts up to 2 years
for commercial use and 3 years for priva-
te use.
- Always include the completed warrenty
certificate when returning equipment.
- The warrenty expires for appliances
which have been modified without
manufacturer’s explicit agreement.
- Damages caused by incorrect operation
or handling through non-authorized per-
sons are not covered under the terms of
warranty.
- In the event of a claim, please indicate the
serial number as well as the article code
number and type name with expressive
description of the fault.
- This warrenty covers damaged parts but
no defects due to wear and tear.
In case of complaint please return the
equipment in its original packaging or other
suitable packaging (caution: danger of
transport damage) to our service depart-
ment.
Always include the completed warrenty
certificate when returning equipment.
Possible shipping costs arising from the
transport to and from point of repair cannot
be borne by us.
Outside of Germany please contact your
specialist dealer in case of warranty claims.
Direct warranty processing with our service
department is in this case not possible.
Equipment start-up date:
Stamp and signature of the authorized
electrician:
Please keep this address in a safe place to-
gether with the installation guide.
To help us answer your questions quickly
and competently, please provide data prin-
ted on the ID plate, to include system type,
article no. and serial no., in all inquiries.

12 GB
Handling procedures for return shipments (RMA) - Details for all returns !
Dear customer
we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an
exeption, please follow the procedures specified below.This enabling us to ensure a quick and smooth
handling of the return shipment.
Form of complaint:
Please absolutely respect for all returns!
•Please add the available RMA-voucher always completely filled out together with an
invoice copy to the return shipment! Do not stick it on the goods or on the packaging.
We do not accept the return shipment without these papers.
•Not prepaid parcels will be refused and returned to Sender! Please always ask for the
RMA-No. for the cheapest return.
•Please pay attention that the goods have to be sent back without visible marks of
use in the original scope of delivery and in original packing.
•Werecommend to use an additional solid and break-proof covering box which should
be padded out with styrofoam, paper or similar. Transport damages as a result of faulty
packing are for the sender‘s account.
2) Faulty goods
•The implied warrenty peri-
od is 2 years.Please con-
tact your dealer in case of
faulty or wrong articles
or missing accessories.
He will discuss with you
the individual case and try
for immediate and custo-
mer-friendly solution.
•For economic returns
within Germany you will
get an RMA-number from
the manufacturer.
• All returns have to be in
the original packing of
the goods with corres-
ponding accessories.
Please repack the goods
to avoid damages. In case
of wrong delivery, please
do not use this article !
3) Problems of installation
and functioning
• Please read the manual
carefully first of all and
pay attention to the indica-
ted assembly or installing
instructions.
•Your dealer should be
the first contact person
because he knows his pro-
ducts best and also knows
possible problems.
• In case of function pro-
blems with an article,
please check at first whe-
ther there is an obvious
material defect. The quali-
ty system in our factory re-
duces malfunctions of new
appliances to almost zero.
.
1) Transport damage
•Please check the content
of your parcel immediately
and advise the forwarding
company of a claim (parcel
service/freight forwarder)
•Do not use damaged
goods!
•Ask the forwarder for a
written acknowledge-
ment of the damages.
• Report the claim prompt-
ly by phone to your dea-
ler. He will discuss with
you how to act in this
case.
•If the transport box has
been damaged, please
use an additional covering
box. Do not forget to add
the acknowledgement of
the damage of the for-
warding company !
!
Table of contents
Other EOS Plumbing Product manuals
Popular Plumbing Product manuals by other brands

Kohler
Kohler K-6228 Installation and care guide

Kohler
Kohler K-2268 Installation and care guide

Arblu
Arblu CONSOLLE TULIP Assembly instructions

Grohe
Grohe Contromix 36 121 manual

Carron Phoenix
Carron Phoenix DANTE PRO Fitting Instructions & Contents List

Hans Grohe
Hans Grohe AXOR Urquiola 11041000 Instructions for use/assembly instructions

Roxtec
Roxtec R Series installation instructions

Viega
Viega 8040.18 Instructions for use

American Standard
American Standard Amarilis 8871.000 Specification sheet

brondell
brondell SIMPLESPA SS-150 owner's manual

RECOUP
RECOUP EASYFIT+ installation instructions

Hans Grohe
Hans Grohe Talis S 160 72815001 Installation/User Instructions/Warranty
