Epic EasyScan M10 User manual

EasySc a n
TM
User
Manual
M10

h
h
t tp://www . epiclidar . cn
Wuhan Eleph-Print Tech Co.,Ltd

EasySc a n
TM
M10
Handheld 3D Laser Scanning
System
User Manual

Catalog
1 Product Introduction ···························································· 1
1.1 Produ ct Overview ·········································································1
1.2 Technical Specification·····························································2
2 Product Configuration·······························································3
2.1 Scanner················································································3
2.2 Mainframe ············································································3
2.3 Battery ·················································································4
2.4 Cable ···················································································5
2.5 Backpack Kit··········································································5
3 Installation & Disassembly·························································6
3.1 Installation Preparation ····························································6
3.2 Installation & Disassembly ·······················································7
4 Operation ·············································································12
4.1 Device Startup ······························································· 12
4.2 Camera Operation ··························································· 12
4.3 Device Connection ·························································· 12
4.4 Device Power-off ····························································· 12
4.5 Battery Charging ······························································ 13
5 Data Collection ·······································································14
5.1 Operation Software Installation················································14
5.2 Software Startup ······························································ 17
5.3 Software Interface ··························································· 17
5.4 Parameter Settings ·························································· 18
5.5 Data Collection ······························································· 18
5.6 Data Transfer ·································································· 18
6 Appendix ·········································································· 19
6.1 Routine Maintenance ·························································· 19

1
1 Product Introduction
1.1 Product Overview
The M10 is a handheld SLAM 3D laser scanning system independently
developed by Wuhan Eleph-Print Tech Co., Ltd. Its designed based on the
concept of making a highly lightweight and user-friendly laser scanner with
integrating multiple technologies such as multi-line LiDAR, imaging, and
inertial navigation acquisition, angle measuring sensor, etc. to ensure rapid
and effective acquisition of high-precision true-color point clouds under
any circumstances, which redefines the development direction of handheld
SLAM 3D laser scanners in industry.
With its compact and lightweight design,fast and efficient performance,
the M10 can be widely used in building facade surveying, accident scene
investigation, stack volume calculation, interior renovation, underground
space scanning, planar elevation profile drawing, digital park, and other
fields.

2
1.2 Technical Specification
Technical
Specification
M10
Technical
Specification
Weight (handheld
part only) ①
≤1.8Kg
Size
L182 × W 82 × D29 0 （ m m）
Power
Consumption
20W(Typical)
Power Supply
18~20V DC
Continuous
Operation
Duration
4h(single battery)
Memory
Storage
USB flash 64GB
Operating
Temp.②
-10℃-50℃
Storage Temp.
-20℃-60℃
Supported
Platform
Handheld/
Backpack
Max. Scanning
Distance
120m
Laser Scanning Unit
Laser Class
Class 1
FoV
260°Cx360°C
Laser Length
905nm
Scannin
g Rate
320,000pts/s
Relevant
Accuracy③
2cm
Absolute
Accuracy
5cm
Camera Unit
（Backpack）
FoV
360°
Resolution
18MP

3
Note:
①Overall weight:2.74kg and Mainframe 0.94kg included.
②Testing temp. 25°~27°.
③The ranging accuracy may be affected by the distance of the target object,
environmental temperature, and target object reflectivity. The typical values are the
average measurements of each channel within a range of 0.5m to 70m, at an outdoor
environmental temperature of 30°C and a target object reflectivity of 50%.

4
DATA GNSS CAM USB ON/OFF
2 Product Configuration
M10 has 2 versions, standard version and advanced version.
Standard version includes handheld scanner,mainframe,battery,
cable,USB flash,etc.
Advanced version includes handheld scanner, mainframe, battery,
cable,panoramic camera kit,USB flash,GNSS kit, backpack frame kit,etc.
2.1 Scanner
LiDAR Sensor
Power supply &Data transfer interface
Handle
Stand
Pic. 2-1 M10 product configuration
2.2 Mainframe
Interface Panel
Pic. 2-2 M10 Mainframe

5
2.3 Battery
The M10 system is powered by a lithium battery, as shown in the following picture,
Pic. 2-4 M10 battery
2.3.1 Battery Power on
When the battery is in the off state, press the power button once briefly
and then press and hold the power button for more than 2 seconds to
turn on the battery. When the battery is turned on, the power indicator
light will be constantly red and the battery level indicator light will display
the current battery level.
2.3.2 Battery Power off
When the battery is in the on state, press the power button once briefly
and then press and hold the power button for more than 2 seconds to
turn off the battery. After the battery is turned off, all indicator lights will
go out.
2.4 Power cable & Data transfer cable
The M10 is equipped with 3 cables,one data transfer cable,one camera
cable and one GNSS cable,as shown in the following figure,
Warning:
·Do not immerse the battery in liquid (such as water, seawater, etc.). When not in
use, the battery should be placed in a cool and dry environment.
·Do not place the battery near high temperature sources (such as fire, heater, etc.)
or use it nearby.
·Do not hit, compress, throw, or step on the battery.
·If the battery appears bulging or deformed, stop using it immediately.
·This battery is equipped with a dedicated battery charger. Do not replace it with
other models of chargers.

6
Note:
The above cable is a directional connecting cable. When connecting, make sure that
the positioning pin (red dot indicator on the connector) is facing upward.
Warning:
The above cable is a system-specific cable. Please do not mix or use other cables to
connect equipment;
·When connecting the cable, please handle it gently to avoid excessively
damaging the equipment due to excessive force."
Pic. 2-5 Data transfer cable
Pic. 2-6 Camera cable
Pic. 2-7 GNSS cable
Data transfer cable: Used for connection
between Scanner and Mainframe
Camera cable: Used for connection between
camera and Mainframe
GNSScable: Used for connection between M10
antenna and Mainframe
2.5 Backpack Frame Kit
