Epica Vimago User manual

Quick Reference
1
Vimago™ Patent Positioning - Head
1) Place the patient on the bed in sternal recumbency
2) Turn ON the lasers


Quick Reference
2
Vimago™ Patent Positioning - Head
3) Rotate the gantry to 90°
4) Move the gantry forward over the patient, using the FW button on the gantry touchscreen



Quick Reference
3
Vimago™ Patent Positioning - Head
5) Use the top laser to align the region of interest Left to Right. Symmetry is imperative
a. To adjust, move the head left or right, tilt the head side to side and align the nose so
it’s pointing straight forward
6) Use the side horizontal laser to center the region of interest Top to Bottom
a. To adjust, use the keypad on the end of the cart to raise or lower the bed

Quick Reference
4
Vimago™ Patent Positioning - Head
7) Usethesideverticallasertoalignthecenterofyourrststack
a. To adjust, use the forward (FW) and back (BK) arrows on the gantry touchscreen
NOTE –
Each acquisition
stack is 12cm
8) Thiswhatyoushouldseewhennished
