Transcend Micro User manual

Micro
User Manual
®
™

Page 6
Your Transcend Micro
a. Power button
b. Bluetooth button
c. Pressure ramp button
d. Dry cycle button
e. Air filter cover
f. Air outlet
g. USB-C data port
h. Power supply inlet
Setting Up Your Transcend Micro
AirFlex™air hose connection
a. Transcend Micro device
b. Air outlet
c. Air hose coupler
d. AirFlex hose

Page 7
1. Connect the hose firmly to the air outlet on the device by inserting the hose
coupler into the air outlet on the device.
2. Locate the arrow on the air hose coupler and arrow on the device.
3. Align the arrows and gently insert at a slight angle and twist the air hose coupler
clockwise until you feel it begin to insert. Continue twisting until the air hose
connector is seated securely into the device. The image below indicates a fully
secured hose with the hose arrow below the parting line of the device.
4. Connect the Transcend WhisperSoft muffler to the opposite end of the air hose.
oIf not using the Transcend WhisperSoft muffler: connect the air hose
coupler of a Transcend AirFlex™Micro air hose into the device air flow outlet.
Then connect the opposite end of air hose to the mask.
oTo remove the hose simply turn it counterclockwise and pull gently away
from the device
NOTE: The hose is the applied part and constitutes the air pathway.
Power supply: AC adapter
Follow steps for the appropriate power supply model included with the Transcend Micro
system.
When connected to power, each LED will flash. When flash sequence is completed, the
green Power LED light and Bluetooth LED will remain on.
For PSA5 Power Supply:
Transcend Micro
AC Adaptor
Power Outlet
Power Cord

Page 8
1. Connect the power cord from AC adapter into the power outlet at the bottom of the
device.
2. Connect one end of the power cord into the AC adaptor and the other end into the
power outlet.
For PSA4 Power Supply:
1. Connect the power cord from AC adapter into the power outlet at the bottom of the
device.
2. Connect power cord from device power inlet directly to power outlet.
NOTE: Ensure the power cord is accessible so that it can be easily
unplugged from the wall.
Power supply: PowerAway battery
To use the Transcend PowerAway battery as the primary power supply.
1. Fully charge the Transcend PowerAway battery before the first use by connecting it
to the AC adapter and a power outlet. The battery will begin to charge
automatically.
NOTE: Do not connect the battery to the Transcend Micro during the initial
charge.
2. Once the battery is fully charged, it is ready for use with the Transcend Micro. It
may take up to eight (8) hours to charge the PowerAway battery.
To use the Transcend PowerAway battery in conjunction with AC line power as a backup
power supply to provide uninterrupted therapy in the case of a power outage.
1. Insert the barrel connector of the battery into the Transcend Micro power jack.
2. Insert the barrel connector from the AC adapter into the Transcend PowerAway
battery.
3. Connect one end of the power cord into the AC adapter and the other end into the
power outlet.
4. When connected to power, each LED will flash once. When completed, the green
Power LED light will remain on.
See the Transcend PowerAway Battery User Guide on myTranscend.com for guidance
information on setup, use and caring for Transcend batteries.
Transcend Micro
Power Cord
Power Outlet

Page 9
Connecting Comfort Features
WhisperSoft™muffler assembly
1. Attach the short muffler air hose to the device.
2. Attach the short muffler air hose to the WhisperSoft muffler.
3. Attach one end of long (mask) air hose to the other end of the muffler and then
attach the opposite end to the mask or HME (Heat/Moisture Exchanger).
AirMist™HME adapter assembly
The Transcend AirMist HME assembly is sold separately and is an add-on accessory that is
not included with the Transcend Micro system.
1. Remove the HME cartridge from foil package. Handle by the plastic shroud not the
foam core.
2. Unscrew the HME adapter bottom from the HME adapter top and place the HME
cartridge inside the HME adapter bottom.
3. Place the HME adapter top onto the HME adapter bottom and gently turn the top
until the adapter compresses together on the HME cartridge.
Securely attach the HME adapter bottom to your hose.
4. Securely attach the HME adapter top to your mask.
a. Short air hose
b. WhisperSoft muffler
c. Long air hose
a. Air hose
b.
HME adapter bottom
c. HME cartridge
d. HME adapter top

Page 10
Navigating the Device Buttons
Control panel
Power button and LED indicators
Standby Mode
When the device is plugged in, it will be in Standby Mode.
•The LED glows green, indicating that the device has power.
•Pressing the power button transitions the device to Therapy Mode.
oAll LEDs will turn off.
oThe blower will start and the device will begin regulating pressure.
Therapy Mode
When the device is powered and in Therapy Mode:
•The LED is off.
•Pressing the power button transitions the device to Standby Mode.
oThe LED glows green.
oThe blower stops.
Bluetooth button and LED indicators
Standby Mode
Pressing the Bluetooth button toggles communication between enabled/disabled.
Bluetooth indicator light is blue
Bluetooth communication is enabled but there
is not an active connection with a mobile
device.
Bluetooth indicator light is green
Bluetooth communication is enabled and there
is an active connection with a mobile device.
a. Bluetooth
b. Pressure ramp
c. Dry cycle
d. Power
e.

Page 11
Bluetooth indicator light is white
Bluetooth communication is disabled.
Therapy Mode
Pressing the Bluetooth button has no effect while in Therapy Mode.
Bluetooth indicator light is off
Therapy Mode is on.
Ramp button and LED indicators
Standby Mode
•The LED glows blue if the Ramp is configured and auto-ramp is enabled.
1. If therapy is started when the ramp LED is on, the device will begin at a
lower, ramp pressure. The device will arrive with Ramp enabled.
•The LED is off if Ramp is not configured, or Auto Ramp is disabled.
1. If therapy is started when the ramp LED is off, the device will begin at the
starting therapy pressure.
•Pressing the button when Ramp is not configured has no effect.
1. See Transcend desktop software user guide to configure
https://mytranscend.com/customer-care/user-guides/
•Pressing the button when Ramp is configured toggles Auto Ramp between enabled
and disabled.
Therapy Mode
•The LED is off.
•If Ramp is active, pressing and holding the button accelerates Ramp increase.
•If Ramp is configured but not active, pressing the button starts Ramp.
•If Ramp is not configured, pressing the button has no effect.
Dry cycle button and LED indicators
Standby Mode
•The LED is off when Drying Mode is off.
•The LED glows blue when Dry Cycle is on.
•Pressing the Dry Cycle button toggles between on and off.
Therapy Mode
•The LED is off.
•Pressing the button has no effect.

Page 12
Using MySleepDash app
Transcend MySleepDash is a smart device app that will guide you through the setup
process of your new Transcend Micro device. It includes setup videos, helpful information,
and can track your sleep health progress. The app is not required in order to operate the
Transcend Micro device.
Before connecting Transcend Micro to a smart device, ensure that the latest version of the
MySleepDash app is installed on the smart device. The app is available for download from
the App Store or Google Play.
Connecting your smart device to the app
•Ensure your Transcend Micro device is set up correctly and plugged into a power
source.
•On your smart device, enable Bluetooth.
•Open the MySleepDash app.
•The first time you open the MySleepDash app, you will be asked to login or create
an account using your email. You will be required to:
1. Provide consent for the use of analytics.
2. Accept Transcend’s terms of use and privacy notice.
3. Provide consent for the MySleepDash app to upload data to the cloud.
Additional information about terms and privacy policies are provided on the Create
Account page.
•Once selections are complete on the Create Account page, tap submit.
After creating your account, you will be required to login using the email and
password you just set up.
•The next step will be to connect your Transcend Micro device to the MySleepDash
app.
Connecting your Transcend Micro to the app
•Ensure Bluetooth is enabled on the Transcend Micro device. The Bluetooth LED will
glow blue to indicate that Bluetooth is enabled.
oIf the Bluetooth LED is glowing white, press the Bluetooth button to enable
Bluetooth.
oIf the Bluetooth LED is off, verify that the device is powered and in standby
mode.
•On the MySleepDash app, tap continue the welcome page.
•Tap the QR code icon to open your camera. You may be required to allow the
device to use the camera features.
•Locate the QR code on the bottom of the Transcend Micro device and scan using the
camera on your smart device.
•Click add to complete adding your device.

Page 13
•The blue LED light on the Transcend Micro will turn green.
•Your device is now connected, follow the on-screen prompts on your smart device
to continue setup.
Starting Therapy
1. Connect the Transcend Micro to a power source and allow it to enter Standby Mode.
2. Be sure your mask fits firmly and in place before starting therapy.
3. Press the Power button or breathe normally to engage SleepStart. Therapy will
begin when the blower delivers or ramps to the prescribed therapy pressure.
NOTE: Some masks are configured differently. Due to this variability SleepStart
may not function.
NOTE: If therapy is interrupted by a power failure, the device will automatically
restart therapy once power is restored.
Using the GentleRise Ramp Function
The Ramp feature lets you acclimate to air flow by starting at a lower pressure and
gradually increasing to the prescribed pressure setting as you fall asleep.
To accelerate the rate of the pressure increase during Ramp mode:
•Hold the Ramp button down until the device reaches a comfortable therapy
pressure.
•When the Ramp button is released, the device will continue in Ramp Mode until it
reaches the prescribed therapy pressure.
•To end Ramp early, hold down the Ramp button until the prescribed therapy
pressure is reached.
•If Ramp is no longer desired, disable it via software. Or disable auto-ramp by
pressing the Ramp button when in standby.
NOTE: Once installed and connected you may use the MySleepDash app to
change ramp settings on compatible Micro devices. Alternatively, to
adjust ramp starting pressure or duration see the Transcend Micro
software manual available on the Transcend website
(mytranscend.com).
Using the AirRelief (EZEX) Function
The AirRelief (EZEX) function is a feature that decreases therapy pressure on exhalation.
This is designed to provide additional comfort to the user by reducing the amount of
resistance they experience as they exhale.
There are four settings: OFF, 1, 2 or 3. Each setting progressively increases the amount of
pressure relief from none to maximum.

Page 14
Once installed and connected you may use the MySleepDash app to change Air Relief
settings on compatible Micro devices. Alternatively, see the Transcend Micro software
manual available on the Transcend website (mytranscend.com) and follow the steps to
change settings.
Ending Therapy
Remove your mask and press the power button to end therapy.
Drying Mode
At the end of each therapy session, it is recommended that the user initiate the Drying
Mode function to dry the attached air hose and accessories.
To initiate Drying Mode:
•Press the Drying Mode button.
•When in Drying Mode, the blower will run at a low speed for 30 minutes.
•During Drying Mode, the Drying Mode LED will continue to glow.
•After 30 minutes, the blower will turn off and the device will enter Standby Mode.
Caring for your Device
Warning Unplug the Transcend Micro device before cleaning and make sure it is dry
before plugging it in again. Do not perform any cleaning or maintenance tasks
while the device is in operation. Damage caused by improperly caring for your
device may not be covered by Transcend’s limited warranty.
•Do not submerge the Transcend Micro device, power supply or power cord in water.
•Prevent water from entering any openings of the device.
•Do not use harsh or abrasive cleaning agents to clean the device or any
components.
•Do not attempt to sterilize the Transcend Micro device.
•Do not place cleaning materials, such as a cloth or liquid, into the device air inlet or
air outlet connector.
•Do not open or modify the device. There are no user-serviceable parts inside the
device. Servicing and repairs should only be performed by an authorized Transcend
person.
•Do not use chlorine, bleach, or scented cleaning solutions, antibacterial or
moisturizing soaps or oils, including scented oils, to clean the device or its
components. These solutions may damage the device or reduce its life.
•Exposure to smoke, including cigarette, cigar or pipe smoke may damage the
device.
•Exposure to ozone or other gases may damage the device..

Page 15
Disconnecting Comfort Features
WhisperSoft muffler assembly
1. Remove the short air hose from the device, by twisting the connector left or
counterclockwise and pulling the hose away from the device. Disconnect the other
end of the hose from the muffler.
2. Remove the muffler from one end of your long hose and your mask from the other
end of the hose.
3. After following the cleaning process, refer to steps in the Connecting Comfort
Feature section to reassemble the muffler.
AirMist HME adapter assembly
1. Remove the HME assembly from your mask
2. Remove the HME assembly from your hose
3. Unscrew the HME adapter bottom from the HME adapter top.
4. Discard the HME cartridge. The HME cartridge plastic and foam are not to be
cleaned and should only be replaced.
5. After following cleaning process, refer to steps in the Connecting Comfort Feature
section to reassemble the HME adapter.
Cleaning the Exterior
Follow these instructions to clean the exterior of the Transcend Micro device.
1. Mix a solution of 5% mild liquid detergent in distilled water (1.6 fl. Oz. liquid
detergent per quart of distilled water). Mild detergent should contain biodegradable
anionic surfactants and no phosphate.
2. Submerge a lint-free cotton cloth into the detergent solution.
a. Short air hose
b. WhisperSoft muffler
c. Long air hose
a. Air hose
b. HME adapter bottom
c. HME cartridge
d. HME adapter top

Page 16
3. Wring excess water from the cloth then wipe the exterior surface of the Transcend
Micro device for approximately 20 seconds using a gentle back and forth wiping
motion. Ensure contact with all accessible surfaces to adequately remove any soil
buildup.
4. Rinse the cloth in clear water to remove residual cleaning solution.
5. Wring excess water from the cloth and wipe the Transcend Micro using a gentle
front to back wiping motion to remove any detergent solution remaining on the
surface.
6. Wipe the device with a dry, lint-free cotton cloth until the device is fully dry.
Cleaning of Accessories
The following accessories should be cleaned with a 5% solution of mild dishwashing liquid
detergent in distilled water (1.6 fl. oz. liquid cleaning detergent per quart of distilled
water). Mild detergent should contain biodegradable anionic surfactants and no
phosphate.
Clean the device and its components as shown in the schedules below in order to maintain
the quality of your device and to help prevent the growth of germs that can adversely
impact your health.
Accessory
Periodic Cleaning Cycle
Product Service Life
AirFlex Hose
Weekly
3 Months
WhisperSoft Muffler
Weekly
3 Months
AirMist HME
Weekly
3 Months
Follow these steps to clean the accessories.
1. Fully immerse the accessory in the cleaning solution. DO NOT immerse the
Transcend Micro device.
NOTE: HME Cartridge must be removed prior to cleaning the HME Adapter. The
HME cartridge cannot be cleaned; discard after 3-7 days of use.
2. While immersed, thoroughly wipe the surface with a lint-free cotton cloth. Apply
firm pressure and ensure contact with all accessible connection surfaces to
adequately remove soil buildup.
3. Clean the inside of the accessory by lifting then lowering the ends of the accessory,
while the accessory is filled with cleaning solution.
4. Rinse accessory by immersing in distilled water. Move the accessory in a back-and-
forth motion for approximately 10 seconds to remove cleaning agent residue.
5. Dry the outside of the accessory with a dry, lint-free cotton cloth. Allow the
accessory to air dry until the inside is dry. Length of drying time will depend on
ambient conditions.

Page 17
Transcend batteries
•DO NOT immerse batteries in water or cleaning solution.
•For long term storage, which is any duration of time greater than three months, the
battery should be:
oStored at a temperature above -20C/-4F but below 20C/68F.
oStored in a dry location and with an approximate 30% charge. Allow 2 hours
to charge battery when fully depleted to achieve 30% charge
See the Transcend PowerAway User Guide on www.mytranscend.com for guidance
information on setup, use and caring for Transcend batteries.
Replacing the Transcend Micro PureFresh™air filter
The Transcend Micro PureFresh air filter should be replaced at a minimum every three
months.
1. Depress the tab on the right side of the filter cover to remove it from the device
2. Remove the filter and discard. Replace with a new filter.
3. Reattach the filter cover by inserting the left side into the device and then clicking
the right-side in.
Cleaning for Multiple Users
If using the device on multiple users, perform the following steps to clean the device
before each new user:
1. Unplug the power supply prior to cleaning.
2. Remove and discard the bacterial/viral filter.
3. Remove and discard the used air supply tube.
4. Follow instructions for cleaning the exterior of the device as noted in Cleaning the
Exterior (above).
5. Apply a new bacterial/viral filter between the hose and the mask before providing
the device to a new user.

Page 18
Warning The air supply tubing, mask assembly and bacterial/viral filters should be
discarded after each patient use using standard institutional biohazard
procedures. No attempt should be made to clean, disinfect, or sterilize these
components for multiple users. These components are for single patient use.
Manufacturer’s instructions must be followed regarding cleaning, disinfecting,
and re-use of patient interfaces (masks).
Warning Only use bacterial/viral filters that are commercially available and designed
for use with CPAP machines. Only use filters that are ISO 23328-1:2003 and
ISO 23328-2:2002 approved. Follow the manufacturer’s instructions for use
of the filter. Only use those commercially available filters that do not require
recalibration of the PAP device.
Warning Do not submerge the Transcend Micro or power supply in liquid. Do not allow
liquid or cleaning solution to enter the device.
Environmental Information
This device should be disposed of separately, not as unsorted municipal waste. To dispose
of your device, you should use appropriate collection and recycling systems available in
your region. If information on these disposal systems is needed, please contact your local
waste administration. If you require information on the collection or disposal of your
device please contact Transcend, your homecare provider or go to
MyTranscend.com/environment.
California Perchlorate Information:
The coin-cell battery within this device may contain Perchlorate Material –special handling
may apply. See: www.dtsc.ca.gov/hazardouswaste/perchlorate
Traveling with Your Transcend Micro
When taking the Transcend Micro device on travels, make sure to have the appropriate
power supply for the region you are traveling to. For information on purchasing, contact
your care provider.
Traveling by airplane
For some airlines, medical devices do not count toward carry-on luggage limits. Please
check with your airline for their policy regarding medical equipment.
You can use your Transcend Micro device on a plane as it meets the Federal Aviation
Administration (FAA) requirements. Air travel compliance letters can be downloaded and
printed from MyTranscend.com.
When using the machine on an airplane:
•When connected to power, disable Bluetooth (enter airplane mode) by pressing the
Bluetooth button until the indicator light is white.
•Do not use the MySleepDash app.
•Use the Start/Stop button on your machine to start therapy.

Page 19
•To reconnect Bluetooth after exiting the plane, press the Bluetooth button and
follow steps to connect to the app.
Troubleshooting
Problem
Possible Cause
Solution
Discomfort due to a feeling
of high pressure.
Device pressure may be set too
high.
Breathe slowly through your nose with
your mouth closed.
Use the ramp pressure, if available.
If the pressure remains problematic,
contact your homecare provider.
Discomfort due to a feeling
of low pressure in mask
Device set too low
Contact home care provider for setting
change.
Excessive leaks around hose or
mask
Check hose, mask and any accessories in
the breathing circuit for air leaks and
proper fit.
Dry nose or throat
irritation.
Dry air
Add humidity to the room.
Replace HME if being utilized. Ensure
proper placement of HME.
Contact your homecare provider.
Dirty air path accessory
Follow cleaning instructions for
accessories.
Dirty air filter
Change the air filter.
Device control panel LEDs
don’t flash or illuminate
when the power supply is
connected to the device.
Power source is not properly
connected.
Check all power connections and verify if
the LED light on the power supply is
illuminated.
AC power may not be active.
Use another power outlet.
Confirm outlet is not controlled by a wall
switch.
No airflow from the device.
Device motor failure; OR
electronics failure
Contact the homecare provider’s
technical service department.
All LEDs flash two times
then pause, then flash
again
Device detects an operating
error
Hold down the power button until all
LEDs stops flashing.
Release the power button, the device will
reset and power up in Standby Mode.
Check hose, mask and any accessories in
the breathing circuit for air leaks and
proper fit.
If problems persist, contact your
homecare provider

Page 20
Device shuts down during
therapy
•
Improper seal of external
hardware (mask, tubing); or
use of external hardware past
recommended service life.
Verify all external equipment in
breathing circuit is seated correctly to
ensure a proper seal.
Check hose for leaks.
Follow mask manufacturer
recommendations for fit and seal.
Breathing circuit not assembled
correctly
Replace any external hardware
exceeding recommended service life.
If the problem persists, contact your
homecare provide.
All LEDs flash four times
then pause, then flash
again
Device detects an operating
error.
Hold down the power button until all
LEDs stops flashing. Release the power
button, the device will reset and power
up in Standby Mode. If the LEDs begin to
flash again, contact your homecare
provider.
Droplets of water in my
mask after therapy
Excess condensation from
breathing
Run drying mode after therapy.
Utilize in a less humid environment
(dehumidifier).
Bluetooth will not connect
Bluetooth disable (White LED
light)
Push Bluetooth button to enable (Blue
LED light).
App not downloaded or issue
with the app/phone function
Verify app is downloaded and installed,
the phone supports Bluetooth Low
Energy and has Bluetooth enabled.
Bluetooth will not connect
Bonded pairing information
stale
Follow instructions on the phone to
forget the Bluetooth connection. On the
device, hold down the BT button until
the BT LED flashes from blue to yellow
once (about 5 seconds).
SleepStart is not
functioning
Breathing circuit has excessive
leaks
Check hose, mask and any accessories in
the breathing circuit for air leaks and
proper fit.
User not breathing deep
enough to trigger SleepStart
Ensure deep breath is taken with mask
securely fitted or press Power button to
start therapy.
If the problem persists, call your
homecare provider’s technical service
department.
Bluetooth LED is red (not
flashing) all other LEDs are
off. Device does not
respond to button presses.
Device detects an error during
boot-up.
Disconnect power, wait at least 15
seconds, re-connect power.
If the problem persists, call your
homecare provider’s technical service
department.

Page 21
Precautions for Use
This section describes the warnings and cautions associated with use of the Transcend
Micro. The following guidelines apply to this document:
Warning Indicates the possibility of serious injury or death to yourself or others.
Caution! Indicates the possibility of minor injury or damage to the equipment.
NOTE: Indicates a tip, explanation, or feature to aid in understanding, or efficient
operation of the device.
Warnings
•Do not allow water to enter this device. Transcend Micro should not be exposed to
environmental conditions where the system may get wet.
•This device is not intended for life support.
•The Transcend Micro must be set up and adjusted by a trained provider before
being used for therapy ramp and pressure.
•The air temperature produced by this device can be as much as 10ºF higher than
the temperature of the room. Exercise caution if the room temperature is warmer
than 90ºF (32ºC).
•Do not block or otherwise obstruct the exhalation ports of the mask. Follow the
manufacturer’s instructions included with your mask.
•This equipment is not suitable for use with oxygen or in the presence of a
flammable anesthetic mixture with air or oxygen, or with nitrous oxide. Sources of
oxygen must be located more than 1 meter from the equipment to avoid the risk of
fire and burns.
•The Transcend Micro is only to be used with the supplied or recommended
accessories. Use of accessories not recommended may result in increased
electromagnetic emissions or decreased electromagnetic immunity of the PAP
system and may be potentially unsafe.
•The Transcend Micro is not defibrillation proof.
•Do not attempt to sterilize Transcend Micro.
•If the device is to be used by multiple patients a main flow bacteria filter should be
installed in-line between the device and the mask to prevent contamination. Only
use filters that are ISO 23328-1:2003 and ISO 23328-2:2002 approved.
•The device should be used only with masks and connectors recommended by
Transcend or a health care professional. A mask should not be used unless the
device is turned on and is properly delivering ramp or therapy pressure. The
exhalation port(s) associated with the mask should never be blocked. Explanation
of the Warning: The device is intended to be used with masks or connectors
specifically designed to have exhalation ports to allow continuous flow of air out of
the mask. When the device is in operation, air flow from the device flushes exhaled

Page 22
air out through the mask exhalation port. When the device is not operating,
however, fresh air will not be provided through the mask and exhaled air may be
rebreathed.
•Failure to use a mask or accessory that minimizes rebreathing of carbon dioxide or
permits spontaneous breathing can cause asphyxiation. Only use masks which
comply with ISO 17510.
•Do not position the equipment in bed. Covering breathing tubes with a blanket or
heating them can affect the quality of therapy or injure the user.
•To prevent disconnection of the tubing during use only Transcend supplied hoses or
hoses in compliance with ISO 5367 or ISO 80601-2-74 should be used.
•Strangulation hazard from power cord and air tube. These can become wrapped
around a neck and STRANGLE. Keep power cord and air tube more than 3 feet from
a baby’s crib and out of baby’s reach. Keep cord and tube out of children’s reach.
•Small parts are unlikely to be expelled from the Transcend Micro enclosure, but in
case of severe damage internal components may fragment and create a swallowing
or choking hazard if they get out of the enclosure.
•Use of this equipment adjacent to or stacked with other equipment should be
avoided because it could result in improper operation. If such use is necessary, this
equipment and the other equipment should be observed to verify that they are
operating normally.
•Use of accessories, transducers and cables other than those specified or provided
by the manufacturer of this equipment could result in increased electromagnetic
emissions or decreased electromagnetic immunity of this equipment and result in
improper operation.
•Portable RF communications equipment (including peripherals such as antenna
cables and external antennas) should be used no closer than 30 cm (12 inches) to
any part of the Micro device.
Cautions
•Federal law in the US restricts this device to the sale by, or on the order of, a
physician.
•Power the Transcend Micro only with the Transcend-supplied power supplies or
batteries.
•Discontinue use of the Transcend Micro and contact your physician if respiratory or
skin irritations occur.
•Do not introduce objects into the Transcend Micro air inlet or air outlet.
•Inspect the power supply for signs of wear or damage before each use. Replace the
power cord if necessary.
•Transcend recommends replacing the hose after every three months of use.
•To protect the environment, some parts and accessories of the Transcend Micro,
including optional batteries, must be disposed of in accordance with local
regulations.

Page 23
•The user should not touch the USB-C data port or the power supply connectors at
the same time while the device is providing therapy.
•The equipment must not be covered or positioned in such a way that adversely
affects the performance of the equipment, as it may also create a safety issue.
Examples of this would include:
oThe equipment must not be positioned in a bed.
oThe equipment should not be placed anywhere other than on a firm, flat
surface.
oDo not position in a location where pets or children can access equipment.
oDo not position near an open window or other location where dust, or pests
(insects) can affect equipment safety and/or performance.
oDo not position next to a curtain that blocks the flow of cooling air, thereby
causing the equipment to overheat.
oDo not block the air intake port, thereby interfering with therapy.

Page 24
Symbols
Ramp functionality
Drying Mode
Power
Caution
IP22
Protected against finger-sized objects and against dripping water when
tilted 15 degrees from specified orientation
Type BF Applied Part
Upper and lower temperature limits
Separate collection for electrical and electronic equipment per EC Directive
2002/96/EC. –Waste Electrical and Electronic Equipment (WEEE).
Consult instructions for use
Rx Only
Prescription only. U.S. federal law restricts this device to sale by or on the
order of a physician or properly licensed practitioner.
Precedes reference or item number
Batch code
Date of Manufacture
Manufacturer
Fragile, handle with care
Keep dry
Serial Number
Bluetooth
Regulatory Compliance Mark –indicates compliance with Australian
Radiocommunications Notice 2014 and Radiocommunications Act 1992
Wireless. FCC part 15 compliant. RTCA/DO-160 Section 21 Category M
compliant & FAA compliant.
Shipping and storage temperature limitation.
Shipping and storage relative humidity limitation.
UL Seal of Approval demonstrating quality, safety and professional
manufacturing of medical product.
