Epsilon Electronics H2-IN-1-BK User manual

1. Instruction of Buttons
Power on
Please read the instructions carefully
before using the product
Attention
With the headset off, tap and hold the touch-key for
3 seconds to turn on or When the earphone is removed
from the charging cabin, it is turned on automatically
Answering Tap the touch-key for either one of the earphones to
answer the phone when a call is incoming.
Hang up Tap the touch-key for either one of the earphones to end
the call during a call
When a call is incoming, tap and hold either one of the
earphones for 2 seconds to reject the incoming call.
Reject
Three-way
calling
In the phone call,there are new calls in,Double-Click the
touch-key ,retain the current call(A),and connect the
new phone calls(B);Double-Click the touch-key once
again,can switch between A/B phone calls. Short press
once to hang up the current call, it will cutover to another
call automatically
Voice
activation Triple tap either one of the earphones for voice activation
Play/Pause Tap either one of the earphones to pause or resume
playback when music playing
Next track Double tap the right earphone to skip to the next track
during music playback
When standby, hold down one earphone for 4 seconds,
and two earphones can be shut down at the same time
Power off
If pairing is not completed within 5 minutes,the headset
will auto power-off
Auto
Power-Off
2. Functional Operation
1)Dual ear pairing model
Using the earphone for the first time,Take out two earphones,the
earphone will automatically start up and establish a connection.or
operated manually when the headset off, tap and hold the R/L earphone
touch-key for 5 seconds at the same time until the red and blue light
flashes alternately, R/L earphone will automatically complete pairing,
The earphone has a voice telling you to team up successfully, (At this time,
one earphone red and blue light flash alternately, the other earphone blue
light flash slowly).Then open the bluetooth menu of the device and search
the bluetooth name "H2GO 2IN1" to connect.
※Note：After the first pairing, the next time when take out it from the
charging case,The earphone will automatically connect to the last
connected phone or Bluetooth device.
2)Single ear pairing model
Take out any one earphone to start up, the red and
blue lights flashing alternately.Or with the headset off,tap and hold the
touch-key for 5 seconds until the light flashes red and blue alternately,
Then open the bluetooth menu of the device and search the bluetooth
name to connect; now earphone can be used independently.
Tap the touch-key to
"H2GO 2IN1"
3. Indicator Light
Power on The blue LED flashes 3 times
Pairing mode The red and blue LED lights flash alternately
Connection
succeeded The blue LED flashes once every 6 seconds
Music playing The blue LED flashes once every 6 seconds
Calls coming The blue LED flashes quickly
During talking
Power off
The blue LED flashes once every 6 seconds
The red LED flashes 3 times then goes out
Earphone
Charging
The red LED stay on when on charging,
when charging is completed the red LED goes out
Low battery When the battery is low, the red led flashes warning,
and there is a sound prompt
4. Headset Accessories
5. Structural Component Description 6. Technical Specification
User Manual
H2-IN-1-BK
1.Please don't let the children play the product.
2.Please disassemble this product by yourself.
3.Please stay away from the signal interference place,to prevent TWS
headset signal connection instability.
don't
Volume + Tap and hold the right earphone for 2 seconds
to increase the volume when music playing
to release
Volume - Tap and hold the left earphone
to decrease the volume when music playing
for 2 seconds to release
Previous track Double tap the left earphone to skip to the previous track
during music playback
3)Speaker base
Hall switch
control
When the headset is turned on and connected, put it in the
speaker base, close the cover (hall switch works), and turn
on the speaker amplifier to play music. The audio of the
headset (left headset) can be switched to the speaker to
play. Open the cover and turn off the speaker amplifier.
Note: when the headset is off, put it in the speaker base,
only charge the headset, but not the speaker amplifier.
Charging
Charging for the battery case，the red light flashes，
Fully charged，the red light bright.
Put the R/L headset into the charging bin. The charging
case can charge the headset. The blue lights.
1) 1x Instruction
2) 1x Charging cable
3) 6x Ear buds(two are equipped on the headset)
Products NO.
Button mode
H2-IN-1-BK
Touch-Key
Bluetooth 5.0+EDR
A2DP，AVRCP ，HFP，HS P
2.40GHz~2.48GHz
16±15%Ω
91±3dB/1KHz
20Hz~20KHz
10m
5h（Maximum volume）
Support agreement
Transmission frequency
Headset speaker
Dimension
Talk time
Headset Charging time
Headset Battery capacity
Base Charging
5h
≤2h
3.7V/40mAh；Li-Poly mer
DC5V/500mA
3.7V/500mAh
3W
3-4h
92*46*35mm
Bluetooth Version
Sensitivity
Frequency response
Operation range
Headset Play time
Base Battery capacity
Speaker Rated power
Speaker box Play time
Microphone
Charging/audio contact point
Touch-key area
Indicator Light
Charging port
Speaker
4.Please don't put the product in water or fire.
5.High temperature and severe cold,the headset performance will be
degradation.
Indicator Light
尺寸：66*87.5mm

Federal Communications Commission (FCC) Statement. This device complies with part 15 of the
FCC Rules. Operation is subject to the following twoconditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation. Note: This equipment has been
tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide Reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one ormore of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by EPSILON
ELECTRONICS, INC may void the FCC authorization to operate this device.Note: The manufacturer
is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user’s authority to operate the equipment.
RF exposure statement:
This device complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. The device is installed and operated without restriction.
