Epson EH-LS10000 User manual

Pro Home Cinema
EH-LS10000

The ultimate home theater demands the ultimate projector. Bring a state-of-the-art movie theater experience to
your home with Epson’s groundbreaking Pro Home Cinema LS10000 projector. Featuring revolutionary 3LCD
Reflective laser projection technology, this high-definition projector delivers phenomenal image quality and
colour brightness that elevates any screening to an enthralling cinematic experience.
PREPARE TO BE AMAZED
1
The ultimate home theater demands the ultimate projector. Bring a state-of-the-art movie theater experience to
your home with Epson’s groundbreaking Pro Home Cinema LS10000 projector. Featuring revolutionary 3LCD
Reflective laser projection technology, this high-definition projector delivers phenomenal image quality and
colour brightness that elevates any screening to an enthralling cinematic experience.
PREPARE TO BE AMAZED
1

Combining 3LCD Reflective panels and a dual laser light source, LS10000 delivers the blackest blacks and bright,
true-to-life colors with one of the widest color gamuts in the industry. With 4K Enhancement Technology*, all of the subtleties
that the filmmakers originally captured suddenly become visible in beautiful, crisp clarity. It’s not just projection — it’s
Epson home theater perfection.
* 4K Enhance Technology shifts each pixel diagonally by 0.5 pixels to double the resolution to
3840 x 2160 and surpass Full HD image quality. Resolution is 1920 x 1080 in 3D mode.
EPSON PRO HOME CINEMA LIKE YOU’VE NEVER SEEN BEFORE
2
4K Enhancement Technology
3LCD Reflective Panels Dual Laser Light Source
Combining 3LCD Reflective panels and a dual laser light source, LS10000 delivers the blackest blacks and bright,
true-to-life colors with one of the widest color gamuts in the industry. With 4K Enhancement Technology*, all of the subtleties
that the filmmakers originally captured suddenly become visible in beautiful, crisp clarity. It’s not just projection — it’s
Epson home theater perfection.
* 4K Enhance Technology shifts each pixel diagonally by 0.5 pixels to double the resolution to
3840 x 2160 and surpass Full HD image quality. Resolution is 1920 x 1080 in 3D mode.
EPSON PRO HOME CINEMA LIKE YOU’VE NEVER SEEN BEFORE
2
4K Enhancement Technology
3LCD Reflective Panels Dual Laser Light Source

AT LAST, LASER PROJECTION COMES HOME
Considering the advantages offered by a laser system, Epson’s decision to use a laser light source for the LS10000 was an obvious
choice. The laser light engine’s long lifespan of up to 30,000 hours* provides virtually worry-free operation. And there’s no waiting for
the projector to warmup or cool down — the projector reaches maximum brightness and turns off almost immediately. Plus, high-speed
contrast control ensures both bright and dark scenes look their best.
WIDE COLOUR GAMUT
Enjoy brilliant, colour-rich performance. The full sRGB colour gamut is
visible even in the brightest mode. And the DCI colour gamut — the
digital cinema standard — is also achievable.
DUAL LASER LIGHT SOURCE
The dual blue laser diode illumination system — one for red and
green, the other for blue — ensures balanced, high-quality images.
3
* 30,000 hours is the estimated projector life when used in ECO mode.
Exceptional contrast for richer blacks and brighter whites
AT LAST, LASER PROJECTION COMES HOME
Considering the advantages offered by a laser system, Epson’s decision to use a laser light source for the LS10000 was an obvious
choice. The laser light engine’s long lifespan of up to 30,000 hours* provides virtually worry-free operation. And there’s no waiting for
the projector to warmup or cool down — the projector reaches maximum brightness and turns off almost immediately. Plus, high-speed
contrast control ensures both bright and dark scenes look their best.
WIDE COLOUR GAMUT
Enjoy brilliant, colour-rich performance. The full sRGB colour gamut is
visible even in the brightest mode. And the DCI colour gamut — the
digital cinema standard — is also achievable.
DUAL LASER LIGHT SOURCE
The dual blue laser diode illumination system — one for red and
green, the other for blue — ensures balanced, high-quality images.
3
* 30,000 hours is the estimated projector life when used in ECO mode.
Exceptional contrast for richer blacks and brighter whites

ABSOLUTE BLACK CONTRAST RATIO 3LCD REFLECTIVE PANELS
Experience incredible, unprecedented black levels —
with zero lumens during Absolute Black scenes.
Light reflection reduces and corrects the variation of
polarization, delivering rich, deep blacks.
NOW PLAYING: 3LCD REFLECTIVE TECHNOLOGY WITH ABSOLUTE BLACK
For decades, 3LCD projectors have been praised within the industry for delivering superior colour and gradation. Now, with Epson’s innovative
3LCD Reflective system, you get remarkably high contrast as well. Featuring advanced liquid crystal on quartz technology, this 3LCD Reflective
projector boasts exceptional performance, including an improved pixel density and increased aperture ratio for smoother, film-like pictures.
Ultra high contrast Zero lumens in Full Black
REFLECTIVE
4
* Color brightness ( color light output ) and white brightness ( white light output ) will vary depending on usage conditions.
Increased aperture ratio delivers smoother pictures
ABSOLUTE BLACK CONTRAST RATIO 3LCD REFLECTIVE PANELS
Experience incredible, unprecedented black levels —
with zero lumens during Absolute Black scenes.
Light reflection reduces and corrects the variation of
polarization, delivering rich, deep blacks.
NOW PLAYING: 3LCD REFLECTIVE TECHNOLOGY WITH ABSOLUTE BLACK
For decades, 3LCD projectors have been praised within the industry for delivering superior colour and gradation. Now, with Epson’s innovative
3LCD Reflective system, you get remarkably high contrast as well. Featuring advanced liquid crystal on quartz technology, this 3LCD Reflective
projector boasts exceptional performance, including an improved pixel density and increased aperture ratio for smoother, film-like pictures.
Up to 1,500 Iumens*Ultra high contrast Zero lumens in Full Black
REFLECTIVE
4
* Color brightness ( color light output ) and white brightness ( white light output ) will vary depending on usage conditions.
Increased aperture ratio delivers smoother pictures

EXPERIENCE STUNNING 4K ENHANCEMENT
Discover a whole new way to watch movies — the way filmmakers intended. Epson’s 4K Enhancement Technology delivers astonishing picture
quality. Now, every subtle intricacy is captured — even your most-loved films will offer something new. Plus, Epson’s Super-resolution with
Detail Enhancement Technology refines surface details for true-to-life images that pop off the screen. Users can adjust levels of sharpness
and detail enhancement for optimal viewing. This isn’t just a new way to watch movies — it’s the best way.
4K Enhancement makes standard and HD content come alive. From the feathers in a plume to freckles on a nose, you’ll see every incredible detail.
4K EnhancementFull HD
Epson’s revolutionary 4K Enhancement
Technology shifts each pixel diagonally by 0.5
pixels for twice the vertical and horizontal
resolution.
Enjoy unbelievable sharpness and clarity, even
closer to the screen. 4K Enhancement delivers
immersive images.
5
4K ENHANCEMENT TECHNOLOGY
PIXEL SCALING FRONT-ROW SEATS TO THE ACTION
EXPERIENCE STUNNING 4K ENHANCEMENT
Discover a whole new way to watch movies — the way filmmakers intended. Epson’s 4K Enhancement Technology delivers astonishing picture
quality. Now, every subtle intricacy is captured — even your most-loved films will offer something new. Plus, Epson’s Super-resolution with
Detail Enhancement Technology refines surface details for true-to-life images that pop off the screen. Users can adjust levels of sharpness
and detail enhancement for optimal viewing. This isn’t just a new way to watch movies — it’s the best way.
4K Enhancement makes standard and HD content come alive. From the feathers in a plume to freckles on a nose, you’ll see every incredible detail.
4K EnhancementFull HD
Epson’s revolutionary 4K Enhancement
Technology shifts each pixel diagonally by 0.5
pixels for twice the vertical and horizontal
resolution.
Enjoy unbelievable sharpness and clarity, even
closer to the screen. 4K Enhancement delivers
immersive images.
5
4K ENHANCEMENT TECHNOLOGY
PIXEL SCALING FRONT-ROW SEATS TO THE ACTION

WITNESS HOME CINEMA IN A WHOLE NEW LIGHT
When it came to designing the LS10000 projector, Epson’s engineers focused on a singular goal: achieving the best possible image
quality, for an unbelievable home theater experience. Unlike laser projectors that are intended for business or commercial settings —
where brightness is the priority — this projector was designed to deliver higher contrast and more natural colour expression. The result is
projector that is capable of Absolute Black like you’ve never seen, as well as smooth, dark gradations and finely-tuned colours.
Choose from an array of colour modes for an optimized viewing
experience. Colour modes include Dynamic, B&W Cinema,
3D Cinema, 3D THX and more.
The laser light source means the correct colour gamut is fully
realized at all times.
Expect accurate picture quality and
exceptional performance.
Exceptional video performance
with ISF Calibration tools.
Enjoy fast, reliable projection from a constant beam of light.
The laser light source delivers images that are more stable.
6
COLOUR MODES RELIABLE PERFORMANCE
FINELY-TUNED COLOUR
THX
®CERTIFICATION ISF ®CALIBRATION
WITNESS HOME CINEMA IN A WHOLE NEW LIGHT
When it came to designing the LS10000 projector, Epson’s engineers focused on a singular goal: achieving the best possible image
quality, for an unbelievable home theater experience. Unlike laser projectors that are intended for business or commercial settings —
where brightness is the priority — this projector was designed to deliver higher contrast and more natural colour expression. The result is
projector that is capable of Absolute Black like you’ve never seen, as well as smooth, dark gradations and finely-tuned colours.
Choose from an array of colour modes for an optimized viewing
experience. Colour modes include Dynamic, B&W Cinema,
3D Cinema, 3D THX and more.
The laser light source means the correct colour gamut is fully
realized at all times.
Expect accurate picture quality and
exceptional performance.
Exceptional video performance
with ISF Calibration tools.
Enjoy fast, reliable projection from a constant beam of light.
The laser light source delivers images that are more stable.
6
COLOUR MODES RELIABLE PERFORMANCE
FINELY-TUNED COLOUR
THX
®CERTIFICATION ISF ®CALIBRATION

PICTURE-PERFECT, PROVEN 2D & 3D TECHNOLOGIES
Whether you’re watching a cinema classic or the latest 3D blockbuster, the advanced projection features on the LS10000 deliver standout
performances. These innovations include Epson’s unique Super-resolution with Detail Enhancement Technology, exceptional frame interpolation
capabilities, as well as powerful Bright 3D Drive projection. Experience a new standard in home entertainment.
TOTAL RECALL: POWERED LENS POSITION MEMORY
Fast, quiet and precise, the LS10000 allows you to preset up to 10 positions for zoom, focus and lens shift for both standard projection and wide
cinema ratios. Project 2.40, 2.35, 1.85 and 1.78 aspect ratios on the same screen without an anamorphic lens — and no downtime when switching
between ratios. Watch movies on a grander scale at the touch of a button, without any disruptive black bars.
SUPER-RESOLUTION WITH DETAIL ENHANCEMENT
1 Right
1 Right
1 Right
1 Right 1 Right
1 Right
1 Right
1 Right
1 Left
1 Left
1 Left
1 Left
1 Left
1 Left
1 Left 1 Left
blackout blackout blackout blackout
1 Left
1 Righ
t
1 Righ
t
1 Righ
t
1 Righ
t
1 Left
1 Left
1 Left
blackout blackout blackout blackout
Super-resolution defines edges for standard and HD content, while Detail
Enhancement refines surface detail for true-to-life images.
FRAME INTERPOLATION
Frame interpolation technology inserts multiple new frames between the
original ones, so motion appears smoother, sharper and more realistic.
BRIGHT 3D DRIVE
Bright 3D Drive Technology doubles the image refresh rate from 240 Hz to
480 Hz and reduces the blackout time of 3D glasses to provide greater
brightness when viewing 3D content.
2.40:1 movie on a 16:9 screen
16:9 2.40:1
2.40:1 movie on a 2.40:1 screen
7
Both lenses are closed at the
same time, lowering 3D luminance.
480 Hz drive shortens the time both lenses
are closed, leading to brighter 3D images.
1/240 sec 240 Hz Drive 1/480 sec 480 Hz Drive
TIME TIME
PICTURE-PERFECT, PROVEN 2D & 3D TECHNOLOGIES
Whether you’re watching a cinema classic or the latest 3D blockbuster, the advanced projection features on the LS10000 deliver standout
performances. These innovations include Epson’s unique Super-resolution with Detail Enhancement Technology, exceptional frame interpolation
capabilities, as well as powerful Bright 3D Drive projection. Experience a new standard in home entertainment.
TOTAL RECALL: POWERED LENS POSITION MEMORY
Fast, quiet and precise, the LS10000 allows you to preset up to 10 positions for zoom, focus and lens shift for both standard projection and wide
cinema ratios. Project 2.40, 2.35, 1.85 and 1.78 aspect ratios on the same screen without an anamorphic lens — and no downtime when switching
between ratios. Watch movies on a grander scale at the touch of a button, without any disruptive black bars.
SUPER-RESOLUTION WITH DETAIL ENHANCEMENT
1 Right
1 Right
1 Left
1 Left
1 Left 1 Left
blackout
1 Left
1 Righ
t
1 Righ
t
1 Righ
t
1 Righ
t
1 Left
1 Left
1 Left
blackout blackout blackout blackout
Super-resolution defines edges for standard and HD content, while Detail
Enhancement refines surface detail for true-to-life images.
FRAME INTERPOLATION
Frame interpolation technology inserts multiple new frames between the
original ones, so motion appears smoother, sharper and more realistic.
BRIGHT 3D DRIVE
Bright 3D Drive Technology doubles the image refresh rate from 240 Hz to
480 Hz and reduces the blackout time of 3D glasses to provide greater
brightness when viewing 3D content.
2.40:1 movie on a 16:9 screen
16:9
2.40:1 movie on a 2.40:1 screen
7
Both lenses are closed at the
same time, lowering 3D luminance.
480 Hz drive shortens the time both lenses
are closed, leading to brighter 3D images.
1/240 sec 240 Hz Drive 1/480 sec 480 Hz Drive
TIME

POWERFUL INNOVATION IN AN ELEGANT PACKAGE
Elegant body. Bold, glamorous curves. Textured black surface. These features are all
part of a premium product that’s packed with innovation and power. Every inch of this
projector has been considered. There’s no wasted space — and no exposed cables.
Even the dark, matte finish of the LS10000 is itself an innovation: It’s not just beautiful
to look at, but it absorbs light, too.
EXTRAORDINARY INSTALLATION
FLEXIBILITY :MOTORIZED LENS SHIFT
In addition to added reliability and amazing colour performance,
the LS10000 has a wide-range motorized lens shift providing a high
level of installation freedom. The LS10000 has an incredible range
of up to 90 percent on the vertical axis and up to 40 percent on
the horizontal axis. Users can operate the lens shift functions using
the remote control, the projector control panel, or control
commands. So, adjustments can be made easily even when the
projector is suspended from the ceiling.
No exposed cables
Bold curves Light-absorbent black finish
Packed with innovation
8
POWERFUL INNOVATION IN AN ELEGANT PACKAGE
Elegant body. Bold, glamorous curves. Textured black surface. These features are all
part of a premium product that’s packed with innovation and power. Every inch of this
projector has been considered. There’s no wasted space — and no exposed cables.
Even the dark, matte finish of the LS10000 is itself an innovation: It’s not just beautiful
to look at, but it absorbs light, too.
EXTRAORDINARY INSTALLATION
FLEXIBILITY :MOTORIZED LENS SHIFT
In addition to added reliability and amazing colour performance,
the LS10000 has a wide-range motorized lens shift providing a high
level of installation freedom. The LS10000 has an incredible range
of up to 90 percent on the vertical axis and up to 40 percent on
the horizontal axis. Users can operate the lens shift functions using
the remote control, the projector control panel, or control
commands. So, adjustments can be made easily even when the
projector is suspended from the ceiling.
No exposed cables
Bold curves Light-absorbent black finish
Packed with innovation
8

A PERFORMER THAT’S THE STRONG, SILENT TYPE
When it comes to home cinema, you want to focus on what’s in front of you — and nothing else. That’s the idea behind the innovative, efficient
cooling system of the LS10000. With noise levels as low as 19 dB, this is among the quietest projectors in the industry. It’s time to enjoy engaging
cinema without distraction — all the better for those moments when the picture takes your breath away.
9
COOLING EFFICIENCY
A whisper-quiet fan that’s so
silent, you won’t even notice
there’s a projector in the room.
PREMIUM COMPONENTS
The projector features
thermal-conductive copper
piping to help dissipate heat.
A PERFORMER THAT’S THE STRONG, SILENT TYPE
When it comes to home cinema, you want to focus on what’s in front of you — and nothing else. That’s the idea behind the innovative, efficient
cooling system of the LS10000. With noise levels as low as 19 dB, this is among the quietest projectors in the industry. It’s time to enjoy engaging
cinema without distraction — all the better for those moments when the picture takes your breath away.
9
COOLING EFFICIENCY
A whisper-quiet fan that’s so
silent, you won’t even notice
there’s a projector in the room.
PREMIUM COMPONENTS
The projector features
thermal-conductive copper
piping to help dissipate heat.

PRACTICAL FUNCTIONALITY, CONVENIENT CONNECTIVITY
Take the trouble out of troubleshooting with enriched network functionality and convenient hands-free features that make servicing the projector easier
than ever before. Dealer representatives can securely and remotely monitor the projector’s status to address issues that may arise. There is even an
email notification function that can send status alerts to a designated recipient.
DUAL HDMI CONNECTIVITY
Simultaneously connect up to two different
HDMI devices directly to the projector.
( Includes one HDMI HDCP2.2 port )
LAN/ETHERNET PORT
Provides automatic email notifications
should problems arise.
Easily integrate the projector
with home automation systems
through the RS-232c port.
HOME AUTOMATION
INTEGRATION
10
PRACTICAL FUNCTIONALITY, CONVENIENT CONNECTIVITY
Take the trouble out of troubleshooting with enriched network functionality and convenient hands-free features that make servicing the projector easier
than ever before. Dealer representatives can securely and remotely monitor the projector’s status to address issues that may arise. There is even an
email notification function that can send status alerts to a designated recipient.
DUAL HDMI CONNECTIVITY
Simultaneously connect up to two different
HDMI devices directly to the projector.
( Includes one HDMI HDCP2.2 port )
LAN/ETHERNET PORT
Provides automatic email notifications
should problems arise.
Easily integrate the projector
with home automation systems
through the RS-232c port.
HOME AUTOMATION
INTEGRATION
10

APR15-01-PROJECTOR
URL: www.epson.com.hk
HK Sales Hotline : [phone]
HK Technical Hotline : [phone]
Macau Hotline : [phone]
Epson Hong Kong Limited
Unit 715-723, 7/F Trade Square, 681 Cheung Sha Wan Road,Cheung Sha Wan, Kowloon, Hong Kong
* Please call our sales hotline for demonstration at our showroom.
Epson Authorized Collection Point
( Kowloon West )
Room 1006-1008, Park-In Commercial Centre,
56 Dundas Street, Mong Kok, Kowloon, Hong Kong
Room 1003, Block B, Sea View Estate,
4-6 Watson Road, North Point, Hong Kong
Epson Authorized Collection Point
( Hong Kong Island )
Unit 901, 9/F, Westin Centre, 26 Hung To Road,
Kwun Tong, Kowloon, Hong Kong
Epson Authorized Customer Service Centre
( Kowloon East )
Unit 7, 21/F, CCT Telecom Building,
11 Wo Shing Street, Fo Tan, New Territories
Epson Authorized Collection Point
( New Territories )
Projection System
Projection Methods
Driving Method
Projected Output
Pixel Number
Color Brightness (Color Light Output)
White Brightness (White Light Output)
Aspect Ratio
Native Resolution
Laser Type
Light Source Life
Size (projected distance)
Contrast Ratio
Projection Lens Type
F-Number
Focal Length
Zoom Ratio
Powered Lens Shift
Lens Cover
Lens Iris
Lens Position
Memory Positions
Display Performance
Aspect Mode
Super-resolution / 4K Enhancement
Frame Interpolation
Color Modes
Input Signal HDMI
Terminal Inputs
Computer Compatibility
Fan Noise
Power Supply Voltage
Power Consumption
Dimensions Exclude Feet (W x H x D)
Weight
Supplied Accessories
SPECIFICATIONS EH-LS10000
* Caution : Class 2 laser product. Do not stare into the beam.
3LCD Reective, 3-chip technology Poly-silicon TFT active matrix
Front / Rear / Ceiling mount
Epson Poly-silicon TFT active matrix, 0.74-inch wide panel Reective HTPS
HD, 2D, 3D, 1080p
2,073,600 dots (1920 x 1080) x 3
1500 lumens
1500 lumens
Native 16:9 widescreen (4:3 resize), compatible with 4:3 and 2.35:1 video formats with Normal, Full or Zoom Modes
Native 1080p (1920 x 1080)
Laser Diode 41.9 mW (Output)
Up to 30,000 hours (ECO Mode)
100" diagonal (wide: 9.3' – tele: 19.8')
Absolute Black (Full White 1500 lm / Full Black 0 lm)
Powered optical zoom / Powered focus
2.5 – 3.7
21.3 mm – 44.7 mm
1 – 2.1
Vertical: 90% max (up and down with horizontal centered)
Horizontal: 40% max (left and right with vertical centered)
Powered, slide lens shutter
Fine adjustments
The following 3 items are saved in memory: Lens Shift Position, Zoom Position, Focus Position
10 (Memory 1 – 10)
1920 x 1080 native 1080p; HD, 2D, 3D, 2D to 3D conversion
Auto / Normal / Full / Zoom / Anamorphic Wide / Horizontal Squeeze
O / 1 / 2 / 3 / 4 / 5 / 4K-1 / 4K-2 / 4K-3 / 4K-4 / 4K-5
O / Low / Normal / High (2D and 3D Mode)
Dynamic, Living Room, Natural, THX, Cinema, B&W Cinema, Adobe RGB, Digital Cinema, 3D Dynamic, 3D Cinema, 3D THX
480i / 576i / 480p / 576p / 720p / 1080i / 1080p / 4K x 2K
2 HDMI (1 HDMI HDCP2.2), 1 RS-232c, 1 RCA (composite),
3 RCA (component), 1 VGA D-sub 15 pin (computer input),
1 Wired LAN (RJ45, 100 Mbps) for command and control only
PC, Mac®
19 dB (4K Enhancement: O)
100 – 240 VAC 10%, 50/60 Hz
100 – 120 VAC, Laser on 459 W, Laser on (ECO) 267 W Standby Mode, Communication: On 2.8 W / O 0.29 W
550 x 225 x 553 mm
Approx. 39.7 lbs / 18kg
Power cable (3m), Two pairs of 3D glasses (RF Type), 3D glasses charger cable, Two HDMI cable clamps,
Remote control with batteries, User's manual set, Cable cover
OPTIONAL ACCESSORIES
ELPAF39 Air Filter
ELPGS03 3D Glasses (RF Type)
ELPAC01 3D Glasses Charger
