Epson EH-TW6000W User manual

User's Guide

Organization of the Guide and Notations in the Guide
1
Using Each Guide
The guides for this projector are organized as shown below.
Safety Instructions/Support and Service Guide
Contains information on using the projector safely, as well as a support and service guide,
troubleshooting check lists, and so on. Make sure you read this guide before using the pro-
jector.
User's Guide (this guide)
Contains information on setting up and basic operations before using the projector, using
the Configuration menu, and handling problems and performing routine maintenance.
Quick Start Guide
Contains information on the procedures for setting up the projector. Read this first.
3D Glasses User's Guide
Contains information on handling the 3D Glasses and warnings and so on.
WirelessHD Transmitter User's Guide
Contains information on handling the WirelessHD Transmitter and warnings and so on.

Organization of the Guide and Notations in the Guide
2
Notations Used in This Guide
Safety Indications
The documentation and the projector use graphical symbols to show how to use the projector safely.
The following shows the symbols and their meanings. Please understand and respect these caution symbols
in order to avoid injury to persons or property.
Warning
This symbol indicates information that, if ignored, could possibly result in personal injury or even death
due to incorrect handling.
Caution
This symbol indicates information that, if ignored, could possibly result in personal injury or physical
damage due to incorrect handling.
General Information Indications
Attention
Indicates procedures which may result in damage or malfunctions to occur.
c
Indicates additional information and points which may be useful to know regarding a topic.
sIndicates a page where detailed information regarding a topic can be found.
Menu Name Indicates Configuration menu items.
Example: Image - Color Mode
Button Name Indicates the buttons on the remote control or the control panel.
Example: button
About the Use of "This Product" or "This Projector"
As well as the main projector unit, supplied items or optional extras may be referred to using the phrase "this
product" or "this projector".

Organization of the Guide and Notations in the Guide
3
Checking Supplied Items
See the following list to check the supplied items.
If anything is missing or damaged, contact the store where you purchased the projector.
Projector Remote control s p.13
Power cable AA size alkaline batteries (x2) s p.21
3D Glasses Pack s p.41
See the documentation supplied with the 3D Glasses
for more information on the 3D Glasses pack.
WirelessHD Transmitter Pack
(EH-TW6000W only)
s p.53
The HDMI cable is two meters long.
Guides s p.1 Cable clamps (x2) s p.11

Contents
4
Organization of the Guide and
Notations in the Guide
UsingEachGuide ..................... 1
NotationsUsedinThisGuide ........... 2
SafetyIndications .......................2
GeneralInformationIndications.............2
AbouttheUse of "ThisProduct"or "This Projector"
..................................... 2
CheckingSuppliedItems .............. 3
Introduction
Projector Features .................... 7
Dynamic3DDisplay ...................... 7
Selecting Modes to Match what you are
Watching(ColorMode) ................... 7
AbsoluteColorAdjustment................7
Conforms to Wireless Transmissions for the
WirelessHD Standards (EH-TW6000W only) . . . . . 8
OtherUsefulFunctions .................... 8
PartNamesandFunctions ............. 9
Front/Top ............................. 9
ControlPanel .......................... 10
Rear ................................ 11
Base ................................ 12
RemoteControl ........................ 13
Appearance ......................... 15
Preparing
SettingUp .......................... 16
VariousProjectionMethods...............16
AdjustingtheProjectionSize ..............17
ConnectingtoDevices ............... 18
ConnectingtoVideoEquipment ............ 18
ConnectingtoaComputer ................ 19
ConnectinganHDMICableClamp ........... 19
ConnectingtoExternalDevices ............. 19
ConnectingUSBdevices ................ 19
Connecting WirelessHD devices (EH-
TW6000Wonly) ...................... 20
PreparingtheRemoteControl ........ 21
InstallingtheRemoteControlBatteries.......21
RemoteControlOperatingRange ........... 21
Operatingrange(lefttoright) ............ 21
Operatingrange(toptobottom) .......... 21
Basic Operations
StartingandEndingProjection ....... 22
Turning on the Projector and Projecting . . . . . . 22
IftheTargetImageisnotProjected .......... 23
TurningoffthePower .................... 23
AdjustingtheProjectionScreen ....... 25
DisplayingtheTestPattern ................ 25
FocusAdjustment ...................... 25
Adjusting the Projection Size (Zoom
Adjustment) ..........................25
AdjustingtheProjector'sTilt ............... 26
CorrectingKeystoneDistortion ............. 26
Correct automatically (Auto V-Keystone) . . . . 26
Correct manually (H-Keystone adjuster) . . . . . 26
Correctmanually(H/V-Keystone) .......... 27
AdjustingtheVolume .................... 28
Hiding the Image and Sound Temporarily (A/V
Mute) ............................... 28
Adjusting the Image
BasicSettingsforImage .............. 29
Selecting the Projection Quality (Color Mode)
.................................... 29
Adjusting the Image's Aspect Ratio (Aspect) . . . . 30
AbsoluteColorAdjustments .......... 32
Adjusting Hue, Saturation, and Brightness . . . . . 32
AdjustingtheGamma ...................33
Selectandadjustthecorrectionvalue......33
Adjustwhileviewingtheimage..........33
Adjust using the gamma adjustment graph
.................................. 34
AdjustingtheRGB(Offset/Gain)............34
Abs.ColorTemp. ....................... 34
SkinTone ............................ 35
DetailedImageAdjustments .......... 36
AdjustingtheSharpness .................. 36

Contents
5
SettingAutoIris ........................ 36
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 38
SavingFunction ........................ 38
SavingaMemory ....................... 38
LoadingaMemory ...................... 39
ErasingaMemory ......................39
RenamingaMemory .................... 39
Useful Functions
Enjoying3DImages .................. 41
Watching3DImages ....................41
Using3DGlasses ..................... 41
Projecting3Dimages .................. 42
ViewingAreafor3DImages ............... 43
WarningsRegardingViewing3DImages......43
Changing Between Two Types of
Images .............................. 47
SplitScreen ........................... 47
ProjectingonaSplitScreen...............47
Startingsplitscreendisplay.............47
Changingthesplitscreensettings ......... 48
HDMILink ........................... 49
HDMILinkFunction ..................... 49
HDMILinkSettings ...................... 49
EnablingHDMILink ................... 49
Checkingforconnecteddevices..........50
Playing Back Image Data (Slideshow)
...................................... 51
CompatibleData ....................... 51
PlayingaSlideshow ..................... 51
Display Settings for Image Files and Slideshow
OperationSettings ...................... 52
Connecting with WirelessHD (EH-
TW6000WOnly) ..................... 53
Installing and Connecting the WirelessHD
Transmitter ........................... 53
WirelessHDSettings ..................... 53
Changingthesource ..................53
Reconnecting ....................... 54
WirelessHDsettingsmenu ..............54
WirelessHDTransmissionRange ............ 55
Configuration Menu
ConfigurationMenuFunctions ........ 56
ConfigurationMenuOperations ............56
ConfigurationMenuTable ................57
Imagemenu ........................ 57
Signalmenu ........................ 58
Settingsmenu ....................... 61
Extendedmenu ...................... 63
Memorymenu ....................... 64
Infomenu .......................... 65
Resetmenu ......................... 65
SplitScreenmenu .................... 66
Troubleshooting
Problem Solving . .................... 67
ReadingtheIndicators ................... 67
Indicatorstatusduringanerror/warning....67
Indicator status during normal operation . . . . 68
WhentheIndicatorsProvideNoHelp........69
Checktheproblem .................... 69
Problemsrelatingtoimages ............. 70
Problemswhenprojectionstarts .......... 74
Problemswiththeremotecontrol ......... 74
Problemswith3D ....................74
ProblemswithHDMI .................. 75
Problems with WirelessHD (EH-TW6000W
only) .............................. 75
ProblemswithUSBstoragedevices ........ 76
Maintenance
Maintenance ........................ 77
CleaningtheParts ...................... 77
Cleaningtheairfilter .................. 77
Cleaningthemainunit ................. 78
Cleaningthelens ..................... 79
Cleaningthe3DGlasses ................ 79
ReplacementPeriodsforConsumables.......79
Airfilterreplacementperiod ............. 79

Contents
6
Lampreplacementperiod..............79
ReplacingConsumables .................. 80
Replacingtheairfilter ................. 80
Replacingthelamp ................... 81
Resettinglamphours .................. 82
Appendix
Optional Accessories and
Consumables ........................ 84
OptionalItems ......................... 84
Consumables .......................... 84
SupportedResolutions ............... 85
ComponentVideo ...................... 85
CompositeVideo ....................... 85
ComputerSignals(AnalogRGB)............85
HDMI1/HDMI2InputSignal ................ 86
3DInputSignal ........................ 86
WirelessHDInputSignal .................. 86
Specifications ....................... 87
Glossary ............................ 90
GeneralNotes ....................... 91
GeneralNotice ......................... 91

Introduction
7
Projector Features
Dynamic 3D Display
Enjoy 3D contents on Blu-ray and images filmed with a 3D camera through a stunning projection display.
s p.41
You need 3D Glasses to view 3D images. s p.41
Selecting Modes to Match what you are Watching (Color Mode)
By simply selecting the Color Mode, you can project the optimum image to suit your surroundings. s p.29
Setting Example
Living Room
For use in a bright room
Cinema
For movies and concerts in a dark room
Absolute Color Adjustment
As well as using Color Mode, you can also adjust the absolute color temperature of the image and skin tones
to suit your taste.
s p.34
What's more, you can obtain colors that match the image and achieve the colors you want through a
combination of gamma adjustment, RGB offset or gain adjustment for each color, and hue, saturation, and
brightness adjustment for each RGBCMY color.
s p.32

Introduction
8
Conforms to Wireless Transmissions for the WirelessHD Standards (EH-TW6000W
only)
The projector can wirelessly receive data and control signals for images and audio from WirelessHD
compatible devices. Because devices do not need to be connected directly to the projector via a cable, they
can be setup wherever you like.
s p.53
Projector Transmitter Player
Other Useful Functions
In addition, the following useful functions are provided.
•The remote control contains a backlight function allowing for easy use even in dark rooms. Operations are also
simplified by only pressing the button. sp.13
•Audio is played back via the built-in speaker eliminating the need for external speakers. The Inverse Audio function
also allows you to switch the left and right audio streams when the projector is suspended from a ceiling. sp.61
•You can view slideshows by simply connecting a USB device to the projector. When a digital camera is connected,
you can view the photos on the camera using Slideshow. sp.51
•The H-Keystone slider allows you to quickly correct keystone distortion when the projector cannot be setup directly
in front of the screen. Because it is a slider, you can make corrections intuitively. sp.26

Introduction
9
Part Names and Functions
Front/Top
Name Function
aLamp cover
Open when replacing the projector's lamp. sp.81
bAir exhaust vent
Exhaust vent for air used to cool the projector internally.
Caution
While projecting, do not put your face or hands near the air exhaust vent,
and do not place objects that may become warped or damaged by heat near
the vent.
cRemote receiver
Receives signals from the remote control. sp.21
dProjector's lens
Images are projected from here.
eLens cover
Install when not using the projector to protect the lens from being scratched or
soiled. sp.22
fAir intake vent
Intake vent for air used to cool the projector internally.
gFront adjustable foot
When setup on a surface such as a table, extend the foot to adjust the horizontal
tilt. sp.26
hAir filter cover
When cleaning or replacing the air filter, open this cover and remove the air filter.
sp.77,p.80
iFocus ring
Adjusts the image focus. sp.25
jZoom ring
Adjusts the image size. sp.25
kH-Keystone slider
Performs horizontal keystone correction. sp.26
lControl panel
Control panel on the projector. sp.10

Introduction
10
Control Panel
Buttons/Indicators Function
a
Brightness sensor
Detects the brightness of the room. When Color Mode is set to "Auto", the
optimum image quality is set according to the brightness detected by the sen-
sor. sp.29
b
Operation indicator
Flashes to indicate warm-up in progress or cool-down in progress. Shows the
projector's status through a combination of other indicators lit and flashing.
sp.67
c
Turns the projector power on or off. sp.22
Lit when the projector is on. sp.68
d
Changes to the image from each input port. sp.23
e
Flashes orange when it is time to replace the lamp. Shows the projector's errors
through a combination of other indicators lit and flashing. sp.67
f
Flashes orange if the internal temperature is too high. Shows the projector's
errors through a combination of other indicators lit and flashing. sp.67
g
Select the adjustment value for the volume and for menu items. sp.28
Performs horizontal keystone correction when the Keystone screen is dis-
played. sp.27
h
Select the adjustment value for the keystone correction and for menu items.
sp.27
i
Return to the previous menu level when a menu is displayed. sp.56
j
Select functions and settings when a menu is displayed. sp.56
k
Displays and closes the configuration menu.
On the configuration menu, you can make adjustments and settings for Signal,
Image, Input Signal, and so on. sp.56

Introduction
11
Rear
Name Function
aSpeaker
The projector's built-in speaker. Outputs audio.
Set Inverse Audio to On to use the built-in speaker when the projector is
suspended from a ceiling. sSettings - Audio - Inverse Audio p.61
bPower inlet
Connects the power cable. sp.22
cRemote receiver
Receives signals from the remote control. sp.21
dExternal 3D IR port
Connects the optional External 3D IR emitter. sp.43
eRS-232C port
When controlling the projector, connect the projector to a computer with an
RS-232C cable. This port is for control use and should not normally be used.
sp.87
fPC port
Connects to the RGB output port on a computer. sp.19
gComponent port
Connects to the component (YCbCr or YPbPr) output port on video equip-
ment. sp.18
hAudio (L-R) port
Inputs audio from equipment connected to the Video port, Component port,
or the PC port. sp.18
iVideo port
Connects to the composite video output port on video equipment. sp.18
jUSB port
Connects USB devices such as a USB memory device or a digital camera, and
projects images as a slideshow. sp.19
kCable holder
Thick HDMI cables with a large outer diameter and so on, may disconnect
easily due to the weight of the cable. To prevent the cable from disconnecting,
fix it in place using the HDMI cable clamp supplied. sp.19
lHDMI2 port
Connects HDMI compatible video equipment and computers. sp.18
mHDMI1 port

Introduction
12
Base
Name Function
aCeiling mount fixing
points (four points)
Attach the optional ceiling mount here when suspending the projector from a
ceiling. sp.84
bFront adjustable foot
When setup on a surface such as a table, extend the foot to adjust the height.
sp.26

Introduction
13
Remote Control
Button Function
a
Turns the projector on. sp.22
b
Turns the projector off. sp.23
c
The remote control buttons light up for ap-
proximately 10 seconds. This is useful when
operating the remote control in the dark.
d
Changes to the image from each input port.
sp.23
The button is only available for EH-
TW6000W.
e
This button displays the settings menu for
HDMI Link.
With the other buttons, you can then start or
stop playback, adjust the volume, and so on
for connected equipment that meets the
HDMI CEC standards. sp.49
f
Adjusts the volume. sp.28
g
Changes between 2D and 3D. sp.42
h
Changes the Color Mode. sp.29
i
Saves, loads, or erases a memory. sp.38
j
Selects menu items and adjustment values.
sp.56
k
When a menu is displayed, it accepts and en-
ters the current selection and moves to the
next level. sp.56
l
The adjustment value returns to its default
value when pressed while the menu's adjust-
ment screen is displayed. sp.56

Introduction
14
Button Function
m
Displays and closes the configuration menu.
On the configuration menu, you can make
adjustments and settings for Signal, Image,
Input Signal, and so on. sp.56
n
Return to the previous menu level when a
menu is displayed. sp.56
o
Sets Auto Iris. sp.36
p
Adjusts the hue, saturation, and brightness
for each RGBCMY color. sp.32
q
Selects the aspect mode according to the in-
put signal. sp.30
r
Splits the screen in two and projects two im-
age sources simultaneously. sp.47
s
Displays and closes the test pattern. sp.25
t
Performs the function assigned to the user
button. sp.61
A
Turns the video and audio on or off. sp.28

Introduction
15
Appearance
Units: mm
aCenteroflens
b Distance from center of lens to suspension bracket fixing point

Preparing
16
Setting Up
Various Projection Methods
Warning
•A special method of installation is required when suspending the projector from a ceiling (ceiling mount). If
it is not installed correctly, it could fall causing an accident and injury.
•If you use adhesives, lubricants, or oil on ceiling mount fixing points to prevent screws from loosening, or if
you use things such as lubricants or oils on the projector, the projector case may crack causing it to fall from
its ceiling mount. This could cause serious injury toanyone under the projector and also damage the projector.
Attention
•Do not setup the projector on its side. This may cause malfunctions to occur.
•Try not to setup the projector in locations subject to high humidity and dust, or in locations subject to smoke
from fires or tobacco smoke.
•Clean the air filter once every three months. Clean it more often if the environment is particularly dusty.
sp.80
Placing on a table and so on and projecting Suspending from the ceiling and projecting
c
•When projecting from a ceiling, change Projection to a ceiling setting. sSettings - Projection p.61
•Set Inverse Audio to On to use the built-in speaker when the projector is suspended from a ceiling.
sSettings - Audio - Inverse Audio p.61
•When the projector cannot be setup directly in front of the screen, you can correct keystone distortion
with the H-Keystone slider. sp.26

Preparing
17
Adjusting the Projection Size
The size of the projection increases as the projector is moved away from the screen.
Use the table below to setup the projector at the optimum position from the screen. The values given here
are for your reference only.
B Distance from the center of the lens to the base of the projection screen
Unit: cm
16:9 Screen Size Projection Distance (C) Distance (B)
A W x H Minimum (Wide) Maximum (Tele)
40" 89 x 50 116 190 0
60" 130 x 75 176 287 0
80" 180 x 100 235 383 0
100" 220 x 120 295 480 0
120" 270 x 150 354 576 0
150" 330 x 190 444 721 1
180" 440 x 250 533 866 1
Unit: cm
4:3 Screen Size Projection Distance (C) Distance (B)
A W x H Minimum (Wide) Maximum (Tele)
40" 81 x 61 143 233 0
60" 120 x 90 216 352 0
80" 160 x 120 289 470 0
100" 200 x 150 361 588 0
120" 240 x 180 434 706 1
150" 300 x 230 544 883 1
200" 410 x 300 726 1179 1

Preparing
18
Connecting to Devices
Attention
•Turn off the equipment you want to connect before connecting. If the equipment is on when you connect,
it could cause a malfunction.
•Check the shape of the cable's connector and the shape of the port, and then connect. If you force a connector
of a different shape into the port, it could cause damage and a malfunction to occur.
Connecting to Video Equipment
To project images from DVD players or VHS video and so on, connect to the projector using one of the
following methods.
When using an HDMI cable
Fix the HDMI cable in place using the HDMI cable clamp. sp.19
When using a video cable
When using a component video cable
c
•The cable differs depending on the output signal from the connected video equipment.
•Some types of video equipment are capable of outputting different types of signals. Check the user's
guide supplied with the video equipment to confirm which signals can be output.

Preparing
19
Connecting to a Computer
To project images from a computer, connect the computer using one of the following methods.
When using a computer cable
For audio connections, make sure you use an audio cable labeled "No resistance" to connect the 2RCA Wstereo
mini-plug.
When using an HDMI cable
Fix the HDMI cable in place using the HDMI cable clamp. sp.19
Connecting an HDMI Cable Clamp
Clamp the HDMI cable to the cable holder to fix it in place.
Connecting to External Devices
Connecting USB devices
You can connect USB devices such as USB memories, and USB compatible digital cameras.
Using the USB cable supplied with the USB device, connect the USB device to the USB (TypeA) port on the
projector.
When the USB device is connected, you can project image files on the USB memory or digital camera as a
slideshow.
s p.51
When you have finished projecting, remove USB devices from the projector. For digital cameras and so on,
turn off the device and then remove it from the projector.
