Epson WorkForce WF-3520DWF User manual

User’s Guide
NPD4670-01EN

Copyright and Trademarks
Copyright and Trademarks
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko
Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither
is any liability assumed for damages resulting from the use of the information herein. The information contained
herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as
applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of
this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to
strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation and its affiliates shall not be liable for any damages or problems arising from the use of any
options or any consumable products other than those designated as Original Epson Products or Epson Approved
Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that
occurs from the use of any interface cables other than those designated as Epson Approved Products by Seiko Epson
Corporation.
EPSON
®
is a registered trademark, and EPSON EXCEED YOUR VISION or EXCEED YOUR VISION is a trademark
of Seiko Epson Corporation.
PRINT Image Matching
™
and the PRINT Image Matching logo are trademarks of Seiko Epson Corporation.
Copyright © 2001 Seiko Epson Corporation. All rights reserved.
SDXC Logo is a trademark of SD-3C, LLC.
Memory Stick Duo, Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick Micro, and MagicGate
Memory Stick Duo are trademarks of Sony Corporation.
Intel
®
is a registered trademark of Intel Corporation.
PowerPC
®
is a registered trademark of International Business Machines Corporation.
Epson Scan software is based in part on the work of the Independent JPEG Group.
libtiff
Copyright © 1988-1997 Sam Leffler
Copyright © 1991-1997 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this software and its documentation for any purpose is
hereby granted without fee, provided that (i) the above copyright notices and this permission notice
appear in all copies of the software and related documentation, and (ii) the names of Sam Leffler and
Silicon Graphics may not be used in any advertising or publicity relating to the software without the
specific, prior written permission of Sam Leffler and Silicon Graphics.
User’s Guide
Copyright and Trademarks
2

THE SOFTWARE IS PROVIDED "AS-IS" AND WITHOUT WARRANTY OF ANY KIND, EXPRESS,
IMPLIED OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER OR NOT
ADVISED OF THE POSSIBILITY OF DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING
OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
Microsoft
®
, Windows
®
, and Windows Vista
®
are registered trademarks of Microsoft Corporation.
Apple
®
, Macintosh
®
, Mac OS
®
, and OS X
®
are registered trademarks of Apple Inc.
ABBYY
®
and ABBYY FineReader
®
names and logos are registered trademarks of ABBYY Software House.
Adobe, Adobe Reader, Acrobat, and Photoshop are trademarks of Adobe systems Incorporated, which may be
registered in certain jurisdictions.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of their
respective owners. Epson disclaims any and all rights in those marks.
© 2012 Seiko Epson Corporation. All rights reserved.
User’s Guide
Copyright and Trademarks
3

Contents
Copyright and Trademarks
CopyrightandTrademarks...................2
Introduction
WheretoFindInformation...................8
Caution,ImportantandNote.................8
OperatingSystemVersions...................9
UsingEpsonConnectService.................9
Important Instructions
SafetyInstructions........................10
ProductAdvisoriesandWarnings.............10
Settingup/usingtheproduct...............11
Using the product with a wireless connection
....................................12
Usingmemorycards.....................12
UsingtheLCDscreen....................12
Handlinginkcartridges...................13
RestrictionsonCopying....................13
ProtectingYourPersonalInformation..........14
Getting to Know Your Product
ProductParts............................15
GuidetotheControlPanel..................17
ButtonandLCD........................18
Lights................................19
Paper and Media Handling
Introduction to Using, Loading, and Storing
Media..................................20
Storingpaper..........................20
SelectingPaper...........................20
PapertypesettingsontheLCDscreen........22
Paper type settings from the printer driver. . . . . 23
LoadingPaperintothePaperCassette..........24
Loading Envelopes into the Paper Cassette. . . . . . . 27
Loading Paper and Envelopes into the Rear Paper
FeedSlot................................31
PlacingOriginals..........................32
AutomaticDocumentFeeder(ADF).........32
Scannerglass..........................35
InsertingaMemoryCard...................35
Copying
CopyingDocuments.......................38
Basiccopying..........................38
2-Sidedcopying........................38
Collatecopying.........................39
Layoutcopying.........................40
CopyModeMenuList......................41
Printing
PrinterDriverandStatusMonitor.............42
AccessingtheprinterdriverforWindows.....42
Accessing the printer driver for Mac OS X. . . . . 43
BasicOperations..........................44
Basicprinting..........................44
Cancelingprinting......................47
OtherOptions...........................48
Printingphotostheeasyway...............48
Product presets (For Windows Only). . . . . . . . . 49
2-sidedprinting........................49
Fittopageprinting......................51
PagesperSheetprinting..................53
SharingtheProductforPrinting..............54
SetupforWindows......................54
SetupforMacOSX......................56
Scanning
Let’sTryScanning.........................57
StartingaScan.........................57
ImageAdjustmentFeatures................59
Basic Scanning from the Control Panel. . . . . . . . . 61
Scanmodemenulist.....................62
BasicScanningfromYourComputer...........62
ScanninginHomeMode..................62
ScanninginOfficeMode..................64
ScanninginProfessionalMode.............65
PreviewingandAdjustingtheScanArea......67
VariousTypesofScanning..................70
ScanningaMagazine.....................70
Scanning Multiple Documents to a PDF File
....................................72
ScanningaPhoto.......................75
User’s Guide
Contents
4

SoftwareInformation......................76
StartingEpsonScanDriver................76
StartingOtherScanningSoftware...........77
Faxing
IntroducingFAXUtility....................79
ConnectingtoaPhoneLine..................79
Aboutaphonecable.....................79
Usingthephonelineforfaxonly............80
Sharinglinewithphonedevice.............80
Checkingthefaxconnection...............83
Noticeswhenthepoweristurnedoff.........84
SettingUpFaxFeatures.....................84
Settingupspeeddialentries................84
Settingupgroupdialentries...............84
Creatingheaderinformation...............85
ChangingFaxOutputsettingtoprint.........86
SendingFaxes............................86
Sendingfaxesbyenteringanumber..........86
Sendingfaxesusingspeeddial/groupdial......87
Sendingfaxesbybroadcasting..............87
Sendingafaxataspecifiedtime.............89
Sending a fax from a connected phone. . . . . . . . 90
ReceivingFaxes...........................91
Settinguptoreceivefaxesautomatically.......91
Receivingfaxesmanually..................92
Receiveafaxbypolling...................93
PrintingReports..........................93
FaxModeMenuList.......................94
More Functions
Menu List of Control Panel
CopyMode..............................97
FaxMode...............................98
ScanMode..............................99
MoreFunctionsModeMenuList..............99
EcoModeMenuList......................100
Wi-FiSetupModeMenuList................101
SetupMode.............................101
HelpMenuList..........................104
Replacing Ink Cartridges
Ink Cartridge Safety Instructions, Precautions,
andSpecifications........................ 105
Safetyinstructions......................105
Precautions on ink cartridge replacement. . . . . 106
InkCartridgeSpecifications...............107
CheckingtheInkCartridgeStatus............ 107
ForWindows......................... 107
ForMacOSX.........................108
Usingthecontrolpanel.................. 109
Temporarily Printing with Black Ink When Color
InkCartridgesareExpended................ 110
ForWindows......................... 110
ForMacOSX.........................112
Conserving Black Ink When the Cartridge Is Low
(ForWindowsOnly)......................113
Replacinganinkcartridge.................. 114
Maintaining Your Product and
Software
CheckingthePrintHeadNozzles.............117
Using the Nozzle Check utility for Windows
................................... 117
Using the Nozzle Check utility for Mac OS X
................................... 117
Usingthecontrolpanel.................. 118
CleaningthePrintHead................... 119
Using the Head Cleaning utility for Windows
................................... 119
Using the Head Cleaning utility for Mac OS X
................................... 119
Usingthecontrolpanel.................. 120
AligningthePrintHead....................120
Using the Print Head Alignment utility for
Windows............................ 120
Using the Print Head Alignment utility for
MacOSX............................121
Usingthecontrolpanel.................. 121
Setting/ChangingTimeandRegion........... 122
SavingPower........................... 123
ForWindows......................... 123
ForMacOSX.........................123
Usingthecontrolpanel.................. 124
CleaningtheProduct......................124
Cleaningtheexterioroftheproduct.........124
Cleaningtheinterioroftheproduct.........125
ReplacingMaintenanceBox.................126
Checkingthemaintenanceboxstatus........126
Handlingprecautions................... 126
Replacingamaintenancebox..............126
TransportingtheProduct.................. 128
CheckingandInstallingYourSoftware.........129
User’s Guide
Contents
5

Checking the software installed on your
computer............................ 129
Installingthesoftware................... 130
UninstallingYourSoftware................. 130
ForWindows......................... 130
ForMacOSX.........................131
Transferring Data Using an External
Storage Device
PrecautionsonStorageDevices.............. 133
Copying Files Between a Storage Device and Your
Computer..............................133
Copyingfilestoyourcomputer............ 133
Savingfilestoastoragedevice............. 134
Error Indicators
ErrorMessagesontheControlPanel.......... 135
Troubleshooting for Printing/Copying
DiagnosingtheProblem................... 136
Checkingproductstatus................. 137
PaperJams............................. 139
Removing jammed paper from the rear cover
................................... 140
Removing jammed paper from inside the
product..............................142
Removing jammed paper from the paper
cassette..............................144
Removing jammed paper from the Automatic
DocumentFeeder(ADF).................146
Preventingpaperjams...................148
Reprinting after a paper jam (for Windows
only)................................148
PrintQualityHelp........................149
Horizontalbanding.....................150
Verticalbandingormisalignment..........150
Incorrectormissingcolors............... 151
Blurryorsmearedprint..................151
MiscellaneousPrintoutProblems.............152
Incorrectorgarbledcharacters.............152
Incorrectmargins...................... 152
Printouthasaslightslant.................153
Size or position of copied image is incorrect. . . 153
Invertedimage........................ 153
Blankpagesprint...................... 153
Printed side is smeared or scuffed. . . . . . . . . . 154
Printingistooslow..................... 154
PaperDoesNotFeedCorrectly.............. 155
Paperdoesnotfeed.....................155
Multiplepagesfeed..................... 155
Paperisimproperlyloaded...............155
Paper is not ejected fully or is wrinkled. . . . . . . 156
TheProductDoesNotPrint................ 156
Alllightsareoff........................156
Lightscameonandthenwentout.......... 156
Onlythepowerlightison................ 156
An ink error is indicated after you replace the
cartridge.............................157
Increasing the Print Speed (For Windows Only)
..................................... 158
OtherProblem.......................... 159
Printingplainpapersquietly.............. 159
Troubleshooting for Scanning
Problems Indicated by Messages on the LCD
ScreenorStatusLight..................... 160
ProblemsWhenStartingaScan.............. 160
Using the Automatic Document Feeder (ADF)
................................... 160
Usingthebutton.......................161
Using scanning software other than Epson
Scandriver........................... 162
ProblemsWhenFeedingPaper..............162
Thepapergetsdirty.....................162
Multiple sheets of paper are fed. . . . . . . . . . . . 162
The paper jams in the Automatic Document
Feeder(ADF).........................162
ProblemsWithScanningTime..............162
ProblemsWithScannedImages..............163
Scanqualityisunsatisfactory.............. 163
The scanning area or direction is
unsatisfactory......................... 164
ProblemsRemainAfterTryingAllSolutions....165
Troubleshooting for Faxing
Cannotsendandreceivefax.................166
Qualityproblems(sending)................. 166
Qualityproblems(receiving)................ 166
Answering machine cannot answer voice calls. . . 167
Incorrecttime...........................167
Product Information
InkandMaintenanceBox.................. 168
Inkcartridges......................... 168
Maintenancebox...................... 168
User’s Guide
Contents
6

SystemRequirements..................... 169
ForWindows......................... 169
ForMacOSX.........................169
TechnicalSpecifications....................169
Printerspecifications....................169
Scannerspecifications................... 171
Automatic Document Feeder (ADF)
specifications......................... 172
Faxspecifications...................... 172
Networkinterfacespecification............ 173
Memorycard......................... 173
Mechanical...........................174
Electrical.............................175
Environmental........................ 176
Standardsandapprovals................. 176
Interface.............................177
ExternalUSBdevice.................... 178
Where To Get Help
TechnicalSupportWebSite.................179
ContactingEpsonSupport..................179
BeforeContactingEpson.................179
HelpforUsersinEurope.................180
HelpforUsersinTaiwan.................180
HelpforUsersinAustralia............... 181
HelpforUsersinSingapore...............181
HelpforUsersinThailand................182
HelpforUsersinVietnam................182
HelpforUsersinIndonesia...............182
HelpforUsersinHongKong..............184
HelpforUsersinMalaysia................184
HelpforUsersinIndia.................. 185
HelpforUsersinthePhilippines........... 186
Index
User’s Guide
Contents
7

Introduction
Where to Find Information
The latest version of the following manuals are available on the Epson support website.
http://www.epson.eu/Support (Europe)
http://support.epson.net/ (outside Europe)
❏Start Here (paper):
Provides you with information on setting up the product and installing the software.
❏Basic Guide (paper):
Provides you with basic information when you are using the product without a computer. This manual may not be
included depending on model and region.
❏User’s Guide (PDF):
Provides you with detailed operating, safety, and troubleshooting instructions. See this guide when using this
product with a computer, or when using advanced features such as 2 sided copying.
To view the PDF manual, you need Adobe Acrobat Reader 5.0 or later, or Adobe Reader.
❏Network Guide (HTML):
Provides network administrators with information on both the printer driver and network settings.
❏Help (on the product display):
Provides basic operating and troubleshooting instructions on the product’s LCD screen. Select the Help menu on
the control panel.
Caution, Important and Note
Caution, Important, and Note in this manual are indicated as below and have the following meaning.
!
Caution
must be followed carefully to avoid bodily injury.
c
Important
must be observed to avoid damage to your equipment.
Note
contain useful tips and restrictions on product operation.
User’s Guide
Introduction
8

Operating System Versions
In this manual, the following abbreviations are used.
❏Windows 7 refers to Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, and
Windows 7 Ultimate.
❏Windows Vista refers to Windows Vista Home Basic Edition, Windows Vista Home Premium Edition, Windows
Vista Business Edition, Windows Vista Enterprise Edition, and Windows Vista Ultimate Edition.
❏Windows XP refers to Windows XP Home Edition, Windows XP Professional x64 Edition, and Windows XP
Professional.
❏Mac OS X refers to Mac OS X 10.5.x, 10.6.x, 10.7.x.
Using Epson Connect Service
Using Epson Connect and other companies’ services, you can easily print directly from your smartphone, tablet PC or
laptop, anytime and practically anywhere even across the globe! For more information about the printing and other
services, visit the following URL;
https://www.epsonconnect.com/ (Epson Connect portal site)
http://www.epsonconnect.eu (Europe only)
You can view the Epson Connect guide by double-clicking the shortcut icon on the desktop.
User’s Guide
Introduction
9

Important Instructions
Safety Instructions
Read and follow these instructions to ensure safe use of this product. Make sure you keep this guide for future
reference. Also, be sure to follow all warnings and instructions marked on the product.
❏Use only the power cord supplied with the product and do not use the cord with any other equipment. Use of other
cords with this product or the use of the supplied power cord with other equipment may result in fire or electric
shock.
❏Be sure your AC power cord meets the relevant local safety standard.
❏Never disassemble, modify, or attempt to repair the power cord, plug, printer unit, scanner unit, or options by
yourself, except as specifically explained in the product’s guides.
❏Unplug the product and refer servicing to qualified service personnel under the following conditions:
The power cord or plug is damaged; liquid has entered the product; the product has been dropped or the casing
damaged; the product does not operate normally or exhibits a distinct change in performance. Do not adjust
controls that are not covered by the operating instructions.
❏Place the product near a wall outlet where the plug can be easily unplugged.
❏Do not place or store the product outdoors, near excessive dirt or dust, water, heat sources, or in locations subject
to shocks, vibrations, high temperature or humidity.
❏Take care not to spill liquid on the product and not to handle the product with wet hands.
❏Keep this product at least 22 cm away from cardiac pacemakers. Radio waves from this product may adversely
affect the operation of cardiac pacemakers.
❏If the LCD screen is damaged, contact your dealer. If the liquid crystal solution gets on your hands, wash them
thoroughly with soap and water. If the liquid crystal solution gets into your eyes, flush them immediately with
water. If discomfort or vision problems remain after a thorough flushing, see a doctor immediately.
❏Avoid using a telephone during an electrical storm. There may be a remote risk of electric shock from lightning.
❏Do not use a telephone to report a gas leak in the vicinity of the leak.
Note:
The following provides safety instructions for ink cartridges.
&“Replacing Ink Cartridges” on page 105
Product Advisories and Warnings
Read and follow these instructions to avoid damaging the product or your property. Make sure you keep this guide for
future reference.
User’s Guide
Important Instructions
10

Setting up/using the product
❏Do not block or cover the vents and openings in the product.
❏Use only the type of power source indicated on the product’s label.
❏Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and off.
❏Avoid electrical outlets controlled by wall switches or automatic timers.
❏Keep the entire computer system away from potential sources of electromagnetic interference, such as
loudspeakers or the base units of cordless telephones.
❏The power-supply cords should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place
objects on top of the power-supply cords and do not allow the power-supply cords to be stepped on or run over. Be
particularly careful to keep all the power-supply cords straight at the ends and the points where they enter and
leave the transformer.
❏If you use an extension cord with the product, make sure that the total ampere rating of the devices plugged into
the extension cord does not exceed the cord’s ampere rating. Also, make sure that the total ampere rating of all
devices plugged into the wall outlet does not exceed the wall outlet’s ampere rating.
❏If you plan to use the product in Germany, the building installation must be protected by a 10 or 16 amp circuit
breaker to provide adequate short-circuit protection and over-current protection for the product.
❏When connecting the product to a computer or other device with a cable, ensure the correct orientation of the
connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation may
damage both devices connected by the cable.
❏Place the product on a flat, stable surface that extends beyond the base of the product in all directions. If you place
the product by the wall, leave more than 10 cm between the back of the product and the wall. The product will not
operate properly if it is tilted at an angle.
❏When storing or transporting the product, avoid tilting it, placing it vertically, or turning it upside down;
otherwise ink may leak.
❏Allow spaces behind the product for the cables, and space above the product so that you can fully raise the
document cover.
❏Leave enough space in front of the product for the paper to be fully ejected.
❏Avoid places subject to rapid changes in temperature and humidity. Also, keep the product away from direct
sunlight, strong light, or heat sources.
❏Do not insert objects through the slots in the product.
❏Do not put your hand inside the product or touch the ink cartridges during printing.
❏Do not touch the white flat cable inside the product.
❏Do not use aerosol products that contain flammable gases inside or around the product. Doing so may cause
fire.
❏Do not move the ink cartridge holder by hand; otherwise, you may damage the product.
User’s Guide
Important Instructions
11

❏Always turn the product off using the Pbutton. Do not unplug the product or turn off the power at the outlet until
the LCD screen has turned off completely.
❏Before transporting the product, make sure that the print head is in the home (far right) position and the ink
cartridges are in place.
❏Be careful not to trap your fingers when closing the scanner unit.
❏If you are not going to use the product for a long period, be sure to unplug the power cord from the electrical
outlet.
❏Do not press too hard on the scanner glass when placing the originals.
❏During the life of your product it may be necessary to replace the waste ink pad when it has become full. Whether
and how often this is required will vary according to the number of pages you print, the type of material that you
print and the number of cleaning cycles that the product performs. Epson Status Monitor, your LCD, or lights on
the control panel will advise you when this part needs replacing. The need for replacement of the pad does not
mean that your product has ceased to operate in accordance with its specifications. The replacement of this part is
a routine product servicing activity within the product’s specification and is not a problem which requires repair.
The Epson warranty does not therefore cover the cost of this replacement. If your product needs the pad replacing
this can be performed for you by any authorised Epson service provider. It is not a user-serviceable part.
Using the product with a wireless connection
Note:
The availability of this feature varies by product.
❏Do not use this product inside medical facilities or near medical equipment. Radio waves from this product may
adversely affect the operation of electrical medical equipment.
❏Do not use this product near automatically controlled devices such as automatic doors or fire alarms. Radio waves
from this product may adversely affect these devices, and could lead to accidents due to malfunction.
Using memory cards
❏Do not remove a memory card or turn off the product while the memory card light is flashing.
❏The methods for using memory cards vary according to card type. Be sure to refer to the documentation packaged
with your memory card for details.
❏Use only memory cards compatible with the product.
&“Memory card” on page 173
Using the LCD screen
❏The LCD screen may contain a few small bright or dark spots, and because of its features it may have an uneven
brightness. These are normal and do not indicate that it is damaged in any way.
❏Only use a dry, soft cloth to clean the touch panel and touchpad. Do not use liquid or chemical cleaners.
User’s Guide
Important Instructions
12

❏The exterior cover of the LCD screen could break if it receives a heavy impact. Contact your dealer if the panel
surface chips or cracks, and do not touch or attempt to remove the broken pieces.
❏The touchpad is a capacitive touch panel, which responds only when touched directly with a finger. The panel may
not respond when touched with wet hand, gloved hands, or touched through a protective sheet or sticker.
❏Press the touch panel/touchpad gently with your finger. Do not press force or operate with your nails.
❏Do not operate by a sharp edge thing such as a ball point pen, sharp pencil, stylus pen and so on.
❏Condensation inside the panel due to abrupt changes in temperature or humidity may cause performance to
deteriorate.
Handling ink cartridges
We will provide ink-related safety instructions and product advice/warnings in the linked section (before “Replacing
Ink Cartridges” section).
&“Replacing Ink Cartridges” on page 105
Restrictions on Copying
Observe the following restrictions in order to ensure the responsible and legal use of the product.
Copying of the following items is prohibited by law:
❏Bank bills, coins, government-issued marketable securities, government bond securities, and municipal securities
❏Unused postage stamps, pre-stamped postcards, and other official postal items bearing valid postage
❏Government-issued revenue stamps, and securities issued according to legal procedure
Exercise caution when copying the following items:
❏Private marketable securities (stock certificates, negotiable notes, checks, etc.), monthly passes, concession
tickets, etc.
❏Passports, driver’s licenses, warrants of fitness, road passes, food stamps, tickets, etc.
Note:
Copying these items may also be prohibited by law.
Responsible use of copyrighted materials:
❏Products can be misused by improperly copying copyrighted materials. Unless acting on the advice of a
knowledgeable attorney, be responsible and respectful by obtaining the permission of the copyright holder before
copying published material.
User’s Guide
Important Instructions
13

Protecting Your Personal Information
This product allows you to store names and telephone numbers in its memory even when the power is turned off.
Use the following menu to erase the memory if you give the product to someone else or dispose of it.
Setup > Restore Default Settings > All Settings
User’s Guide
Important Instructions
14

Getting to Know Your Product
Note:
The illustrations in this manual are from a similar product model. Although they may differ from your actual product, the
method of operation is the same.
Product Parts
a. ADF cover
b. Automatic Document Feeder (ADF)
c. Edge guide
d. ADF input tray (place your originals here to be copied)
e. ADF output tray (your originals are ejected here as they are copied)
f. Paper cassette 1
g. Paper cassette 2 *
* The availability of this part varies by product.
User’s Guide
Getting to Know Your Product
15

a. Edge guides
b. Rear paper feed slot
c. Output tray
d. Output tray extension
e. Stopper
f. Edge guides
g. Paper cassette
a. Document cover
b. Scanner glass
c. Control panel
d. Memory card slots
e. Memory card light
f. External interface USB port
User’s Guide
Getting to Know Your Product
16

a. Scanner unit
b. Ink cartridge cover
c. Ink cartridge holder
d. Print head (under the ink cartridge holder)
a. Maintenance box
b. Rear cover
c. AC inlet
d. LINE port
e. EXT. port
f. LAN port
g. USB connector
Guide to the Control Panel
Note:
❏Control panel design varies depending on location.
❏Although the control panel design and what displayed on the LCD screen such as menu names and option names may
differ from your actual product, the method of operation is the same.
User’s Guide
Getting to Know Your Product
17

Button and LCD
Buttons Function
aTurns the product on or off.
bReturns to the top menu. When on the top menu, switches between the modes.
cDisplays the last number dialed. When entering numbers in fax mode, this inserts a pause
symbol (-) that acts as a brief pause during dialing.
dDisplays the Contacts list in fax mode.
e - LCD screen displays menus. If your product has a touch panel, you can scroll the screen by
swiping the LCD screen. Try swiping a little harder if the touch panel is slow to respond.
fCancels/returns to the previous menu.
gl, u, r, d, OK Press l, u, r, dto select menus. Press OK to confirm the setting you have selected and go to
next screen. When typing a fax number, lacts as a backspace key, and rinserts a space.
h +, - Sets the number of copies.
i 0 - 9, *, # Specifies the date/time or the number of copies, as well as fax numbers. Enters alphanumeric
characters and switches between uppercase, lowercase, and numbers each time it is pressed.
It may be easier to use the software keypad to enter text instead of using these buttons.
jStarts printing/copying/scanning/faxing in black and white.
kStarts printing/copying/scanning/faxing in color.
lStops the current operation or initializes the current settings.
mu, dScrolls the screen.
User’s Guide
Getting to Know Your Product
18

Lights
Lights Function
On when the product is on.
Flashes when the product is receiving data, printing/copying/scanning/faxing, replacing an
ink cartridge, charging ink, or cleaning the print head.
Stays on while the printer is connected to a network. Flashes while network settings are being
adjusted (green: Wi-Fi/orange: Ethernet). This light turns off in sleep mode.
Note:
For more information on the icons displayed on the LCD screen, see the Help on the control panel.
User’s Guide
Getting to Know Your Product
19

Paper and Media Handling
Introduction to Using, Loading, and Storing Media
You can achieve good results with most types of plain paper. However, coated papers provide superior prints because
they absorb less ink.
Epson provides special papers that are formulated for the ink used in Epson ink jet products, and recommends these
papers to ensure high-quality results.
When loading special paper distributed by Epson, read the instruction sheets packed with the paper first and keep the
following points in mind.
Note:
❏Load the paper into the paper cassette printable side down. The printable side is usually whiter or glossier. See the
instruction sheets packed with the paper for more information. Some types of paper have cut corners to help identify the
correct loading direction.
❏If the paper is curled, flatten it or curl it slightly in the opposite direction before loading. Printing on curled paper may
cause ink to smear on your prints.
Storing paper
Return unused paper to the original package as soon as you finish printing. When handling special media, Epson
recommends storing your prints in a resealable plastic bag. Keep unused paper and prints away from high
temperature, humidity, and direct sunlight.
Selecting Paper
The following table shows supported paper types. The loading capacity, paper source, and availability of borderless
printing vary by paper as shown below.
User’s Guide
Paper and Media Handling
20
