Ricoh MD-P1 User manual

Model MD-P1
Machine Code: M040/M041
Field Service Manual
January, 2009
Subject to change

Safety Notices
Important Safety Notices
Prevention of Physical Injury
1. Before disassembling or assembling parts of the printer and peripherals, make sure that the printer
power cord is unplugged.
2. The wall outlet should be near the printer and easily accessible.
3. If any adjustment or operation check has to be made with exterior covers off or open while the main
switch is turned on, keep hands away from electrified or mechanically driven components.
4. The printer drives some of its components when it completes the warm-up period. Be careful to keep
hands away from the mechanical and electrical components as the printer starts operation.
5. The inside and the metal parts of the fusing unit become extremely hot while the printer is operating.
Be careful to avoid touching those components with your bare hands.
Health Safety Conditions
Toner is non-toxic, but if you get either of them in your eyes by accident, it may cause temporary eye
discomfort. Try to remove with eye drops or flush with water as first aid. If unsuccessful, get medical attention.
Observance of Electrical Safety Standards
The printer and its peripherals must be serviced by a customer service representative who has completed
the training course on those models.
Safety and Ecological Notes for Disposal
1. Do not incinerate toner bottles or used toner. Toner dust may ignite suddenly when exposed to an
open flame.
2. Dispose of used toner, the maintenance unit which includes developer or the organic photoconductor
in accordance with local regulations. (These are non-toxic supplies.)
3. Dispose of replaced parts in accordance with local regulations.
• To prevent a fire or explosion, keep the machine away from flammable liquids, gases, and aerosols.
A fire or an explosion might occur.
1

Laser Safety
The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical units
in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite
equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser
chassis is not repairable in the field. Customer engineers are therefore directed to return all chassis and
laser subsystems to the factory or service depot when replacement of the optical subsystem is required.
• Use of controls, or adjustment, or performance of procedures other than those specified in this manual
may result in hazardous radiation exposure.
WARNING
WARNING:
Turn off the main switch before attempting any of the procedures in the Laser Optics Housing Unit section.
Laser beams can seriously damage your eyes.
CAUTION MARKING:
2

Symbols, Abbreviations and Trademarks
This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations are
as follows:
*See or Refer to
Clip ring
Screw
Connector
Clamp
E-ring
SEF Short Edge Feed
LEF Long Edge Feed
Trademarks
Microsoft®, Windows®, and MS-DOS® are registered trademarks of Microsoft Corporation in the United
States and /or other countries.
PostScript® is a registered trademark of Adobe Systems, Incorporated.
PCL® is a registered trademark of Hewlett-Packard Company.
Ethernet® is a registered trademark of Xerox Corporation.
PowerPC® is a registered trademark of International Business Machines Corporation.
Other product names used herein are for identification purposes only and may be trademarks of their
respective companies. We disclaim any and all rights involved with those marks.
3

TABLE OF CONTENTS
Safety Notices.....................................................................................................................................................1
Important Safety Notices...............................................................................................................................1
Laser Safety.....................................................................................................................................................2
Symbols, Abbreviations and Trademarks.........................................................................................................3
Trademarks.....................................................................................................................................................3
1. Product Information
Specifications......................................................................................................................................................7
Supported Paper Sizes.......................................................................................................................................8
Machine Overview.............................................................................................................................................9
Component Layout.........................................................................................................................................9
Paper Path....................................................................................................................................................10
Drive Layout..................................................................................................................................................11
Machine Configuration....................................................................................................................................13
Model (M040/M041)...............................................................................................................................13
Guidance for Those Who are Familiar with Predecessor Products..............................................................14
2. Installation
Installation Requirements.................................................................................................................................15
Environment..................................................................................................................................................15
Machine level...............................................................................................................................................16
Machine Space Requirement.....................................................................................................................16
Power Requirements....................................................................................................................................16
Installation Procedure..................................................................................................................................17
3. Preventive Maintenance
Preventive Maintenance..................................................................................................................................19
4. Replacement and Adjustment
Before You Start...............................................................................................................................................21
Special Tools....................................................................................................................................................22
Exterior Covers.................................................................................................................................................23
Rear Cover...................................................................................................................................................23
Operation Panel...........................................................................................................................................24
Right Cover...................................................................................................................................................25
Left Cover......................................................................................................................................................27
Front Cover Unit...........................................................................................................................................28
4

Laser Optics......................................................................................................................................................30
Caution Decal Locations.............................................................................................................................30
Laser Optics Housing Unit...........................................................................................................................30
AIO Cartridge..................................................................................................................................................35
AIO Cartridge (All In One Cartridge) .......................................................................................................35
Black AIO Motor.........................................................................................................................................35
Color AIO Motor.........................................................................................................................................37
Image Transfer..................................................................................................................................................39
Image Transfer Belt Unit..............................................................................................................................39
Agitator Motor.............................................................................................................................................40
ITB (Image Transfer Belt) Contact Motor...................................................................................................41
ITB (Image Transfer Belt) Contact Sensor..................................................................................................42
TM (Toner Mark) Sensor Base....................................................................................................................43
Waste Toner Bottle Set Sensor...................................................................................................................44
Waste Toner Overflow Sensor...................................................................................................................45
Air Intake Fan...............................................................................................................................................46
Paper Transfer..................................................................................................................................................48
Transfer Unit.................................................................................................................................................48
Transfer Roller..............................................................................................................................................48
Registration Roller........................................................................................................................................50
Registration Sensor......................................................................................................................................51
Registration and Duplex Clutch..................................................................................................................51
By-pass Clutch..............................................................................................................................................53
Front Cover Open Sensor...........................................................................................................................53
Image Fusing....................................................................................................................................................55
Fusing Unit....................................................................................................................................................55
Fusing Lamp..................................................................................................................................................55
Thermostat....................................................................................................................................................58
Thermistors....................................................................................................................................................59
Transport/Fusing Motor..............................................................................................................................61
Paper Feed and Exit.........................................................................................................................................63
Paper Feed Clutch.......................................................................................................................................63
Paper Feed Roller........................................................................................................................................63
5

Separation Pad............................................................................................................................................64
By-pass Separation Pad..............................................................................................................................65
By-pass Pick-up and Feed Rollers...............................................................................................................66
Paper End Sensor.........................................................................................................................................68
Paper Exit Sensor.........................................................................................................................................69
Electrical Components.....................................................................................................................................71
Controller Board..........................................................................................................................................71
EGB (Engine Board)....................................................................................................................................72
Interlock Switches........................................................................................................................................74
Fusing Fan Motor.........................................................................................................................................74
LSU Fan Motor.............................................................................................................................................75
ID Chip Board..............................................................................................................................................76
PSU................................................................................................................................................................77
High Voltage Power Supply Board............................................................................................................79
Temperature/Humidity Sensor...................................................................................................................80
Tray Set Sensor............................................................................................................................................80
EEPROM.......................................................................................................................................................81
5. System Maintenance Reference
Service Program...............................................................................................................................................85
Overview......................................................................................................................................................85
Configuration Page Information......................................................................................................................86
Overview......................................................................................................................................................86
Error Log ......................................................................................................................................................86
Counter and Coverage (Printer Model Only)...........................................................................................87
Firmware Updating..........................................................................................................................................88
Controller Firmware.....................................................................................................................................88
Boot Loader Firmware.................................................................................................................................92
6. Troubleshooting
Troubleshooting Guide....................................................................................................................................93
Image Problems................................................................................................................................................94
Overview......................................................................................................................................................94
Checking a Sample Printout........................................................................................................................94
INDEX.............................................................................................................................................................97
6

1. Product Information
Specifications
See "Appendices" for the "General Specifications".
7
1

Supported Paper Sizes
See "Appendixes" for the "Supported Paper Sizes".
1. Product Information
8
1

Machine Overview
Component Layout
1. Laser Optics Housing Unit
2. Print Cartridge (AIO)
3. Paper Exit
4. Inverter Path
5. Fusing Belt
6. Pressure Roller
7. Fusing Lamp
8. ITB (Image Transfer Belt) Unit
9. By-pass Tray
10. Transfer Roller
11. Registration Roller
12. By-pass Feed Roller
13. Paper Feed Roller
14. Tray 1
15. OPC (AIO)
16. Waste Toner Bottle
17. EGB/ Controller Board
Machine Overview
9
1

Paper Path
1. Paper path from the tray 1 to the output tray
2. Paper path in the duplex path
3. Paper path from the by-pass tray
4. Paper path from the optional tray 2 to the output tray
1. Product Information
10
1

Drive Layout
1. Color AIO Motor
2. Black AIO Motor
3. Transport/Fusing Motor
4. Registration Clutch
5. Duplex Clutch (P1d only)
6. By-pass Clutch
7. Paper Feed Clutch
8. Agitator Motor
9. ITB (Image Transfer Belt) Contact Motor
•Color AIO Motor:
This drives the color AIO cartridges (Cyan, Magenta and Yellow)
•Black AIO Motor:
This drives the black AIO and the ITB (Image Transfer Belt).
•Transport/Fusing Motor:
This drives the fusing unit, paper feed roller, registration roller and paper exit roller* via the paper
feed clutch, registration clutch and gears. (*: This motor only drives the paper exit roller in non-duplex
models.)
Machine Overview
11
1

•Registration Clutch:
This transfers drive from the transport/ fusing motor to the registration roller.
•Duplex Clutch (P1d only):
This transfers drive from the transport/ fusing motor to the duplex rollers.
•By-pass Clutch
This transfers drive from the transport/ fusing motor to the duplex rollers.
•Paper Feed Clutch:
This transfers drive from the transport/ fusing motor to the paper feed roller.
•Agitator Motor:
This moves the agitators in the waste toner bottle.
•ITB Contact Motor:
This moves the ITB into contact with and away from the color OPCs.
1. Product Information
12
1

Machine Configuration
Model (M040/M041)
Models Duplex
Unit
Optional
Memory
Optional
Tray (G849)
PCL
PS
MD-P1b (M040) Manual Y 500x1 Y
MD -P1c (M041) Auto Y 500x1 Y
Machine Configuration
13
1

Guidance for Those Who are Familiar with
Predecessor Products
Machine M040/M041 is a similar model with Machine G165/G166/G167. If you have experience
with those products, the following information will be of help when you read this manual.
Different Points from Previous Products
M040/M041 G165/G166/G167
Print Cartridge (AIO) Longer life Print Cartridge (AIO) -
Operation Panel 2 Lines LCD No LCD
Paper Input Capacity 500 sheets (Mainframe) 250 sheets (Mainframe)
By-pass 100 sheets (automatic) 1 sheet (manual)
Waste Toner Bottle 55 K prints/bottle 25 K prints/bottle
Fusing Belt Fusing
Drawer Connection
Roller Fusing
Harness Connection
Tray Detection Tray Set Sensor No Tray Set Sensor
1. Product Information
14
1

2. Installation
Installation Requirements
Environment
1. Temperature Range: 10°C to 32°C (50°F to 89.6°F)
2. Humidity Range: 15% to 80% RH
3. Ambient Illumination: Less than 2,000 lux (do not expose to direct sunlight)
4. Ventilation: 3 times/hr/person
5. Do not put the machine in areas that get sudden temperature changes. This includes:
• Areas directly exposed to cool air from an air conditioner
• Areas directly exposed to heat from a heater.
6. Do not put the machine in areas that get exposed to corrosive gas.
7. Do not install the machine at locations over 2,500 m (8,125 ft.) above sea level.
8. Put the machine on a strong, level base. (Inclination on any side must be no more than 5 mm.)
9. Do not put the machine in areas with strong vibrations.
15
2

Machine level
Front to back: Within 5 mm (0.2") of level
Right to left: Within 5 mm (0.2") of level
Machine Space Requirement
Put the machine near the power source with these clearances:
Left side: Over 20 cm (7.9")
Rear: Over 10 cm (4")
Right side: Over 10 cm (4")
Front: Over 70 cm (27.5")
Power Requirements
• Make sure that the plug is tightly connected to the outlet.
• Avoid multi-wiring.
• Make sure that you ground the machine.
Input voltage level 120 V, 60 Hz: More than 11 A (for North America)
220 V to 240 V, 50 Hz/60 Hz: More than 6 A (for Europe/ Asia)
Permitted voltage fluctuation: 10%
Do not set anything on the power cord.
2. Installation
16
2

Installation Procedure
Refer to the Quick Installation Guide for details about installing the machine.
Installation Requirements
17
2

2. Installation
18
2
