Equinox Systems EQLED020 User manual

EQUINOX
SLENDER BEAM BAR QUAD
User Manual
EQLED020
Contents
1. Safety Instructions
2. Features & Specifications
3. How To Set The Unit
4. Troubleshooting
5. Fixture Cleaning

1. Safety Instruction
WARNING
Please keep this User Guide for future consultation. If you sell the unit to
another user be sure that they also receive this.
Unpack and check carefully that there is no transportation damage before
using the unit.
Before operating, ensure that the voltage and frequency of the power
supply match the power requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to
avoid electric shock.
The unit is for indoor use only. Use only in a dry location.
The unit must be installed in a location with adequate ventilation, at least
50cm from adjacent surfaces. Be sure that no ventilation slots are
blocked.
Disconnect the mains power before replacement or servicing.
Make sure there are no flammable materials close to the unit while
operating as they may cause a fire hazard.
Always use a safety cable when installing this unit. Do not carry the unit
with its head only, always carry it using the base.
The maximum ambient temperature is: 40℃. Don’t operate it where the
temperature is higher than this.
In the event of a serious operating problem stop using the unit
immediately. Never try to repair the unit by yourself. Repairs carried out
by unskilled people can lead to damage or malfunction. Please contact
the nearest authorized technical assistance center. Always use the same
type spare parts.
Do not touch any power cables during operation as the high voltage may
cause an electric shock.
Warning
To prevent or reduce the risk of electrical shock or fire, do not expose the
unit to rain or moisture.
Do not open the unit within five minutes after switching off.
The housing and lenses must be replaced if they are visibly damaged.
Installation
The unit should be mounted via its screw holes onto the bracket. Always
ensure that the unit is firmly fixed to avoid vibration and slipping while
operating. Make sure that the structure to which you are attaching the
unit to is secure and is able to support a weight of 10 times of the unit’s
weight. Always use a safety cable that can hold 12 times of the weight of
the unit when installing the fixture.
The equipment must be installed by professionals and it must be installed
in a place where is out of the reach of people and no one can pass by or
under it.
2. Features & Technical Specifications
◇Control: Sound active, auto, Master/slave and DMX 512 and CA-8 modes
◇DMX Channels: 1CH/6CH/12CH/14CH/27CH
◇Electronic dimming: 0-100%
◇Compact size with a high output
Voltage: 100V~240V, 50/60Hz
Fuse: T 6.3A
Power consumption: 85W
Light source: 4 x 10W quad colour LED
Dimension: 808 x 89 x253mm
Weight: 7.5 kg
Pan/Tilt: 540°/270°
Power sockets: IEC IN/OUT
XLR sockets: 3-pin XLR IN/OUT
Please read the instructions carefully as they include important
information about installation, usage and maintenance.

3. How To Set The Unit
3.1 Control panel
Display
Shows the various menus and selected functions
Button
MENU Selects the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER Confirms the selected functions
Mains input
Connection to the power supply.
DMX input/output
For DMX-512 linking. Use a 3-pin XLR cables to link to the controller or to
other units.
3.2 Main Functions
To select any of the given functions, press the MENU button up to where
the required function is showing on the display. Select the function by
pressing the ENTER button and the display will blink. Use the DOWN and
UP buttons to change the mode. Once the required mode has been
selected, press the ENTER button to confirm. To go back to the functions
without any changes, press the MENU button again. Press and hold the
MENU button for one second or wait for one minute to go back to the main
menu.
The main functions are as below:
Menu
ADDR 001-512
CHMD 1CH/6CH/12CH/14C
H/27CH
SLMD
MAST
SL1
SL2
SHMD
SH1
SH2
SH3
SH4
SOUN ON
OFF
SENS 000-100
LED ON
OFF
DISP→INVERT
PAN INVERT YES
NO
TILT INVERT YES
NO
TEST SELF-TEST
FHRS Fixture hours
0 ~ 9999
VER Software Version
RSET RSET

DMX Address Setting
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to choose the address to
confirm. To go back to the functions without any changes press the MENU
button again. Press and hold the MENU button for one second or wait for
one minute to go back to the main menu.
Channel Mode
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (1
Channel) or (6 Channel) or (12 Channel) or (14
Channel) or (27Channel)mode.Once the mode has been selected,
press the ENTER button to confirm. To go back to the functions without
any changes press the MENU button again. Press and hold the MENU
button for one second or wait for one minute to go back to the main menu.
Master Mode or Slave Mode
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the
(Slave 1), (Slave 2) or (Master) mode. Once the mode has
been selected, press the ENTER button to confirm. To go back to the
functions without any changes press the MENU button again. Press and
hold the MENU button for one second or wait for one minute to go back to
the main menu.
Show Mode
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the
(show 1) or (show 2) or (show 3) or (show 4) mode.
Once the mode has been selected, press the ENTER button to confirm. To
go back to the functions without any changes press the MENU button
again. Press and hold the MENU button for one second or wait for one
minute to go back to the main menu.
Sound Mode
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the
(sound on) or (sound off) mode. Once the mode has been selected,
press the ENTER button to confirm. To go back to the functions without
any changes press the MENU button again. Press and hold the MENU
button for one second or wait for one minute to go back to the main menu.
Sound Sensitivity
Press the MENU and use the UP and DOWN buttons to select and
select the sound sensitivity between value 0 and 100. Press the ENTER
button for confirmation after value selection. To go back to the functions
without any changes press the MENU button again.
Led Display
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the

(Led display on) or (Led display off) mode. Once the mode has
been selected, press the ENTER button to confirm. To go back to the
functions without any changes press the MENU button again. Press and
hold the MENU button for one second or wait for one minute to go back to
the main menu.
Display Inversion
Press the MENU button to select . Press the ENTER button to change
the mode (display normal), it will be automatically saved after 8
seconds. Press the ENTER button again to select the mode (display
inversion). To go back to the functions press the MENU button. Press and
hold the MENU button for one second or wait for one minute to go back to
the main menu.
Display normal mode is for floor standing the unit.
Display inversion mode is for hanging the unit upside down.
Pan Inversion
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the
(normal) or (pan inversion) mode. Once the mode has been
selected, press the ENTER button to confirm. To go back to the functions
without any changes press the MENU button again. Press and hold the
MENU button for one second or wait for one minute to go back to the main
menu.
Tilt Inversion
Press the MENU button to select . Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the
(normal) or (tilt inversion) mode. Once the mode has been selected,
press the ENTER button to confirm. To go back to the functions without
any change press the MENU button again. Press and hold the MENU
button for one second or wait for one minute to go back to the main menu.
Auto-Test
Press the MENU button to select . Press the ENTER button and the
unit will run a self-test with its built-in programs. To go back to the functions
without any changes press the MENU button again. Press and hold the
MENU button for one second or wait for one minute to go back to the main
menu.
Fixture Hours
Press the MENU button up to when the is showing on the display.
Press the ENTER button and the display will show the number of working
hours of the unit. To go back to the functions press the MENU button.
Software version
Press the MENU button up to when the is showing on the display.
Press the ENTER button and the display will show the version of software of
the unit. To go back to the functions press the MENU button.

Reset
Press the MENU button to select . Press the ENTER button and all
channels of the unit will return to their standard position.
4. How To Control The Unit
1. Master/slave built-in preprogram function
2. Universal DMX controller
There is no need to turn the unit off when you change the DMX address as
new DMX address setting will be effected at once. Every time you turn the
unit on, it will show “ ”on the display and move all the motors to their
‘home’ position and you may hear some noises for about 20 seconds. After
that the unit will be ready to receive a DMX signal or run the built in
programs.
4.1 Master/Slave Built In Preprogrammed Function
By linking the units in master/slave connection, the first unit will control
the other units to give an automatic, sound activated, synchronized light
show. This function is good when you want an instant show. You have to
set the first unit as master and select show 1,show 2,show 3 or show
4from the Show Mode. The other units must be set to either Slave 1
(normal) or Slave 2 (2 light show) mode. A DMX cable between the units
for daisy chaining is needed.
2-light show
In slave mode,Slave 1 means the unit works normally and Slave 2
means 2-light show. In order to create a great light show, you can set
Slave 2 on the second unit to get contrast movement to each other, even
if you have two units only.
4.2 CA-8 Controller
Your Slender Beam Quad Bar can be controlled using the optional CA-8
easy controller (order code CONT10)
BLACKOUT: The fixture can be blacked out by pressing the STANDBY
button. To turn the fixture back on simply press the STANDBY button
again.
MODE (LED OFF): In this mode repeated pressing of the FUNCTION
button will trigger the movement of the heads without any music playing.
MODE (LED FULL ON): In this mode by pressing the FUNCTION button
you can scroll through the four built-in light shows.
MODE (LED SLOW FLASHING): In this mode you can select the speed of
the auto movements. Nine speeds are available (slow>fast)
MODE (LED FAST FLASHING): In this mode you can select the colour of
the heads. Fifteen colours are available.
4.3 DMX Controller
By using a universal DMX controller to control the units, you will need to
set a DMX address from 1 to 512 so that the units can receive a DMX signal.
Press the MENU button until is showing on the display. Press the
ENTER button and the display will blink. Use the DOWN and UP buttons to
change the DMX-512 address. Once the address has been selected, press
the ENTER button to confirm. To go back to the functions without any
changes press the MENU button again. Press and hold the MENU button
one second or wait for one minute to go back to the main menu.

Please refer to the below diagram to address your first 4 units：
Channel
mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
1 channel 1 2 3 4
6channel 1 7 13 19
12channel 1 13 25 37
14channel 1 15 29 43
27channel 1 28 55 82
4.3 DMX 512 Configuration
1 CHANNEL MODE:
Channel Function Value
1 Show mode
000-007 0
008-022 Movement 01
023-037 Movement 02
038-052 Movement 03
053-067 Movement 04
068-082 Movement 05
083-097 Movement 06
098-112 Movement 07
113-127 Movement 08
128-142 Movement 09
143-157 Movement 10
158-172 Movement 11
173-187 Movement 12
188-202 Movement 13
203-217 Movement 14
218-232 Movement 15
233-247 Movement 16
248-255 Sound active
6CHANNEL MODE
Channel Function Value
1
Dimmer
0-255 Dimmer 0%-100%
2
Strobe 0-007 open
008-255 Strobe Slow>Fast
3
Pan/Tilt Movement
000-007 Movement 0
008-022 Movement 01
023-037 Movement 02
038-052 Movement 03
053-067 Movement 04
068-082 Movement 05
083-097 Movement 06
098-112 Movement 07
113-127 Movement 08
128-142 Movement 09
143-157 Movement 10
158-172 Movement 11
173-187 Movement 12
188-202 Movement 13
203-217 Movement 14
218-232 Movement 15
233-247 Movement 16
248-255 Sound active
4 Movement Speed 000-255 slow to fast
5 Color Chase
000 - 014 color
015 - 255 Color Chase
6 Chase Speed 000 - 255 slow to fast

12 CHANNEL MODE
Channel Function Value
1 Pan1 000 - 255 Pan 0°~ 540°
2 Tilt1 000 - 255 Tilt 0°~ 270°
3 Color1
000 - 007 Blackout
008 - 024 R
025 - 041 G
042 - 057 B
058 - 074 W
075 - 090 R + G
091 - 107 R + B
108 - 123 R + W
124 - 140 G + B
141 - 156 G + W
157 - 173 B + W
174 - 189 R + G + B
190 - 206 R + G + W
207 - 222 R + B + W
223 - 239 G + B + W
240 - 255 R + G + B + W
4 Pan2 000 - 255 Pan 0°~ 540°
5 Tilt2 000 - 255 Tilt 0°~ 270°
6 Color2
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W
7 Pan3 000 – 255 Pan 0°~ 540°
8 Tilt3 000 – 255 Tilt 0°~ 270°
9 Color3
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W
10 Pan4 000 - 255 Pan 0°~ 540°
11 Tilt4 000 - 255 Tilt 0°~ 270°
12 Colo4
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W

14 CHANNEL MODE
Channel Function Value
1 Dimmer 000 - 255 0%~ 100%
2 Strobe 000-007 Open
008-255 (Speed 0 - 100%)
3 Pan1 000 - 255 Pan 0°~ 540°
4 Tilt1 000 - 255 Tilt 0°~ 270°
5 Color1
000 - 007 Blackout
008 - 024 R
025 - 041 G
042 - 057 B
058 - 074 W
075 - 090 R + G
091 - 107 R + B
108 - 123 R + W
124 - 140 G + B
141 - 156 G + W
157 - 173 B + W
174 - 189 R + G + B
190 - 206 R + G + W
207 - 222 R + B + W
223 - 239 G + B + W
240 - 255 R + G + B + W
6 Pan2 000 - 255 Pan 0°~ 540°
7 Tilt2 000 - 255 Tilt 0°~ 270°
8 Color2
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W
9 Pan3 000 – 255 Pan 0°~ 540°
10 Tilt3 000 – 255 Tilt 0°~ 270°
11 Color3
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W
12 Pan4 000 - 255 Pan 0°~ 540°
13 Tilt4 000 - 255 Tilt 0°~ 270°
14 Color4
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W

27 CHANNEL MODE
Channel Function Value
1 Dimmer 000 - 255 0%~ 100%
2 Strobe 000-007 Open
008-255 (Speed 0 - 100%)
3 Pan1 000 - 255 Pan 0°~ 540°
4 Pan fine 1 000 - 255
5 Tilt1 000 - 255 Tilt 0°~ 270°
6 Tilt fine 1 000 - 255
7 Pan Tilt speed1 000 – 255 fast to slow
8 Color1
000 - 007 Blackout
008 - 024 R
025 - 041 G
042 - 057 B
058 - 074 W
075 - 090 R + G
091 - 107 R + B
108 - 123 R + W
124 - 140 G + B
141 - 156 G + W
157 - 173 B + W
174 - 189 R + G + B
190 - 206 R + G + W
207 - 222 R + B + W
223 - 239 G + B + W
240 - 255 R + G + B + W
9 Pan2 000 - 255 Pan 0°~ 540°
10 Pan fine 2 000 - 255
11 Tilt2 000 - 255 Tilt 0°~ 270°
12 Tilt fine 2 000 - 255
13 Pan Tilt speed2 000 – 255 fast to slow
14 Color2
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W
15 Pan3 000 – 255 Pan 0°~ 540°
16 Pan fine 3 000 – 255
17 Tilt3 000 – 255 Tilt 0°~ 270°
18 Tilt fine 3 000 – 255
19 Pan Tilt speed3 000 – 255 fast to slow
20 Color3
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W
21 Pan4 000 - 255 Pan 0°~ 540°
22 Pan fine 4 000 - 255
23 Tilt4 000 - 255 Tilt 0°~ 270°

24 Tilt fine 4 000 - 255
25 Pan Tilt speed4 000 – 255 Fast to slow
26 Color4
000 – 007 Blackout
008 – 024 R
025 – 041 G
042 – 057 B
058 – 074 W
075 – 090 R + G
091 – 107 R + B
108 – 123 R + W
124 – 140 G + B
141 – 156 G + W
157 – 173 B + W
174 – 189 R + G + B
190 – 206 R + G + W
207 – 222 R + B + W
223 – 239 G + B + W
240 – 255 R + G + B + W
27 Special Function
000-199 No function
200-209 Reset
210-239 No function
240-255 Stand-alone
4.Troubleshooting
Following are a few common problems that may occur during
operation and some suggestions for easy troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connection of the power and the main fuse.
B. Not responding to DMX controller
1. Check DMX cables to see if linked correctly.
2. If the DMX address is showing but no response to the controller, check
the address settings and DMX polarity.
3. Try another DMX controller.
C. No response to the sound
1. Make sure the unit is not receiving a DMX signal.
2. Check the microphone to see if it is good by tapping it. The microphone
is located on the bottom plate of the unit.
5. Fixture Cleaning
The cleaning of external optical lenses must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in
which the fixture operates: damp, smoky or particularly dirty surrounding
can cause a greater accumulation of dirt on the unit’s optics.
Clean with a soft cloth using normal glass cleaning fluid or mild soapy
water.
Always dry the parts carefully.
Clean the external optics at least every 20 days.
---------------------www.prolight.co.uk----------------------------------
