Erbauer EPR710 User manual

EPR710
EAN: 3663602796282
ORIGINAL INSTRUCTIONS
710W router MNL_EPR710_TPS_GB_V2_BX220IM-10-8-2020
6/6/18 8:40 AM

2
Safety instructions 7
Product description 17
Assembly 20
Use 24
Care & maintenance 28
Guarantee 31
Declaration of conformity 32
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 2 6/6/18 8:40 AM

3
1
x1
WARNING! Please read all safety warnings carefully and be
sure that they are fully understood before handling the tool.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 3 6/6/18 8:40 AM

4
Product description
1
14c
14 14b 14a
15c
15a 15
15b
16
1 2 3 4
5
7
13
12 1711
10
9
8
6
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 4 6/6/18 8:40 AM

5
A
17
12
10
1.
3.
2.
4.
B
2. 1.
4.
5.
6.
3.
13
14
C D
15c15a
15b 13
11
1. 3.
4.
6.
5.
2.
16
E F
ON
OFF
23
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 5 6/6/18 8:40 AM

6
G
3.
1.
2.
4. H
I J
K
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 6 6/6/18 8:40 AM

7
Safety instructions
GENERAL POWER TOOL SAFETY WARNING
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 7 6/6/18 8:40 AM
WARNING Read all safety warnings, instruc-
tions, illustrations and specifications
provided with this power tool. Failure to follow all
instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching out-
lets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is

8
4)
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 8 6/6/18 8:40 AM
an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
NOTE The term “residual current device (RCD)” can be replaced
by the term “ground fault circuit
interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.
3) Personal safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power tool
while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask, non-skid
safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating

9
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 9 6/6/18 8:40 AM
part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery.
Keep your hair and clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within a
fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on
and off. Any power tool that cannot be controlled with the switch
is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove
the battery pack, if detachable, from the power tool before
making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s

10
SAFETY WARNINGS FOR ROUTER
c) The power tool shall not be wet or applied in wet
environment.
d) The voltage of the power source must agree with the
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 10 6/6/18 8:40 AM
operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of the
power tool for operations different from those intended could
result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free
from oil and grease. Slippery handles and grasping surfaces do
not allow for safe handling and control of the
tool in unexpected situations.
5) Service
a) Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that the
safety of the power tool is maintained.
a) Hold the power tool by insulated gripping surfaces only,
because the cutter may contact its own cord. Cutting a
"live" wire may make exposed metal parts of the power tool
"live" and could give the operator an electric shock.
b) Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by your hand or against the body leaves it unstable
and may lead to loss of control.

11
e) Check the product, its power cord and plug as well as
accessories for damage before each use. Do not use the
product if it is damaged or shows wear.
f) Be aware of kickback.
g) Turn the product off immediately, if the cutting blade gets
jammed.
h) Never touch the workpiece with your hand when you are
working on it.
i) Ensure that the workpiece is free of foreign objects such as
screws or nails.
j) Keep the handles dry to ensure safe control. Grip the
product securely with two hands so you have full control at
all times.
k) Ensure that the air vents are always unobstructed and
clear. Clean them if necessary with a soft brush. Blocked
air vents may lead to overheating and damage the product.
l) Switch the product off immediately if you are disturbed
while working by other people entering the working area.
Always let the product come to complete stop before
putting it down.
m)Do not overwork yourself. Take regular breaks to ensure
you can concentrate on the work and have full control over
the product.
n) Always keep the power cord behind the power tool.
The following information applies to professional users only
but is good practice for all users:
ADDITIONAL SAFETY WARNINGS FOR
CONSTRUCTION DUST
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce the
risks associated with silica, wood and gypsum dusts.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 11 6/6/18 8:40 AM

12
Construction workers are one of the at-risk groups within this
because of the dust that they breathe: silica dust is not just a
nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts in things
like sand, sandstone and granite. It is also commonly found in
many construction materials such as concrete and mortar. The
silica is broken into very ne dust (also known as Respirable
Crystalline Silica or RCS) during many common tasks such as
cutting, drilling and grinding. Breathing in very ne particles of
crystalline silica can lead to the development of:
• lung cancer
• Silicosis
• Chronic obstructive pulmonary disease (COPD).
And breathing in ne particles of wood dust can lead to the
development of Asthma. The risk of lung disease is linked to
people who regularly breathe construction dust over a period
of time, not on the odd occasion.
To protect the lung, the COSHH Regulations sets a limit on
the amount of these dusts that you can breathe (called a
Workplace Exposure Limit or WEL) when averaged over a
normal working day. These limits are not a large amount of
dust: when compared to a penny it is tiny – like a small pinch
of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
How to reduce the amount of dust?
1. Reduce the amount of cutting by using the best sizes of
building products.
2. Use a less powerful tool e.g. a block cutter instead of
angle grinder.
3. Using a different method of work altogether – e.g. using
a nail gun to direct fasten cable trays instead of drilling
holes rst.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 12 6/6/18 8:40 AM

13
Please always work with approved safety equipment, such
as those dust masks that specially designed to lter out
microscopic particles and use the dust extraction facility at all
time.
For more information, please see the HSE website:
http://www.hse.gov.uk/construction or http://www.hse.gov.uk/
pubns/cis69.pdf
WARNING! Some dust particles created by
power sanding, sawing, grinding, drill and other
construction jobs contain chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks and cement and
other masonry products.
• Arsenic and chromium from chemically treated
timber.
Your risk from these exposures varies, depending
upon how often you do this type of work. To reduce
your exposure to these dusts:
• Work in a well-ventilated.
• Work with approved protective equipment, such
as those dust masks that are specially designed
to lter microscopic particles.
VIBRATION
The European Physical Agents (Vibration) Directive has
been brought in to help reduce hand arm vibration syndrome
injuries to power tool users. The directive requires power tool
manufacturers and suppliers to provide indicative vibration
test results to enable users to make informed decisions as to
the period of time a power tool can be used safely on a daily
basis and the choice of tool.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 13 6/6/18 8:40 AM

14
SEE TECHNICAL SPECIFICATIONS IN THE INSTRUCTION
MANUAL FOR THE VIBRATION LEVELS OF YOUR TOOL.
The declared vibration emission value should be used as a
minimum level and should be used with the current guidance
on vibration.
Calculating the actual period of use can be difcult and the
HSE website has further information.
The declared vibration total value has been measured in
accordance with EN 60745-1 and EN 60745-2-17 and may be
used for compare one tool with another.
The declared vibration total value may also be used in a
preliminary assessment of exposure.
WARNING! The vibration emission during actual
use of the power tool can differ from the declared
total value depending on the ways in which the
tool is used:
• How the materials are grinded, cut or drilled.
• If the tool is in good condition and well maintained.
• Use correct accessory for the tool and ensure it is
sharp and in good condition.
• The tightness of the grip on the handles.
• And the tool is being used as intended by its
design and these instructions.
While working with this power tool, hand/arm
vibrations occur. Adopt the correct working
practices in order to reduce the exposure to
vibration. This tool may cause hand-arm vibration
syndrome if its use is not adequately managed.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 14 6/6/18 8:40 AM

15
WARNING! Identify safety measures to protect the
operator that are based on an estimation of exposure
in the actual conditions of use (taking account of all
parts of the operating cycle such as the times when
the tool is switched off and when it is running idle in
addition to the trigger time).
Note:
• The use of other tools will reduce the users’ total
working period on this tool.
• Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
• Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
• Avoid using tools in temperatures of 10 ºC or
less. Plan your work schedule to spread any high
vibration tool use across a number of days.
HEALTH SURVEILLANCE
All employees should be part of an employer’s health
surveillance scheme to help identity any vibration related
diseases at an early stage, prevent disease progression and
help employees stay in work.
VIBRATION AND NOISE REDUCTION
To reduce the impact of noise and vibration emission, limit
the time of operation, use low-vibration and low-noise
operating modes as well as wear personal protective
equipment.
Take the following points into account to minimise the vibration
and noise exposure risks:
1. Only use the product as intended by its design and these
instructions.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 15 6/6/18 8:40 AM

16
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure they
are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these instructions
and keep it well lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration tool
use across a longer period of time.
7. Prolonged use of the product exposes the user to vibrations
that can cause a range of conditions collectively known as
hand-arm vibration syndrome (HAVS) e.g. ngers going
white; as well as specic diseases such as carpal tunnel
syndrome. To reduce this risk when using the product,
always wear protective gloves and keep your hands warm.
RESIDUAL RISKS
Even if you are operating this product in accordance
with all the safety requirements, potential risks of injury
and damage remain. The following dangers can arise in
connection with the structure and design of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken attachments
or the sudden impact of hidden objects during use.
3. Danger of injury and property damage caused by ying
objects or poor power tool accessories.
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 16 6/6/18 8:40 AM

17
WARNING! This product produces an electromagnetic
eld during operation! This eld may under some
circumstances interfere with active or passive
medical implants! To reduce the risk of serious or fatal
injury, we recommend persons with medical implants
to consult their doctor and the medical implant
manufacturer before operating this product!
Product description
Part index
The index below refers to Fig. 1 on page 4.
1. Cord guard and power cord
2. On/off switch
3. Speed dial
4. Air vents
5. Carbon brush cover (x2)
6. Fine depth adjustment wheel
7. Scale for cutting depth
8. Quick release lever
(for cutting depth adjustment)
9. Locking lever
(for cutting depth adjustment)
10. Spindle lock
11. Base plate
12. Clamp nut with collet
(1/4” for UK; 6mm for EU)
13. Parallel guide xing knob
14. Parallel guide assembly
a. Angle bracket
b. Screw
c. Wing nut
15. Roller guide assembly
a. Fixing knob
b. Fine adjustment knob
c. Roller guide
16. Template guides (16 mm)
17. Wrench
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 17 6/6/18 8:40 AM

18
Symbols
On the product, the rating label and within these instructions you will nd among others
the following symbols and abbreviations. Familiarise yourself with them to reduce
hazards like personal injuries and damage to property.
Always wear eye protection. Always wear ear protection.
Wear a dust mask. Wear protective gloves.
Lock / to tighten or secure. Unlock / to loosen.
Note / Remark. Caution / Warning.
Wrong. Correct.
dB(A) Decibel (A-rated) n0No-load speed
To reduce the risk of injury, user must read instruction manual.
Switch the product off and disconnect it from the power supply before
assembly, cleaning, adjustments, maintenance, storage and transportation.
This product is of protection class II. That means it is equipped with
enhanced or double insulation.
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
WEEE symbol. Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your
Local Authority or local store for recycling advice.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx)
3 metre Power Cord Length
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 18 6/6/18 8:40 AM

19
Technical data
Rated voltage, frequency
Rated power input
Rated no load speed n0
Collet size
Max. plunge depth
Protection class
Weight
Sound pressure level LpA
Sound power level LWA
Uncertainty KpA, KWA
Vibration total value ah
Uncertainty K
:220-240 V~, 50 Hz
:710 W
:10000 - 30000 min-1
:¼ inch/ 6.35mm for UK
:6 mm for EU
:35 mm
:II
:approx. 1.7 kg
:82.4 dB(A)
:93.4 dB(A)
:3 dB(A)
:6.9 m/s2
:1.5 m/s2
The sound emission values have been obtained according to the noise test code given
in EN 60745-1 and EN 60745-2-17. The noise for the operator may exceed 80 dB(A)
and ear protection measures are necessary.
Rating label explanation
EPR710 = Model number
E = Erbauer
PR = Palm Router
710 = Power (Watts)
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 19 6/6/18 8:40 AM

20
Assembly
01 Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices, if applicable.
3. Make sure the delivery contents are complete and free of any damage. If you nd
that parts are missing or show damage do not use the product but contact your
dealer. Using an incomplete or damaged product represents a hazard to people
and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Wear protective gloves for this assembly work and always lay the product
on a at and stable surface while assembling.
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There is
a danger of choking and suffocation!
710W router MNL_EPR710_TPS_GB_V1_V10518_20180606.indd 20 6/6/18 8:40 AM
