ERGOPIXEL GD-0004 User manual

KG
25mm/s
100-240V
710mm
12 0mm
0~40°C
2
Bx8
M6
C
M6
D
ST4.2
E
Cable Tie
F
x1
G
Ax4
M6
x8
x6
x6
x16
ST4.2
Allen Key 4x4 mm
100
0
1 00-1 00mm
1 7
MODEL : GD-0004
Assembly Video:
Page 1 of 7

6
1
3 2
7
1
8
1
1 2 2 2
5
1
9
1
10
1
11
4 2
22
12
No. Part Qty No. Part Qty
No. Part Qty No. Part Qty
No. Part Qty No. Part Qty
No. Part Qty No. Part Qty
No. Part Qty No. Part Qty
No. Part Qty No. Part Qty
Feet Lifting column
Connection rod
Left
supporting beam
Right
supporting beam Side bracket
Adapter arm Adapter
Control Box
HandSet
(Option)
Power PlugAdapter cable
1
3
8
2
10
9
12
6
7
4
5
11
Page 2 of 7

Connect the connection rod (3) with the left supporting
beam (4) and the right supporting beam (5), flip over
and tighten the screws with the allen key (G).
Using the screws (A) connect the side bracket (6) with the
right supporting beam (5), and tighten them with the allen
key (G).
Using the screws (A) connect the side bracket (6) with the
left supporting beam (4), and tighten them with the allen
key (G).
Page 3 of 7

Using screws (B) to connect the lifting column (2) with the
left supporting beam (4) and the right supporting beam (5),
and tighten them with the allen key (G).
Connect the feet(1) and the lifting column (2) with screws (C),
and tighten them with the allen key (G).
Use the allen key to loosen the screws. This will allow
you to increase and decrease the distance of the
supporting beam (can be adjusted according to actual use).
Page 4 of 7

Buckle the adapter arm (7) into the left supporting
beam before opening the tabletop(4).
After adjusting to the correct distance, tighten the screws
with the allen key.
Connect the Desktop to the end of the supporting beams (F)
with screws as shown in the image below.
Page 5 of 7

Install the handset (10) with screws (F) as shown in the
image below.
Install the control box (9) with screws (F) as shown in
the image below.
Insert the adapter (8) into the adapter arm (7) as shown
in the image below
Page 6 of 7

Connect cables to the control box to complete assembly.
10
1
1
12
8
9
Dx6
Ex6
11
Tear off Fix cables
Manage
cables
Fix the cables to the tabletop with cable management (E), and then use screw (D) to fix the cable management (E) to keep the desk cables organized.
DC
HS M1 M2
Port for
handset
Port for
adapter cable
Port for cable
connected to
the lifting column
Assembly Video:
Page 7 of 7
