Sim-Lab GT2 User manual

Copyright 2020 - SimLab | Revision 1.0
GT2
INSTRUCTION MANUAL

Thank you for purchasing a Sim-Lab GT2 Direct drive Cockpit! On
the following pages you will find a detailed instruction how to build
this cockpit. Assembling requires a set of simple tools, and general
knowledge of how to use them and a bit of technical insight.
Generally it takes about 3-4 hours to build this cockpit. Before
starting please check contents (page 8) and make sure all the parts
are accounted for in the packages.
5/6 mm 11 mm
Required tools:
BOX B (Hardware kit) - 45x45x11 cm
BOX A (Profile kit) - 125x14x14 cm

B7 B8 B1
A1
A2
B1
B3

B4
B6 B9
B6 B10
A3
B10
Mount caps (B3) on 40x80 profile before
mounting to base
B17

B24 B25 B30
B24 B30 B20
B25
B30
B23
B23
B30
B18
B22 B19
6x B20,
6x B21,
12x B30
12X B24

B5
B42
B39
B44
B31
*break off the lip on the connector bracket
B38
B42
B41
B31 B32
B5 B39 B42
B40 B32
B41 B42 B38

B10
B6
B10

Parts list
BOX A Base Profiles (Black)
A1 Profile 40 mm slot 8 (Black, 40x80L) - 1195mm 2Units
A2 Profile 40 mm slot 8 (Black, 40x80L) - 420mm 3Units
A3 Profile 40 mm slot 8 (Black, 40x80L) - 500mm 2Units
A4 Cover strip for profile (Red) 4Meter
BOX B Hardware kit
Hardware kit
B1 Connector bracket 40x40 8Units
B2 Cover cap for connector bracket 40x40 8Units
B3 End cap profile (40x80L) 8Units
B4 Rubber feet 4Units
B5 Handle M8x20 2Units
B6 Slot 8 nut (M6) 20 Units
B7 Slot 8 nut (M8) 50 Units
B8 Bolt - DIN 912 (Galvanised, 16mm, M8) 20 Units
B9 Bolt - DIN 912 (Galvanised, 20mm, M6) 4Units
B10 Bolt - DIN 7991 (Black steel, 20mm, M8) 30 Units
B11 Nut (M8, DIN 985 locknut, Galvanised) 8Units
B12 Bolt - DIN 912 (Black steel, 25mm, M8) 4Units
B13 Bolt - DIN 912 (Black steel, 20mm, M8) 10 Units
B14 Bolt - DIN 912 (Black steel, 16mm, M6) 4Units
B15 Plastic sleeve black (10mm) 2Units
B16 Simlab sticker TR1 1Units
Pedal frame
B17 GT2 Pedal deck triangle set (Left and Right) 1Units
B18 Profile 40mm slot 8 (Black, 40x40L) - Threaded 500mm 2Units
B19 Profile 40mm slot 8 (Black, 40x40L) - 420mm 3Units
B20 Corner Bracket 40x40 10 Units
B21 Cover cap for corner bracket 40x40 10 Units
B22 End cap profile (40x40L) 2Units
B23 Joint 40 2Units
B24 Slot 8 nut (M8) 34 Units
B25 Bolt - DIN 912 (Black steel, 20mm, M8) 2Units
B26 Slot 8 nut (M6) 12 Units
B27 Slot 8 nut (M5) 12 Units
B28 Bolt - DIN 912 (Black steel, 16mm, M6) 12 Units
B29 Bolt - DIN 912 (Black steel, 16mm, M5) 12 Units
B30 Bolt - DIN 912 (Galvanised, 16mm, M8) 12 Units
Front mount set
B31 GT2 Front mount set (Front + Lef + Right plate) 1Units
B32 Connector bracket 40x40 4Units
B33 Cover cap for connector bracket 40x40 4Units
B34 Bolt - DIN 912 (Black steel, 20mm, M6) 4Units
B35 Bolt - DIN 912 (Black steel, 20mm, M8) 6Units
B36 Bolt - DIN 912 (Black steel, 40mm, M8) 4Units
B37 Spacer - male / female (10mm, M6) 4Units
B38 Nut (M8, DIN 985 locknut, Galvanised) 12 Units
B39 Washer (Black steel, M8, Plain black) 4Units
B40 Slot 8 nut (M8) 4Units
B41 Bolt - DIN 7991 (Black steel, 30mm, M8) 4Units
B42 Bolt - DIN 7991 (Black steel, 25mm, M8) 4Units
B43 TR1/GT2 Brace 1Units
B44 GT2 45 degree bracket set (Left + Right) 1Units
