Ericsson EDACS M-RK I User manual

LBI-38733B
EDACSM-RK I
PORTABLE RADIO
Operator’s Manual

TTAABBLLEE OOFF CCOONNTTEENNTTSS
INTRODUCTION . . . . . . . . . . . . . . . . 5
CONTROLS AND INDICATORS . . . . . . . . 7
BUTTONS AND KNOBS . . . . . . . . . . 9
INDICATORS . . . . . . . . . . . . . . . . 12
UNIVERSAL DEVICE CONNECTOR (UDC) 13
ALERT TONES . . . . . . . . . . . . . . . 13
Call Originate . . . . . . . . . . . . . . . 13
Autokey(Trunked Mode Only) . . . . . . . 13
Call Queued (Trunked Mode Only) . . . . 14
System Busy (Trunked Mode Only) . . . . 14
Call Denied (Trunked Mode Only) . . . . . 14
CarrierControlTimer . . . . . . . . . . . 15
Low Battery Warning . . . . . . . . . . . 15
Low Battery Alert . . . . . . . . . . . . . 15
KeyPress Alert . . . . . . . . . . . . . . 16
OPERATION . . . . . . . . . . . . . . . . . . 16
TURNING ON THE RADIO . . . . . . . . . 16
SYSTEM/GROUP/CHANNEL SELECTION 16
TRUNKED MODE OPERATION . . . . . . 17
Receiving A Call . . . . . . . . . . . . . 17
Sending A Call . . . . . . . . . . . . . . 18
Emergency Operation . . . . . . . . . . 19
Wide Area System Scanning . . . . . . . 20
ScanningTrunkedGroups . . . . . . . . 21
Copyright© January 1993, Ericsson GE Mobile Communications Inc.
This manual is published by Ericsson Inc. without any warranty.
Improvements and changes to this manual necessitated by typo-
graphical errors, inaccuracies of current information, or improvements
to programs and/or equipment, may be made byEricsson Inc. at any
time and without notice. Such changes will be incorporated into new
editions of this manual. No part of this manual may be reproduced or
transmitted in any form or by any means, electronic or mechanical,
including photocopying and recording, for any purpose, without the
express written permission of Ericsson Inc.
22

TTAABBLLEE OOFF CCOONNTTEENNTTSS ((CCOONNTT))
SPECIAL CALLS . . . . . . . . . . . . . . . 23
Receiving And Responding To A Special Call 23
Initiating And Sending A Special Call . . . . 24
CONVENTIONAL FAILSOFT . . . . . . . . 25
CONVENTIONAL MODE OPERATION . . . 26
Receiving A Call . . . . . . . . . . . . . . 26
Sending A Call . . . . . . . . . . . . . . . 27
Emergency Operation . . . . . . . . . . . 28
Scanning Conventional Channels . . . . . . 29
AEGIS AND VOICE GUARD OPERATION . . . 31
VOICE MODES . . . . . . . . . . . . . . . . 31
Clear Modes . . . . . . . . . . . . . . . . 33
Aegis Digital Modes . . . . . . . . . . . . 33
Aegis Private And Voice Guard
Private Modes . . . . . . . . . . . . . . . 34
TRANSFERRING KEYS INTO THE RADIO . 35
KEY ZERO . . . . . . . . . . . . . . . . . . 36
PRIVATE OPERATION . . . . . . . . . . . . 36
Receiving An Encrypted Call . . . . . . . . . 36
Transmitting An Encrypted Call . . . . . . . . 37
Scanned Group Calls . . . . . . . . . . . . . 37
PORTABLE DATA OPERATION . . . . . . . . . 38
Data Off Operation . . . . . . . . . . . . . . 38
Data On Operation . . . . . . . . . . . . . . 39
Exiting Data Calls . . . . . . . . . . . . . . . 39
STATUS/MESSAGE OPERATION . . . . . . . . 40
Status Operation . . . . . . . . . . . . . . . 40
Message Operation . . . . . . . . . . . . . . 41
EDACS CONVENTIONAL P1 SCAN . . . . . . 41
DYNAMIC REGROUP OPERATION . . . . . . . 41
Emergency Operation . . . . . . . . . . . . 42
MACRO KEY OPERATION . . . . . . . . . . . 43
OPERATING RULES AND REGULATIONS . . . 43
33

TTAABBLLEE OOFF CCOONNTTEENNTTSS ((CCOONNTT))
OPERATINGTIPS . . . . . . . . . . . . . . . 45
BATTERY PACKS . . . . . . . . . . . . . . . 46
CHARGING THE BATTERY PACK . . . . . 46
RECHARGEABLE BATTERY PACK
DISPOSAL . . . . . . . . . . . . . . . . . 47
INSTALLING THE BATTERY PACK . . . . . 47
REMOVING THE BATTERY PACK . . . . . 47
INTRINSICALLY SAFE USAGE . . . . . . . . 49
BATTERY PACKS . . . . . . . . . . . . . . 49
GLOSSARY . . . . . . . . . . . . . . . . . . 50
RADIO PROGRAMMING . . . . . . . . . . . 54
WARRANTY . . . . . . . . . . . . . . . . . . 58
NICKEL-CADMIUM BATTERY WARRANTY . . 59
44

IINNTTRROODDUUCCTTIIOONN
This manual describes the operation of the Ericsson
GE EDACS

M-RK l portable radio. The M-RK l is a
synthesized, microprocessor-based, high-performance
portable FM radio providing reliable two-way communi-
cations for Enhanced Digital Access Communications
System (EDACS) trunking environments and conven-
tional communication systems.
In the EDACS or trunked system mode the user
selects a communications system and group. In this
mode, radio channel selection is transparent to the user;
it is controlled by digital communication with the EDACS
site equipment. This provides advanced programmable
features and fast access to communication channels.
In conventional mode, the user selects a radio chan-
nel and directly communicates on that channel. In this
mode, a system refers to a set of channels.A channel is
a transmit/receive radio frequency pair.
The radio’s exact operation will depend on its current
operating mode, its programming, and the particular
radio system. Many features described in this manual
can be enabled or disabled through programming.Con-
sult the system administrator for the particular features
that are programmed into the M-RK l.
55

Battery
Battery latch
Push-To-Talk
(PTT) button
SYSTEM/GROUP/
CHANNEL knob
POWER ON-OFF/
VOLUME knob
Microphone
CLEAR/MONITOR
button
OPTION button
Antenna
EMERGENCY
button
Indicators
Universal
Device
Connector
(UDC)
Speaker
Figure 1- EDACS M-RK 1 Portable Radio
66

CCOONNTTRROOLLSS AANNDD IINNDDIICCAATTOORRSS
M-RK l operating controls are located on the top and
side panels of the radio. The top panel houses a rotary
SYSTEM/GROUP/CHANNEL knob, a POWER ON-
OFF/VOLUME control knob and a protected red EMER-
GENCY button. Controls located on the left side panel
(viewed from front) include an OPTION button, a
CLEAR/MONITORbuttonanda Push-To-Talk(PTT)but-
ton. The Universal Device Connector (UDC) is located
on the right side panel (viewed from front). This connec-
tor is utilized for accessory connections. It is also used
by the maintenance personnel when the radio is pro-
grammed.
The speaker, microphone and three (3) illuminating
indicators are located on radio’s front panel. These indi-
catorslight-uptoshowvariousoperatingconditionssuch
as transmitter on, channel busy, scanning, or a low
battery.
77

Figure 2 - Top And Side Panel Views
88

BBUUTTTTOONNSS AANNDD KKNNOOBBSS
This section describes the basic functions of the
button and knob controls.
SYSTEM/
GROUP/
CHANNEL
KNOB
This 16-position rotary control is primarily
used to select the systems and groups or
conventionalradiochannelsprogrammed
intotheradio.Iftheradioisprogrammedto
makespecialcalls,thisknobisalsousedto
select the programmed special calls.
Special calls include trunked mode
individualcallsandtelephoneinterconnect
calls. See the ’OPERATION’ section for
specificdetails.
POWER
ON-OFF/
VOLUME
KNOB
This control provides power and volume
controlfortheradio.
Rotating the control clockwise out of the
detentpositionappliespowertotheradio.At
powerup,theradiowillbeepifthepower-up
alert tone is programmed on (enabled).
Thisbeepindicatestheradioisoperational.
Rotating this control clockwise increases
volume and counter-clockwise rotation
decreasesvolume.Minimumvolumelevels
canbeprogrammedintotheradiotoprevent
missedcallsduetoalowvolumesetting.
99

EMER-
GENCY
BUTTON
TheEMERGENCYbuttonprovidesinstant
emergency channel access when it is
pressed.
There are raised bars on each side that
protect it fromaccidental activations. See
the "Emergency Operation" sections in
the "TRUNKED MODE OPERATION" or
the ’CONVENTIONAL MODE OPERA-
TION"sectionsforspecificdetails.
OPTION
BUTTON Thisbuttoncanbeprogrammedtoprovidea
toggle feature or to enable special call
mode.
IftheOPTIONbuttonisprogrammedfora
toggle feature, pressing it will toggle the
programmedfeaturebetweentwodifferent
states (for example: on and off).
The toggle features that can be
programmed are: scan on/off, sys-
tem/group/channel bank 1/2, repeater
talkaround on/off, data on/off, Pri-
vate/clear, status on/off, message on/off,
P1 Conv.Scan on/off, and transmitoutput
power high/low. The button can only
providetoggleofonefeature.
Trunked mode individual calls, and
telephone interconnect calls are special
callsthatcanbeprogrammedintotheradio.
If the OPTlON button is programmed to
enable special call mode, the particular
specialcallmustfirstbeselectedusingthe
1100

SYSTEM/GROUP/CHANNEL knob.
Thespecialcallistheninitiatedbypressing
the OPTION button and then the PTT
button.
CLEAR/
MONITOR
BUTTON
This button serves several purposes
dependingontheoperatingmode.
IftheCLEAR/MONITORbuttonispressed
whentheradioisoperatingintrunkedmode,
theradiowillexitthecurrentoperationand
returntothegroupreceivemode.
IftheCLEAR/MONITORbuttonispressed
when the radio is operating on a
conventional channel the receiver will
unmute (unsquelch) so activity on the
selected channel can be monitored.
Holding the button depressed for
approximatelythree(3)secondswilltoggle
tone decoding (Channel Guard, Digital
Channel Guard) programmed for the
selected channel on,- and off Selecting a
new conventional channel will turn the
decode function on if it was previously
turnedoff.
PUSH-TO-
TALK
BUTTON
Pressing this button enables the’ ’radio’s
(PTT) transmitter.Releasing it returns the
radiotoreceivemode.
1111

IINNDDIICCAATTOORRSS
The three(3)indicatorson thefrontpanel oftheradio
light-up to show various operating conditions such as
transmitter on, channel busy, scanning, or a low battery.
Each indicator can flash or light continuously (not flash)
in different color combinations to indicate various modes
as defined in Table 1.
TABLE 1 - Indicators
OPERATING CONDITION INDICATOR CONDITION COLOR
Transmitting TX/BAT Continuous Red
Battery Low Warning TX/BAT Flashes Red
Busy BSY/SCN Continuous Green
Call Queued * BSY/SCN Flashes Green
Scanning BSY/SCN Flashes Red
BankSelect Enabled OPT Flashes Green
Talkaround Enabled OPT Flashes Green
Special Call Enabled* OPT Continuous Green
High Power Transmit On OPT Flashes Green
Emergency Transmit Enabled OPT Continuous Red
Emergency Receive Enabled* OPT Flashes Red
Private OPT Flashes Green
No Data* OPT Flashes Green
Status/Message OPT Flashes Green
Conv.P1 Scan OPT Flashes Green
*Trunked Mode Only
1122

UUNNIIVVEERRSSAALL DDEEVVIICCEE CCOONNNNEECCTTOORR ((UUDDCC))
The UDCprovidesconnectionsforexternalaccesso-
ries such as a headset or a speaker-microphone. When
the radio is locked in a vehicular charger/repeater the
UDC provides the audio and control connections be-
tween the radio and the vehicular charger/repeater The
UDC is also used to program the radio.
AALLEERRTT TTOONNEESS
The M-RK l radio alsoprovides audible alert tones or
"beeps’ to indicate various operating conditions. Alert
tones can be enabled or disabled through programming.
CCaallll OOrriiggiinnaattee
A short mid-pitched alert tone sounds after keying
the radio (afterpressing the PTTbutton).At this time, the
TX/BAT indicator lights red and, in trunked mode, the
BSY/SCN indicator lights green.This indicates the radio
has been assigned a workingchannelor it is transmitting
on a conventionalchannel and voice communication can
begin immediately. In conventional mode, this alert tone
may be delayed slightly after PTT activation due to
GE-STAR signalling if GESTAR is enabled through pro-
gramming.
AAuuttookkeeyy ((TTrruunnkkeedd MMooddee OOnnllyy))
The site calls the radio when a channel becomes
available after a call is placed in queue or if the PTT
button is released prior to a working channel assignment
1133

At this point, the radio automatically keys the transmitter
(autokey) for a short period to hold the channel and it
sounds a mid-pitched tone when it is clear to talk. The
operator should immediately press the PTT button to
keep the assigned channel.
CCaallll OOuueeuueedd ((TTrruunnkkeedd MMooddee OOnnllyy))
A high-pitched tone will sound and the BSY/SCN
indicator will flash green if a call request is placed in
queue after PTT activation. The receiving unit(s) also
hearthetoneto notifythemthatacallshouldbe received
shortly. If the PTT button is released when a call is
queued, the radio will autokey whenever a channel be-
comes available (see "Autokey").
SSyysstteemm BBuussyy ((TTrruunnkkeedd MMooddee OOnnllyy))
Three (3) low-pitched beeps will sound if the radio is
keyed when the system is busy, if no channels are
available for sending the message, if the call queue is
full, or if an individual call is being attempted to a radio
that is transmitting. Release the PTT button and re-key
the radio to re-initiate the call request.
CCaallll DDeenniieedd ((TTrruunnkkeedd MMooddee OOnnllyy))
A low-pitched tone will sound at PTT activation if the
radio is not authorized to operate on the currently se-
lected system.
1144

CCaarrrriieerr CCoonnttrrooll TTiimmeerr
If the programmed time for continuous transmission
is exceeded, five (5) short high-pitched alert tones fol-
lowed by a long low-pitched alert tone will sound. The
transmitter will shut down shortly after hearing the alert
tones and the TX/BAT indicator will turn off Communica-
tion is interrupted.Release and re-key the PTT button to
maintain communications.This will reset the carrier con-
trol timer and turn the transmitter back on.
LLooww BBaatttteerryy WWaarrnniinngg
If the battery pack’s charge is/becomes low, a low-
pitchedtonewillsoundandtheTX/BATindicatorwillflash
red. The radio will continue to receive and transmit nor-
mally however, the battery pack should be charged or
replaced as soon as possible.If the radio is keyed during
this time, the TX/BAT indicator will lightcontinuously (not
flash) to indicate the radio is transmitting.
LLooww BBaatttteerryy AAlleerrtt
If the battery pack’s charge is too low to allow the
radiototransmit(usuaIlyaftera lowbatterywarning),the
radio will sound a low-pitched tone, (continue to) flash
the TX/BAT indicator red and disabIe any transmission.
The radio will continue to receive calls until the battery
pack is discharged beyond the point of operation.
1155

KKeeyy PPrreessss AAlleerrtt
A short low-pitched alert tone will sound if no action
is taken when a button is pressed. For example, if the
currentIy selected conventional channel has the channel
busy transmit lockout feature enable and the radio is
keyed when the channel is busy the radio will sound this
low-pitched alert tone to warn the operator that no trans-
mission is occurring.
OOPPEERRAATTIIOONN
TTUURRNNIINNGG OONN TTHHEE RRAADDIIOO
Be fore turning the radio on, verify the antenna and
battery pack are properly connected.To turn the unit on,
rotate the POWER ON-OFF/VOLUME knob clockwise
out of the detent position. If enabled through program-
ming, a short beep will sound to indicate the radio is
operational. The radio will begin operation on the cur-
rently selected system/group or channel.
SSYYSSTTEEMM//GGRROOUUPP//CCHHAANNNNEELL SSEELLEECCTTIIOONN
The M-RK l is programmed withone of the following
system/group/channel selection methods:
•
The radio is programmed with up to sixteen (16)
different system/group or channels that are selected
with the SYSTEM/GROUP/CHANNEL knob.Radios
programmed in this manner use the OPTION button
1166

to provide a toggle feature or to enable special call
mode.
•
The radio is programmed with up to thirty-two (32)
different system/group or channels selected in two
(2) different banks of sixteen (16). If programmed in
this manner, the OPTION button is used to toggle
between the two banks and then the SYS-
TEM/GROUP/CHANNEL knob is rotated to select
thesystem/grouporchannel.Nospecialcalls canbe
initiated by a radio programmed in this manner
TTRRUUNNKKEEDD MMOODDEE OOPPEERRAATTIIOONN
Digital trunking provides fast communicationaccess.
In this mode the operator selects a communications
system andgroupand theaudio communicationchannel
(working channel) is automatically allocated by the
EDACS site.
RReecceeiivviinngg AA CCaallll
1. Turn the radio on by rotating the POWER ON-
OFF/VOLUME knob clockwise out of the detent posi-
tion. Adjust the volume to an approximate mid-range
position.
2. Select the desired system and group using the SYS-
TEM/GROUP/CHANNEL knob in accordance with
the radio’s programming. The radio is now ready to
receive group and individuaI calls.
1177

3. When a Call is received, the radio will unmute (un-
squelch) on the assigned working channel and the
BSY/SCN indicator will light-up green. Adjust the
volume as necessary.
4. GROUP CALL - If the call is a group caIl and a repIy
is necessary, follow the instructions outlined in the
section entitled "Sending A Call" (Steps 2 - 3).
INDIVIDUAL CALL - An individual call is a call di-
rected to only one radio. The radio may be pro-
grammed to ring when it receives a call of this type.If
not answered, the ring will continue until the call-back
hangtime (programmable) expires.
Responding to an individualcalIprior tothe call-back
hangtime time-out will automatically direct the call to
the originating unit on an individual basis. The OPT
indicator lights green during the call-back hangtime.
See the section entitled "SPECIAL CALLS" for ad-
ditional details on individual calls.
SSeennddiinngg AA CCaallll
1. Turn the radio on and set the desired volume level
Select the desired system and group in accordance
with the radio’s programming.
2. Press and hold the PTT button.The radiowill perform
signallingrequiredtoobtainaworkingchannel.When
transmitting, it will light the TX/BAT indicator red.
When the working channel is assigned, the radio will
sound the short mid-pitched call originate aIert tone
1188

and light the BSY/SCN indicator green.If two or more
tones, or a high-pitched tone is heard, the system is
busy and the call request has been placed in queue
or the request has been denied.Refer to the"ALERT
TONES" section for details.
3. After the call originate alert tone sounds, hold the
radio approximately three (3) inches from the mouth
and speak in a normal voice into the microphone.
Release the PTT button when the transmission is
complete and listen for a reply.
EEmmeerrggeennccyy OOppeerraattiioonn ((TTrruunnkkeedd MMooddee))
The radio’s ability to declare an emergency to clear
an emergency and to remain locked on an emergency
group, can each be enabled or disabled through pro-
gramming.
RReecceeiivviinngg AAnn EEmmeerrggeennccyy CCaallll
The radio will sound an alert beep and flash the OPT
indicator red when an emergency call on the selected
system and group is received. Follow standard emer-
gency procedures.
DDeeccllaarriinngg AAnn EEmmeerrggeennccyy CCaallll
Todeclareanemergency callon theselected system
and group or on a preprogrammed (optional) emergency
group, proceed as follows:
1.
1199

Press and hold the red EMERGENCY button on the
top of the radio for approximately one second. This
time is programmable and therefore could be longer
or shorter - check with the system administrator If the
radio is scanning when an emergency is declared, it
will Stop scanning until the emergency is cleared.
2. When the working channel is assigned, the radio
sounds a single beep (Autokey alert tone), the OPT
indicator lights red, the TX/BAT indicator lights red
and the BSY/SCN indicator lights green. This indi-
cates the radio is ready for voice transmissions. The
OPT indicator will remain lit until the emergency is
cleared.
3. Press the PTT button and speak into the microphone
in a normal voice.The TX/BAT indicator will continue
to light red as the radio is transmitting.
4. Release the PTT button when the transmission is
complete and listen for a reply
CClleeaarriinngg AAnn EEmmeerrggeennccyy CCaallll
If the radio has supervisor privileges (enabled
through programming) an emergency can be cleared by
pressing and holding the CLEAR/MONlTOR button fol-
lowed by pressing the EMERGENCY button, and then
releasing both buttons.
2200
