ESAB ET 210iP Advanced User manual

Renegade
ET 210iP Advanced
Instruction manual
0463 859 001  GB  20230314 Valid for: OP241-YYXX-XXXX

TABLE OF CONTENTS
0463 859 001 -4- © ESAB AB 2023
1 SAFETY ...................................................................................................................................... 5
1.1 Meaning of symbols .................................................................................................... 5
1.2 Safety precautions ..................................................................................................... 5
2 INTRODUCTION ......................................................................................................................... 9
2.1 Equipment.................................................................................................................... 9
3 TECHNICAL DATA ..................................................................................................................... 10
3.1 ECO design information ............................................................................................. 12
4 INSTALLATION........................................................................................................................... 13
4.1 Location........................................................................................................................ 13
4.2 Lifting instructions ...................................................................................................... 14
4.3 Mains supply................................................................................................................ 14
5 OPERATION ............................................................................................................................... 16
5.1 Connections and controls .......................................................................................... 16
5.2 Connecting welding and return cables ..................................................................... 17
5.3 Connect to cooler EC 1001 ......................................................................................... 17
5.4 Fan control................................................................................................................... 18
5.5 Thermal protection ...................................................................................................... 18
5.6 Control panel ............................................................................................................... 18
5.6.1 How to navigate.................................................................................................. 18
5.7 Information screen ...................................................................................................... 19
5.8 Settings screen............................................................................................................ 19
5.9 Remote screen............................................................................................................. 21
5.10 Jobs screen ................................................................................................................. 21
5.11 Welding screen ............................................................................................................ 22
5.12 MMA welding................................................................................................................ 22
5.12.1 MMA/Stick Home screen.................................................................................... 22
5.12.2 MMA/Stick Menu screen .................................................................................... 23
5.13 TIG welding .................................................................................................................. 24
5.13.1 TIG Home screen ............................................................................................... 25
5.13.2 TIG Menu screen................................................................................................ 26
5.14 Foot pedal functions explanation .............................................................................. 32
6 MAINTENANCE.......................................................................................................................... 34
6.1 Routine maintenance .................................................................................................. 34
6.2 Cleaning instruction.................................................................................................... 35
7 TROUBLESHOOTING ................................................................................................................ 38
8 CALIBRATION AND VALIATION ............................................................................................... 39
8.1 Measurement methods and tolerances ..................................................................... 39
8.2 Requirements specifications and standards ............................................................ 39
9 ERROR CODES.......................................................................................................................... 40
9.1 Error code descriptions .............................................................................................. 40
10 ORDERING SPARE PARTS ....................................................................................................... 41
WIRING DIAGRAM ................................................................................................................................ 42
ORDERING NUMBERS ......................................................................................................................... 43
ACCESSORIES ..................................................................................................................................... 44

1  SAFETY
0463 859 001 -5- © ESAB AB 2023
1 SAFETY
1.1 Meaning of symbols
As used throughout this manual: Means Attention! Be Alert!
DANGER!
Means immediate hazards which, if not avoided, will result in immediate, serious
personal injury or loss of life.
WARNING!
Means potential hazards which could result in personal injury or loss of life.
CAUTION!
Means hazards which could result in minor personal injury.
WARNING!
Before use, read and understand the instruction manual and
follow all labels, employer´s safety practices and Safety Data
Sheets (SDSs).
1.2 Safety precautions
Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or
near the equipment observes all the relevant safety precautions. Safety precautions must meet the
requirements that apply to this type of equipment. The following recommendations should be observed
in addition to the standard regulations that apply to the workplace.
All work must be carried out by trained personnel well-acquainted with the operation of the equipment.
Incorrect operation of the equipment may lead to hazardous situations which can result in injury to the
operator and damage to the equipment.
1. Anyone who uses the equipment must be familiar with:
• its operation
• location of emergency stops
• its function
• relevant safety precautions
• welding and cutting or other applicable operation of the equipment
2. The operator must ensure that:
• no unauthorised person is stationed within the working area of the
equipment when it is started up
• no-one is unprotected when the arc is struck or work is started with the
equipment
3. The workplace must:
• be suitable for the purpose
• be free from drafts

1  SAFETY
0463 859 001 -6- © ESAB AB 2023
4. Personal safety equipment:
• Always wear recommended personal safety equipment, such as safety
glasses, flame-proof clothing, safety gloves
• Do not wear loose-fitting items, such as scarves, bracelets, rings, etc.,
which could become trapped or cause burns
5. General precautions:
• Make sure the return cable is connected securely
• Work on high voltage equipment may only be carried out by a
qualified electrician
• Appropriate fire extinguishing equipment must be clearly marked and
close at hand
• Lubrication and maintenance must not be carried out on the equipment
during operation
If equipped with ESAB cooler
Use ESAB approved coolant only. Non-approved coolant might damage the equipment and jeopardize
product safety. In case of such damage, all warranty undertakings from ESAB cease to apply.
For ordering information, see the "ACCESSORIES" chapter in the instruction manual.
WARNING!
Arc welding and cutting can be injurious to yourself and others. Take precautions when
welding and cutting.
ELECTRIC SHOCK - Can kill
• Install and ground the unit in accordance with instruction manual.
• Do not touch live electrical parts or electrodes with bare skin, wet gloves
or wet clothing.
• Insulate yourself from work and ground.
• Ensure your working position is safe
ELECTRIC AND MAGNETIC FIELDS - Can be dangerous to health
• Welders having pacemakers should consult their physician before
welding. EMF may interfere with some pacemakers.
• Exposure to EMF may have other health effects which are unknown.
• Welders should use the following procedures to minimize exposure to
EMF:
○ Route the electrode and work cables together on the same
side of your body. Secure them with tape when possible. Do
not place your body between the torch and work cables.
Never coil the torch or work cable around your body. Keep
welding power source and cables as far away from your body
as possible.
○ Connect the work cable to the workpiece as close as possible
to the area being welded.
FUMES AND GASES - Can be dangerous to health
• Keep your head out of the fumes.
• Use ventilation, extraction at the arc, or both, to take fumes and gases
away from your breathing zone and the general area.
ARC RAYS - Can injure eyes and burn skin
• Protect your eyes and body. Use the correct welding screen and filter
lens and wear protective clothing.
• Protect bystanders with suitable screens or curtains.

1  SAFETY
0463 859 001 -7- © ESAB AB 2023
NOISE - Excessive noise can damage hearing
Protect your ears. Use earmuffs or other hearing protection.
MOVING PARTS - Can cause injuries
• Keep all doors, panels and covers closed and securely in place. Have
only qualified people remove covers for maintenance and
troubleshooting as necessary. Reinstall panels or covers and close doors
when service is finished and before starting engine.
• Stop engine before installing or connecting unit.
• Keep hands, hair, loose clothing and tools away from moving parts.
FIRE HAZARD
• Sparks (spatter) can cause fire. Make sure that there are no inflammable
materials nearby.
• Do not use on closed containers.
HOT SURFACE - Parts can burn
• Do not touch parts bare handed.
• Allow cooling period before working on equipment.
• To handle hot parts, use proper tools and/or insulated welding gloves to
prevent burns.
MALFUNCTION - Call for expert assistance in the event of malfunction.
PROTECT YOURSELF AND OTHERS!
CAUTION!
This product is solely intended for arc welding.
WARNING!
Do not use the power source for thawing frozen pipes.
CAUTION!
Class A equipment is not intended for use in residential locations
where the electrical power is provided by the public low-voltage
supply system. There may be potential difficulties in ensuring
electromagnetic compatibility of class A equipment in those
locations, due to conducted as well as radiated disturbances.
NOTE!
Dispose of electronic equipment at the recycling facility!
In observance of European Directive 2012/19/EC on Waste
Electrical and Electronic Equipment and its implementation in
accordance with national law, electrical and/or electronic
equipment that has reached the end of its life must be disposed of
at a recycling facility.
As the person responsible for the equipment, it is your
responsibility to obtain information on approved collection
stations.
For further information contact the nearest ESAB dealer.

1  SAFETY
0463 859 001 -8- © ESAB AB 2023
ESAB has an assortment of welding accessories and personal protection equipment for
purchase. For ordering information contact your local ESAB dealer or visit us on our website.

2  INTRODUCTION
0463 859 001 -9- © ESAB AB 2023
2 INTRODUCTION
Renegade ET210iPAdvanced is an inverter-based power source intended for MMA (Manual Metal
Arc), TIG (Tungsten Inert Gas) and HF TIG (High Frequency Tungsten Inert Gas) welding.
ESAB accessories for the product can be found in the "ACCESSORIES" chapter of this manual.
2.1 Equipment
RenegadeET210iPAdvanced includes:
• Power source
• Work clamp leadset
• Gas hose
• Shoulder strap
• Safety manual
• Quick setup guide

3  TECHNICAL DATA
0463 859 001 - 10 - © ESAB AB 2023
3 TECHNICAL DATA
RenegadeET210iPAdvanced
Outlet voltage 230 V ±15%,
1~ 50/60 Hz
115 V ±15%,
1~ 50/60 Hz
Primary current
Imax 26A 29A
No-load power demand when inenergy-saving
mode 27W 27W
Setting range
MMA 15-180A 15-110A
TIG 10-210A 10-140A
Permissible load at MMA
25 % duty cycle 180A / 27.2V 110A / 24.4V
60 % duty cycle 135A / 25.4V 71A / 22.8V
100% duty cycle 105A / 24.2V 55A / 22.2V
Permissible load at TIG
25 % duty cycle 210A / 18.4V 140A / 15.6V
60 % duty cycle 135A / 15.4V 90A / 13.6V
100% duty cycle 105A / 14.2V 70A / 12.8V
Apparent power I2at maximum current 6.1kVA 3.33kVA
Active power I2at maximum current 6kW 3.3kW
Power factor at maximum current
MMA 0.99
TIG 0.99
Efficiency at maximum current
MMA 83% 81%
Open-circuit voltage U0max
VRD 35 V deactivated 78V
VRD 35 V activated <30V
Operating temperature -10 to +40°C (+14 to 104°F)
Transportation temperature -20 to +55°C (-4 to +161°F)
Constant sound pressure when idling <70 db
Dimensions l × w × h 460 × 200 × 320 mm (18.1×7.9×12.6in.)
Weight 11kg (24.3lbs)
Insulation class F
Enclosure class IP 23
Application class

3  TECHNICAL DATA
0463 859 001 - 11 - © ESAB AB 2023
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or cut at a
certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.
Enclosure class
The IP code indicates the enclosure class, i.e. the degree of protection against penetration by solid
objects or water.
Equipment marked IP23 is intended for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased electrical
hazard.

3  TECHNICAL DATA
0463 859 001 - 12 - © ESAB AB 2023
3.1 ECO design information
The equipment has been designed in order to be compliant with the Directive 2009/125/EC and the
Regulation 2019/1784/EU.
Efficiency and idle power consumption:
Name Idle power Efficency when max power
consumption
Renegade ET 210iPAdvanced 27W 83%
The value of efficiency and consumption in idle state have been measured by method and conditions
defined in the product standard EN 60974-1:2012.
Manufacturer’s name, product name, serial number and date of production can be read from rating
plate.
1. Product name
2. Manufacturer's name and address
3. Serial number
3A. Manufacturing location code
3B. Revision level (last digit of year and week number)
3C. Year & week produced (last two digits of year and week number)
3D. Sequential number system (each week starts with 0001)

4  INSTALLATION
0463 859 001 - 13 - © ESAB AB 2023
4 INSTALLATION
The installation must be carried out by a professional.
CAUTION!
This product is intended for industrial use. In a domestic environment this product may cause
radio interference. It is the user's responsibility to take adequate precautions.
4.1 Location
Position the power source so that cooling air inlets and outlets are not obstructed.
A. Minimum 200 mm (8 in.)
B. Minimum 200 mm (8 in.)
WARNING!
Secure the equipment - particularly if the
ground is uneven or sloping.

4  INSTALLATION
0463 859 001 - 14 - © ESAB AB 2023
4.2 Lifting instructions
These units are equipped with a handle for carrying purposes.
WARNING!
Electric shock can kill. Do not touch live electrical parts. Disconnect input power conductors
from de-energized supply line before moving the welding power source.
WARNING!
Falling equipment can cause serious personal injury and equipment damage.
Lift the unit with handle on top of case.
4.3 Mains supply
NOTE!
Mains supply requirements
This equipment complies with IEC 61000-3-12 provided that the short-circuit power is greater
than or equal to Sscmin at the interface point between the user's supply and the public system.
It is the responsibility of the installer or user of the equipment to ensure, by consultation with
the distribution network operator if necessary, that the equipment is connected only to a supply
with a short-circuit power greater than or equal to Sscmin.
1. Rating plate with supply connection data.

4  INSTALLATION
0463 859 001 - 15 - © ESAB AB 2023
Recommended fuse sizes and minimum cable area for the Renegade ET 210iPAdvanced
Supply voltage 230VAC 115VAC
Mains cable area 2.5mm22.5mm2
Maximal current rating Imax
MMA/Stick (SMAW)
26A 29A
I1eff MMA/Stick (SMAW) 15.5A 14.5A
Fuse anti-surge type D MCB 20A 20A
Maximum recommended
extension cord length
100m (328ft) 100m (328ft)
Minimum recommended
extension cord size
2.5mm22.5mm2
Supply from power generators
The power source can be supplied from different types of generators. However, some generators may
not provide sufficient power for the welding power source to operate correctly. Generators with
Automatic Voltage Regulation (AVR) or with equivalent or better type of regulation, with rated power of
7kW are recommended.
WARNING!
If used under 115VAC input supply, the supply plug rating must be higher than 20A.

5  OPERATION
0463 859 001 - 16 - © ESAB AB 2023
5 OPERATION
General safety regulations for handling the equipment can be found in the "SAFETY" chapter
of this manual. Read it through before you start using the equipment!
NOTE!
When moving the equipment use intended handle. Never pull the cables.
WARNING!
Electric shock! Do not touch the workpiece or the welding head during operation!
5.1 Connections and controls
1. Display 7. Positive output (+)
2. Main knob for menu navigation or value
adjusments
8. Menu button
3. Back button 9. Power switch
4. Negative output (-) 10. Remote/torch control connection
5. Gas outlet 11. Cooler connection
6. Torch connection 12. Shield gas inlet

5  OPERATION
0463 859 001 - 17 - © ESAB AB 2023
5.2 Connecting welding and return cables
The power source has two outputs, a positive welding terminal (+) and a negative welding terminal (-),
for connecting welding and return cables. The output to which the welding cable is connected depends
on the welding method or type of electrode used.
Connect the return cable to the other output on the power source. Secure the return cable’s contact
clamp to the workpiece, and make sure that there is a good contact between the workpiece and the
output for the return cable on the power source.
• For TIG welding, the negative welding terminal (-) is used for the welding torch and
the positive welding terminal (+) is used for the return cable.
• For MMA welding, the welding cable can be connected to the positive welding
terminal (+) or negative welding terminal (-), depending on the type of electrode used.
The connection polarity is stated on the electrode packaging.
5.3 Connect to cooler EC 1001
NOTE!
Take care so that the interface cable does not get squeezed between the power source and
the cooling unit!
NOTE!
Power supply of the cooling unit is done from the welding power source via the connection
cable (for more information, refer to the cooling unit instruction manual).

5  OPERATION
0463 859 001 - 18 - © ESAB AB 2023
5.4 Fan control
The ET 210iPAdvanced is fitted with a fan as an additional feature. When cooling fan is not in use, the
fan will automatically turns off.
This has two advantages:
1. To minimize power consumption,
2. To minimize the amount of pollutants absorbed into the power source, such as dust.
NOTE!
When cooling requires, the fan will operate otherwise it will automatically turn off.
5.5 Thermal protection
The power source includes thermal protection against overheating. When overheating
occurs the welding is stopped an error message Error206 shows in the display. The
protection is automatically reset when the temperature has been sufficiently reduced.
5.6 Control panel
General safety regulations for handling the equipment can be found in the "Safety precautions" section
in the "SAFETY" chapter of this manual.
General information about operation can be found in the "OPERATION" chapter of this manual.
Read and follow your employer's safety practices before installing, operating, or servicing this
equipment
NOTE!
After power-ON has completed the main menu appears on the control panel.
5.6.1 How to navigate
1. Left button switch (Back button)
a) Press Back button to return to
previous screen
b) Press and hold for 3s to delete jobs
(on Jobs screen)
2. Menu navigation: turn and push to select
or change values
3. Right button switch (Menu button)
Press Menu button to direct return to
menu screen

5  OPERATION
0463 859 001 - 19 - © ESAB AB 2023
5.7 Information screen
In Information menu user can find information about wears and spares, accessories, recommended
filler metals, general maintenance and user manual QR code.
1. Information
5.8 Settings screen
Press Menu button to enter Menu screen. Turn main knob to Settings icon and press main knob to
enter settings menu screen.
1. Settings screen

5  OPERATION
0463 859 001 - 20 - © ESAB AB 2023
1. Language settings
2. Brightness settings
3. Basic/Advanced (Only TIG)
This item can be used to select basic view
or advanced view of TIG welding sequencer
in Home screen. Enter selection screen by
turn main knob and press when TIG Home
view is highlighted. Navigate between Basic
and Advanced options and confirm selection
by pressing main knob. Display will return to
menu screen.
4. Remote min. settings (the percentage of
setting Amps)
This is used to set the minimum current for
the foot pedal. It is set in % of the set
current in the range from 0–99% in steps of
1%.
For example: If the current is set to 100A
and the remote min current function is set to
20, the remote min current will be 20A. If
the current is set to 80A and the remote min
current function is set to 50, the remote min
current will be 40A.
Enter adjustment screen by pressing main
knob when Remote min. level is highlighted
and turn main knob to adjustment
percentage value as displayed. Confirm
settings by pressing main knob and display
will return to menu screen.
5. Trigger job shift ON/OFF (Only TIG)
Trigger job setting is used to recall stored
jobs when machine is on, but arc is not
ignited. This function permits changing
between different welding data memories by
pressing the trigger of the welding torch.
User can select one of the first three jobs
positions and to recall, trigger needs to be
pressed number of times equal to job
location (example to recall job #2 quick
press trigger twice).
User can turn ON or OFF trigger job shift
function by pressing main knob when this
item is highlighted.
6. Cooler ON/OFF (Only TIG)
7. Reset setting
8. About (software version)
