Esco 70134 User manual
Equipment Supply Company
Instruction Manual
HD Adjustable Wheel Dolly
ESCO #70134
Copyright © 2019 Equipment Supply Co., All rights reserved
REV.11.19.A
21.800.352.9852 • [email protected] • www.esco.net
ESCO HD Adjustable Wheel Dolly Model #70134
REV.11.19.A
CAUTION:
THIS PRODUCT, AS WELL AS ALL TIRE TOOLS, SHOULD NEVER
BE USED BY PERSONS UNLESS THEY HAVE BEEN TRAINED
PROPERLY ACCORDING TO OSHA REGULATIONS 29CFR
1910.177 ENTITLED “SERVICING SINGLE-PIECE &
MULTIPIECE RIM WHEELS”.
FOR THE SAFE USE OF THIS PRODUCT, PLEASE READ
INSTRUCTIONS. FAILURE TO DO SO CAN LEAD TO A VOID IN
WARRANTY OR SERIOUS INJURY. PLEASE USE THIS TOOL AND
OTHER TIRE SERVICE TOOLS WITH THE UPMOST SAFETY
PRECAUTIONS.
Product Description
The HD Adjustable Wheel Dolly [Model #70134] is designed to assist service
technicians as they move through the tire/wheel service process. Its light-
weight, portable, and adjustable design makes it an ideal tire dolly for any
service shop. This tire dolly completely eliminates the need to lift and move
any large and heavy wheels by easily rolling the unit up to the wheel and
rolling it away and onto the vehicle. In addition to saving on labor and time,
using the wheel dolly will also allow for saving an accidental damage to
expensive rim while servicing.
Before using the product, carefully read the instructions manual and all
stickers and warnings noted on the product. This is necessary to avoid
injury to the operator and damage to the product.
3
ESCO HD Adjustable Wheel Dolly Model #70134
REV.11.19.A
Product Specications
Lifting Capacity: 330 lbs. | 150 kg
Tire Diameter: 23.5” - 43.5” | 597 mm - 1105 mm
Roller Spread: 12” - 24” | 304 mm - 609 mm
Length: 47” | 1193 mm
Width: 27.5” | 698 mm
Weight: 27 lbs. | 12.7 kg
RECOMMENDED PRODUCTS
#10390 #10802 #10803 #90518-100-KIT
41.800.352.9852 • [email protected] • www.esco.net
ESCO HD Adjustable Wheel Dolly Model #70134
REV.11.19.A
BEFORE USE:
• Before use of this tool please verify that the application of this tool is
compatible. For more information about this tool or any other tools
• Assemble product according to parts breakdown and assembly
provided.
• Read the entire operation manual including warnings before any use
of this tool.
• Always inspect the tool before use to ensure it is working properly. If
rollers do not roll smoothly, DO NOT put into service. Contact the
manufacturer or an authorized distributor of ESCO product and parts
for replacement parts or consultation.
OPERATION:
• Follow the vehicle manufacturer’s recommended removal and
installation procedures for tire, wheel or hub.
• After the tire/wheel assembly has been loosened from the hub or axle
and is ready to be removed, position the TIRE WHEEL DOLLY under
the tire to be removed. Adjust cart position such that the tire/wheel
assembly will balance between rollers without falling.
PLACING TIRE ON WHEEL DOLLY:
REMINDER: DO NOT EXCEED WEIGHT CAPACITY OF TIRE WHEEL DOLLY
• NEVER use the TIRE WHEEL DOLLY as a wheel pulling device. Before
transporting wheel assembly, ensure that it is free from the hub or drum
assembly and balanced between the rollers.
• When the weight of the loosened tire and wheel assembly is supported
by the TIRE WHEEL DOLLY, cautiously roll the TIRE WHEEL DOLLY
away from the drum or axle.
5
ESCO HD Adjustable Wheel Dolly Model #70134
REV.11.19.A
When using the TIRE WHEEL DOLLY ALWAYS use two-hands.
(See Figure 1 for example)
Figure 1 - Always Use Both Hands
MOVING TIRE ON TIRE WHEEL DOLLY:
1. Make sure the tire is properly centered on the rollers of the TIRE
WHEEL DOLLY.
2. When wheel assembly has cleared the hub or the axle, push or pull
to desired location. Walk slowly, exercise caution and look ahead to
avoid obstacles while using both hands to control the tire and the TIRE
WHEEL DOLLY.
61.800.352.9852 • [email protected] • www.esco.net
ESCO HD Adjustable Wheel Dolly Model #70134
REV.11.19.A
#70134 Parts Breakdown
Item Description QTY Item Description QTY
1 Hand Sleeve 1 13 Bushing 4
2 Rear Handle 1 14 Screw 4
3 Bolt 1 15 Wheel 2
4 Spring Washer 3 16 Lock Nut 4
5 Wing Nut 3 17 Snap Pin 2
6 Front Handle 1 18 Axle 2
7 Screw 1 19 Spring Pin 2
8 Bushing 1 20 Ball Bearing 4
9 Wheel 4 21 Roller 2
10 Washer 1 22 Washer 2
11 Bolt 2 23 Spring Pin 2
12 Base Frame 1 24 Bushing 2
#70134 Replacement Part Numbers
REV.11.19.A
7
ESCO HD Adjustable Wheel Dolly Model #70134
REV.11.19.A
GUARANTEED 1 Day Turnaround Service.
Received by ESCO - Repaired in 24 Hours - Returned to You!
XESCO will pick up product for repair/warranty at your location.
XESCO will guarantee Repair/Service for 30 days.
XESCO has rental tools available
XESCO repairs IMT, FEC, Stellar, Blackhawk, OTC, Power Team, Ame Int., & Enerpac hydraulic
pumps, bead breaker, and cylinders.
XAuthorized ESCO Repair & Warranty Centers Located through the US & Canada. For more informa-
tion contact your ESCO sales representative.
XTechnical Support Over the Phone Available by Calling 1-800-352-9852
Prompt, reliable service after the sale is very important to ESCO. ESCO maintains an
in-house repair facility in Brooksville, Florida. To insure that our customers have as little
down-time as possible, we offer a 1 day turnaround service. Our factory repair service is equipped with all the
tools and machinery needed to repair your equipment quickly and affordably. Our trained technicians are the
best in the industry. Not only do we service our own products, but we also service our competitors’ products.
In addition to ESCO’s 30 years of providing quality repair service, ESCO has reached out and partnered with
more than 50+ hydraulic repair facilities across the US & Canada, to deliver quality repair and timely return of
products. Visit www.esco.net or call 1.800.352.9852 to hear more about the newly added “Authorized ESCO
Warranty & Repair Facilities” across the US.
If you have a bead breaker, ram, or hydraulic pump that needs repair, ESCO xes your
product with factory parts and guarantees the repair. In addition to servicing ESCO brand products, we also re-
pair CP, IMT, Elrick, Branick, Goodyear, FEC, Ame Int., and Haltec lines of hydraulic bead breakers, rams, pumps,
jacks, and many other hydraulic tire service equipment.
