ESI ES1247 Operating instructions

ES1247
1 Channel Programmer
User and Installaon
Instrucons

What is a Channel Programmer? 1
Introducon to the 1 Channel Programmer 2
Programming the Unit- The Factory-set Programme 3
- Changing the Programme 4
Operang the Unit - Choosing the Operang Mode 5
- Using the Advance Funcon 6
- Using the +HR Boost Funcon 7
Basic Sengs - Seng the Time & Date 8
- Seng the Backlight 9
- Reseng the Unit 9
- Power Interrupon 9
INDEX
User Instrucons

Installaon Instrucons
Technical Data 10
Installaon Safety Instrucons, Maintenance & Safety Noce 11
Pre-Installaon Unit Set Up 12
Fing the Back Plate 12
New Installaons 13
Exisng Installaons 13
Wiring Diagram 14
Fing the Programmer 15
Commissioning 15
Configuraon 16
INDEX

User
Instrucons
Technical Data 10
Installaon Safety Instrucons, Maintenance & Safety Noce 11
Pre-Installaon Unit Set Up 12
Fing the Back Plate 12
New Installaons 13
Exisng Installaons 13
Wiring Diagram 14
Fing the Programmer 15
Commissioning 15
Configuraon 16

What is a Channel Programmer?...
An explanaon for householders
On some programmers you must also set whether you want the
Heang and Hot Water to run connuously, run under the chosen
‘On’ and ‘Off’ heang periods, or be permanently off. The me on
the programmer must be correct. Some types have to be adjusted in
Spring and Autumn upon the changes between Winter and Summer
me.
You may be able to temporarily adjust the heang programme, for
example, ‘Override’,‘Advance’ or ‘Boost’. These are explained in the
manufacturer’s instrucons. The heang will not work if the room
thermostat has switched the heang off. And, if you have a Hot
Water cylinder, the water heang will not work if the cylinder
thermostat detects that the Central Hot Water has reached the
correct temperature.
1
Programmers allow you to set ‘On’ and ‘Off’ me
periods. Some models switch the Central Heang and
domesc Hot Water on and off at the same me, while
others allow the domesc Hot Water and Heang to come on and
go off at different mes. Set the ‘On’ and ‘Off’ me periods to suit
your own lifestyle.

What is a Channel Programmer?...
An explanaon for householders
Introducon to the 1 Channel Programmer
This programmer can automacally switch your Central Heang or
Hot Water ON and OFF up to 3 mes a day, at whatever mes you
choose. Timekeeping is maintained through power interrupons
by a non replaceable baery designed to last for the lifeme of the
programmer and the clock is automacally put forward 1 hour at
1:00am on the last Sunday of March and back 1 hour at 2:00am on
the last Sunday of October. The clock is factory pre-set to UK me
and date, but you can alter it if you wish. During installaon, the
installer selects 24 hour, or 5 day/ 2day, or 7 day programming and
2 or 3 on/off periods per day, via a 4 posion DIP switch on the back
of the unit (see installaon instrucons).
The large, easy to read display makes programming easy and the
unit is designed to eliminate the possibility of accidental changes to
your programme. Buons normally visible, only affect your set
programme temporarily. All buons which can permanently change
your programme are located behind the flip over facia.
- The 24 hour programmer opon runs the same programme every
day.
- The 5/2 Day programmer opon allows different ON/OFF mes at
weekends.
- The 7 Day programmer opon allows different ON/OFF mes for
each day of the week.
IMPORTANT: These sengs should only be changed by a qualified
person. Contact your installer. This programmer is not suitable for
the switching of devices greater than 6Amp rated. (e.g. Not suitable
for use as an immersion mer)
2

Introducon to the 1 Channel Programmer Programming the Unit
The Factory-Set Programme
This is the factory-set programme built into the unit. If the user
changes from the factory-set programme and wishes to return to it,
pressing the reset buon with a non metallic pointed tool will return
the unit to the factory-set programme. NB. Every me the reset is
pressed, the me and date must be set again (page 8).
If the unit is installed as a 24 hour programmer the built in
programme will be the same for each day (i.e. Sat-Sun be same as
Mon-Fri above).
Changing The Programme (refer to Fig.1, Page 4)
For 7 Day Programmer Opon - the inial programme displayed will
be for Monday. You can go to any day of the week by pressing the
DAY buon repeatedly. The COPY buon will copy the current
programme onto the next day. NB. It is not possible to copy Sunday
to Monday.
For 5/2 Day Programmer Opon - the inial programme displayed
will be for Monday - Friday. Press the DAY buon for Saturday -
Sunday programme. The COPY buon will copy the current
programme onto the next day group. NB. It is not possible to copy
Saturday-Sunday programme to Monday-Friday programme.
For 24 Hour Programmer Opon - the built in programme will be
the same for each day. The COPY & DAY buons have no effect if
installed as a 24 hour programmer.
3
Configuraon
2PU & 2Gr
Configuraon
3PU & 3Gr Mon-Fri Sat-Sun

Programming the Unit
Fig. 1
4
To change the Programme mes
1. Press the SET buon (1) four mes unl the programme icon (2)
flashes, and the first ON me appears.
2. Press the +/- buons (3) to adjust the ON me. Please note, the
me will change quicker if pressed connually.
3. Press the NEXT buon (4). The display will now show 1 OFF (5).
4. Press the +/- buons (3) to adjust the OFF me. Please note, the
me will change quicker if pressed connually.
5. Press the NEXT buon (4) to access the remaining ON/OFF
periods and adjust in the same manner as above.
6. To return to RUN mode, press the SET buon (1) unl the display
indicates RUN on the display.
N.B: Programming is in 10 minute segments.
(1) (3)
(5)
(2) (4)

Fig. 1
Operang the Unit
Choosing the Operang Mode
5
ON : Central Heang and Hot Water is ON connuously
AUTO: Central Heang and Hot Water will be switched ON and
OFF in accordance with set programmes
ALL DAY: Central Heang and Hot Water will switch ON at the first
ON and switch OFF at last OFF
OFF: Central Heang and Hot Water will be permanently OFF
Mode

Using the Advance Funcon
The ADVANCE funcon allows the user to move to the next ON/OFF
programme for a “one off” event, without having to change the
programme or use the ON or OFF buons.
NB: The ADVANCE funcon is only available when the programme is
in AUTO or ALL DAY operang modes.
6
To Advance Central Heang and/or Hot Water
Press the ADV (1) buon. This will turn the Central Heang (and/or
Hot Water) ON if it is in an OFF period and OFF if it is in an ON period.
It will stay in this state unl either the ADV buon (1) is pressed
again, or unl a programmed ON/OFF period commences. The word
ADV will appear in the le hand side of the LCD.
Fig. 2
(1)

Press the +HR buon (2). One press of the buon will give one extra
hour of Central Heang (and/or Hot Water); two presses of the
buon will give two extra hours; three presses of the buon will
give the maximum three extra hours. Pressing it again will switch off
the +HR funcon. The + 1HR , +2HR or +3HR status of each zone will
appear on the right of the display.
Fig. 3
7
Using the +HR Boost Funcon
The +HR funcon allows the user to have up to 3 hours of extra
Central Heang or Hot Water, without having to change the
programme or use the ON or OFF buons.
NB: The +HR funcon is only available when the programme is in
AUTO, ALL DAY or OFF operang modes. If the programmer is in
AUTO or ALL DAY mode when the +HR buon is pressed and the
resulng me of the boost overlaps a START/ON me, the boost will
disengage.
To +HR Boost Central Heang and/or Hot Water
(2)

8
Basic Sengs
Seng the Time (refer to fig.4)
1. Press the SET buon (1) once. The configuraon seng will
appear on the screen. (E.G. 2PU)
2. Press the SET buon (1) again. The clock icon (2) on the
screen will flash.
3. Press the +/- buons (3) to adjust the me. The me will change
quicker if pressed connually.
4. Press SET (1) once to move on to seng the DATE or press
mulple mes to return to RUN mode.
Seng the Date (refer to fig.4)
1. Press the SET buon (1) unl the Y:XX icon (Year) appears and the
D (DATE) icon (4) flashes.
2. Press the +/- buon (3) to set the year.
3. Press NEXT buon (5). M:XX appears (Month).
4. Press +/- buon (3) to set month.
5. Press NEXT buon (5). D:XX appears (Day).
6. Press +/- buon (3) to set day.
(1) (3) (5)
(2) (4)
Fig. 4

Reseng the Unit
Press the reset buon with a non-metallic pointed tool to reset the
unit. This will restore the built in programme and also reset the me
to 12:00pm and the date to 01/01/2000. Inially the display shows
all segments lit for a few seconds, but then will show the current
configuraon. To set the me and date, please refer to page 8.
NB: As a safety feature aer reseng the unit will be in OFF operat-
ing mode. Reselect your required operang mode (page 5). Use of
excessive force may result in the reset buon scking behind the
front cover of the programmer. If this happens the unit will “freeze”
and the buon can only be released by a qualified installer.
Basic Sengs
Seng the Date (refer to fig.4)
Fig. 4
Seng the Backlight
The backlight can either be set permanently ON or OFF. The
programmer backlight is pre-set to be permanently OFF. When the
backlight is permanently OFF, the backlight will turn ON for 15
seconds when + or – buon is pressed, then turn OFF automacally.
To change seng to permanently ON, press SET repeatedly unl L
IR is displayed. Press + or – to turn backlight ON or OFF. Press SET to
confirm.
NB: Do not use Advance or +HR Boost Buon to acvate the
backlight as it may engage the Advance or +HR facility and turn on
the boiler. Only use + or - buon under facia cover.
9
Power Interrupon
In the event of a mains supply failure the screen will go blank but the
back-up baery ensures that the programmer connues to keep the
me and retain your stored programme. When power is restored, if
there has been no change to the rear DIP switch, the programmer
then goes to RUN mode. If the configuraon seng on the rear DIP
switch has been altered during the power interrupon the screen
will inially show the new configuraon and the appropriate factory
default programme will be installed. Press SET buon to return to
RUN mode.

Installaon
Instrucons

Technical Data
10

Technical Data Installaon Safety Instrucons
The unit must be installed by a suitably qualified person in accord-
ance with the latest IEE Wiring Regulaons.
Isolate mains supply before commencing installaon. Please read all
instrucons before proceeding.
Ensure that the fixed wiring connecons to the mains supply is via a
fuse rated at not more than 6 amps and class ‘A’ switch having a
contact separaon of a minimum of 3mm in all poles. The recom-
mended cable sizes are 1.0mm sqr or 1.5mm sqr.
No earth connecon is required as the product is double insulated
but ensure connuity of earth throughout the system.
If the unit is fied to a metal surface, IT IS ESSENTIAL that the metal
be earthed. DO NOT use a surface mounng box.
NEVER fit or remove the unit to a live wall-plate.
Maintenance
Always isolate the mains supply before commencing any work,
servicing or maintenance on the system. And please read all instruc-
ons before proceeding.
Arrange for an annual maintenance and inspecon schedule to be
carried out by a competent person on every part of the heang and
hot water system.
WARNING!
ALWAYS ISOLATE THE AC MAINS SUPPLY BEFORE INSTALLING.
THIS PRODUCT MUST BE FITTED BY A COMPETENT PERSON, AND
INSTALLATION MUST COMPLY WITH THE GUIDANCE PROVIDED IN
THE CURRENT EDITIONS OF BS767 (IEE WIRING REGULATIONS) AND
PART “P” OF THE BUILDING REGULATIONS.
11
Safety Noce

Pre-Installaon Unit Set Up
Before installing, set the bank of 4 DIP Switches on the back to
configure the unit according to the chart below:
(DIP Switches shown in Factory Default Posions.
24 Hr: runs the same programme every day.
5/2 Day: allows different on/off mes at weekend.
7 Day: allows different on/off mes every day.
Fing the Back Plate
1. Posion the wall-plate (terminals along top edge) with 60mm
(min) clearance to its right, 25mm (min) above, 90mm (min) below.
Ensure that the supporng surface will fully cover the back of the
programmer.
2. Offer the back plate to the wall in the posion where the
programmer is to be mounted, remembering that the back plate
fits to the le side of the programmer. Mark the fixing posions
through the slots in the back plate, drill and plug wall, then secure
back plate in posion.
3. All necessary electrical connecons should now be made. Ensure
that the wiring to the wall-plate terminals leads directly away from
the terminals and is completely enclosed within the wall-plate
aperture. Wire ends must be stripped and screwed to the terminals
so that minimal bare wire is showing.
12
Not Used
24 Hr
2 On/Off
Not Used
7 Day
5/2 Day
3 On/Off

Example circuit diagram for a typical installaon is shown below.
This diagram is schemac and should be used as a guide only.
Please ensure that all installaons comply with the current IEE
regulaons.
For reasons of space and clarity the diagram has been simplified. For
instance some Earth connecons have been omied. Other control
components shown in the diagram i.e. Valves, Room Stats etc are
general representaons only. However, the wiring detail can be
applied to the corresponding model of most manufacturers e.g.
Horstmann, Honeywell, Danfoss Randall, Drayton, ESi Controls etc.
1. Remove old programmer from its back plate mounng loosening
any securing screws as dictated by its design.
2. Check compability of exisng back plate & wiring arrangement
with that of the new programmer. See online Programmer Replace-
ment Guide for direcon.
3. Make all necessary changes to back plate & wiring arrangement
to suit new programmer. 13
Exisng Installaons
New Installaons

14
Wiring Diagram
