Instruction Manual
REFRIGERATOR
Model:ES 7295 NF
ES 7295 IN NF
ES 7490 IN NF

Contents
1. SAFETY WARNINGS............................................................................................................ 1
2. INSTALLATION ................................................................................................................... 2
2.1 Location...................................................................................................................... 2
2.2 Door Handle Install Illumination(optional) ................................................................ 2
2.3 Reversing the Door Swing .......................................................................................... 4
2.4 Door Space Requirements.......................................................................................... 6
2.5 Levelling the Unit ....................................................................................................... 6
2.6 Cleaning Before Use................................................................................................... 6
2.7 Before Using Your Unit............................................................................................... 6
2.8Interior Accessories.................................................................................................... 7
3. PRODUCT OVERVIEW ........................................................................................................ 8
4. OPERATION........................................................................................................................ 8
4.1 Operation Instructions ............................................................................................... 8
4.2 Noise Inside the Unit!............................................................................................... 10
4.3 Tips for Keeping Food in the Unit............................................................................. 10
4.4 Change the Light Bulb .............................................................................................. 11
5. CLEANING ........................................................................................................................ 11
5.1 Defrosting................................................................................................................. 11
5.2 Cleaning the Interior and the Exterior of the Unit ................................................... 11
5.3 Cleaning Tips ............................................................................................................ 11
6. MAINTENANCE ................................................................................................................ 11
6.1 Changing the Internal Light...................................................................................... 11
6.2 Care When Handling / Moving Your Unit................................................................. 11
6.3 Servicing ................................................................................................................... 11
6.4 Switching Off for Long Periods of Time.................................................................... 11
6.5 Do not shield positions of air outlet and return air inlet of the refrigerator........... 12
7. Trouble shooting ............................................................................................................. 12
7.1 Warm tips:................................................................................................................ 12
8. TIPS FOR ENERGY SAVING ............................................................................................... 12
9. DISPOSAL ......................................................................................................................... 13

1
1. SAFETY WARNINGS
1) WARNING―Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
2) WARNING―Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
3) WARNING―Do not damage the refrigerant circuit.
4) WARNING―Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
5) The appliance has to be unplugged after use and before carrying out user maintenance on the
appliance.
6) This appliance can be used by children aged from 8 years and above and persons with reduce
physical sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
7) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
8) Please abandon the refrigerator according to local regulators for it use flammable blowing gas
and refrigerant.
9) Please according to local regulations regarding disposal of the appliance for its flammable
refrigerant and blowing gas. Before you scrap the appliance, please take off the doors to prevent
children trapped.
10) This appliance is intended to be used in household and similar applications such as
–staff kitchen areas in shops, offices and other working environments;
–farm houses and by clients in hotels, motels and other residential type environments;
–bed and breakfast type environments;
–catering and similar non-retail applications.
11) Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED SERVICE PERSONNEL TO
CARRY OUT SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT REPAIRS YOURSELF.

2
2. INSTALLATION
2.1 Location
When selecting a position for your unit you should make sure the floor is flat and firm, and the
room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator.
Also avoid direct sunlight as it may increase the electrical consumption. Extreme cold ambient
temperatures may also cause the unit not to perform properly. This unit is not designed for use in
a garage or outdoor installation. Do not drape the unit with any covering.
When installing the unit, ensure that 10 cm of free space is left at both sides, 10 cm at the rear
and 30 cm at the top of the unit. This will allow cold air to circulate around the wine cooler and
improve the efficiency of the cooling process.
2.2 Door Handle Install Illumination(optional)
1) Take out the screw caps from the door
handle holes.
2) Put the handles into the screw holes and
then hit them to fix .

3
3) Cap the screw caps on the handle screws.
4) Take out the screw caps from the handle
screw holes.
5) Remove the screws and take the handles
down.
6) Cap the screw caps on the door handle
holes again.

4
7) Install the handles into the door handle
holes of the other side in accordance with
the handle installation instructions.
2.3 Reversing the Door Swing
1) Take off knuckle guard. 2) Take off top hinge.

5
3) Take off the door of refrigerating
chamber.
4) Take off middle hinge with a screw driver.
5) Take off the door of freezing chamber.
6) Take off hinge assembly with a screw
driver , Assemble lower hinge assembly to
left side of the cabinet with a screw driver.
7) Assemble the door of freezer chamber on
the lower hinge.
8) Assemble middle hinge assembly to left
side of the cabinet .
9) Assemble the door of refrigerating.
10) Take on knuckle guard.

6
2.4Door Space Requirements
The unit's door must be able to open fully as shown.
W×D≥990×1025mm
2.5 Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the door and magnetic seal alignments
will not be covered properly.
Make sure that the foot touches the ground before use.
Look down from the top, clockwise and counterclockwise loosening, tightening.
2.6 Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a 'Wrung-out' sponge or cloth. Wash the shelves and salad bin in warm soapy water
and dry completely before replacing in the unit. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
2.7 Before Using Your Unit
The refrigerator adopts 220~240V/50Hz AC power, voltage fluctuations over the range of 187 ~
264V will cause malfunction or even damage.
Do not damage the power cord under any condition so as to ensure safety use, do not use when
the power cord is damaged or the plug is worn.
Do not put flammable, explosive, volatile and highly corrosive items in the refrigerator to prevent
damages to the product or fire accidents.
Do not place flammable items near the refrigerator to avoid fires.
This product is household refrigerators and shall be only suitable for the storage of foods.
According to national standards, household refrigerators shall not be used for other purposes,
such as storage of blood, drugs or biological products.
Do not place items such as bottled or sealed container of fluid such as bottled beers and
W
D

7
beverages in the freezer to prevent bursts and other losses.
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
Do not damage the power cord under any condition so as to ensure safety use, do not use when
the power cord is damaged or the plug is worn.
Do not put flammable, explosive, volatile and highly corrosive items in the refrigerator to prevent
damages to the product or fire accidents.
Do not place flammable items near the refrigerator to avoid fires.
This product is household refrigerators and shall be only suitable for the storage of foods.
According to national standards, household refrigerators shall not be used for other purposes,
such as storage of blood, drugs or biological products.
Do ot place items such as bottled or sealed container of fluid such as bottled beers and beverages
in the freezer to prevent bursts and other losses.
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
◆Before Plugging in
You must check that you have a socket which is compatible with the plug supplied
with the unit.
◆Before Turning On!
Do not turn on until two hours after moving the unit.
2.8 Interior Accessories
Various glass or plastic storage shelves are included with your appliance - different
models have different combinations.
You should always slide one of the full size glass storage shelves into the lowest set of
guides, above the fruit and vegetable containers, and keep it in this position. To do
this, pull the storage shelf forward until it can be swivelled upwards or downwards
and removed.
Please do the same in reverse to insert the shelf at a different height.
In order to make the most of the volume of the fresh food storage compartment and
frozen-food storage compartment, the user can remove one or more shelves, drawers, out
of the appliance, according to your daily use.

8
3. PRODUCT OVERVIEW
*Dotted line represents the position of air outlet and return air inlet.
*All images in this instruction manual are for indication only; please refer to your individual unit for details.
4. OPERATION
4.1 Operation Instructions
Temperature control
Temperature control of fresh food storage compartment.
（Built-in ）
2 c 3 c 4 c 6 c 8 cTEMPERATURE FAST COOL
A fast cool① ② ③ ④ ⑤
