Essential Garden Mission Creek User manual

Mission Creek 10x12 Hardtop Gazebo with netting
garden
USE AND CARE GUIDE
Product Code: 06447232-7
UPC Code: 749241314179
Date of purchase: _____/ _____/ _____
1

Thank you for your purchase
Thank you for your purchase!
We are pleased that you have chosen Kmart for your outdoor furniture purchase.
We hope that you enjoy the unmatched quality, comfort, and style of your new patio
set. Every piece is meticulously considered all the way down to the smallest details,
exclusively for you, by our world class design team. We know you have a choice when
it comes to your patio furniture needs, so from our team to yours, thank you for letting
us be a part of your outdoors.
Table of contents
Table of Contents ....................................................................................2
Safety Information ..................................................................................3
Set Up your Shelter Properly ................................................................3
Examine your Shelter ............................................................................3
Warranty ..................................................................................................3
Excluded ................................................................................................3
Service Center .......................................................................................3
Care and Maintenance ............................................................................4
Pre-Assembly ...........................................................................................5
Hardware Included ................................................................................5
Package Contents ..................................................................................6
Assembly Instructions .............................................................................9
Customer Service ....................................................................................22
2

Safety Information
SET UP YOUR SHELTER PROPERLY
Please read and understand this entire manual before attempt to assemble, operate, or
install the product.
If any part is missing or damaged. Do not attempt to assemble the product.
Two to four people are needed for assembly.
In order to avoid damage to the gazebo and its components please use appropriate tools.
Do not use the structure as support.
Check all bolts on a regular basis to maintain the solidity of the structure.
Keep instruction for future use.
Approximate time: 2 – 3 hours
.
EXAMINE YOUR SHELTER
Examine occasionally to ensure there are no loose parts. If loose parts are found, they
must be retightened fully immediately.
3
Warranty
5 YEARS WARRANTY FOR FRAME AND 1 YEAR WARRANTY FOR NETTING
3 YEARS WARRANTY FOR POLY CARBONATE ROOF PANEL
Limited warranty is applicable on parts only. Warranty extends solely to the original
purchaser who must offer original sales receipt for record.
WHAT IS COVERED
Limited warranty is applicable on parts only. We warranty to the original purchase for
5 years limited from the date of purchase that the frame and frame will be free from
manufacturing defects.
SERVICE CENTER
The purchaser must contact our customer service center directly if this product is
found to be defect in material or workmanship. The manufacturer, as its option, will
repair or replace the defectives parts.
Please contact us via 1-800-961-9838, 9AM-5PM, Pacific Time Zone, Monday-Friday,
or [email protected]
.
WHAT IS NOT COVERED
Product used for commercial, contract, or other non-residential purposes, or damage
due to acts of nature, vandalism, misuse, or improper assembly is not covered.
Corrosion or rusting of hardware is not covered. Warranty is to the original purchaser
and is non-transferable. Any replacement of warranted items will be in the original style
and color, or a similar style and color if the original is unavailable or has been
discontinued.

Care and Maintenance
4
For cleaning, use a mild detergent solution and rinse with water. Do not use acetone
abrasive or others special detergents to clean and air dry only.
Due to the nature of steel, surface oxidation (rusting) will occur if this protective coating
is scratched. This is a natural process. To minimize this condition, it is recommended
that care be taken when assembling and handling the product in order to prevent the
paint from being scratched.
Warning
WARING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS
TENT FABRIC.
The tent meets the flammability requirements of CPAI-84. The fabric may burn if left in
continuous contact with any flame source. The application of any foreign substance to the
tent fabric may render the flame-resistant properties ineffective.

5
Pre-Assembly
PLANNING ASSEMBLY
To prevent damage, place all parts on a soft surface during assembly.
Tools required for assembly (not included): Allen wrench (included), a screwdriver,
stepladder (min. 5ft.) and other safety items such as gloves, safety eyewear, and hardhat.
To avoid injury from exposed sharp edges, it may be necessary to use the above safety
equipment.
Do not leave it unattended if not fully assembled even if bolted to the ground.
HARDWARE INCLUDED
NOTED: Hardware not shown
to actual size.
AA CC DD
EE
Part Description Size QTY.
AA
BB
CC
DD
EE
BOLT
BOLT
BOLT
BOLT NUT
ALLEN WRENCH
( )
6 x 15mm
( )
6 x 35mm
( )
6 x 100mm
106
32
16
16
1
BB
FF
FF SPANNER 1

6
Pre-Assembly (continued)
Package Contents
A
B
I
R
QOS
T
C
D
E
F
N
U
V
P
K
L
M
G
M
J
H
W
X
S
T
Q
R
Y
ZAB
AC

Pre-Assembly (continued)
Package Contents
Part Description Qty Illustration
7
A
B
C
D
E
F
G
H
I
J
K
L
M
N
4
4
4
4
4
4
2
2
2
2
6
1
1
6
Post
Base flange
Long crossbar 1
Long crossbar 2
Inner connector
Short crossbar 1
Short crossbar 2
Center connector
Corner eave connector
Roof connector
Roof top cover
Long roof tube
Short roof tube
Corner connector

8
Pre-Assembly (continued)
Package Contents
Part Description IllustrationQty
2
2
4
4
4
4
6
4
12
1
O
P
Q
R
S
T
U
V
W
X
Roof panel 1
Roof panel 2
Roof panel 3
Roof panel 4
Roof panel 5
Roof panel 6
Roof center connector
Roof corner connector
Stake
Mosquito net
Y
Z
AB
AC
2
4
4
4
Support tube 1
Support tube 2
Support tube 3
Outer connector

9
Assembly Instructions
1. Attach base flange (B) on the bottom of post (A), then secure with bolts (AA) as
figure 1 shown. Repeat for the remaining post (A) and base flange (B).
A x 4 B x 4
A
B
AA
A
B
B
A
1
1
AA x 8

10
Assembly Instructions
2. Insert inner connector (E) in between long crossbar 1, 2 (C, D) secure with bolts (AA)
see figure 1. Secure outer connector (AC) with long crossbar (C, D) using bolts (CC) and
bolt nut (DD) as figure 2 shown. Secure center connector (H) onto the long crossbar (C, D) by
using bolts (AA) as figure 3 shown. Repeat for remaining long crossbar (C, D).
Notes: Please check the upper fig, and make sure all the parts in right position.
Don’t tighten all bolts before assembly completed.
CC x 8
3
AA
3
3
1
2
E
C
D
H
H
2
H
D
C
AC
AC
DD
CC
CD
AA
1
C x 2
H x 4
E x 2
D x 2
AC x 2 AA x 24
DD x 8

11
Assembly Instructions
3. Insert inner connector (E) in between short crossbar 1, 2 (F, G) secure with bolts
(AA). See figure 1.
Secure center connector (H) onto the inner connector (E) by using bolts (AA) as
figure 1 shown.
AA
E x 2
x 2
H
Secure outer connector (AC) with short corssbar (G, F) by using bolts (CC) and
bolt nut (DD) as figure 2 shown.
Repeat for remaining short crossbar (G, F).
Notes: Please check the upper fig. And make sure all the parts in right position.
Don’t tighten all bolts before assembly completed.
x 2
AC
FHG
FG
EH
AC
1
2
2
G
F
AC
DD
CC
1
Gx 2
Fx 2
CC x 8
AA x 16
DD x 8

12
Assembly Instructions
4. Secure the assembled short crossbar set (F, G) with both post (A) by using bolts (BB)
as figure 1 shown.
Repeat for remaining assembled short crossbar set (F, G) and post (A).
Don’g tighten all bolts before assembly completed.
1
A
A
G
BB
1
GF
A
1
BB x 16

as figure 1 shown.
13
Assembly Instructions
5. Secure the assembled long crossbar set (C, D) with both post (A) by using bolts (BB)
Repeat for remaining assembled long crossbar set (C, D).
Don’t tighten all bolts before assembly completed.
1
BB
A
D
F
1
1
1
1
C
C
D
D
GG
F
F
A
A
A
A
BB x 16

14
Assembly Instructions
6. Secure long crossbar 2 (D) and short crossbar 1 (F) with corner eave connector (I) by
using bolts (AA) .
Repeat for the remaining corner eave connector (I).
I X 4
D
D
C
C
F
F
G
G
I
I
I
I
D
F
AA
1
1
1
1
1
AA x 8

15
M
HAA
F
G
2
Assembly Instructions
7. Use bolts (AA) secure roof connector (J) underneath with short roof tube (M) as figure 1
show, then insert bolts (AA) through center connector (H) secure with other side of short
roof tube (M) as figure 2 shown.
Repeat for remaining short roof tube (M). Don’t tighten all bolts before assembly completed.
M X 6
G
F
M
M
C
D
H
J
1
22
2
2
2
1
MJ
M
1
AA
AA x 12

16
N X 4
084
Assembly Instructions
8. Secure corner connector (N) onto long roof tube (L) by using bolts (AA) as figure 1
shown. Repeat for remaining long roof tube (L) and corner connector (N).
Notes: Please check the fig, and make sure all the parts in right position.
L X 4
N
L
L
N1
1
N
414
511
AA x 4

17
Assembly Instructions
9. Use bolts (AA) secure roof connector (J) with long roof tube (L) as figure 1 shown,
then insert bolts (AA) through corner connector (N) of long roof tube (L) secure with
post (A) as figure 2 shown.
Repeat for remaining long roof tube (L). Don’t tighten all bolts before assembly completed.
A
A
A
A
2AA
L
N
A
L
LAA
J
1
J
L
L
MLMM
L
1
2
2
2
2
AA x 12

18
Assembly Instructions
10. Insert bolts (AA) through roof connector (J) underneath secure with roof top cover
(K) as figure 1 shown. Don’t tighten all bolts before assembly completed.
K x 1
K
J
AA
M
L
L
K
L
MLMM
1
1
J
AA x 2

19
Assembly Instructions
11. Insert bolts (AA) through support tube 2 (Z) and support tube 3 (AB), secure with short
roof tube (M) as figure 1 shown.
Insert bolts (AA) through support tube 3 (AB) and support tube 2 (Z), secure with long
roof tube (L) as figure 2 shown.
Insert bolts (AA) through support tube 3 (AB) and support tube 1 (Y), secure with short
roof tube (M) as figure 3 shown.
Repeat for remaining supprt tube (Y, Z, AB).
Don’t tighten all bolts before assembly completed.
L
Z
AB
AA
2
ZYAB
MM
M
M
L
L
L
L
AB
Z
M
AB
Z
AA
1
1
2
M
YAB
AA
3
332
Z X 4
Y X 2
AB X 4 AA x 10

20
V
L
AA
T
M
MT
Assembly Instructions
12. Peel off the protection sheet from the panel, then insert roof panel 5 (S) into short roof
tube (M) and long roof tube (L), then insert roof panel 6 (T) into short roof tube (M) and
long roof tube (L). Repeat the step for remaining roof panels (O, P, Q, R, S, T).
Insert bolts (AA) through roof center connector (U) secure with short roof tube (M).
Insert bolts (AA) through roof corner connector (V) secure with long roof tube (L).
Please do not let the panels slide off.
Please make sure the lower roof panel against to the upper roof panel (fig. X & X).
O X 2 P X 2
Q X 4 R X 4
S X 4
T X 4
U X 6 V X 4
QO
P
R
S
T
S
T
Q
R
O
P
Q
R
ST
Q
R
S
T
MM
LUU
V
V
U
M
AA
LQ
R
MS
AA x 10
R
Q
X
Q
RX
