Essential Garden L-GG076PST User manual

Safety Information
SET UP YOUR SHELTER PROPERLY
Please read and understand this entire manual before attempt to assemble, operate, or
install the product.
If any part is missing or damaged. Do not attempt to assemble the product.
Two to four people are needed for assembly.
In order to avoid damage to the gazebo and its components please use appropriate tools.
Do not use the structure as support.
Check all bolts on a regular basis to maintain the solidity of the structure.
Keep instructions for future use.
Approximate time: 1 hour
.
EXAMINE YOUR SHELTER
Examine occasionally to ensure there are no loose parts. If loose parts are found, they
must be retightened fully immediately.
2
Warranty
1 YEAR WARRANTY FOR FRAME
Limited warranty is applicable on parts only. Warranty extends solely to the original
purchaser who must offer original sales receipt for record.
WHAT IS COVERED
Limited warranty is applicable on parts only. We warranty to the original purchase for
one year limited from the date of purchase that the frame and fabric cover will be free
from manufacturing defects.
SERVICE CENTER
The purchaser must contact our customer service center directly if this product is
found to be defect in material or workmanship. The manufacturer, as its option, will
repair or replace the defectives parts.
Please contact us via 1-800-961-9838, 9AM-5PM, Pacific Time Zone, Monday-Friday,
or [email protected]
.
WHAT IS NOT COVERED
Product used for commercial, contract, or other non-residential purposes, or damage
due to acts of nature, vandalism, misuse, or improper assembly is not covered.
Corrosion or rusting of hardware is not covered. Warranty is to the original purchaser
and is non-transferable. Any replacement of warranted items will be in the original style
and color, or a similar style and color if the original is unavailable or has been
discontinued.

3
L
G
I
J
F
F
H
C
A
B
E
D
K
M

4
Item Description Qty Illustration
A
B
C
D
E
F
G
H
I
J
K
L
AA
BB
CC
1
1
1
1
2
2
1
1
2
1
4
1
6
24
1
Post
Post
Post
Post
Crossbar
Bend crossbar
Bend crossbar
Roof tube
Supporting pole
Fence
Stake
Canopy
Short screw M6 x 15mm
Long screw M6 x 35mm
Hex wrench
MHook 8

5
1. Insert long screw (BB) through fence (E) secure with post (A), then repeat for other side of fence (E)
and post (C) as figure 1 shown.
2. Insert long screw (BB) through bend crossbar (G) secure with post (A), then repeat for other side of
bend crossbar (G) and post (C) as figure 2 shown.
A
E
C
G
11
11
G
C
A
E
A
G
BB
AE
BB
1 1
2
2
2
1

1. Insert long screw (BB) through fence (E) secure with post (B), then repeat for other side of fence (E)
and post (D) as figure 1 shown.
2. Insert long screw (BB) through bend crossbar (H) secure with post (B), then repeat for other side of
bend crossbar (H) and post (D) as figure 2 shown.
6
B
E
D
H
11
11
B
H
D
E
B
B
H
E
BB
BB
2
2
2
1
11

7
1. Insert long screw (BB) through crossbar (F) secure with post (A), then repeat for other side
of crossbar (F) and post (B) as figure 1 shown.
Repeat this step for remaining crossbar (F).
F2
F
A
C
B
D
A
F
BB
F
1
1
11

8
1. Insert short screw (AA) through supporting pole (I) secure with bend crossbar (G), then repeat
for other side of supporting pole (I) and bend crossbar (H).
Repeat for remaining supporting pole (I).
I2
G
I
I
F
H
G
I
AA
1
1
1
1
1

9
1. Place roof tube (J) onto supporting pole (I), then secure roof tube (J) with supporting pole (I) by
using short screw (AA), then repeat for other side of roof tube (J) as figure shown.
J1
I
JI
I
J
AA 1
1
1

10
1. Place the canopy (L) onto the top frame, then secure the hook of canopy into the hole of
bend crossbar (H) as figure 1 shown. Repeat this step for other hooks of canopy.
2. Hang 4 hooks on each fence (E) as figure 2 shown.
3. Insert stake (K) through post into ground as figure 3 shown.
K L
41M8
L
A
C
B
D
H
L
K
1
2
2
2
3
1
3
3
3
3
E
E
M
M
E

11
