Essentials C700VC18 User manual

Bagless Cylinder
Vacuum Cleaner
Instruction Manual
C700VC18
C700VC18_IB_RC_190826_grace.indd 1 26/8/2019 2:56 PM

C700VC18_IB_RC_190826_grace.indd 2 26/8/2019 2:56 PM

Contents
Safety Warnings..................................................................................................................................... 4
Unpacking..............................................................................................................................................6
Product Overview..................................................................................................................................7
Preparation Before Use......................................................................................................................... 8
Operation ...............................................................................................................................................9
Powering O and Storage...................................................................................................................10
Emptying the Dust Bin ........................................................................................................................11
Cleaning the Filters in the Dust Container ........................................................................................12
Cleaning the Exhaust Filter.................................................................................................................12
Specications.......................................................................................................................................13
C700VC18_IB_RC_190826_grace.indd 3 26/8/2019 2:56 PM

4
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock, please follow all the
safety precautions listed below.
• Read all the instructions carefully before using the appliance and keep them for future
reference.
• Retain the manual. If you pass the appliance onto a third party make sure to include this
manual.
• Check that the voltage marked on the rating label matches your mains voltage.
• Consult your dealer if you are ever in doubt about the installation, operation or safety of your
appliance.
• Do not remove any xed cover as this may expose dangerous voltages.
• Do not allow any electrical appliance to be exposed to dripping or splashing.
• To protect against electrical shock, do not immerse the mains cable, mains plug, or any part
of the appliance in water or other liquids.
• Make sure the dust bag is properly installed before use.
• Never vacuum up water or any other liquids. Never vacuum up ammable substances and do
not vacuum up ashes until they are cold.
• Never use the appliance without the motor protection lter. Without this, the motor will be
damaged and the life of the appliance will be shortened.
• If a blockage is found in the brushes, hoses or tubes, it should be removed before use.
• Store and use the appliance well away from heat sources such as radiators or gas / electric
res.
• Do not run over the mains cable with the appliance.
• Close supervision is necessary when any appliance is used by or near children.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervised.
• Keep the appliance and its cord out of reach of children less than 8 years.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not point the hose, tube or any other accessory at the eyes, ears or mouth during
operation.
• Unplug the appliance from the mains socket when it is not in use and before replacing the
dustbag or lter.
• Allow the appliance to cool completely before cleaning or storing.
C700VC18_IB_RC_190826_grace.indd 4 26/8/2019 2:56 PM

5
• Do not use the appliance for other uses than its intended use.
• The use of accessories not recommended by the appliance manufacturer may cause injury.
• Do not use the appliance outdoors.
• Do not operate an appliance with a damaged mains cable or mains plug, or in an abnormal
state. If the mains cable is damaged it must be replaced by the manufacturer, its service
agent, or similarly qualied persons in order to avoid a hazard.
• Do not continue to operate the appliance if you are in any doubt about it working normally
(e.g. abnormal noise, smell, smoke), or if it is damaged in any way - switch o, withdraw the
mains plug and consult your dealer.
• Any maintenance and repair must be handled by a professional technician. Do not try to
repair by yourself.
• This appliance is designed for indoor, household use only.
• Make sure the unit is earthed properly during use. Use of any extension sockets must have an
earth connection. If in doubt, contact a qualied electrician.
C700VC18_IB_RC_190826_grace.indd 5 26/8/2019 2:56 PM

6
Thank youfor purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational features
it oers. You will also nd some hints and tips to help you resolve any
issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Main Unit
Extension Tube Combination
Nozzle
Instruction ManualFloor Brush
Hose
Instruction
Manual
C700VC18_IB_RC_190826_grace.indd 6 26/8/2019 2:56 PM

7
Product Overview
1. Hose Suction Control
2. Extension Tube Switch
3. Floor Brush Pedal
4. Combination Nozzle
5. Hose Connector
6. Dust Container Clasp
7. Bin Release Button
8. Cyclonic Filter
9. Dust Container
10. Dust Filter
11. ON/OFF Button
12. Cord Rewind Button
13. Brush Clip
14. Mains Plug
15. Grill and Exhaust Filter
2
6
1
34
5
7
12
14
13
10
9
8
15
11
C700VC18_IB_RC_190826_grace.indd 7 26/8/2019 2:56 PM

8
Preparation Before Use
1. To connect the hose, insert the hose connector into
the hose connection opening until you hear a “click”
sound.
2. Connect the telescopic tube to the handgrip of the
hose.
3. Extend the telescopic tube to a length you nd
most comfortable by pushing the button forward.
The button is on the telescopic tube. Connect a
nozzle / brush suitable for the oor type to be
cleaned.
4. The hard oor brush can be used with the brush
lowered ( for carpet) or raised ( for hard
oor) . You may also connect the nozzle to vacuum
corners, slots or grooves (not included).
C700VC18_IB_RC_190826_grace.indd 8 26/8/2019 2:56 PM

9
Operation
1. Hold the mains plug and pull the retractable mains cable out of the vacuum cleaner.
Connect it to the mains socket.
The YELLOW mark indicates the ideal length to extend the cable. Do not extend
the mains cable beyond the RED mark which indicates the maximum length.
2. Press the ON/OFF button on the top of the vacuum cleaner to turn it on.
3. To move the vacuum cleaner from room to room, you can unplug and carry it by either
the handle or the handgrip. Never use the mains cable to pull the vacuum cleaner.
C700VC18_IB_RC_190826_grace.indd 9 26/8/2019 2:56 PM

10
Powering O and Storage
1. Press the ON/OFF button on the top of the vacuum cleaner to turn it o.
2. Unplug the mains cable from the mains socket.
3. Press the cord rewind button to rewind the retractable mains cable.
4. Detach the hard oor brush / nozzle from the
telescopic tube.
5. Pull the telescopic tube rmly to detach it from the
hose.
6. Press button on the hose connector to detach the
hose from the unit.
7. Place the oor brush on the brush clip at the back of
the unit.
C700VC18_IB_RC_190826_grace.indd 10 26/8/2019 2:57 PM

11
Emptying the Dust Bin
Ensure the vacuum cleaner is fully unplugged
from the mains socket.
1. Press the release button at the top of the lid handle.
2. Lift the container up and remove it from the unit
base.
3. Press the release button at the back of the container
to open the base cover.
You might empty the dust container over a
litter bin or litter bag to prevent small particles
of dust from scattering around on the oor.
C700VC18_IB_RC_190826_grace.indd 11 26/8/2019 2:57 PM

12
Cleaning the Filters in the Dust Container
Ensure the vacuum cleaner is fully unplugged
from the mains socket.
1. After lifting up the container lid, remove the
cyclonic lter (a) and the dust lter (b) from the dust
container.
Cleaning the Exhaust Filter
Ensure the vacuum cleaner is fully unplugged
from the mains socket.
1. Remove the lter cover from the unit.
a
b
2. Remove the lter from the unit.
2. Clean the lters, and then dry them thoroughly before replacing back into the dust
container.
3. Wash the lter, and dry it thoroughly before replacing into the container.
C700VC18_IB_RC_190826_grace.indd 12 26/8/2019 2:57 PM

13
Specications
Model C700VC18
Rating 220-240 V~, 50 Hz, 700 W, Class II
Dust bin capacity 1.2L
Features and specications are subject to change without prior notice.
C700VC18_IB_RC_190826_grace.indd 13 26/8/2019 2:57 PM

C700VC18_IB_RC_190826_grace.indd 14 26/8/2019 2:57 PM

C700VC18_IB_RC_190826_grace.indd 15 26/8/2019 2:57 PM

Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.
With over 1 million spares and accessories available we can deliver direct to your door
the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only).
Calls charged at National Rate.
The symbol on the product or its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to
dispose of your waste equipment by handing it over to a designated collection point
for the recycling of waste electrical and electronic equipment. The separate collection
and recycling of your waste equipment at the time of disposal will help conserve
natural resources and ensure that it is recycled in a manner that protects human health and the
environment.
For more information about where you can drop o your waste for recycling, please contact your
local authority, or where you purchased your product.
