EST RKU Series User manual

P/N 270244
Revised 14JUL97
Equipment Enclosures
Installation Manual
firealarmresources.com

DEVELOPED BY Edwards Systems Technology
6411 Parkland Drive
Sarasota, FL 34243
[phone]
COPYRIGHT NOTICE Copyright © 1997 Edwards Systems Technology, Inc.
This manual and the products it describes are copyrighted by
Edwards Systems Technology, Inc. (EST). You may not reproduce,
translate, transcribe, or transmit any part of this manual without
express, written permission from EST.
This manual contains proprietary information intended for distribution
to authorized persons or companies for the sole purpose of
conducting business with Edwards Systems Technology, Inc. If you
distribute any information contained in this manual to unauthorized
persons, you have violated all distributor agreements and we may
take legal action.
CREDITS This manual was designed and written by the EST Technical
Services - Documentation Department, Sarasota.
firealarmresources.com

Equipment Enclosures Manual i
Content
CAB-2, CAB-3/CAB-3F, CAB-6F Equipment Enclosures 1
Description 1
Application 1
Layout and Dimensions 2
Specifications 4
CB17 / CB31 / CB45 Semi-Flush 19” Rack Enclosures 5
Description 5
Application 5
Layout 6
Specifications 7
Installation 8
MFC Enclosure 12
Description 12
Application 12
Installation 12
BC-1 Battery Cabinet 14
Description 14
Application 14
Specifications 14
Dimensions 15
RKU-Series 19 Inch Equipment Racks 16
Applicable Racks 16
Description 16
Application 16
Specifications 17
firealarmresources.com

ii Equipment Enclosures Manual
Important information
Limitation of liability
The content of this manual is proprietary in nature and is intended
solely for distribution to authorized persons, companies, distributors
and/or others for the sole purpose of conducting business associated
with Edwards Systems Technology, Inc. The distribution of
information contained within this manual to unauthorized persons shall
constitute a violation of any distributor agreements and may result in
implementation of legal proceedings.
This product has been designed to meet the requirements of NFPA
Standard 72, 1996 Edition; Underwriters Laboratories, Inc., Standard
864, 7th Edition; and Underwriters Laboratories of Canada, Inc.,
Standard ULC S527. Installation in accordance with this manual,
applicable codes, and the instructions of the Authority Having
Jurisdiction is mandatory. EST, Inc. shall not under any circumstances
be liable for any incidental or consequential damages arising from loss
of property or other damages or losses owing to the failure of EST, Inc.
products beyond the cost of repair or replacement of any defective
products. EST, Inc. reserves the right to make product improvements
and change product specifications at any time.
While every precaution has been taken during the preparation of this
manual to ensure the accuracy of its contents, EST assumes no
responsibility for errors or omissions.
FCC warning
This equipment can generate and radiate radio frequency energy. If this
equipment is not installed in accordance with this manual, it may cause
interference to radio communications. This equipment has been tested
and found to comply within the limits for Class A computing devices
pursuant to Subpart B of Part 15 of the FCC Rules. These rules are
designed to provide reasonable protection against such interference
when this equipment is operated in a commercial environment.
Operation of this equipment is likely to cause interference, in which
case the user at his own expense, is required to take whatever measures
may be required to correct the interference.
firealarmresources.com

Equipment Enclosures Manual iii
Document history
Equipment Enclosures Installation Manual P/N 270244
Revision Status
Revision Date Reason For Change
1.0 September 1995 Re-write of old manual.
1.5 July 1997 Major revision of layout and content.
firealarmresources.com

iv Equipment Enclosures Manual
firealarmresources.com

Equipment Enclosures Manual 1
CAB-2, CAB-3/CAB-3F, CAB-6F Equipment Enclosures
Description
The CAB-2 and 3 are surface mounted enclosures. The CAB 3F and 6F
are semi-flush mounted enclosures. All are for the installation of control
hardware. All cabinets are UL listed, constructed of 16 gauge welded
steel, and feature mounting rails with speed nuts for mounting modules.
The surface mounted enclosures feature a removable door which is
hinged on the left side. The doors on the semi-flush mounted
enclosures are integral to the finished frame. All doors are provided
with a Lexan insert for viewing system indicators and are secured with
a standard key lock assembly.
All enclosures feature mounting studs for mounting a door tamper
switch, which is required for security panel operations. Door
assemblies and back boxes are painted white. Red enclosures may be
specified by adding an “R” suffix to part and model numbers.
Electrical knockouts are provided on the top, bottom, and sides of the
back box, and keyhole mounting slots are located on the back. The
removable backplane permits mounting and wiring of control panel
components out of the back box for bench testing and facilitates easy
installation. Space for batteries is provided at the bottom of the
enclosure.
Application
The CAB-2, 3, 3F, and 6F enclosures are designed for installing
equipment in surface or semi-flush enclosures.
Note: Do not install conduit in bottom of enclosure.
firealarmresources.com

2 Equipment Enclosures Manual
Layout and Dimensions
CAB-2
CONTROL MODULE
CM1 (N) - CM2 (N)
6.5 AH MAX.
BATTERY
6.5 AH MAX.
BATTERY
POWER SUPPLY
PS4/8B
REMOVABLE BACK PANEL
12.00"
12.00"
4.81"
SIDE SIDE
15.00"
23.00"
3/4" CONDUIT KNOCKOUTS
3/4" CONDUIT KNOCKOUTS
3
/
4" CONDUIT KNOCKOUTS
HINGES
[CAB-001.CDR]
CAB-3
AA75 SERIES
AMPLIFIER
BATTERY BATTERY
CONTROL MODULE
CM1 (N) - CM2 (N)
POWER SUPPLY
PS4/8B
REMOVABLE BACK PANEL
29.25"
3/4" CONDUIT KNOCKOUTS
3/4" CONDUIT KNOCKOUTS
HINGES
18.00"
12.75"
15.00"
4.81"
SIDE SIDE
[CAB-002.CDR]
firealarmresources.com

Equipment Enclosures Manual 3
CAB-3F
AA75 SERIES
AMPLIFIER
BATTERY BATTERY
CONTROL MODULE
CM1(N) - CM2(N)
POWER SUPPLY
PS4/8B
REMOVABLE BACK PANEL
29.25"
3/4" CONDUIT KNOCKOUTS
3/4" CONDUIT KNOCKOUTS
HINGES
18.00"
12.75"
15.00"
4.25"
SIDE
FLAN
G
E
SIDE
[CAB-003.CDR]
0.75"
CAB-6F
OPTION MODULE AA75 SERIES
AMPLIFIER
6.5 AH MAX.
BATTERY
6.5 AH MAX.
BATTERY
6.5 AH MAX.
BATTERY
6.5 AH MAX.
BATTERY
CONTROL MODULE
CM1(N) - CM2(N)
CONTROL MODULE
CM2(N)
POWER SUPPLY
PS4/8B
CONTROL MODULE
CM2(N)
REMOVABLE BACK PANEL REMOVABLE BACK PANEL
3/4" CONDUIT KNOCKOUTS
3/4" CONDUIT KNOCKOUTS
3
/
4" CONDUIT KNOCKOUTS
HINGES
4.25" FLANGE
28.16"
0.75"
25.92"
SIDE SIDE
[CAB-004.CDR]
29.25"
18.00"
firealarmresources.com

4 Equipment Enclosures Manual
Specifications
Enclosure Dimensions
CAB-2 CAB-3 CAB-3F CAB-6F
Finished Height 23” 29.25” 31” 31”
Finished Width 15” 15” 16-15/16” 30”
Finished Depth 4.81” 4.81” .75” .75”
Back Box Height 23” 29.25” 29.25” 29.25”
Back Box Width 15” 15” 15” 28-5/32”
Back Box Depth 4.81” 4.81” 4.25” 4.25”
Backplane Module Spaces 2 3 3 6
Side Wall 1/2 Module Mounting 2 2 2 2
Battery Allocation 2 x 6.5 AH 2 x 6.5 AH 2 x 6.5 AH 4 x 6.5 AH
firealarmresources.com

Equipment Enclosures Manual 5
CB17 / CB31 / CB45 Semi-Flush 19” Rack Enclosures
Description
The CB17, 31, and 45 semi-flush mounted enclosures are functional and
secure cabinets for the installation of control hardware. All cabinets are
UL Listed, constructed of 16 gauge steel and feature a space frame 19"
rack mount which facilitates equipment installation, wiring and servicing.
Mounting rails with speed nuts are also provided for the RMOF rack
mount option faceplate, which is used to mount a CM1/2(N) with RM
option. The space frame rack mount is hinged on both sides with spring
loaded pin hinges. This allows total access to all points of the equipment
mounted on the back plane as well as that installed directly in the rack.
The removable enclosure door is secured in an integral pan frame, and
may be hinged on either the left or right side. The door is provided with a
Lexan insert for viewing system annunciators, and is secured with a
standard key lock assembly. Mounting studs are provided for mounting a
door security switch, which is be required for security panel operations.
Backboxes are finished in a matte black finish, door assemblies are
painted white. Electrical knockouts are provided on the top, bottom and
sides of the backbox, and keyhole mounting slots are located on the back.
Note: These cabinets do not dedicate space for batteries.
Application
The CB17, 31, and 45 enclosures are designed for installing 19" rack
mounted equipment in semi-flush, wall mounted enclosures. Installation
of a CM1/2(N) with RM option requires a RMOF rack mount faceplate.
firealarmresources.com

6 Equipment Enclosures Manual
Layout
CB17
BACKBO
X
17.5" VERTICAL
RACK SPACE
19" RACK MOUNT
MOUNTING RAILS
NOTE: DASHED LINES INDICATE SEMIFLUSH LINES.
[CAB-005.CDR]
CB31
BACKBO
X
31.5" VERTICAL
RACK SPACE
19" RACK MOUNT
MOUNTING RAILS
NOTE: DASHED LINES INDICATE SEMIFLUSH LINES.
[CAB-006.CDR]
firealarmresources.com

Equipment Enclosures Manual 7
CB45
BACKBOX
45.5" VERTICAL
RACK SPACE
19" RACK MOUNT
MOUNTING RAILS
NOTE: DASHED LINES INDICATE SEMIFLUSH LINES.
[CAB-007.CDR]
Specifications
Enclosure Dimensions
CB17 CB31 CB45
Finished Height 27 7/8”, 70.8 cm 41 7/8”/ 106.4 cm 55 7/8”, 141.9 cm
Finished Width 27 5/8”, 70.2 cm 27 5/8”, 70.2 cm 27 5/8”, 70.2 cm
Finished Depth 8”, 20.3 cm 8”, 20.3 cm 8”, 20.3 cm
firealarmresources.com

8 Equipment Enclosures Manual
Backplane Module Spaces 4 8 12
Side Wall 1/2 Module Mounting 4 4 8
19” Rack Space 17.5”, 44.5 cm 31.5”, 80 cm 45.5”, 115.6 cm
19” Rack Space 5.75”, 14.6 cm 5.75”, 14.6 cm 5.75”, 14.6 cm
Installation
The following table lists the equipment which may be installed in the
CB17, 31, and 45 style enclosures. Total vertical rack space of
installed components may not exceed that listed in the table. Rack
depth indicates the clearance required behind rack mounted
components. Backplane height indicates the clearance required in front
of backplane mounted components. The sum of the rack depth and
backplane height can not exceed 5.75 inches.
Component Dimensions
Component Vertical Rack
Space
Rack Depth Backplane
Height
AA75 N/A N/A 3.5”
ACP 12.25” 5.5” N/A
ACP-6 19.25” 5.5” N/A
APS8B N/A N/A 3.0"
ARM-8 N/A N/A 3.0”
BP1 1.75” N/A N/A
BP2 3.5” N/A N/A
BP3 5.25” N/A N/A
CM1N/CM2N USE RMOF USE RMOF 3.5”
FCCA 7.0” 5.75” N/A
FCCD 7.0” 2.5” N/A
FSWP 3.5” 1.25” N/A
ISP-96 5.25” 2.75” N/A
LEDP 5.25” 2.0” N/A
MUX-8 N/A N/A 1.875”
CNC-8, PCPU, or
DCPU
N/A N/A 2.875”
PS4/8B N/A N/A 4.0”
RAMM N/A N/A 2.5”
RMOF FACEPLATE 7.0” 1.75” N/A
RPSB 3.5” 5.5” N/A
RSAN-6 10.5” 3.0” N/A
firealarmresources.com

Equipment Enclosures Manual 9
RZB 12-6 w/RZMP N/A N/A 2.5”
SWP 5.25” 2.25” N/A
UIO-12 / MFC N/A N/A 1.625”
CB17 Installation
[CAB-008.CDR]
17.00"
3.60"
2.00"
17.50" 20.50"
9.00"
21.19"
6.81"
20.50"
24.19"
9.00"
24.19"
CABINET MOUNTING HOLES
3/4" CONDUIT
KNOCKOUTS
3/4" CONDUIT
KNOCKOUTS 1 1/2"
1.25"
2.00"
INSIDE W/O DOOR
SIDE VIEW
TOP AND BOTTOM VIEW
NOTE: DASHED LINES INDICATE SEMI-FLUSH TRIM.
27.62"
8.00"
Note: Backbox rough-in depth = 5-7/8"
firealarmresources.com

10 Equipment Enclosures Manual
CB31 Installation
[CAB-009.CDR]
17.00"
3.60"
3.00"
30.50" 34.50"
12.50"
21.19"
6.81"
34.50"
24.19"
12.50"
24.19"
CABINET MOUNTING HOLES
3/4" CONDUIT
KNOCKOUTS
3/4" CONDUIT
KNOCKOUTS 1 1/2"
1.25"
2.00"
INSIDE W/O DOOR
SIDE VIEW
TOP AND BOTTOM VIEW
NOTE: DASHED LINES INDICATE SEMI-FLUSH TRIM.
1.0"
27.62"
8.00"
Note: Backbox rough-in depth = 5-7/8"
firealarmresources.com

Equipment Enclosures Manual 11
CB45 Installation
[CAB010.CDR]
17.00"
27.62"
3.60"
3.00"
44.50" 48.50"
19.50"
21.19"
6.81" 8.00"
48.50"
24.19"
19.50"
24.19"
CABINET MOUNTING HOLES
3/4" CONDUIT
KNOCKOUTS
3/4" CONDUIT
KNOCKOUTS 1 1/2"
1.25"
2.00"
INSIDE W/O DOOR
SIDE VIEW
TOP AND BOTTOM VIEW
NOTE: DASHED LINES INDICATE SEMI-FLUSH TRIM.
1.0"
Note: Backbox rough-in depth = 5-7/8"
firealarmresources.com

12 Equipment Enclosures Manual
MFC Enclosure
Description
The MFC enclosure is a surface mounted cabinet designed for remote
mounting of a single module. The MFC is equipped with a quick
release cover with captive mounting screws. RZB module mounting
studs and conduit knock-outs are provided for easy installation. The
cabinet is manufactured from 16 gauge steel, and is painted red.
Application
The MFC is designed for remote mounting of an RZB12-6 or UIO-12
module. Low profile, full footprint modules may also be mounted in
the MFC using the RZMP mounting plate adapter.
Installation
Installation must allow for cable and wire access and for removal of the
front cover.
Use of the RZMP mounting plate adapter will permit low profile, full
footprint modules such as an ARM-8 (without cover) to be mounted in
the MFC.
MOUNTING HOLES FOR
ATTACHMENT TO CABINET
USE #6 SCREWS
MOUNTING HOLES FOR
ATTACHMENT TO CABINET
USE #6 SCREWS
MOUNTING STUDS FOR RZB SERIES
OR UIO SERIES
USE #6 SCREWS
[CAB-011.CDR]
RZMP Mounting Plate
firealarmresources.com

Equipment Enclosures Manual 13
1
3
2
6
5
1
2
3
4
5
6
7
RZB P.C. BOARD
SLOTTED PAN HEAD SCREW #6-32X3/8
LOCK WASHER #6
MFC ENCLOSURE #240143
QUICK OPENING SCREW #362219
CONDUIT KNOCKOUT
TAMPER SWITCH MOUNTING SCREWS
RZB/ INSTALLATIONMFC
[CAB-012.CDR]
RZB / MFC Installation
1
1
7
2
3
4
5
6
7
4
3
5
3
2
6
RZB P.C. BOARD
MOUNTING PLATE
SLOTTED PAN HEAD SCREW #6-32X3/8
LOCK WASHER #6
HEX NYLON STANDOFF #6-32X1/2
SLOTTED PAN HEAD SCREW #6-32X1/4
CABINET BACKPLATE
RZB/RZMP INSTALLATION
[
CAB-013.CDR
]
NOTE: EXTRUDED
PRESS NUTS FACE
REAR
RZB / RZMP Installation
firealarmresources.com

14 Equipment Enclosures Manual
BC-1 Battery Cabinet
Description
The BC-1 battery cabinet is a surface mounted secure enclosure for the
installation backup batteries. The cabinet is constructed of 16 gauge
steel and features a locking door. A terminal strip and in-line fuse is
mounted within the cabinet to facilitate battery wiring.
The cabinet has an off-white finish. Electrical knockouts are provided
on the top and sides of the cabinet with keyhole mounting slots on the
back panel.
Application
The BC-1 is designed for housing large batteries which are too large to
fit inside standard surface and semi-flush mounted enclosures. Cabinets
may be bolted together vertically to increase capacity.
Specifications
Specifications
Material 16 Gauge Steel
Finish Off-White
Dimensions 14” x 18.25” x 7.25” (H W D)
BC-1 Battery Cabinet Capacity
Battery P/N Voltage Amp-
Hour
Capacity
B1250 372001 12 V 5.0 AH 4
B12700 372012 12 V 7.0 AH 4
B12100 372024 12 V 10.0 AH 4
B12150 372014 12 V 15.0 AH 4
B12200 372015 12 V 20.0 AH 2
B12240 372016 12 V 24.0 AH 2
B12333 372016 12 V 33.0 AH 2
B12400 372018 12 V 40.0 AH 2
firealarmresources.com
