General information General
1 General
1.1 General information
Copyright
All contents of this document are property of ETA
Heiztechnik GmbH and are protected by copyright.
Any reproduction, transfer to third parties or use for
other purposes is prohibited without written permission
from the owner.
Subject to technical changes
We reserve the right to make technical modifications
without notice. Printing and typesetting errors or
changes of any kind made in the interim are not cause
for claims. Individual configurations depicted or
described here are only available optionally. In the
event of contradictions between individual documents
regarding delivery scope, the information in our current
price list applies.
Software Description
The software version described in this documentation
corresponds to the version valid at the time of publica-
tion. The software version installed on your product
may differ from that described in this documentation.
A software update to a more recent version can
always be performed. With the appropriate au-
thorisation, the required files can be found at
"www.eta.co.at".
Explanation of symbols
Instructions and information
Layout of safety instructions
SIGNAL WORD!
Type and source of danger
Possible effects
• Measures for avoiding the danger
Types of safety instruction
CAUTION!
On non-compliance withthis safety instruction, there is
a risk of material damage.
WARNING!
On non-compliance withthis safety instruction, there is
a risk of physical injury.
DANGER!
On non-compliance with this safety instruction, there is
a risk of major physical injury.
1.2 Preface
Dear customer,
Safe and satisfactory operation of the product
depends, above all, on correct installation. In this user
manual, you can find out all the important installation
steps, information and instructions for this product
beforehand. Please take the time to look through it.
Warranty and guarantee
You should also read the "Conditions for warranty,
guarantee, liability" (see 1.3 "Warranty, guarantee and
liability") carefully. As a rule, these conditions will be
satisfied by a professional heating technician. Never-
theless, inform the technician of our warranty
conditions. All of the requirements we impose are
intended to prevent damage that neither you nor we
wish to occur.
Training the customer
To avoid errors in operation, please explain to your
customer exactly how his new product works and how
it should be operated and maintained.
Extended warranty
We grant an extended warranty if the product is com-
missioned by an authorised partner company or by our
own customer service. In this regard, please note the
warranty conditions applicable at the time of purchase.
Service agreement
You can ensure the best care for your heating system
by taking out a service agreement with one of our
certified contractors or our own customer service.
1.3 Warranty, guarantee and liability
Requirements
We can only accept liability for the function of our
products if they are correctly installed and operated.
This is only possible if the conditions below are
complied with.

General Warranty, guarantee and liability
5
Observe local building and fire safety regulations
Local building and fire safety regulations must be
observed.
Suitable fuel – pellets
The pellet discharge conveyor is suitable for the
transport of wood pellets per ISO 17225-2-A1 and
ENplus-A1.
Maximum of one filling per year
The fabric of the ETAbox is dimensioned for a
maximum of one filling per year over a period of
approx. 20 years.
Installation in a dry, frost-proof room
A dry, frost-proof room is required for the installation.
Repairs
Repairs are only permitted using spare parts provided
by us. The only exceptions are common standardised
parts such as electrical fuses or fastening materials, as
long as they possess the required features and do not
restrict the functionality of the system.
Proper installation
The installing contractor is liable for proper installation
according to the corresponding installation instructions
and the relevant rules and safety regulations. If you as
customer have installed the heating system partly or
entirely without relevant training and in particular
without up-to-date practical experience, without having
the installation checked by a trained and responsible
expert, we exclude defects in our delivery and conse-
quential damages resulting from this cause from our
warranty, guarantee and liability.
Repair of defects
For repairs of defects carried out by the customer or by
a third party, ETA shall only bear the costs or remain
obligated by warranty if this work was approved in
writing in advance by the customer service of ETA
Heiztechnik GmbH.

6 www.eta.co.at
Technical data
2 Technical data
Technical data
Floor load at maximum filling
Dimensions and data ETAbox 17 ETAbox 21
Lenght (L) x Width (B) 1700 x 1700 mm 2100 x 2100 mm
Height (H) adjustable in increments of 100 mm 1800 - 2500 mm 1800 - 2500 mm
Height (H1) 700 mm 860 mm
Height (H2) 1360 mm 1360 mm
Distance between the filling nozzles (D) 500 mm 500 mm
Storage volume / capacity at H = 1800 mm 3.1 m³ 2.0 t 4.3 m³ 2.8 t
Storage volume / capacity at H = 2100 mm 3.9 m³ 2.5 t 5.6 m³ 3.6 t
Storage volume / capacity at H = 2500 mm 5.0 m³ 3.2 t 7.3 m³ 4.7 t

Installation room General information
7
3 Installation room
3.1 General information
Minimum size of the installation room
For installation, on 3 sides the boiler room must be at
least 200 mm bigger and one side at least 1000 mm
bigger than the external dimensions of the ETAbox.
The entire vertical height up to the ceiling can be
used as the height of the ETAbox can be set in
100 mm increments.
Minimum clearance between the boiler and
ETAbox
Depending on the country-specific regulations, a
minimum clearance must be kept between the ETAbox
and the boiler.
Country-specific building and fire protection
regulations must be observed. It is possible that
setting up the ETAbox in the same room as the boiler
is not permitted.
Minimum 200 mm gap to the wall
On the opposite side to the filling nozzles, a minimum
distance of 200 mm must be maintaned from the
adjacent wall. So that the pellets are cushioned by the
fabric sack during filling and do not shatter against the
wall.
Permanent ventilation and extraction is necessary
Permanent ventilation and exhausting of the boiler
room must be available, for example, through a
window.
ETAbox may not make contact with damp walls
The fabric sack of the ETAbox may not touch damp
walls.
Protecting the fabric sack from UV light
Prevent the fabric sack of the ETAbox being irradiated
by UV light, because then the fabric sack will become
brittle over longer periods of time. Attach dark film or
transparent UV protective film to the window, for
example.
Protecting the fabric sack against damage
Remove or cover pointy or sharp objects near the
fabric sack in order to protect the fabric sack.
Outdoor installation is possible
Outdoor installation is possible if the ETAbox is
protected from the effects of weather. A waterproof
roof as well as side covers are absolutely essential.
The pellet hoses must also be protected against UV
light and sunlight.
Sufficient load bearing capacity of the floor
The floor below the ETAbox must have sufficient load
bearing capacity, because high loads are exerted on
the individual support surfacesformaximum filling; see
2 "Technical data"for more details.
If the ETAbox is set up on a floating screed
(insulation under the screed), the screed in the
area of the support points must be removed and the
area must be filled with concrete.
Or 2 x 12 mm round steel (either threaded rod or
concrete iron) must be placed at each support point of
the feet and on each corner of the extraction unit. Drill
at least 30 mm through the screed into the concrete
floor, clean out the hole, drive the round steel into the
base of the hole with a heavy hammer and cut off the
protruding end.
Extending the filling nozzles
Optional extensions and 45° arches are available for
the filling nozzles. The filling nozzles are extended with
these and thus made accessible.
The extensions may only have a few changes of
direction and the maximum length may not
exceed 10 m.

8 www.eta.co.at
Sample Installation room
3.2 Sample
Decide where to place the ETAbox in the installa-
tion room
Fig. 3-1: Installation example
1 Access to the filling nozzles as well as permanent
ventilation and extraction
2 Filling hoses of the pellet supplier
3 Side inspection ports for the fill level
4 Pellet hoses from the ETAbox to the boiler
5 A minimum clearance must be kept between the
ETAbox and the boiler (dependent on the country-
specific regulations)
Before assembly, the ETAbox's final position in
the room must be determined. The following
points are to be observed in the process:
• The extraction unit of the ETAbox is to be set up so
that the connectors for the pellet hoses are aligned
with the boiler and easily accessible.
• Orient the ETAbox so that the filling nozzles are
accessible for later filling, If possible, the ETAbox
should abut an external wall, so that the filling
nozzles are accessible from outside. The filling
nozzles can be extended if required.
• One of the two side inspection ports must be easily
accessible for monitoring the fill level in the fabric
sack of the ETAbox.
• On the opposite side to the filling nozzles, a
minimum gap of 200 mm must be maintained from
the adjacent wall, so that the pellets are cushioned
and do not shatter against the wall.
• A minimum clearance must be kept between the
ETAbox and the boiler depending on the country-
specific regulations.

Installation room Sample
9
Required clearance for filling

10 www.eta.co.at
Information about pellet hoses
4 Information about pellet hoses
Suitable pellet hose
DN50 pellet hoses with copper litz wire (for earthing)
are required for the suction and return air.
Maximum length - 20 m
The maximum length of the pellet hose is 20 m.
Minimum bending radius: 250 mm
The minimum bending radius for pellet hoses is
250 mm.
If the radius is below this value, thecross section of the
pellet hose is reduced and the friction on the inner
walls increases. As a result, the pellets are damaged,
blockages can occur and the service life of the pellet
hose is reduced.
Installation tips for pellet hoses
Fig. 4-1: Unroll pellet hoses instead of pulling them out
Fig. 4-2: Note bending radius
Fig. 4-3: Avoid twisting pellet hoses
Fig. 4-4: Use pipe guides or pipe supports
Single-piece suction hose
The suction hose for the pellets must always consist of
a single piece.
Suction hoses made from several parts have higher
friction on the inner walls, which can result in damage
to the pellets.
Only the pellet hose for the back air may be made
of multiple parts.
Straight paths
Lay out the pellet hoses as straight as possible.
Suction hoses laid out in loops have higher friction on
the inner walls, which can result in damage to the
pellets.
Earthing
The pellet hoses must be earthed as they acquire an
electrostatic charge during pellet transport. A copper
litz wire is moulded into the pellet hoses for earthing.

Information about pellet hoses
11
On the ends of the pellet hoses, free around 5 cm of
copper litz wire from the hose and bend it inwards into
the hose.
This establishes a contact between conveyor and the
boiler. At the boiler, the copper litz wires are clamped
to the earthing cable near the pellet hose attachment
nozzles.
No contact with uninsulated heating pipes
The pellet hoses are designed for a temperature range
of -15°C to +60°C, so they may not come into contact
with uninsulated heating pipes.
UV protection outdoors
When pellet hoses are installed outdoors, they must be
enclosed in a protective conduit to protect them from
ultraviolet radiation. If the pellet hoses are not
protected, they can become brittle, leading to a
reduced service life.

12 www.eta.co.at
Installation
5 Installation
Assembly and installation only by qualified
specialist personnel
The assembly and installation may be performed
by specialist personnel with the corresponding
qualifications only.
Mounting the extraction unit
Turn the shaft on the drive motor and align the key with
the slot in the gearbox. Push the drive onto the
gearbox and fasten with 4 screws M8 x 25.
Installing the frame
Set the feet to the required height. This can be
adjusted in increments of 100 mm. To fix use 2 M8 x 60
screws and nuts each.
Then mount the 4 rectangular cross bars between the
feet hand-tight with 4 M8 x 60 screws and washers.
Fastening the hopper panels
Align the extraction unit approximately in the middle of
the frame. If space is tight in the installation room, turn
the extraction unit so that the connectors for the pellet
hoses all point in the right direction. Thus the frame will
no longer need to be turned after assembly.

Installation
13
Find the 4 hopper panels with the side edging on the
connecting web.
Fig. 5-1: Hopper panel with edging
Hook a hopper panel into the frame and hand tighten
this with an M 8x 20 screw on the extraction unit.
Then hook the 3 other hopper panels with the edging
offset (see diagram) onto the frame and screw them
into the extraction unit.
Hookthe4 remaining hopperpanelsintotheframeand
in the side edging.

14 www.eta.co.at
Installation
Also tighten each of these with an M8 x 20 screw to the
extraction unit.
Then tighten all screws.
Installing the clamps
Loosely attach 3 clamps to each cross bar with
2 M8 x 60 screws and nuts.
Preparing the fabric sack
Fold up the underside of fabric sack facing outwards.
Thread-in a rectangular cross bar on each side of the
fabric sack in both upper straps and in the bottom pipe
strap.

Installation
15
Threading the fabric sack into the frame
First align the fabric sack so that both filling openings
point to the correct side of the installation room. Then
hook the fabric sack into the frame.
Install each of the threaded cross bars with 4 M8 x 45
screws and nuts hand-tight.
Fix the threaded pipe on the underside of the fabric
sack with the clamps. Tighten the M8 x 60 screws for
this.
Then tighten all screws.
Installing the filling nozzle
Hook the bracket into the frame and fix it with 4 M8 x
20 screws.

16 www.eta.co.at
Installation
Fasten both filling nozzles to the pipe with the clamps.
Fasten both filling nozzles on the bracket with 4 M8 x
20 screws and guide into the fabric sack.
Tie both openings for the filling nozzles to the
fabric sack with bands, so that no dust can
escape during filling.
Attach the covers to the filling nozzles.
Also tie both side inspection openings for the
filling level, so that no dust can escape during
filling or no objects get into the ETAbox.
Fig. 5-2: Inspection opening for fill level
Tighten the lashing strap
Tighten the lashing strap on the top side, to avoid
sagging of the fabric sack. Do not over-tighten to
prevent damage.
Fig. 5-3: Lashing strap

Installation
17
Attaching earthing to the frame
The ETAbox must be earthed. Connect the earthing of
the house's electrical system to a foot with a 6 mm²
earthing cable.
Fig. 5-4: Connecting earthing
Fastening the ETAbox to the floor
The ETAbox must be fastened to the floor. Use the
fastening holes in the feet for this.
Attaching pellet hoses to the ETAbox
On the ends of both pellet hoses, free around 5 cm of
copper wire from the hose and bend it inwards into the
pellet hose.
Push both pellet hoses onto the ETAbox connectors
and fasten them with the hose clamps.
Fig. 5-5: Connections for pellet hoses
1 Return air line from the boiler
2 Pellet suction hose to the boiler
Note instructions about laying pellet hoses
When laying the pellet hoses, take note of the
comments; see 4 "Information about pellet
hoses".

18 www.eta.co.at
Installation
Attach pellet hoses to boiler
On the ends of both pellet hoses, free around 5 cm of
copper litz wire from the hoses.
Fig. 5-6: Exposed copper litz wire
Push both pellet hoses onto the nozzles on the boiler
and fasten them with the hose clamps.
Connect the copper litz wires from both pellet hoses to
the yellow-green earthing cable (next to the nozzles).
Attaching filling instructions
Stick the filling instructions supplied onto the ETAbox
next to the filling nozzles or at the entrance to the in-
stallation room.
Fig. 5-7: Filling instructions

Configuration
19
6 Configuration
Content of this configuration
Only the steps required for the configuration of this
product are described below. The configuration of the
complete heating system is described in the "Configu-
ration" manual supplied with the boiler.
Starting the configuration assistant
The process of starting the configuration assistant
differs depending on the installed software version.
Software version X.35.X and earlier
• Increase the authorisation to [Service]. Then open
the [Toolbox] menu by pressing the button and
the [Configure system] button.
Software version X.36.0 and later
• In the system settings , increase the authoriza-
tion to [Service] and open the system configuration
menu with the [Systems configuration] button.
Start the configuration assistant with the
[Starting the assistant] button.
Description for software version X.36.0 and later
The following description and screen shots represent
the software interface of version X.36.0 and later.
Adjusting function block [Store]
This function block has already been installed at
the factory and configured as pellet conveyor
[Standard screw]. Setting[ETAbox with conveyor
screw] must be selected for the ETAbox with discharge
screw.
Select the function block from the [Selected function
blocks] column.
Open the settings for the function block. Here, make
the following selections:
Press the [Accept] button to save.
Configure rest of heating environment
Configure the rest of the heating environment
(heating circuits, buffers, hot water tanks, etc.);
see the separate "Configuration" manual provided with
the boiler.
Establishing a [Pellets] connection
Establish a new connection by pressing the button
[New connection] and select the connection
type [Pellets] The producers and consumers must be
specified for these; see the following table.
Terminal assignment of the ETAbox
The terminal assignment for the ETAbox is shown in
function block of the pellet store. The ETAbox is
connected to the terminal [S29] of the [PE-C] circuit
board at the factory.
Further configuration and installation
Continue with configuration and installation of the
heating system as described in the "Configura-
tion" manual supplied with the boiler.
Selected function blocks
PE-C 0
Store
ETAbox with conveyor screw
Connections
Pellets
Producers
PE-C 0: Store: Pellets
Consumers
PE-C 0: Boiler: Fuel

20 www.eta.co.at
Electrical connections
7 Electrical connections
Electrical connection must only be made by
qualified specialist personnel
The electrical installation must only be performed
by specialist personnel with the corresponding
qualifications.
DANGER!
Electric shock
There are live parts on the circuit boards. If
touched, they can cause injury and
property damage.
Before beginning any work, isolate the system
completely from all power sources, ensure that it
cannot be switched back on, and verify that it is
safely isolated from supply.
CAUTION!
Flexible stranded conductors
If flexible stranded conductors are not used for the
wiring, the contacts in the plug connections will be
subjected to excessive mechanical strain. In this case,
the warranty for the electronics would become null and
void.
Only flexible stranded conductors may be used for
the wiring.
Connecting the drive
Feed the line for the power supply of the drive from the
boiler circuit board to the ETAbox and connect the
drive.
The ETAbox is connected to the terminal [S29] of
the [PE-C] circuit board at the factory.
Fig. 7-1: Connection of the drive
The drive's power is automatically monitored by
the ETA regulation. Thermal protection (overload
protection) is already integrated into the drive. The
thermal protection terminal is not connected to the
boiler circuit board.
Checking the drive's direction of rotation
The correct rotational direction of the discharge
screw is clockwise looking from the gearbox to
the ETAbox.
Fig. 7-2: Correct direction of rotation
