ETS-Lindgren BiConiLog 3143B User manual

Model 3143B
BiConiLog™ Antenna
User Manual
Model 3143B shown in horizontal polarization

ii |
ETS-Lindgren Inc. reserves the right to make changes to any product described
herein in order to improve function, design, or for any other reason. Nothing
contained herein shall constitute ETS-Lindgren Inc. assuming any liability
whatsoever arising out of the application or use of any product or circuit
described herein. ETS-Lindgren Inc. does not convey any license under its
patent rights or the rights of others.
© Copyright 2012-2018 by ETS-Lindgren Inc. All Rights Reserved. No part
of this document may be copied by any means without written permission
from ETS-Lindgren L.P.
Trademarks used in this document: The ETS-Lindgren logo, BiConiLog, and
FACT are trademarks of ETS-Lindgren Inc.
Revision Record | MANUAL,3143B | Part #399338, Rev. B
Revision Description Date
A Initial Release July, 2012
B Added symmetry data May, 2018

| iii
Table of Contents
Notes, Cautions, and Warnings ................................................ v
1.0 Introduction .......................................................................... 7
Tripod Options ............................................................................................... 9
ETS-Lindgren Product Information Bulletin ................................................. 10
2.0 Maintenance ....................................................................... 11
Annual Calibration ....................................................................................... 11
Replacement and Optional Parts ................................................................. 11
Service Procedures ..................................................................................... 12
3.0 Specifications ..................................................................... 13
Electrical Specifications ............................................................................... 13
Physical Specifications ................................................................................ 13
4.0 Assembly Instructions ...................................................... 15
Attach Bowtie Elements ............................................................................... 16
5.0 Mounting Instructions ....................................................... 19
Using Included Mounting Adapters .............................................................. 20
Using the Stinger to Mount to a Model 2175 MiniMast ................................ 22
Additional Mounting Options ........................................................................ 25
4-TR Mounting Options........................................................................ 25
7-TR and Mast Mounting Options ........................................................ 26
2x2 Boom Mounting Options ............................................................... 28
6.0 Typical Data ........................................................................ 29
Typical Antenna Factor and Gain ................................................................ 29
Typical VSWR .............................................................................................. 30
Typical Beamwidth ....................................................................................... 31
Typical Power Requirements ....................................................................... 32
Horizontal ............................................................................................. 32
Vertical ................................................................................................. 33
Symmetry ............................................................................................. 34
Appendix A: Warranty ............................................................. 37

iv |
This page intentionally left blank.

| v
Notes, Cautions, and Warnings
Note: Denotes helpful information intended to
provide tips for better use of the product.
Caution: Denotes a hazard. Failure to follow
instructions could result in minor personal injury
and/or property damage. Included text gives proper
procedures.
Warning: Denotes a hazard. Failure to follow
instructions could result in SEVERE personal injury
and/or property damage. Included text gives proper
procedures.
See the ETS-Lindgren Product Information Bulletin for safety,
regulatory, and other product marking information.

vi |
This page intentionally left blank.

Introduction | 7
1.0 Introduction
The ETS-Lindgren
Model 3143B BiConiLog™
Antenna is designed as a
dual-purpose antenna that can
be used for both immunity and
emission testing. From 26 MHz
to 6 GHz, the Model 3143B
exhibits an average 5.5 dB gain
improvement. Applications for
the Model 3143B include
emissions testing, immunity
measurements, and medical
equipment testing.
Model 3143B shown in vertical polarization

8 | Introduction
Model 3143B shown in horizontal polarization
The Model 3143B includes a stinger mount; it also includes a mounting bracket
and 1/4–20 thread knob to attach to an ETS-Lindgren tripod or tower adapter.
For the variety of mounting options available for the Model 3143B, see
Mounting Instructions on page 19.

Introduction | 9
Tripod Options
ETS-Lindgren offers the following non-metallic, non-reflective tripods for use at
both indoor and outdoor EMC test sites.
For easy horizontal and vertical polarization, the ETS-Lindgren
Model 7-TR tripod is recommended.
 4-TR Tripod—Constructed of linen
phenolic and delrin, designed with an
adjustable center post for precise
height adjustments. Maximum height is
2.0 m (80.0 in), and minimum height is
94 cm (37.0 in). This tripod can support
up to an 11.8 kg (26.0 lb) load.
 7-TR Tripod—Constructed of PVC and
fiberglass components, providing
increased stability for physically large
antennas. The unique design allows for
quick assembly, disassembly, and
convenient storage. Allows several
different configurations, including
options for manual or pneumatic
polarization. Quick height adjustment
and locking wheels provide ease of use
during testing. Maximum height is
2.17 m (85.8 in), with a minimum height
of 0.8 m (31.8 in). This tripod can
support a 13.5 kg (30 lb) load.

10 | Introduction
ETS-Lindgren Product Information Bulletin
See the ETS-Lindgren Product Information Bulletin included with your shipment
for the following:
 Warranty information
 Safety, regulatory, and other product marking information
 Steps to receive your shipment
 Steps to return a component for service
 ETS-Lindgren calibration service
 ETS-Lindgren contact information

Maintenance | 11
2.0 Maintenance
Before performing any maintenance,
follow the safety information in the
ETS-Lindgren Product Information
Bulletin included with your shipment.
Maintenance of the Model 3143B is
limited to external components such as
cables or connectors.
If you have any questions concerning
maintenance, contact ETS-Lindgren
Customer Service.
Annual Calibration
See the Product Information Bulletin included with your shipment for information
on ETS-Lindgren calibration services.
Replacement and Optional Parts
ETS-Lindgren may substitute a similar part or new part number with
the same functionality for another part/part number. Contact
ETS-Lindgren for questions about part numbers and ordering parts.
Following are the part numbers for ordering replacement or optional parts for the
Model 3143B.
Part Description Part Number
Polarizing Mounting Adapter 100989
Thread Insert 105861
For additional/optional mounting hardware, see Additional Mounting
Options on page 25.
WARRANTY

12 | Maintenance
Service Procedures
For the steps to return a system or system component to ETS-Lindgren for
service, see the Product Information Bulletin included with your shipment.

Specifications | 13
3.0 Specifications
Electrical Specifications
Frequency Range: 26 MHz–1 GHz
Input Impedance (Nominal): 50 Ω
VSWR (Average): 2:1 above 80 MHz
Maximum Continuous Power
30 MHz—60 MHz: 500 W
60 MHz—600 MHz: 1 kW
600 MHz—1000 MHz: 500 W
Peak Power: 1.3 kW
Pattern Type: Directional
Polarization: Linear
Connector: Type N female
Physical Specifications
Height (Overall): 76.2 cm (30 in)
Length: 124.35 cm (48.96 in)
Width: 133.75 cm cm (52.66 in)
Weight: 5.5 kg (12 lb)

14 | Specifications
This page intentionally left blank.

Assembly Instructions | 15
4.0 Assembly Instructions
Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your
shipment.
The Model 3143B BiConiLog™ Antenna consists of the following:
 Antenna
 Bowtie elements (2)
 10–32 thumbscrew knobs to attach bowtie elements (2)
 Mounting bracket and mounting knob

16 | Assembly Instructions
Attach Bowtie Elements
Photos of bowtie elements used in this section may differ from the
bowtie elements for your Model 3143B; the assembly procedure is the
same for both.
The Model 3143B ships with the bowtie elements detached. To attach the bowtie
elements:

Assembly Instructions | 17
1. For stability, mount the Model 3143B onto a tripod or tower. See
Mounting Instructions on page 19 for the steps to mount the antenna.
2. Slide the narrow end of one of the bowtie elements into the
receptacle hole on the antenna balun, and then align the bowtie with
the receptacle on the balun.
Do not cross thread this connection or
permanent damage to the bowtie element could
occur.
3. Insert one of the 10–32 thumbscrew knobs into the opposite side of the
balun from where you inserted the bowtie. Slowly tighten the knob,
taking care not to cross thread the connection.
4. Repeat steps 2 and 3 for the second bowtie element.

18 | Assembly Instructions
This page intentionally left blank.

Mounting Instructions | 19
5.0 Mounting Instructions
Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your
shipment.
The Model 3143B antenna is a precision
measurement device. Handle with care.
Contact with any metal or non-metallic structure can capacitively load the
antenna, which may cause unrepeatable results. Therefore, make sure that no
part of the dipole elements or bowties is in contact with the tripod or tower,
particularly in vertically-polarized tests. Where possible, run the feed cable
straight one meter or more back from the Model 3143B BiConiLog™ Antenna
before dropping vertically.

20 | Mounting Instructions
Using Included Mounting Adapters
In addition to the attached mounting bracket and mounting knobs, the
Model 3143B ships with these mounting adapters:
 100989 Polarizing Mounting
Adapter with 7/8–14 thread
receptacle
If you need to convert the polarizing
adapter to a 1/4–20 receptacle,
insert the 1/4–20 thread insert into
the polarizing adapter
 105861 1/4–20 Thread Insert
