Etymotic Research ER4XR User manual

ETYMOTIC RESEARCHINC.
61 Martin Lane • Elk Grove Village, IL 60007
www.etymotic.com • 888-389-6684 • 847-228-0006
User Manual
360 285
360 285

CAUTION
Etymotic earphones exclude most external sounds. It is unsafe to use in-ear
earphones while operating a motorized vehicle, operating machinery,
bicycling or jogging, because you may not be alerted to potential danger.
In rare instances an eartip may come o in the ear canal when removing the
earphone. If this should occur and the eartip cannot be easily removed, it is
recommended that you promptly contact an audiologist or other medical
professional. A professional can use blunt tweezers to remove the eartip.
Consult an audiologist or physician if you have excessive ear wax, diculty
inserting the eartips, or discomfort after prolonged use.
Do not listen at excessively loud levels. Research conrms that earphones
that seal the ear canal allow listeners to listen at safer levels. Noise-induced
hearing loss is a function of exposure time, the average sound level and the
peak output of very loud sounds. A sealed eartip and lower listening levels
allow for longer periods of safe listening.
2

IN THE BOX
A. Earphones
B. Detachable, 5 ft cord with 3.5 mm gold
plated stereo plug
C. 1 ⁄4" stereo phone adapter
D. Assortment of eartips
E. Filter removal tool
and replacement lters
F. Shirt clip
G. Zippered storage case
H. Performance certicate (not shown)
Accessories are available at www.etymotic.com
3
G
C
F
B
E
A
3-Flange
Small
7-11 mm
Large
8-13 mm
Foam
Black
8-13 mm
D

IDENTIFICATION
4
Eartip
Earphone Body
Cable Connector
Gold Plated 3.5mm
Stereo Plug
designed for most
earphone cases
Braided Cable
for extended
ex life
Splitter Cable
Cable Connector
unsnaps from Earphone Body
Keytab
Notch

SELECTING AN EARTIP
The eartips that are most comfortable are the best choice, but they
should seal well in the ears for best noise isolation and sound quality.
NOTE: Hold the earphone body–not the cable connector–when
removing the eartips to avoid accidentally detaching cable.
When changing eartips
make sure the eartip ts
securely on the stem of
the earphone.
Large 3-ange
8-13 mm
correct incorrect
Small 3-ange
7-11 mm
Foam
8-13 mm
5
Cable Connector
Braided Cable
for extended
ex life

6
PROPER INSERTION
Important: Sound quality, full bass response and noise isolation all depend
on a good eartip seal in the ear canal. See a video demonstration of how
to get a proper t at www.etymotic.com
• While pulling up and out on
the back of the ear carefully
insert the earphone.
• Twist the earphone into the
ear canal while inserting, until
outside noise is blocked out.
• 3-ange eartips: Moistening
eases insertion.
• Foam eartips: Roll down or compress foam eartip before inserting.
Hold the eartip in place for about 5 seconds while the foam expands
to create a tight seal in the ear canal.
REMOVAL
Remove earphones slowly with a twisting motion to gradually break the seal.
Do not pull on the cable to remove the earphones.

7
SHIRT CLIP
CORD SLIDER
Attaching the Clip
Shirt clip attaches to the splitter cable.
Using the Slider
Slider is used to snug the
cable under the chin to
help secure the earphones.
Note: Securing
splitter cable helps
reduce cable noise.

DETACHABLE CABLES
8
Detaching Cables
Attaching Cables
1. Grab the body of the earphone. 2. Pull the cable connector away from
the earphone body. Do not twist.
Pull straight out to prevent damage
to the key tab.
Note: Do not pull or twist
from the cable connector. It's
important to pull straight out.
Note: If the key tab is
not aligned with the
notch, snap will not
engage.
2. Press together until you feel it
snap in.
1. Align the key tab with the notch in
the body of the earphone and cable
connector.
Key Tab
Notch

9
CHANGING FILTERS
Etymotic earphones have special lters that smooth the frequency response
and prevent earwax from entering the earphones. A lter is located
at the end of the earphone and is visible when the eartip is removed.
If a lter becomes clogged, it should be replaced. A dirty lter will reduce
earphone output. The lter should be changed if loudness decreases or the
sound quality declines. Note: Filters are not reusable.
Filter Removal
Note: Use the tool to remove the lter.
1.
Remove eartip. 2. Insert tool into
the lter.
3. Remove lter.
2. Press gently
against a hard
surface to secure
it in place.
3. Re-attach eartip.1. Insert a new lter.
Filter Replacement
Note: Do not use the tool to replace the lter.
Note: Do not pull or twist
from the cable connector. It's
important to pull straight out.

10
CLEANING AND REPLACING EARTIPS
IMPORTANT
Over time eartips may lose their elasticity. For best performance and
retention, replace 3-ange eartips every 60-90 days. Replace foam
and glider eartips frequently.
To clean 3-ange eartips:
1. Remove the eartip from the earphone.
2. Clean with water and mild soap.
3. Dry the eartip before placing it back on the earphone.
• Do not expose the earphones to extreme temperatures.
•
Avoid dropping and strong impact.
• Leave eartips on the earphones for shock protection.
•
Do not pull on the cord to remove the earphone from the audio
device or the ear.
• Clean or replace eartips prior to use by others.
•
For best performance and retention in the ear, replace 3-ange eartips
every 60-90 days.
•
Replace foam eartips frequently.

WARRANTY
Etymotic Research, Inc. warrants this product against defects in material or
workmanship for a period of two years from the date of original purchase
from an authorized Etymotic distributor or reseller.
Etymotic will repair or replace the defective product at its option if returned
within the warranty period to our service facility. This warranty is in lieu of
all other warranties, expressed or implied, including, but not limited to any
implied warranty of merchantability or tness for a particular purpose.

ETYMOTIC RESEARCHINC.
61 Martin Lane • Elk Grove Village, IL 60007
www.etymotic.com • 888-389-6684 • 847-228-0006 ©2016
ER004579
