Etymotic Research ETY-COM ER-22 User manual

User Manual
Important:
read fitting
instructions
before use

Important Instructions
Best performance is achieved by
• obtaining a good seal in the ear canal
• positioning the microphone close to the mouth
Earphone
Select an eartip that allows the earphone to seal the ear canal so
that it stays in position and the boom does not rotate downward
during use. Position the earphone securely in the ear. Moisten
the eartip if necessary to ease insertion.
Microphone
The microphone is highly directional. It will pick up your voice
within a narrow range and reject background noise that comes
from outside that range. To stay in this range, bend the boom so
that the microphone is within 1/2 inch of your mouth. Excessive
jaw movement can cause the eartip to work out of the ear if it is
not well sealed. Occasionally check the
fit of the eartip to ensure that the boom
remains in place and the microphone
does not move away from your mouth;
otherwise the microphone will reject
your voice and you will be difficult to hear.

Insertion
White eartip insertion
• For best results,moisten the eartip before insertion.
• Insert the eartip by pulling the ear outward and
upward. The eartip should seal deeply and
comfortably in the ear canal.
• Adjust the gooseneck so that the microphone
is within 1/2" of your mouth.
• Once properly inserted the microphone (boom)
should not move.
Foam eartip insertion
• Use a foam eartip if a good seal cannot be obtained with a
white eartip.
• Compress the foam at the end of the earphone by rolling
it between your thumb and forefinger before inserting it.
Hold the earphone in place for about 5 seconds while the
foam expands to create a tight seal.
Remove the eartip slowly with a twisting motion to break the seal.
Removal

Eartips
The ETY-COM headset is supplied with assorted eartips to achieve
an optimal fit.
White eartip
Cleaning:
1. Carefully remove the eartip from the earphone.
2. Use water and mild soap to remove dirt and
earwax from the eartip.
3. Rinse and completely dry the eartip.
4. Push the eartip completely on the stem.
Foam eartip
Replace the foam eartip as needed.
2-flange
(small)
2-flange
(large)
3-flange
(long stem)
3-flange
(standard)

Earphone Filter
The ETY-COM headset has a special filter that smoothes the
frequency response and prevents earwax from entering the
earphone. The filter,identified by green acoustic mesh in a small
plastic barrel,is located at the end of the headset and is visible
when the eartip is removed. If the filter becomes clogged it
should be replaced. A dirty filter will reduce or block the headset
output. The need to change filters varies widely among users.
The filter should be changed if the volume decreases or the
sound quality declines.
Changing the filter
1. Remove eartip 2. Remove filter with tool
provided
3. Insert new filter
5. Attach eartip4. Gently press into place

Proper Care
• Do not expose the headset to extreme temperatures.
• Avoid dropping or strong impact.
• Always leave an eartip on the headset for shock protection.
• Do not pull on the cord to remove it from the jack or the ear.
• Clean or replace the eartip prior to use by others.
• Replace the disposable foam eartips regularly.
• Earwax buildup can reduce the headset output. When the filter
becomes clogged it should be replaced. See “Changing the filter.”

Specifications
RECEIVER
Transducer type: balanced armature
Impedance: 32 Ohms @ 1 kHz
Maximum continuous input: 1 V
Sound pressure level 1 kHz: 97 ±3 dB @ 0.1 V
Frequency response: 22 Hz to 12 kHz
MICROPHONE
Microphone type: directional electret
Operating voltage: 1.0 V to 10.0 V
Close talking sensitivity: -46 ±3 dB dB re:1 V/Pa @ 1 kHz
(measured @ 15 mm from source)
Noise Rejection: 10 dB
(compared to an omnidirectional microphone at the same location)
Noise Isolation
The earphone provides the highest noise isolation of any mobile
phone headset. Noise reduction is 37 dB,averaged over the
octave frequencies from 125 to 8000 Hz,allowing only the audio
from the caller to enter the ear. As an earplug, it has a calculated
noise reduction rating (NRR) of 24 dB. The microphone provides
4 to 11 dB greater noise rejection than other microphones at the
same location,and up to 25 dB more noise rejection than booms
that are not close to the mouth.

Warranty
Etymotic Research, Inc.warrants this product against defects in
material or workmanship for a period of 90 days from the date
of original purchase from an authorized Etymotic distributor
or reseller. The warranty can be extended to 1 year if Etymotic
receives a warranty card anytime within 90 days of purchase.
ER will repair or replace the defective product at its option if
returned within the warranty period to our service facility.
This warranty is in lieu of all other warranties, expressed or
implied,including, but not limited to, any implied warranty
of merchantability or fitness for a particular purpose.

Etymotic Research Inc.
Etymotic Research, Inc.(ER) is a research,development and
manufacturing company that designs products to measure,
improve and protect hearing. ER has developed many innovative
hearing technologies available today. ER products are used by
musicians and others who insist on superior sound quality.
Etymotic means“true to the ear.”
Other ETYMOTIC RESEARCH consumer products:
ER-4 MicroPro™Earphones
ER-6 Isolator™Earphones
ER-9, 15, 25 Musicians Earplugs™
ER-20 High Fidelity Earplugs

ETYMOTIC RESEARCH INC.
61 Martin Lane • Elk Grove Village, IL 60007
www.etymotic.com • 1-888-ETYMOTIC
ETY-COM™ is a trademark of Etymotic Research,Inc. The ETY-COM™ headset is covered by one or more of the
following U.S.patents:#4,677,679, #4,763,753, #5,878,147,#5,887,070,#6,075,869, #6,134,344,#6,151,399,
#6,285,771,#6,567,526 and other patents pending.
ER22-20000-3/04
