EUCHIPS RSSW Series User manual

SHANGHAI EUCHIPS INDUSTRIAL CO.,LTD
RSSW Series User Manual V02.1 1 www.euchips.com
RSSW Series
Reset Switch Panel
RSSW-01 RSSW-02 RSSW-03
Product Description
Model
RSSW-XX(XX is from 01 to 03,show the number of switch pole)
Type
Dual control switch
Voltage
12VDC
Current
＜50mA
Electric Life
A million times
Dimension
86 Socket
N.W.
145g
Material
Brushed stainless steel, wrapping
Color
Gentleman grey
Feature
Fashion, and easy to use
Application
Used to trigger weak signal
Switch Sequence

SHANGHAI EUCHIPS INDUSTRIAL CO.,LTD
RSSW Series User Manual V02.1 2 www.euchips.com
Wiring Diagram
In the case of RSSW-03, if only part of them are needed, please keep others blank. If you need to complete the same
function with two keys on the same panel, you need to connect them together.
Installation Guide
1. Install the electrical box on the wall.
2. Connect wire according to wire diagram
3. Gently pry gaps in panel with a screwdriver, and then you can slowly remove the panel.
4. Use screws to fit the bottom cover reliably into the electrical box on the wall.
5. Check the direction of the panel and install it on the bottom cover.

SHANGHAI EUCHIPS INDUSTRIAL CO.,LTD
RSSW Series User Manual V02.1 3 www.euchips.com
Attachment: Installation Dimension（Unit：mm）
