EUFAB iBike Miniped User manual

Page 1 / 16
Art.-no. 14500
iBike Miniped
Content
1. Proper usage 2
2. Scope of supply 2
3. Specifications 2
3.1 Miniped 2
3.2 Motor 2
3.3 Battery 2
3.4 Charging unit 3
3.5 Controls 3
3.6 Electrical wiring diagram, general 3
3.7 Electrical wiring diagram, controls 4
4. Safety notes 4
4.1 General 4
4.2 Charging unit 5
4.3 Battery 5
5. Operating instructions 6
5.1 Assembly 6
5.1.1 Handlebar assembly 6
5.1.2 Pedal assembly 6
5.1.3 Rear mudguard assembly 6
5.1.4 Battery assembly 6
5.1.4 Front light assembly 7
5.2 Overview 7
5.2.1 General 7
5.2.2 Handlebars 8
5.2.3 Digital instrument 8
5.2.4 Remote control 8
5.2.5 Charging unit 8
5.2.6 Battery 9
5.3 Operation 9
5.3.1 Charging the battery 9
5.3.2 Remote contro functions, switching the Miniped on/off 9
5.3.3 Folding mechanism 10
5.3.4 Adjusting the seat height 11
5.3.5 Parking the Miniped 11
6. Maintenance and care 12
6.1 Maintenance 12
6.1.1 Tyre pressure 12
6.1.2 Battery 12
6.1.3 Chain 12
6.1.4 Brakes 12
6.1.5 Replacing the remote control batteries 12
6.2 Inspection and service plan 13
6.3 Care 13
7. Environmental protection notes 14
8. Contact information 14

Page 2 / 16
WARNING
Read through all operating instructions carefully before operating and observe all
safety information!
Non-compliance can lead to personal injury, damage to the device or to your property!
Keep the original packaging, the purchase receipt as well as these instructions for
future reference! When transferring this product pass on these instructions as well.
Before operating, check that the content of the package is intact and complete!
Subject to technical changes!
1. Intended usage
The Miniped is designed for short trips on paved roads in urban areas. It is not suitable for usage where
road and weather conditions are bad (e.g. rain, snow or icy roads). It cannot be used for extreme sports
and demonstrations.
The range of the Miniped is measured at an outdoor temperature of about 25 °C with a load of approx.
70 kg on a smooth road. This can deviate depending on the weight of the driver, driving performance,
outdoor temperature and road condition.
This device is not suitable to be used by children and people with reduced mental capacity or without
the necessary specialised knowledge. Children should keep away from the device.
This device is not intended for commercial usage.
Proper usage also includes observing all the information in these instructions, especially observance of
the safety notes. Any other usage is considered improper and can lead to property damage and personal
injury. EAL GmbH is not liable for damages that occur due to improper usage.
2. Scope of supply
1 x Miniped 1 x connectible front light
2 x keys 1 x back mudguard
2 x remote control 1 x wrench set
1 x charging unit 1 x operating instructions
1 x battery 1 x service booklet
2 x pedals 1 x warranty form
3. Specifications
3.1 Miniped
Wheelbase: 825 mm
L x W x H: 1180 x 1100 x 550 [mm]
L x W x H (folded together): 1130 x 680 x 380 [mm]
Maximum speed: 25 km/h
Max. range: 40 km
Max. load: 120 kg
Noise level: < 60 dB
Weight: 21 kg
3.2 Motor
Nominal voltage: 36 V
Rated power: 250 W
Rotor rated speed: 450 U / min
Max. torque: 28 Nm
Max. efficiency: 80 %
Type: brushless and gearless
3.3 Battery
Voltage: 36V
Capacity: 8.7 Ah
Model: Panasonic 18650 – 2900PF
Service life: over 1,000 loading cycles
Discharge rate: 3 C

Page 3 / 16
Charging time: 4 hours
3.4 Charging unit
Input voltage: 230 V
Output voltage: 42 V
Output current: 2 A
3.5 Controls
Model: Sine wave
Maximum current: 14 A
Minimum voltage 29 V
3.6 Electrical wiring diagram, general
bold, red
bold, black
bold, blue
bold green
bold yellow
thin red
thin yellow
thin blue
thin green
thin black
thin red
thin blue
thin green
thin black
thin white
thin orange
thin blue
thin green
thin orange
thin black
thin violet
thin white
thin white
thin red
thin black
Battery
Battery
Speedo-
meter
Anti-theft
alarm
Charging unit
Charging
Connection
Battery +
Battery -
Measuring signal speed
Signal throttle valve
Brake signal
Brake signal
Lock ACC
Lock ACC
Lock motor CLK
Line phase detection
Battery – GND
Line FE1
Battery + ACC
GND
Energy Light
Brakes
Acoustic signal
generator
Switch
Warning light
horn
Throttle valve
LCD measuring
device
Maximum speed
Anti-theft alarm
Anti-theft alarm
Brake light
Reverb
Brake signal

Page 4 / 16
3.7 Electrical wiring diagram, controls
4. Safety information
4.1 General information
• The warning triangle identifies all instructions that are important for safety. Be sure to
always follow these, otherwise you could injure yourself or damage the device.
• Children are not allowed to play with the device.
• Cleaning and user maintenance cannot be performed by children without supervision.
• Do not leave the packaging material lying around. It can be a dangerous toy for children!
• Only use this product for its intended purpose!
• Do not tamper with or disassemble the device!
• For your own safety, only use accessories or replacement parts that are listed in the
instructions or the usage of which is recommended by the manufacturer!
• Adjust the seat height so that you can ride safely and comfortably and are able to place
feet on the ground quickly.
• Before each ride, ensure that the brakes function, the tire pressure is ok, and that all fixtures
are in faultless condition.
• Ensure that accessory parts are mounted at the right positions and familiarise yourself with
the functions.
• When using the Miniped for the first time, first try it out on a short, safe section of road.
Only drive in road traffic when you have good control riding the Miniped.
• A quick-release lever that isn't completely closed can re-open. This can lead to serious
falls. Turning the quick-release lever must be so difficult that the heel of the hand is required
to do so. Only then is the tension strong enough.
• Always wear a helmet.
• Wear bright and noticeable clothing. Be sure not to wear loose clothing that could get stuck
in the chain, handlebars, pedals or wheels.
thin orange
thin blue
thin green
thin orange
thin black
thin violet
thin white
thin white
thin red
thin black
bold, red
bold, black
bold, blue
bold green
bold yellow
Battery
Battery +
Battery -
Measuring signal speed
Signal throttle valve
Brake signal
GND
Energy
Lock ACC
Lock motor CLK
Phase detection line
Line FE1
Battery + ACC
Battery – GND
Lock ACC
Brake signal
thin red
thin blue
thin green
thin black
thin white
LCD measuring device
Maximum speed
Anti-theft alarm
Anti-theft alarm
Brake light
thin red
thin yellow
thin blue
thin green
thin black
red
yellow green blue
black
Reverb

Page 5 / 16
4.2 Charging unit
• Do not use the charging unit in a moist or wet environment.
• Be sure to prevent water from penetrating the device. If liquid should get inside,
immediately separate the charging unit from the power supply and have it checked by an
authorised dealer.
• Place the charging unit on an even surface only so that it stands firmly.
• Do not operate the charging unit with damaged cable or plug.
• Do not operate the charging unit after it has received a strong hit, has fallen or been
damaged in any other way.
• Do not attempt to repair the device yourself. Do not open or disassemble the device. Have
the charging unit checked by your authorised dealer.
• Before cleaning, separate the charging unit from the power supply and from the battery.
4.3 Battery
• The Miniped's charging unit and battery are mutually compatible. Never charge the battery
using a different charging unit.
• Protect the battery from moisture and hard impacts.
• Do not use the battery after it has received a strong hit, has fallen or been damaged in any
other way.
• Do not attempt to repair the device yourself. Do not open or disassemble the casing of the
battery. Have the battery checked by your authorised dealer.
• Do not touch the battery contacts with metal objects.
• Never leave the battery permanently connected to the charging device when not in use for
a long period of time.
• Do not leave the battery unattended during the charging procedure.

Page 6 / 16
5. Operating Instructions
5.1 Assembly
5.1.1 Handlebar assembly
The handlebars of the Miniped are pre-assembled
and just need to be attached to the head tube. Do to
so, loosen the screw (A) and remove the protective
cap (C), see Image 1. Place the handlebars onto the
head tube.
ATTENTION: The electrical cables and
brake lines cannot be twisted, kinked or
clamped.
Straighten the handlebars and tighten both screws (B). Place the screw (A) back in the control head and
tighten it.
5.1.2 Pedal assembly
The pedals are marked with the letter "R" for the
right and "L" for the left side, see Image 2. The right
pedal has a right-hand thread, the left one has a left-
hand thread. Screw the right pedal clockwise into
the threaded hole of the right pedal crank. Screw the
left pedal counter-clockwise into the threaded hole
of the left pedal crank.
5.1.3 Rear mudguard assembly
Place the mudguard on the frame of the back wheel.
Align it with the mounting holes and screw it tight
with both screws, Image 3.
5.1.4 Battery assembly
Insert the key into the lock on the right side of the
battery and turn in a counter-clockwise motion as far
as it will go, Image 4. The battery locking
mechanism is now completely open.
Image 3: Back mudguard
Image 4: Opening the locking
mechanism
Image 2: Labelling on the pedals
Image 1: Assembling the
handlebars

Page 7 / 16
Now put the battery into the mount as depicted in the following images, Image 5 to 7.
Press the battery firmly into the mount at the top
end. When the battery makes contact with the
Miniped's electrical system, an acoustic signal will
sound. Hold the battery there firmly. Turn the key
clockwise as far as it will go, Image 8. Remove the
key. The battery is now firmly locked.
Ensure that the battery connections do not
come into contact with metal objects
during assembly. It may cause a fire and
explosion hazard.
5.1.4 Front light assembly
Insert the front light into the mount on the front of the MIniped's head tube using the sheet metal tabs.
Switch the front light on and adjust it so that the light beam shines onto the street approx. 10 m in front
of the Miniped. Turn the front light off again.
5.2 Overview
5.2.1 General Information
1 Front wheel
2 Front brakes
3 Suspension fork
4 Mount for front light
5 Handlebars
6 Seat
7 Quick-lock seat fastener
8 Locking lever, folding mechanism
9 Battery
10 Rear light
11 Back mudguard
12 Back brake
13 Back wheel with hub motor
14 Pedals
Image 9: Overview, general
Image 5: Inserting the battery
Image 6: Pressing the battery
Image 7: Battery assembled
Image 8: Closing the locking
mechanism

Page 8 / 16
5.2.2 Handlebars
15 Brake handle, back wheel
16 Adjusting screw, back wheel brake
17 Adjusting screw, front wheel brake
18 Brake handle right, front wheel
19 Bell
20 Light switch
21 Digital instrument
5.2.3 Digital instrument
22 Speed display
23 Mileage
24 Battery display
25 Travel time
26 Outside temperature
5.2.4 Remote control
27 Control light
28 Anti-theft alarm on switch
29 Anti-theft alarm off switch
30 Vehicle search button
31 Start button
32 Eyelet for keyring
5.2.5 Charging unit
33 Power plug
34 Charging plug
35 Charging unit
36 Control light
Image 10: Handlebars overview
Image 11: Digital instrument
overview
Image 12: Remote control overview
Image 13: Charging unit overview

Page 9 / 16
5.2.6 Battery
37 Lock
38 Charging socket with protective cap
39 Rear light
40 Connections
41 Locking mechanism
5.3 Operation
5.3.1 Charging the battery
The battery can be charged in an installed and uninstalled state. Switch the Miniped off (see Section
5.3.2) when charging the battery that is not installed.
Connecting the charging unit:
First remove the protective cap from the charging socket (Position 38 in the overview) on the left side of
the battery. Plug the charging plug (Position 34 in the overview) into the charging socket and tighten the
plug's cap nut. Lastly, plug the power plug (Position 33 in the overview) of the charging unit into the
socket.
The control light (Position 36 in the overview) of the charging unit lights up while the battery is charging.
When the battery is full, the control light turns green.
Removing the charging unit:
First pull the power plug out of the socket. Then loosen the cap nut of the charging plug and pull it out
of the battery's charging socket. Reattach the protective cap. Always observe this sequence.
5.3.2 Remote control functions, switching the Miniped on and off
The control light (Position 27 in the overview) lights up each time a remote control button is pressed.
Remote control functions
On switch
(Position 28 in the overview)
Activating the anti-theft alarm
system
press once
Switching on the acoustic
alarm
press for 2 seconds
Off switch
(Position 29 in the overview)
Deactivating the anti-theft
alarm system
press once
Switching off the acoustic alarm
press for 2 seconds
Search button
(Position 30 in the overview)
Acoustic signal to find the
vehicle
press once
Set the sensitivity of the sensor
that triggers the anti-theft alarm
(high/low)
press for 2 seconds
Start button
(Position 31 in the overview)
Turn on the Miniped
press 2 times in 3 seconds
Chart 1: Remote control functions
Switching the Miniped on/off
In order to switch on the Miniped, first switch the anti-theft alarm system off (press the off switch once).
Then press the start button twice within 3 seconds. An acoustic signal is heard and the digital instrument
Image 14: Battery overview

Page 10 / 16
is activated. The Miniped is now ready to be ridden.
Turn the Miniped off by pressing the off switch once.
Activating/Deactivating the anti-theft alarm system
First, switch the Miniped off. Press the on switch once to activate the anti-theft alarm system. An acoustic
signal will sound.
You can set the sensitivity of the triggering sensor for the anti-theft alarm system to two levels: High,
very sensitive, triggered at the slightest movement of the Miniped. Low, in order to be triggered the
Miniped must be moved away from its spot. These settings are selected by pressing the search button
for 2 seconds.
Press the off switch once to deactivate the anti-theft alarm system.
5.3.3 Folding mechanism
Folding the Miniped
First switch the Miniped off before actuating the folding mechanism.
Loosen the quick-release mechanism of the seat post (Position 6 in the overview) and turn the seat tip
to the side (Image 15 to 18). Then lock the quick-lock again.
Hold the Miniped firmly with one hand on the
handlebars. Use the other hand to push the locking
lever (Image 19) (Position 8 in the overview)
upwards on the frame. Now pull the frame upwards
and release the lever. Lift the frame with the seat
post until the locking mechanism audibly clicks into
place.
The Miniped has now been folded (Image 20) and
can be stowed away to save space or be
transported.
Image 15: Quick-lock
closed
Image 16: Quick-lock
open
Image 17: Seat
straight
Image 18: Seat turned
Image 19: Releasing the locking
mechanism
Image 20: Folded
Miniped

Page 11 / 16
Folding the pedals
You can still fold the Miniped's pedals. This can be helpful when you want to take the Miniped onto public
transportation. Proceed as depicted in Images 21 and 22.
Put the pedal back into riding position by lifting the outer end until the pedal clicks into place.
Always take hold of the pedal from the outside, never close to the pedal crank. There is a risk
of fingers getting crushed.
Unfolding the Miniped
Hold the Miniped firmly with one hand on the handlebars. Use the other hand to push the locking lever
(Image 19) upwards on the frame. Hold the lever firmly and press the frame with the seat post downward.
Let go of the lever halfway down and press the frame into riding position until the locking mechanism
clicks back into place. Straighten the seat again.
Ensure that the seat post quick-lock sits firmly and the tension lever is flat against the seat
tube.
5.3.4 Adjusting the seat height
To ri d e c o m fo rt ab ly a nd s af el y, th e se at m us t be s et t o f it y ou r b o dy s iz e.
To ad ju st t he h ei gh t, o pe n th e q u i c k -lock on the seat post (Image 15). Set the seat at a height where the
foot rests on the pedal on the lowest position while sitting with the leg not fully straight. You should be
able to comfortably touch the floor with the tips of your feet. Press the quick-lock lever until tight again.
Only pull the seat post out up to the
marking, lines, Image 23. The marking
cannot be visible!
Ensure that the seat post quick-lock sits firmly and the tension lever is flat against the seat
tube.
5.3.5 Parking the Miniped
First switch the Miniped off before parking it.
Only park the Miniped on a firm surface (no sand,
gravel or other loose surfaces). Fold out the stand
(Image 24) and lean the Miniped until the stand
touches the ground. Check that the Miniped stands
securely before letting go of it.
Image 23: Markings on the seat post
Image 24: Folding down the stand
Image 21: Releasing the locking
mechanism
Image 22: Folding the pedal
Marking for
maximum seat height

Page 12 / 16
Ensure that the stand is completely folded up and clicked in place before riding away in the
Miniped. A folded-down stand can lead to serious falls while riding.
6. Maintenance and care
Do not park the MIniped outdoors unprotected. Avoid direct sunlight or rain. Rainwater permeating the
interior of the Miniped can lead to short circuits thereby destroying the electronics.
Perform a brake test after cleaning and/or before starting a trip.
6.1 Maintenance
6.1.1 Tyre Pressure
The wheels of the Miniped are outfitted with Schrader valves (car tyre valves). The tyres can be inflated
using a conventional air pump for this type of valve, or with compressors.
When using compressors (e.g. at a gas station) the maximum filling pressure is quickly
attained due to the small volume.
Tyre pressure front and back: max. 2.8 bar
If you aren't using the Miniped for a longer period of time, park it in such a way that the tyres are
unencumbered.
6.1.2 Battery
Control the charge level of the battery regularly by reading the battery display in the digital instrument.
If only one charging bar is visible re-charge the battery. In the event of longer periods of non-use, e.g.
winter break, charge the battery every three months. When starting to use the Miniped after a long break,
connect the battery to the charging device for approx. one day.
6.1.3 Chain
Lubricate the chain every 500 km or after each cleaning and after every ride in the rain with a chain
lubricant from a specialised bike shop. Check the chain tension every 500 km. To do this, lift the returning
part of the chain in the middle. If the chain can be lifted more than the height of five chain links, the chain
tension is too low and the chain must be tightened or replaced.
6.1.4 Brakes
If the performance of the brakes decreases and you have to pull the brake handle very far, readjust the
brake cables by untwisting the adjusting screw on the brake lever. When this is no longer enough to
guarantee safe braking performance, find a specialised bike workshop to repair the brakes.
6.1.5 Changing remote control batteries
Two button batteries, Type CR2025, 3V, lithium, are needed for replacement. Open the remote control
and switch the batteries as depicted in Images 25 to 28.
When inserting the battery ensure that the positive terminal of the button batteries is on top.
Image 25:
Remove
casing screws
Image 27:
Remove battery
holder
Image 26:
Carefully remove
circuit board
from the casing
Image 28:
Place batteries into the
battery holder

Page 13 / 16
Assembly is performed in reverse sequence.
6.2 Inspection and service plan
Inspection and service intervals
Runtime in km
300
2000
4000
6000
electr. system, lighting
C
C
C
C
Tyre pressure, tread depth at least 1 mm
C
C
C
C
Suspension fork, shock absorption /
impermeability
C
C
C
C
Battery charging voltage
C
C
C
C
Check battery for impermeability
C
C
C
C
Check brake cables for damage
C
C
C
C
Brake disk, brake pad front
C
C
C
C/R
Brake disk, brake pad back
C
C
C
C/R
Bell
C
C
C
C
Check main motor cable for damage
C
C
C
C
Pedal / bearing play
C
C
C
C
Check that the electric motor is centrally mounted
C
C
C/R
C/R
Tightness of all screws relevant for safety
C
C
C
C
Brake light switch
C
C
C
C
Headlight settings
C
C
C
C
Wheels: Bearing play, smooth operation
C
C
C
C
Check tyres for damage and foreign objects
C
C
C
C/R
Steering head bearing play, handlebar screws
C
C
C
C
Speedometer
C
C
C
C
Lubrication areas: Lines, levers, brake cams, side
stands, locking mechanisms, chain *)
C
C
C
C
C = Check, R = Replace
*) see Chapter 6.1.3
6.3 Care
Never clean the Miniped with a high-pressure cleaner. This can damage the tyres and destroy
seals. Water can permeate the bearings and the electric system.
Use conventional cleaning and care products for bikes when cleaning. Prevent penetration of liquid into
the interior of the electrical system and into the digital instrument. Do not use a polishing product for the
plastic surfaces.

Page 14 / 16
7. Notes about environmental protection
Never dispose of electrical devices in household waste! Electrical and electronic devices must
be collected and brought in for environmentally compatible recycling. Ask your municipality or
city administration for disposal options for electrical and electronic devices.
At the end of their service lives, old batteries cannot be disposed of in household waste - or
carelessly in the environment. Hand in old batteries at distributor (dealer) collection points. By
doing so you are making a valuable contribution to protecting the environment. Municipalities
partially take back old batteries, for instance through waste collection vehicles or at recycling
yards.
8. Contact information
EAL GmbH
Otto-Hausmann-Ring 107
42115 Wuppertal
Germany
Telephone: [phone]
Fax: [phone]
Internet: www.eal-vertrieb.com
E-Mail: [e-mail]

Page 15 / 16

Page 16 / 16
EAL GmbH • Otto-Hausmann-Ring 107 • D – 42115 Wuppertal
© EAL 14500 Ma17
