Eureka 2500 Series User manual

HouseholdType
Owner’s Guide
2500 Series
Index
Important Safeguards..................... 2
Service Information ........................ 5
Assembly ........................................ 7
Preparation ..................................... 8
Use........................................... 11-15
Maintenance ............................ 16-18
Problem Solving ........................... 19
Order Form ................................... 21
Warranty ....................................... 23
IMPORTANT
Do not return this
product to the store.
For assembly problems or
questions contact: Eureka’s
Customer Service Division toll
free at 1-800-282-2886*, 8
a.m.to 7:30 p.m., (CST),
Monday - Friday and 10 a.m.
to 6:30 p.m.Saturday.
For replacement of broken
or missing items to be
shipped direct to you, call 1-
800-438-7352*, 8 a.m. to 4:45
p.m., (CST), Monday - Friday.
*EnMexico llame al5670-6169
Rating Plate
The model, type, and serial numbers are on the rating plate on the back of
your shampooer.Write these numbers here on the front page and refer to
them when inquiring about service.
Model &Type__________________________________
Serial No. _____________________________________
MODEL TYPE SERIAL NO.
VOLTS AMPS. HERTZ
SERVICE INFORMATION:1-800-282-2886
THE EUREKA COMPANY
BLOOMINGTON,ILLINOIS 61701
www.eureka.com

IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USINGTHIS CARPET SHAMPOOER/EXTRACTOR.
WARNING
To reduce the risk of fire, electric shock, or injury.
•Do not immerse product. Use only on surfaces moistened by cleaning process.
•Do not use outdoors or expose to rain.
•Use only commercially available floor cleaners intended for machine application.
• Do not leave the Carpet Shampooer/Extractor when plugged in. Turn OFF the switch and unplug the electrical cord
when not in use and before servicing.
•Do not allow to be used as a toy.Close attention is necessary when used by or near children.
•Use only as described in this manual.Use only manufacturer’s recommended attachments.
•Do not use with damaged cord or plug. If the Carpet Shampooer/Extractor is not working properly, has been dropped,
damaged, left outdoors, or dropped into water, return it to a service center immediately.
•Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners.
Do not run the Carpet Shampooer/Extractor over cord.Keep cord away from heated surfaces.
•Connect to a properly grounded outlet only (refer to Grounding Instructions).
•Do not use extension cords or outlets with inadequate current carrying capacity.
•Turn off all controls before unplugging.
•Do not unplug by pulling on cord.To unplug, grasp the plug, not the cord.
•Do not handle plug or Carpet Shampooer/Extractor with wet hands.
•Donot put anyobjectinto openings.Donot usewith any openingblocked;keepfreeof dust,lint, hair,and anythingthat may
reduce airflow.
•This Carpet Shampooer/Extractor creates suction. Some models also contain a revolving brush roll. Keep hair, loose
clothing, fingers, and all parts of body away from openings and moving parts.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot fireplace or barbecue ashes.
•Do not use without recovery tank in place.
•Use extra care when cleaning on stairs.
•If the machine tips over during use, shut it off immediately, set it upright, and wait for the motor to stop completely.This
allows the ball float to return to normal position and permits proper airflow through the cleaner.
•Do not use to pick up gasoline, acetone, perfumes, colognes, paint thinners and other flammable liquids or use in places
where they may be present.
•Operate and store indoors in an area above 32°F where the machine will not freeze.
•Keep your work area well lighted.
SAVE THESE INSTRUCTIONS
2

CONSEILSDESÉCURITÉIMPORTANTS
L’utilisation d’un appareil électrique sous-entend l’observation de certaines règles de sécurité élémentaires:
LIRETOUTES LES INSTRUCTIONS AVANT D’UTILISER L’ASPIRATEUR.
AVERTISSEMENT
Pour réduire les risques de feu, de secousse électrique ou de blessure:
•Ne pas immerger.Utiliser uniquement sur un tapis mouillé par le dispositif de nettoyage.
•Ne pas utiliser à l’extérieur. Ne pas exposer à la pluie.
•Utiliser uniquement des produits nettoyants offerts sur le marché pour l’application à la machine.
•Ne pas s’absenter tant que l’aspirateur est branché. Éteindre l’appareil et le débrancher lorsqu’on ne s’en sert plus et
avant son entretien.
•Veiller à ce que l’aspirateur ne serve pas de jouet, particulièrement si l’usager est un enfant ou si l’on s’en sert près d’un
enfant.
•Nes’en servirque selonla descriptionqu’endonne le guide.N’employer que lesaccessoires que recommandele fabricant.
• Ne pas s’en servir si le cordon ou la fiche sont abîmés. Avant de se servir de l’aspirateur, le retourner à un centre de
réparation s’il ne fonctionne pas comme il faut, s’il est tombé ou abîmé, si on l’a laissé dehors ou laissé tomber dans l’eau.
•Ne pas le tirer ou le transporter par le cordon, ne pas se servir du cordon comme d’une poignée, ne pas coincer le cordon
en fermant une porte et ne pas tirer le cordon sur des encoignures ou des bordures pointues.Ne pas passer l’aspirateur
sur le cordon.Éloigner le cordon des surfaces chauffées.
•Branchez toujours l’aspirateur dans une prise à trois (mise à la terre).
•Ne pas se servir de cordons de rallonge ou de prises d’intensité admissible mal adaptée aux besoins.
•Éteindre complètement l’aspirateur avant de le débrancher.
•Ne pas tirer sur le cordon pour débrancher l’aspirateur. Le débrancher en tirant sur la fiche et non sur le cordon.
•Ne toucher ni à la fiche ni à l’aspirateur avec les mains mouillées.
•Ne pas introduire d’objets dans les orifices. Ne pas se servir de l’aspirateur avec une ouverture bouchée et en écarter
poussière, charpie, cheveux et autres qui risquent de réduire la circulation de l’air.
•Cetaspirateurcrééde lasuccion.Certains modèlessont équipésd’un rouleau-brosse.Maintenirlescheveux,les vêtements
amples, les doigts et toutes les parties du corps à l’écart des ouvertures et des pièces mobiles.
•Ne rien ramasser de brûlant ou de fumant, comme par exemple mégots, allumettes ou cendres chaudes des cheminées
ou des grilles.
•Ne pas utiliser aussi si le réservoir n’est pas installé.
•Redoubler de prudence lorsqu’on aspire les escaliers.
•Sil’aspirateur serenversequand il estenusage, tout-de-suiteil fautl’éteindre,mettre- leà la positiondroite et attendre que
lemoteurs’arrête complètement.Celapermettraquelaflotteurretourneàsa positionnormaleet laisselanormale circulation
d’air passée dans l’aspirateur.
•Ne vous servez pas de l’appareil pour ramasser de l’essence, acétone, parfum, colgone, diluant a peinture et d’autres
liquides inflammables, ne l’utilisez pas non plus là où ces produits risquent d’être présents.
•Pour éviter le risque de gel, utiliser et entreposer à l’intérieur dans un endroit où la température est toujours au-dessus de
32°F (0°C).
• Bien éclairer la surface de travail.
CONSERVER CES INSTRUCTIONS 3

Grounding Instructions
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock.This appliance is equipped with a cord having an equipment-grounding
conductor and grounding plug.The plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
DANGER
Improperconnection ofan equipment-groundingconductor can resultin riskofelectric shock.Checkwithaqualified electrician
or service person if you are in doubt as to whether the outlet is properly grounded.Do not modify the plug provided with the
appliance.If it will not fit the outlet, have the proper outlet installed by a qualified technician.
This appliance is for use on a nominal 120 volt circuit and has a grounding plug that looks like the plug illustrated in Figure A.
A temporary adapter which looks like the adapter illustrated in Figure B may be used to connect this plug to a two-pole
receptacle,asshown,ifa properlygroundedoutletis not available.The temporary adapter shouldbe used only untila properly
groundedoutlet,FigureA, can be installedbya qualified electrician.The greencolored rigid ear,lug, or the likeextendingfrom
the adapter must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the adapter
is used, it must be held in place by a metal screw.
NOTE: In Canada, the use of a temporary adapter is not permitted by the Canadian Electrical Code.
INSTRUCTIONS VISANT LA MISE À TERRE
Cetappareil doit être misà la terre.Encas défaillanceoude panne éventuelles,lamise à la terrefournit au courantun chemin
de moindre résistance qui réduit le risque de choc électrique.Cet appareil est pourvu d’un cordon muni d’un conducteur de
terreet d’une fiche avecbroche de terre.Lafiche doit être branchée dansune priseappropriée correctement installée et mise
à la terre conformément aux règlements et ordonnances municipaux.
AVERTISSEMENT
Un conducteur de terre mal raccordé peut entraîner un risque de choc électrique.Consulter un électricien ou un technicien
d’entretien qualifié si vous n’êtes pas certain que la prise est correctement mise à la terre. Ne pas modifier la fiche fournie
avec l’appareil-si elle ne eput être insérée dans la prise, faire installer une prise adéquate par un électricien qualifié.
Note. Au Canada, l’utilisation d’un adaptateur temporaire n’est pas autorisée par le Code canadien de l’électricité.
Cet appareil est destiné à un circuit de 120V et est muni d’une fiche de mise à la terre semblable à celle illustrée par le Figure
A.S’assurer que l’appareil est branché à une prise de courant ayant la même configuration que la fiche.Aucun adaptateur ne
devrait être utilisé avec cet appareil.
4
Grounding Blade is
Longest of the Three
Blades
La Lame de Terre Est
La Plus Longue Des
Trois Lames
Grounded Outlet Box
Boîte de Prise de Terre
Figure A
Adapter
Adaptateur Grounded Outlet Box Boîte de Prise deTerre
Metal Screw
Vis de Métal Grounding Tab
Taquet de Terre
Figure B

GENERAL INFORMATION
NOTE: Thoroughly clean carpet, upholstery and stairs with a vacuum cleaner before using the Carpet Shampooer/
Extractor. Also, sweep any hard surface floors before using the carpet shampooer/extractor.
Automatic Suction Shut-Off
The automatic suction shut-off functions when the recovery tank is full of liquid. As the tank fills, the ball float (inside the
recovery tank) rises until it seats itself against the motor.This shuts off the suction causing the motor sound to become high
pitch.When this happens, empty the recovery tank.
The automatic suction shut-off also functions if the carpet shampooer/extractor tips over. To continue use, turn the Carpet
Shampooer/Extractor OFF and set it upright.Wait a few seconds to allow the motor to come to a complete stop. Restart the
CarpetShampooer/Extractor.
Service Information
The instructions in this booklet serve as a guide to routine maintenance.For additional service information telephone our toll
free number for the nearest Eureka Authorized Warranty Station. You should know the model, type and serial numbers
when you call: USA: 1-800-282-2886
Mexico: 5760-6169
Canada: 1-800-282-2886
If you prefer, you can write to The Eureka Company, Service Division, 807 North Main Street, Bloomington, Illinois 61701,
USA.In Canada write toThe Eureka Company, 866 Langs Drive, Cambridge, Ontario N3N 2N7.Refer toThe Eureka Limited
Warranty for complete service information.
DO NOT OIL the motor or the brush roll at any time.The bearings have a seal and are permanently lubricated.
5

6
Carpet Shampooer/Extractor Parts
Some Eureka carpet shampooer/extractor
models do not feature an attachment hose
and selector knob. These features are
specified only on selected models.
Handle
CleanWater
SolutionTank
Selector
Knob
Suction
Cover
Hose
Handle
Release
Hardware
Lift
RecoveryTank with
Lid and Filter
Carrying Handle
Tank Lid
Filter
Cleaning Solution
NOTICE
ON MODELSWITHTHE ACCESSORY HOSE,
YOU MAY NOTICE SMALL WATER
DROPLETS INTHEWATER LINE.THIS IS DUE
TO THE FACT THAT ALL UNITS ARE 100%
INSPECTED ON THE PRODUCTION LINE
USING WATER TO ASSURE PROPER
FUNCTION OFTHE ACCESSORIES.

7
I. HOW TO ASSEMBLE
NOTE: Completely assemble the carpet shampooer/extractor before using.
B. Store Attachment Hose
(Available on specific models only)
•Wrap the hose around the hose hooks.
•Push Upholstery/Stair Nozzle into caddy.
C. Store Electrical Cord
•Wrap cord around bottom and top cord wrap hooks.
D. Check Recovery Tank
•After assembling the unit, remove the recovery tank
from the unit and take the tank lid off.Then remove the
filterand checkthatthe filterframeis snappedsecurely
into place.
Recovery
Tank
Upholstery/
Stair Nozzle
Hose
Tool Caddy
Hose Hook
A. Attach Handle
•Align handle above carpet
shampooer/extractor.
•Push handle all the way down.
•Secure with two screws. CordWrap Hook
CordWrap Hook
Some Eureka carpet shampooer/extractor models do not feature an attachment hose
and selector knob.These features are specified only on selected models.

8
II. PREPARING THE CARPET
BEFORE CLEANING
Vacuum Carpet
NOTE: Never use this carpet shampooer/
extractor as a standard vacuum cleaner.
For best results, vacuum carpets with a
vacuum cleaner that has a brush roll. The
bristles of the brush roll help loosen and
remove soil that is deep in the carpet nap.
(1.) Pretest for Color Fastness
Before cleaning the carpet, we recommend testing
the carpet for color fastness. Moisten a white towel
with the cleaning solution. Test a small hidden area
ofthe carpetin a closetor in a corner. Gently rub the
cloth over the carpet. Check each color. If the towel
does not pick up any color, it should be safe to use
the cleaning solution on the entire area. See page
13 for additional information.
(2.) Remove Furniture
Remove asmuchfurniturefromtheroom aspossible.
Place aluminum foil or plastic film under or around
the legs and bases of the remaining furniture to
prevent stains. Leave the foil or plastic in place until
the carpet is completely dry. Use masking tape or
pins to hold furniture skirts and draperies up out of
the way.
Helpful Hints for Deep-Cleaning Carpet
Follow the instructions in this owner’s guide. Here are a
few extra hints that will make deep-cleaning carpet easier.
•Before you begin using the carpet shampooer/
extractor, vacuum carpet thoroughly.
• Donot use the carpet shampooer/extractor fordry
vacuuming as this can damage the unit.
•Allowplentyof time tothoroughly deep-cleancarpets.
Rushing the cleaning job may give poor results.
•To speed drying time, deep-clean carpets during dry
periods of the year or when the heating system is in
operation.
•Use consistent forward and reverse strokes over the
carpet surface.
•Wipe cleaning solution from woodwork and wood
furnitureimmediately to prevent damage to the wood
or upholstery.
•Fluff damp fibers against the nap after wet cleaning
to help the drying and prevent matting.
•Ventilate the room while cleaning to speed drying.
•Try not to walk on carpets until they are dry.
• If the carpet shampooer/extractor is difficult to push
when operating, try pushing the cleaner at a different
90 degree angle so it moves with the grain and not
against the grain of the carpet fibers.
Consult a professional cleaner before wet cleaning
Oriental rugs.
After Cleaning
•Allow carpets to dry thoroughly. Try to keep children
and pets off the carpet until it is completely dry.
•Use towels or white cloths to step on if you must walk
on the area before it is dry.
•If furniture must be placed back in the room before
the carpet is dry, use aluminum foil or plastic under
the furniture legs to prevent staining the carpet.

9
Lift
Latch
III. HOW TO PREPARE THE CARPET SHAMPOOER/EXTRACTOR
FOR CARPET CLEANING
IMPORTANT: For best results, begin with a clean surface by vacuuming surface or item before using the
carpet shampooer/extractor.
A. Fill the Clean Water Solution Tank
1) Lift up the tank latch to release the clean water solution tank.
2) Grasp the carrying handle on the clean water solution tank and
remove it from unit.
3) Remove cap and add 4 ounces of Genuine Eureka carpet/
upholstery shampoo to the tank.
4) Filltankto thedesignated filllinewith warm tapwater,not toexceed
120°F, replace cap (see diagram).
5) Place clean water solution tank into the carpet shampooer/
extractor unit by
a) slightly tilting the tank top away from unit
b) place the bottom of tank into the reservoir.
c) gently push upper portion of tank into unit until it snaps
securely into place.
Fill Line -
1 Gallon
NOTE: When moving the carpet shampooer/extractor from one location to another, always make sure the recovery
andclean water solution tanks are completely empty.Then tilt the unit slightly backward and roll on rear wheels
or use the carpet shampooer/extractor’s carrying handle for transporting up and down stairs.
NOTE: Mix cleaning solution properly to avoid
damage to carpet and upholstery.
NOTE: Familiarize yourself with the parts of the
carpet shampooer/extractor by reading this
owner’s manual before using.
Carrying
Handle
Tank Latch
4)

10
Recovery
Tank
Latch
Slide
Automatic Shut-Off
The automatic suction shut-off functions when the recovery tank is full of
liquid. This can be detected by a noticeable difference in the motor sound.
Immediatelyturn offthe unit when this happensandempty the recovery tank.
RecoveryTank
Tank Lid
Lift
Recovery Tank
Filter
FIGURE 2
FIGURE 1
B. Emptying the Recovery Tank
NOTE: Turn off the power switch and unplug the carpet shampooer/extractor
to empty the recovery tank.
1) Press the recovery tank latch downward to release the tank from the carpet
shampooer/extractor unit as shown in Figure 1.
2) Slide the recovery tank out from the lower portion of the carpet shampooer/
extractor unit.
3) Lift off the recovery tank lid and empty contents into a suitable water drain.
4) Rinse out the recovery tank and tank lid thoroughly.
5) Remove and clean the filter by rinsing it with water after each use. Place the
same filter back in the recovery tank as shown in Figure 2.
6) Replace the recovery tank lid by aligning notches in lid over tank tabs.
7) Close lid securely.
8) Return the recovery tank to the carpet shampooer/extractor unit.
9) Pushthe recoverytank allthe wayinto carpetshampooer/extractoruntil secure.
Be sure the ridge on the latch snaps securely in place.
10) Resume cleaning.
Some Eureka carpet shampooer/
extractor models do not feature an
attachment hose and selector
knob.These features are specified
only on selected models.

IV. HOWTO USE THE CARPET SHAMPOOER/EXTRACTOR
Carpet Cleaning
A. Make sure the selector knob is in the carpet position.
B. Place electrical cord into an outlet.
Solution
Release
Trigger
CleanWater
SolutionTank
11
Handle
Release
C. Step on the handle release.
Lower handle to operating position.
Handle
Release
Selector Knob
(Available on specific models only.)
Some Eureka carpet shampooer/extractor models do
not feature an attachment hose and selector knob.
These features are specified only on selected models.

V. OPERATING THE CARPET SHAMPOOER/EXTRACTOR
D. Push power switch on, which is located on the back side of the
unit.
E. Pull up and hold the solution release trigger and apply two
spraying strokes by moving the carpet shampooer/extractor
forward and then backward at a moderate pace two times. As
the nozzle moves over the carpet, the cleaning solution is
sprayed onto the carpet. At the same time the nozzle picks up
the dirty water and places it in the recovery tank.It is important
to move the carpet shampooer/extractor in a steady motion
over any surface.
F. Release the trigger to stop the solution flow. Avoid over-
soaking.
G. Move the carpet shampooer/extractor over the carpet several
moretimes without engaging the trigger.Thisremovesexcess
water and helps the carpet dry faster.
H. Repeat steps E, F, and G on heavily soiled areas.
Transporting the Carpet Shampooer/Extractor
When moving the carpet shampooer/extractor from one location to another, always make sure the recovery and clean water
solution tanks are completely empty.Then tilt the unit slightly backward and roll on rear wheels or use the carpet shampooer/
extractor’s carrying handle for transporting up and down stairs.
12
()
Power
Switch
0 = Off
I=On
Some Eureka carpet shampooer/extractor
models do not feature an attachment hose and
selector knob.These features are specified only
on selected models.

13
VI. HOW TO PREPARETHE CARPET
SHAMPOOER/EXTRACTOR FOR
UPHOLSTERY AND STAIR
CLEANING
(only for models with an attachment hose and
upholstery/stair cleaning nozzle)
Vacuum Upholstery or Stairs
Vacuum upholstery and stairs with a vacuum cleaner’s
attachment tool. Use a crevice tool for hard to reach areas
such as tufts and corners.
IMPORTANT: Cleaning some upholstery fabrics
with a wet cleaning solution may
damage the fabric. Know what the
fabric content is and how to clean
it before using a cleaning solution
on upholstery fabrics.
Most manufacturers care code their fabrics with cleaning
methods. Somevery delicateand unusualfabricsareDRY
CLEAN ONLY. If in doubt of the fabric type, call a dealer or
take a cushion or arm cover to a dealer for advice.
Check the stuffing material if possible
Lookinsidethe cushionsoron theunderneathside.Iffilling
isadarkcolor,itmaybleedthroughand discolorthe fabric.
Moststuffingmaterialthatiswhitetolightyellowiscolorfast
and will not bleed colors through to the fabric covering.
Test clean a hidden area
Be sure to test clean a hidden area several hours before
starting toclean. Let the test areadrycompletely. Inspect
forchangesin color,bleeding,stretching,orshrinking. Test
another area if in doubt.
Pretest for Color Fastness
Before cleaning the upholstery, we recommend testing it
for color fastness.Moisten a white towel with the cleaning
solution.Test a small area of thecushionback.Gentlyrub
theclothoverthearea.Checkeachareaforcolorbleeding.
If the towel does not pick up any color, it should be safe to
use the cleaning solution on the entire area.
Fabric Code Ratings:
• W for wet clean.
• S-W for solvent-dry or wet clean.
• S for solvent-dry clean only. Do not wet clean.

14
VII. HOW TO USE THE CARPET SHAMPOOER/EXTRACTOR FOR UPHOLSTERY
OR STAIR CLEANING
(only for models with an Attachment Hose and Upholstery/Stair
Cleaning Nozzle)
NOTE: Use extra caution when cleaning on stairs.
To prevent the carpet shampooer/extractor from falling, do not place the unit on stairs. It is suggested that the carpet
shampooer/extractor be placed at floor level to clean the lower portion of the stairs and be securely placed at the top
of the stairway to clean the upper portion of the stairs.
CleanWater
SolutionTank
A. Turn selector knob to the Attachment Mode.
Selector
Knob
B. Lift the attachment hose
from the tool caddy on the
back of the shampooer/
extractor.

15
How to Use the Carpet Shampooer/Extractor
for Upholstery and Stair Cleaning (Continued)
C. Place the Upholstery Nozzle at the top of the cleaning area.
D. Pullupandholdthesolution releasetrigger andpullthenozzle
backward at a moderate pace.
E. Release the trigger at the end of the stroke.
F. Lift nozzle and start again at the top. Apply one to three
spraying strokes. Avoid over-soaking the area.
NOTE: As the nozzle moves over the surface, the cleaning
solution sprays onto the surface. At the same time
the nozzle picks up the dirty water and places it in
the recovery tank.
G. Movethe nozzle overthe surfaceseveralmore timeswithout
engaging the trigger. This removes excess water and helps
the surface dry faster.
H. Brush roll does not rotate when cleaning in the attachment
mode.
SolutionTube
Trigger “M” Shaped Piece
1)Removethe“M”shaped piece on the underside of the
Upholstery/Stair Nozzle (Use a small screwdriver to
pry loose).
2) Clear and rinse any debris from the“M” shaped piece
by placing it under running water.
3) Replace the “M” shaped piece into the solution tube
then position and lock the piece into place.
NOTE: If the cleaning solution and water are not released from the upholstery/stair nozzle,there
may be an air lock.With unit in the Off position, raise the attachment handle above your
head.Then engage the attachment handle trigger for 4 seconds.Turn unit On to resume
spraying.
NOTE: If you should encounter a clog in the Upholstery/Stair Nozzle Filter:
Solution
Release
Trigger

16
VIII. HOW TO MAINTAIN THE CARPET SHAMPOOER/EXTRACTOR
Theinstructions inthisbooklet serveasa guidetoroutine maintenance. Followthese suggestionstoavoidunnecessary
service calls.
Before storing the carpet shampooer/extractor, on a linoleum or vinyl surface put the unit in the floor mode
and use clean water (without solution) to flush out all remaining particles in the carpet shampooer/extractor
unit.
• Place clean water in the clean water solution tank.
• Operate the unit,by pulling up on the DispensingTrigger located in the carpet shampooer/extractor’s
handle.
• Activate the trigger for 4 strokes (2 forward and 2 backward).
• Then, release the trigger while operating the unit for another 4 strokes or until the flooring is dry.
For models featuring the Attachment Hose,on a linoleum or vinyl surface, activate the trigger on the attachment
handle to run clear water through the nozzle using 4 backward strokes.Then release trigger and proceed with
any additional strokes to remove moisture.This will flush out all the remaining particles.
A. Clean Water SolutionTank Maintenance
NOTE: Turn off the power switch and unplug the
electrical cord before cleaning.
1. Remove the clean water solution tank by lifting up
on the tank latch to release the clean water solution.
2. Graspthe carryinghandle to removethe cleanwater
solution tank from the carpet shampooer/extractor
unit.
3. Empty any remaining liquids from the clean water
solution tank.
4. Rinse the tank with warm tap water.
5. Thoroughly air dry the clean water solution tank
before storing.
6. Place the dry, clean water solution tank back onto
the carpet shampooer/extractor unit making sure it
snaps securely into place. See page 9 for more
detailed instructions on how to install clean water
solution tank.
B. Recovery Tank Maintenance
NOTE: Turn off the power switch and unplug the
electrical cord before cleaning.
1. Remove the recovery tank from the carpet shampooer/
extractor unit by pushing the recovery tank latch
downward to release it from the unit.
2. Pull the tank out from the lower portion of the carpet
shampooer/extractorunit.
3. Lift the tank lid off and empty contents into a suitable
water drain.
4. Cleantherecoverytankand lidwith soapand water.Also,
rinse the filter after each use with water.
5. Thoroughly air dry the recovery tank before storing.
6. To replace the recovery tank into the unit, push the dry
recovery tank all the way into the carpet shampooer/
extractor until the latchsnaps to secure thetank.Besure
the ridge on the latch is pushed all the way under the
carpet shampooer/extractor housing.
Lift
Carrying Handle
Tank Latch
Filter
CleanWater
SolutionTank
Tank Lid

17
HOW TO MAINTAIN
NOTE: Turn off the power switch and unplug the electrical cord to service cleaning nozzles.
C. Cleaning the Carpet Shampooer/Extractor’s Suction Cover
1. Remove the screws from each side
of the suction cover.
2. Lift the suction cover off and clean
the area of dirt and lint.
3. Replacethe suctioncoverbysliding
the tabs on top of the suction cover
into the top slots on the hood.Make
sure the suction cover gasket is in
place on the unit before replacing
cover.
4. Align one of the screw holes in the
suction cover, hood and base then
secure with screw. Also complete
this step for second screw hole.
D. Cleaning the Carpet
Shampooer/Extractor’s
Plunger, Boot Seal and Filter
1. Remove the clean water solution tank.
2. Remove the Plunger, Boot Seal and Filter
Assembly by lifting up the Boot Seal.This will
pull out the Plunger, Boot Seal and Filter
Assembly (see Figure 1).
3. Remove the Reservoir Filter and clean it by
removing any debris and rinsing with water.
4. Reinsert the Filter on the Plunger stem and
placethe Assemblydirectly into thereservoir.
Install this assembly into the reservoir by
pressingdownonthetopofthe plasticplunger.
Do not press down on the rubber boot seal.
IMPORTANT! Make sure the plunger stem
is placed into the hole in the
bottom of the reservoir for a
secure fit (see Figure 2).
5. Replace the Clean Water Solution Tank back
onto the carpet shampooer/extractor unit.
Suction
Cover
Boot Seal
Plunger Stem Assembly
Reservoir Filter
Correct installation
of assembly
FIGURE 1
FIGURE 2
Plunger,Boot Seal and Filter Assembly
Tabs
Suction Cover Gasket
(around rim of suction
cover area on unit)

18
HOWTO MAINTAIN (only for models that feature a brush roll)
Brush Roll Belt (for models with a brush roll)
The brush roll belt on the carpet shampooer/extractor drives the
brush to agitate, sweep, and comb the carpet nap. Check the belt
regularly to be sure it is in good condition. Replace the belt if it is
stretching,crackingor slipping. Cutaway anyhair or thread wound
around the brush roll or the belt pulley because the buildup could
cause the belt to rotate unevenly.
1. Tipthecarpetshampooer/extractorback toplace thehandle
on the floor (See Figure 1).
2. Positionyourselfin front ofthe carpetshampooer/extractor’s
base and remove the screw from the right side of base
(Figure 2).
3. Lift off the belt cap.
4. Lift brush roll out and remove worn belt.
5. Squeeze the sides of new belt together and place it around
the motor pulley. Squeezing the belt will aid in placing the
belt on the pulley.
6. Place the pulley end of brush roll inside the belt.
7. Align brush roll end caps with openings in base.
8. Push down on the brush roll to secure it (Figure 3).
9. Rotate the brush roll until the belt is in place.
10. Replace belt cap and secure with screw.
E. How to Replace the Carpet Shampooer/
Extractor’s Belt
NOTE: Turn off the power switch and unplug the electrical cord to
replace the brush roll belt.
NOTE: Ifthetanks contain liquid,removeboth tanksbeforeplacing
the handle on the floor. FIGURE 1
Motor
Pulley
Belt
Cap
Brush Roll
End Cap
Belt
Belt
Cap
FIGURE 2
FIGURE 3
NOTE: When reinstalling the brush roll, check the end caps for correct alignment into the base of the unit.
Sometimes the squares of the end caps become off-center. By holding one end and turning the other,
realignment can be corrected.

Motor will not start. 䡺Electric Plug 䡺Push plug securely into outlet.
䡺Try another outlet.
䡺Check circuit breaker.
䡺Power switch is not turned ON 䡺Make sure power switch is in ON position.
Cleaning solution 䡺Clean Water Solution Tank is 䡺Be sure Clean Water Solution Tank is locked securely into
and water are not incorrectly installed place.
released from the 䡺Refill Clean Water Solution Tank with clean water and solution.
Carpet Nozzle 䡺Carpet nozzle area clogged 䡺Remove debris from the carpet nozzle area.
䡺Check Plunger, Boot Seal and Filter Assembly (see p. 17)
Cleaning solution 䡺Air Lock 䡺With unit in the OFF position, raise the attachment handle
and water are not above your head.Then engage the attachment handle trigger
released from the for 4 seconds.Turn unit ON to resume spraying.
Upholstery/Stair 䡺Low water solution level in clean 䡺Check the water level in the Clean Water Solution Tank
Nozzle water solution tank and refill.
䡺Clog in Upholstery/Stair Nozzle 䡺Clear the Upholstery/Stair Nozzle of debris.
䡺Clog in Upholstery/Stair Nozzle 䡺Remove the “M” shaped piece on the underside of the
tubing Upholstery/Stair Nozzle, then remove, rinse and replace
the filter into the Solution Tube (see p. 15).
䡺Plunger, Boot Seal and Filter 䡺Check Plunger, Boot Seal and Filter Assembly (see p. 17)
Assembly is not in correct position
Does not pick up 䡺Recovery Tank is full 䡺Empty Recovery Tank. Replace lid and return to cleaner.
the dispensed Resume cleaning.
cleaning solution 䡺There may be excessive foam in the Recovery Tank.
and water from Use correct cleaning solution and water mix ratio:
carpet (4 ounces of cleaning solution per 1 gallon of water.)
Empty Recovery Tank, then clean or replace the filter.
䡺Recovery Tank is not fully installed 䡺Make sure Recovery Tank is fully locked into position.
䡺Selector Knob is not in carpet position 䡺Make sure the Selector Knob is in the carpet position.
Does not clean the 䡺Belt 䡺Replace a cut, loose, or out of shape belt (see p. 18)
carpet 䡺Brush Roll 䡺Remove belt cap and clean hair, thread and debris from bristles
and brush roll area. Replace brush roll if bristles are worn.
䡺Improper cleaning solution used 䡺Use Genuine Eureka Carpet/Upholstery Cleaning Solution.
䡺Selector Knob not in carpet position 䡺Make sure Selector Knob is in carpet position.
Clean Water 䡺Plunger, Boot Seal and Filter 䡺Remove Clean Water Solution Tank and check Plunger, Boot
Solution Tank Assembly is not in correct position Seal and Filter Assembly by removing it and reinstalling it into
leaks prior to the reservoir by pressing the top of the plastic plunger
activating handle downward.Do not press down on the rubber Boot Seal.
trigger or
Upholstery/Stair
Nozzle Trigger
Minimal suction at 䡺Selector Knob is not in the 䡺Make sure Selector Knob is in attachment position.
the end of the hose attachment position
䡺Upholstery/Stair Nozzle is clogged 䡺Remove any visible clogs from nozzle that restricts the airflow.
䡺Activate the Upholstery/Stair Nozzle Trigger and flush with
clean water while the unit is in attachment mode (see p. 15).
䡺Recovery Tank not completely 䡺Make sure Recovery Tank is in locked secured position.
installed
Water appears on 䡺Plunger, Boot Seal and Filter 䡺Remove Clean Water Solution Tank and check Plunger, Boot
top of the Assembly is not correctly installed Seal and Filter Assembly by removing it and reinstalling it into
Recovery Tank the reservoir by pressing the top of the plastic plunger
downward.Do not press down on the rubber Boot Seal.
Suction shuts off 䡺Excessive foam in the 䡺Use correct cleaning solution and water mix ratio:
prematurely Recovery Tank (4 ounces of cleaning solution per 1 gallon of water.)
Empty Recovery Tank, then clean or replace the filter.
䡺Improper cleaning solution used 䡺Use Genuine Eureka Carpet/Upholstery Cleaning Solution.
Missing parts 䡺Call 1-800-438-7352 between 8:00 a.m. and 4:45 p.m. central
standard time, Monday through Friday. Know the model & serial
numbers when you call.
Questions 䡺Call 1-800-282-2886 between 8 a.m. to7:30 p.m. (CST), Mon
day - Friday and 10 a.m. to 6:30 p.m. Saturday. Know the model
and serial numbers when you call.
19
PROBLEM SOLVING
NOTE: Turn off the switch and unplug the electrical cord before servicing.
PROBLEM CAUSE SOLUTION
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Some Eureka carpet shampooer/extractor models do not feature an attachment
hose and selector knob.These features are specified only on selected models.
✓
