Eurolux B41 User manual

Large and Small Round Bulkheads
B41 / B42 / B45 / B55: Excluding 1 x E27 GLS maximum 100W
B53 / B56: Excluding 1 x E27 GLS maximum 60W
ILLUSTRATIONS
MODEL
MODELMODEL
B41 / B42 / B45 / B53 / B55 / B56
PRODUCT CODE
Cape Town - 9 Racecourse Road, Milnerton, 7441
Johannesburg - 10 Milkyway Avenue, Linbro Business Park, Sandton, 2065
www.eurolux.co.za
Please read instructions before commencing installation and retain for future reference.
N
L
Connecting the Terminal Block
Connect main supply (Brown = Live, Blue = Neutral)
into terminal block, ensuring all connections are
tight and secure.
Standard Bulkhead Gridded / Covered Bulkhead
ENVIRONMENTAL PROTECTION
Waste electrical & Electronic equipment regulations requires that any of our products
showing this marking must not be disposed of with other household or commercial
waste. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate any such products from other waste types and recycle
it responsibly at your local facilities.
Connecting the Terminal Block
connect main supply (Brown = Live, Blue = Neutral)
into terminal block, ensuring all the connections are
tight and secure

Installation:
Switch the power off before commencing with the installation.
1. Fix the cable through the grommet of the lamp base, or by using the appropriate water
proof gland.
Note the green/yellow wire should be connected to the earth terminal.
2. Use the plastic screws, x the lamp base to the mounting surface.
3. Connect the brown/red wires to the L and the blue/black wires to the N position of the lamp
socket, and connect the green/yellow wires to the lamp body where the earth symbol is placed.
4. Screw the lamp into the socket. The power of the lamp should not exceed the maximum
power which is rated.
5. Mount the upper cover and x it in place with the screws.
Changing the lamp:
Switch the power off before commencing with the installation.
1. Always ensure the lamp has been allowed to cool before attempting to change the lamp.
2. Open the luminaire cover.
3. Carefully unscrew the lamp.
4. Carefully screw in the new replacement lamp.
5. Close the luminaire, fastening any loose screws before re-connecting the electricity and
turning the luminaire on.
B41 / B42 / B45 / B53 / B55 / B56 - attachments:
If the external exible cable or cord of this luminaire is damaged, it should be exclusively replaced
by the manufacturer or his service agent or a similar qualied person in order to avoid a hazard.
To ensure that you get maximum longevity and maximum use out of your luminaire, please
observe the following safety instructions.
Electrical products can cause death, injury, or damage to property.Installation of the
luminaire must be carried out by a qualied electrician, in accordance with SANS 10142. On
completion of installation, ensure that the Certicate of Compliance is updated.
• Before connecting this luminaire, ensure that voltage indicated on the rating label corresponds
with the mains voltage in your home.
• When changing the lamp, ensure that the power is turned off.
• This luminaire is checked in full for conformity to the quality standards and safety requirements.
• The manufacturer / supplier is not responsible for any damage of properties and persons,
caused by the incorrect use or installation of the luminaire.
• Should you be unsure of how to install this luminaire correctly, please consult a professional
electrician or your supplier for assistance.
• Ensure all items / components, threads and screws are tightly secured.
IMPORTANT:
• Tampering with this luminaire, i.e. using silicon sealers or incorrect cabling, will invalidate
your warranty.
• When the protection glass is damaged, it should be replaced immediately. The luminaire must
not be used without the protection glass.
• Please check whether the connection of the power cord is safe and reliable before installation.
• Always ensure that the mains supply voltage is correct.
• Always replace the lamp with one of an identical rating.
• Ensure that you do not place the luminaire near any combustible materials and / or surfaces.
• Choking hazard: May contain small parts. Keep away from children.
IMPORTANT SAFEGUARDS
INSTALLATION
CLEANING
• Before cleaning always ensure the power supply is turned off.
• Do not immerse the luminaire in water.
• No abrasive products, solvents, detergent may be used to clean this luminaire.
• Ensure that the tting does not come in contact with corrosive chemicals, etc.
• Coastal areas ensure that the luminaire is cleaned fortnightly.
SPECIFICATIONS
• Fitting: Die Cast Aluminium.
• Lamp type:
B41 / B42 / B45 / B55: Excluding: 1 X E27 GLS Maximum 100W.
B53 / B56: Excluding: 1 X E27 GLS maximum 60W.
• Voltage: 220V - 240V ~ 50Hz.
• Protection against electric shock: Class 1. Requires earthing.
• IP Rating: IP44. Dust Protected. Ingress of dust not totally prevented, but will not penetrate in
a quantity to interfere with satisfactory operation or to impair safety. Protected against splashing
water.
• Commercial use.
• Suitable for outdoor use.
• Maximum Ambient temperature range: 20ºC - 40ºC.
• Can be used in coastal areas and other corrosive environments.
• Dimensions:
B41: (Ø)240mm X (D)120mm
B42: (Ø)240mm X (D)115mm
B45: (Ø)240mm X (D)120mm
B53: (Ø)180mm X (D)100mm
B55: (Ø)180mm X (D)90mm
B56: (Ø)180mm X (D)95mm
• Spare glass:
B41: Code: X173
B42: Code: X173
B45: Code: X173
B53: Code: X175
B55: Code: X175
B56: Code: X175
• Do not insert your ngers or any part of your body into the electrical contact and sockets of this
product whilst it is connected to the electricity supply.
• Item may vary slightly from the picture on the carton.
• Coastal humidity may effect the longevity of the luminaire.
• Outdoor luminaires must be cleaned to prevent rust occurring.
• Use a copper grease on all screws or strings.
