Euromaid EHPD700 User manual

User Manual
Description 7KG Heat Pump Dryer
MODEL NO. EHPD700G

Contents Page
1. Important instructions for safety and environment
1.1
1.1.1
1.1.2
1.2
1.3
1.4
1.5
1.6
1.7
1.8
General Safety
Electrical Safety
Product Safety
Stacking over a washing machine
Intended Use
Child Use
Compliance with the WEEE regulations and disposing of the waste product
Compliance with the RoHS directive
Package Information
Technical Specification
2. Your dryer
2.1 Overview
2.2 Package Contents
3. Installation
3.1 Appropriate installation location
3.2 Removing the transportation assembling location
3.3 Connecting to the drain
3.4 Adjusting the dryer
3.5 Transportation of the dryer
3.6 Warning about sounds
3.7 Changing the illumination lamps
4. Preparation
4.1 Laundry suitable for drying in the dryer
4.2 Laundry not suitable for drying in the dryer
4.3 Preparing laundry for drying
4.4Things to be done for energy savings
4.5 Correct load capacity
5. Operating the product
5.1 Control Panel
5.2 Symbols
5.3 Preparation of drying maching
5.4 Program selection and consumption chart
5.5 Auxiliary functions
5.6 Warning indicators
5.7 Starting the program
5.8 Child Lock
5.9 Changing the program after it is started
5.10 Cancelling the program
5.11 End the program
6. Maintenance and cleaning
6.1 Cleaning Lint Filter / Loading Door Inner Surface
6.2 Cleaning the sensor
6.3 Draining the water tank
6.4 Cleaning the filter drawer
6.5 Cleaning the evaporator
7. Troubleshooting
8. Manufactures Guarantee
Pg 4
Pg 5
Pg 5
Pg 5
Pg 7
Pg 8
Pg 8
Pg 8
Pg 8
Pg 8
Pg 9
Pg 10
Pg 10
Pg 10
Pg 10
Pg 10
Pg 10
Pg 11
Pg 11
Pg 12
Pg 12
Pg 12
Pg 13
Pg 13
Pg 13
Pg 13
Pg 13
Pg 13
Pg 14
Pg 14
Pg 14
Pg 14
Pg 15
Pg 17
Pg 17
Pg 17
Pg 17
Pg 18
Pg 18
Pg 19
Pg 20
Pg 20
Pg 20
Pg 21
Pg 21
Pg 22
Pg 23
Pg 24

Please read this user manual first!
Dear Customer,
Thank you for preferring aEuromaid
product. We hope that your product which
has been manufactured with high quality and
technology will give you the best results. We
advise you to read through this manual and the
other accompanying documentation carefully
before using your product and keep it for
future reference. If you transfer theproduct
to someone else, give its manual as well. Pay
attention to all details and warnings specified
in theuser manual and follow the instructions
given therein.
Use this user manual for the model indicated
on the cover page.
• Read the instructions.
Explanation of symbols
Throughout this user manualthe following
symbols are used:
BDANGER!
• Warning against electric shock.
DANGER!
• Warning against fire hazard.
AWARNING!
• Warning for hazardous situations with regard
to life and property.
WARNING!
• Warning against hot surfaces.
WARNING!
• Warning against scaldinghazard.
CNOTE
• Important information or useful hints about
usage.
Packaging materials of theproduct
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packagingwastes with
thedomestic waste or other wastes, discard
them tothededicated collection points
designated by the localauthorities.
2960312888

4
Dryer / User Manual
1Important instructions for safety and environment
CNOTE
• This section contains safety
instructions that will help protect
from risk of personal injury or
property damage. Failure to follow
these instructions shall void any
warranty.
1.1 General safety
AWARNING!
•This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to
ensure that they do not play with the
appliance. Cleaning and maintenance
works should not be performed by
children.
•Children should be kept away unless
continuously supervised.
•Adjustable feet should not be
removed. The gap between the dryer
and the floor should not be reduced
with materials such as carpet, wood
and tape. This will cause problems
with the dryer.
AWARNING!
• Always have the installation and
repairing procedures carried out by
the
Authorised Service Agent.
The manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorised persons.
• Never wash the dryer by spraying
or pouring water onto it! There is
the risk of electric shock!
For the products with a steam
function:
AWARNING!
• Use only distilled water or water
condensed in the water tank of the
machine in steam programs. Do
not use mains water or additives.
When using condensed water in the
water tank, it should be filtered and
cleared of fibres.
• Do not open the door when steam
programs are running. Hot water
may be expelled.
• Before putting laundry in a steam
program, stains on it should be
removed.
• You may only put laundry that is not
dirty or stained but permeated with
unpleasant odour in steam (odour
removal) program.
• Do not use any dry cleaning sets
or additional materials in a steam
program or in any program.

5
1.1.1 Electrical safety
BDANGER!
• Electrical safety instructions
should be followed while
electrical connection is made
during the installation.
• The appliance must not be
supplied through an external
switching device, such as a
timer,or connected to a circuit
that is regularly switched on
and off by utility.
• Connect the dryer to a grounded
outlet protected by a fuse at the
value specified on the type label.
Have the grounding installation
performed by a qualified electrician.
The manufacturer shall not be liable
for any damages that will arise when
the dryer is used without grounding
in accordance with the local
regulations.
• The voltage and allowed fuse
protection is stated on the type label
plate.
• The voltage specified on the type
label must be equal to your mains
voltage.
• Unplug the dryer when it is not in
use.
• Unplug the dryer from the mains
during installation, maintenance,
cleaning and repair works.
• Do not touch the plug with wet
hands! Never unplug by pulling
on the cable, always pull out by
grabbing the plug.
BDANGER!
• Do not use extension cords, multi-
plugs or adaptors to connect the dryer
to power supply in order to decrease
the risk of fire and electric shock.
• Power cable plug must be easily
accessible after installation.
• If the supply cord is damaged, it
must be replaced by the
manufacturer, its service agent or
similarly qualified persons in
order to avoid a hazard.
• If the dryer is faulty, it must not
be operated unless it is repaired
by an authorised service agent!
There is the risk of electric shock!
1.1.2 Product safety
DANGER!
• Superheating of the clothes inside
of the dryer can occur if you cancel
the programme or in the event of
a power failure whilst the dryer is
running, this concentration of heat
can cause self-combustion and fire
so always activate the ventilation
programme to cool down or quickly
remove all laundry from the dryer in
order to hang them up and dissipate
the heat.
Points to be taken into
consideration for fire hazard:
Below specified laundry or items
must not be dried in the dryer
considering fire hazard.
• Unwashed laundry items

6
Dryer / User Manual
AWARNING!
• Ensure that the air inlet of the dryer
is open and it is well-ventilated.
• Product contains R290 refrigerant.
• R290 is an environment-friendly, but
flammable refrigerant.
• Keep the product away from
potential heat sources that may
cause it to ignite.
DANGER!
• Items soiled with oil, acetone,
alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin or
paraffin removers must be washed
in hot water with plenty of detergent
before being dried in the dryer.
For this reason especially the items
containing the above specified
stains must be washed very well,
to do this use adequate detergent
and choose a high washing
temperature.
Below specified laundry or
items must not be dried in the
dryer due to the fire hazard:
• Garments or pillows bolstered with
rubber foam (latex foam), shower
bonnets, water resistant textiles,
materials with rubber reinforcement
and rubber foam pads.
• Clothing cleaned with industrial
chemicals.
I
DANGER!
Items such as lighter, match,
coins, metal parts, needle etc. may
damage the drum set or may lead
to functional problems. Therefore
check all the laundry that you will
load into your dryer.
Never stop your dryer before the
programme completes. If you must
do this, remove all laundry quickly
and lay them out to dissipate the
heat.
• Clothes that are washed
inadequately may ignite on their
own and may even ignite after items
in the dryer.
• You must provide enough ventilation
in order to prevent gasses exiting
from devices operating with other
types of fuels including the naked
flame from accumulating in the
room due to the back fire effect.
• Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as in
a tumble dryer. The items become
warm, causing an oxidation reaction
in the oil. Oxidation creates heat. If
the heat cannot escape, the items
can become hot enough to catch
fire. Piling, stacking or storing oil-
affected items can prevent heat
from escaping and so create a fire
hazard.
• If it is unavoidable that fabrics that
contain vegetable or cooking oil or
have been contaminated by hair
care products be placed in a tumble
dryer they should first be washed in
hot water with extra detergent - this
will reduce, but not eliminate, the
hazard.

7
AWARNING!
• Underwear that contains metal
reinforcements should not be dried
in the dryer. Dryer may be damaged
if metal reinforcements come loose
and break off during drying.
CNOTE
• Use softeners and similar products
in accordance with the instructions
of their manufacturers.
Always clean the lint filter before or
after each loading. Never operate
the dryer without the lint filter
installed.
AWARNING!
• Never attempt to repair the dryer
by yourself. Do not perform any
repair or replacement procedures
on the product even if you know
or have the ability to perform the
required procedure unless it is
clearly suggested in the operating
instructions or the published service
manual. Otherwise, you will be
putting your life and others’ lives in
danger.
• There must not be a lockable,
sliding or hinged door that may
block the opening of the loading
door in the place where your dryer
is to be installed.
• Install your dryer at places suitable
for home use. (laundry room)
• Make sure that pets do not enter
the dryer. Check the inside of the
dryer before operating it.
AWARNING!
• Do not lean on the loading door
of your dryer when it is open,
otherwise it may fall over.
• The lint must not be allowed to
accumulate around the tumble dryer
• The tumble dryer is not to be used if
industrial chemicals have been used
for cleaning.
•Fabric softeners, or similar products.
should be used as specified by the
fabric softener instructions.
• Exhaust air must not be discharged
into a flue which is used for
exhausting fumes from appliances
burning gas or other fuels.
• The final step of the drying cycle
(cool-down cycle) occurs without
applying heat to ensure that the
items are left at a temperature that
will not damage them.
1.2 Stacking over a washing machine
• A fixing device should be used between
the two machines when stacking the
dryer above a washing machine. Ensure
you follow the instructions on the
Stacking Kit very carefully.
• Total weight of the washing machine
and the dryer -with full load- when
they are placed on top of each other
reaches to approx. 180 kilograms. Place
the products on a solid floor that has
sufficient load carrying capacity!
AWARNING!
• Washing machine cannot be placed on
the dryer. Pay attention to the above
warnings during the installation on your
washing machine.

8
Dryer / User Manual
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm < 50 cm
54 cm Can be installed Cannot be
installed
60 cm Can be
installed Cannot be installed
1.3 Intended use
• Dryer has been designed for domestic
use. It is not suitable for commercial
use and it must not be used out of its
intended use.
• Use the dryer only for drying laundry that
are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect usage
or transportation.
1.4 Child safety
• Packaging materials are dangerous for
the children. Keep packaging materials
away from children.
• Electrical products are dangerous for the
children. Keep children away from the
product when it is operating. Do not let
them tamper with the dryer. Use the child-
proof lock in order to prevent the children
to tamper with the dryer.
CNOTE
Child-proof lock is on the control panel.
(See Child lock)
• Keep loading door closed even when the
dryer is not in use.
1.5 Compliance with the WEEE
regulation and disposing of the waste
product
This product complies with EU
WEEE Directive (2012/19/EU). This
product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality parts and
materials which can be reused and are suitable
for recycling. Do not dispose of the waste
product with normal domestic and other
wastes at the end of its service life. Take it
to the collection center for the recycling of
electrical and electronic equipment. Please
consult your local authorities to learn about
these collection centers.
DANGER!
• R290 is an flammable refrigerant. Thus,
ensure that the system and the pipes
are not harmed during operation and
handling.
• Keep the product away from potential
heat sources that may cause it to ignite in
case of damage.
• Do not dispose of the product by putting
it in fire.
1.6 Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials
specified in the Directive.
1.7 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.

9
1.8 Technical Specifications
EN
Height (Min. /
Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 56,8 cm
Capacity (max.) 7 kg**
Net weight
(± %10) 44 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are
closed.
Max. height: Height with adjustable feet are
opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading
door.
CNOTE
• Technical specifications of the dryer
are subject to change without notice to
improve the quality of the product.
• Figures in this manual are schematic and
may not match the product exactly.
• Values stated on markers on the dryer
or in the other published documentation
accompanying with the dryer are
obtained in laboratory in accordance with
the relevant standards. Depending on
operational and environmental conditions
of the dryer, these values may vary.

10
Dryer / User Manual
2 Your Dryer
11
10
1
2
3
4
5
6
7
8
9
2.1 Overview
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. In models where the tank is placed below,
the water tank is inside the toe board
8. Type label
9. Lint filter
10. Water tank drawer (in models where the
tank is placed above)
11. Power cord
2.2 Package Contents
1. Water
drain
hose *
5. Drying
basket
user
manual*
2. Filter
drawer
spare
sponge*
6. Water
Filling
Container*
3. User
Manual
7. Pure
Water*
4. Drying
basket*
8.
Fragrance
Capsules
Group*
*Optional - may not be included, depends on
model.
3 Installation
Before the calling the nearest Authorized
Service for the installation of the dryer, ensure
that electrical installation and water drain is
appropriate referring to the user’s manual.
If they are not suitable, contact a qualified
electrician and technician to make necessary
arrangements.
CNOTE
• Preparation of the dryer’s location
as well as the electrical and waste
water installations is under customer’s
responsibility.
AWARNING!
• Prior to installation, visually check if the
dryer has any defects on it. If the drier
is damaged, do not have it installed.
Damaged products cause risks for your
safety.
• Let your dryer wait for 12 hours before
starting to use it.
3.1 Appropriate installation location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer will
be adversely affected and it can get
damaged.

11
• The rear surface of the tumble dryer shall
be placed against a wall.
BDANGER!
Do not place the dryer on the power cable.
* Ignore following warning if your
product’s system does not contains
R290.
DANGER!
• Dryer contains R290 refrigerant.*
• R290 is an environment-friendly, but
flammable refrigerant.*
• Ensure that the air inlet of the dryer is
open and it is well-ventilated.*
• Keep potential flame sources away from
the dryer.*
•It is hazardous for anyone other than
an Authorised Service Person to
service this appliance. In Queensland -
the authorised Service Person MUST
hold a Gas Work Authorisation for
hydrocarbon refrigerants to carry out
servicing or repairs where the gas
system is being opened or charged.
3.2 Removing the transportation
safety assembly
AWARNING!
• Remove the
transportation
safety assembly
before using the
dryer for the first
time.
3.3 Connecting to the drain
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining the
water collected in the water tank.
Connecting the water drain hose
1
3 4
2
1-2 Pull hose at
the behind of
the dryer by
hand in order
to disconnect
it from where it
is connected.
Do not use
any tools to
remove the
hose.
3Connect one end of the drain hose
supplied with the dryer to the connection
point from where you removed the hose of
the product in previous step.
4Connect the other end of the drain hose
directly to the wastewater drain or to the
washbasin.
CNOTE
• Water drain hose should be attached to a
height of maximum 80 cm.
• Make sure that the water drain hose is not
stepped on and it is not folded between
the drain and the machine.
• If there is an accessories pack supplied
with your product, please see the detailed
description.
3.4 Adjusting the feet
• Turn the feet to
left or right until
the dryer stands
level and firmly.

12
Dryer / User Manual
3.5 Transportation of the dryer
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
AWARNING!
• We recommend carrying the dryer in
upright position. If it is not possible to
carry the machine in the upright position,
we recommend carrying it by tilting
towards the right side when looked from
the front.
3.6 Warnings about sounds
CNOTE
• It is normal to
hear a metallic
noise from the
compressor
sometimes during
operation.
• Water collected during operation is
pumped to water tank. It is normal to
hear pumping noise during this process.
3.7 Changing the illumination lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.The lamp(s) used in this
appliance is not suitable for household room
illumination. The intended purpose of this
lamp is to assist the user to place laundry in
the tumble dryer in a comfortable way. The
lamps used in this appliance have to withstand
extreme physical conditions such as vibrations
and temperatures above 50 °C

13
4 Preparation the condenser once in a month or after
every 30 operations regularly.
• Clean the filter periodically.Read the
Maintenance and cleaning of filters for
detalied information.
• For models with flue unit: comply with the
flue connection instructions and clean the
flue.
• During the drying process, air the room
well where your tumble dryer is operating
• On models with heat pump, check the
condenser at least every 6 months and
clean it if it is dirty.
• If you are using the environmentally-
friendly filter, you do not need to clean it at
every cycle. Replace the filter cloth when
the environmentally-friendly filter symbol is
displayed on the screen..
4.5 Correct load capacity
Follow the instructions
in the “Programme
selection and
consumption table”.
Do not load more than
the capacity values
stated in the table.
Following weights are given as examples.
Laundry Approximate
weights (g)* Laundry Approximate
weights (g)*
Cotton
quilt covers
(double)
1500 Blouses 150
Cotton quilt
covers (single) 1000 Cotton shirts 300
Bed sheets
(double) 500 Shirts 250
Bed sheets
(single) 350 Cotton
dresses 500
Large
tablecloths 700 Dresses 350
Small
tablecloths 250 Jeans 700
Tea towels 100 Handkerchiefs
(10 pieces) 100
Bath towels 700 T-Shirts 125
Hand towels 350
*Dry laundry weight before washing.
4.1 Laundry suitable for drying in the
dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a
label stating that they are suitable for drying in
a dryer.
4.2 Laundry not suitable for drying in
the dryer
Items with this symbol
Do not dry
with dryer should not be
dried in the dryer.
CNOTE
• Delicate embroidered fabrics, woollen,
silk garments, delicate and valuable
fabrics, airtight items and tulle curtains
are not suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other
after washing. Separate the laundry items
before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for energy
saving
• Spin your laundry at the highest speed
possible when washing them. Thus,
the drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type of
laundry together. For example thin kitchen
towels and tableclothes dry quicker than
thick bathroom towels.
• Follow the instructions in the user manual
for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation
• For models with a condenser unit: clean

14
Dryer / User Manual
5 Operating the product
5.1 Control Panel
4. Dryness
5. Alarm Duration
Select the desired program using the On/Off/
Program selection knob, the machine will turn
on.
CNOTE
• Selecting a program using the On/Off/
Program selection button does not mean
that the program started. Press the
Start / Pause button to start the program.
5.3. Preparation of drying machine
• Plug the drying machine.
• Open the loading door.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
AWARNING!
• Ensure that no
laundry is jammed
to the loading
door.
Volume up
Filter
cleaning
Tank
full
Child-proof
lock
Mute
Filter drawer /
Heat exchanger
cleaning
End/anti-
creasing
On/O Delay Start Drying Cupboard
Dry
Iron Dry
Express
14’
Delicates
Jeans BabyProtect Extra dry Cupboard
dry plus
Sport Freshen Up
Start
pause
cancel
Cottons
Synthetics
Mix
Express
30’
Drying Rack/
TimeDry
Daily
Bedding/
Duvet
Express Shirt 30' Wool Refresh
Hygiene
(BabyProtect+)
Shirts
Cottons Eco Refreshment Low
temperature
select
Dryness
Level+
Dryness
Level++
Dryness
Level
DownWear
3
4 5
2
1
1. On/Off/Program selection
2. Start/Pause button
3. Delay Start button
5.2 Symbols

15
5.4 Program selection and consumption chart
EN
Programmes Programme Description
Capacity (kg) Spin speed in washing machine (rpm) Drying Time (minutes)
Cottons Iron Dry
You may dry your cotton laundry to be
ironed in this program to have them
slightly damp for ease of ironing. (Shirt,
T-shirt, tablecloth, etc.)
7 1000 139
Cottons Eco Dry It dries single layer, casual cotton textiles
in the most economical way. 7 1000 174
Cottons Cupboard Dry
You may use this program for extra
dryness in thick laundry such as pants,
tracksuit. You can put your laundry in the
wardrobe without ironing.
7 1000 179
Cottons Extra Dry
You may dry your thick cotton laundry in
this program such as towels, bathrobe,
etc. You can put your laundry in the
wardrobe without ironing.
7 1000 210
Synthetics Iron Dry
You may dry your synthetic laundry to
be ironed in this program to have them
slightly damp for ease of ironing. (Shirt,
T-shirt, tablecloth, etc.)
4 800 59
Synthetics Cupboard Dry
You may dry all your synthetic laundry in
this program. (Shirt, T-shirt, underwear,
tablecloth, etc.) You can put your laundry
in the wardrobe without ironing.
4 800 70
TimerProgrammes
You may select from time programmes
between 10 and 160 minutes to
achieve the desired drying level at low
temperature. In this programme, tumble
drier’s operation lasts for the set time
independently from the dryness of laundry.
This product is available to be used with a
drying basket as option. For products that
are sold without a basket, you can obtain
a basket from an authorized service and
use the drying programs specified above.
For details of use, see the drying basket
user guide.
- - -
Refresh
Ventilates for 10 minutes without blowing
hot air. You can ventilate the cotton and
linen clothes that have been enclosed for
a long time with this program to remove
their odour. You can use this program to
ventilate and soften wool laundry that can
be washed in a washing machine. Do not
use for full drying.
- - 10

16
Dryer / User Manual
Delicates
It dries the shirts in a more sensitive
manner, and causes less creasing and
easier ironing.
2 1200 50
Jeans You may dry denim pants, skirts, shirts or
jackets in this program. 4 1200 125
Sport
Use it to dry your clothes made of
synthetics, cotton or mixed fabrics or
waterproof products such as functional
jacket, raincoat etc. Turn them inside out
prior to drying.
2 1000 135
Mixed
You can dry both cotton and synthetic
laundry with this programme.Sports and
fitness clothes may be dried with this
program.
4 1000 110
Hygienic Care
It is a long-term program that you can
use for the clothes (baby clothes, towels,
underwear, etc. cotton) you require
hygiene. Hygiene is provided with high
temperature. It is especially suitable for
durable fabrics.
5 800 185
Bedding
You can dry your feather or fibre filled
textile that has “can be dried in dryer
label” as a single piece of laundry. You can
dry double duvet, pillow or coats as single
piece of laundry. Dry your cloths such as
coats and jackets turned inside out.
- 800 165
Xpress 30 Use this program to have 2 shirts ready
for ironing. 0,5 1200 30
Energy consumption values
Programmes Capacity (kg)
Energy
consumption
value kWh per
year
Energy
rating star
Cottons-Extra Dry*
Dryness Level 1 7 144 6
* : Energy Label standard program (EN 61121:2012) All values in the table are determined
according to EN 61121:2012 standard. Consumption values may vary from the values in the chart
depending on laundry type, wringing speed, ambient conditions and voltage levels.
* : Energy Label standard program (AS/NZS 2442) “All the filters must be cleaned prior to test
series.”
All values given in the table have been fixed according to standard laboratory conditions.
These values may deviate from the table according to the laundry type, laundry spin speed,
environmental conditions and voltage fluctuations.

17
Changing the delay start time
If you want to change the duration during the
countdown:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and repeat the Delay Start selection
process.
Cancelling the end time function
If you want to cancel the Delay Start
countdown and start the program immediately:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and press the Start/Pause-by button.
5.6 Warning indicators
CNOTE
• Warning indicators may vary depending
on the model of your dryer.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.
Water tank
When the program is completed, the warning
indicator to empty the water tank turns on.
If the water tank fills up while the program
continues, the warning indicator starts flashing
and the machine goes into stand-by. In this
case, empty the water tank and start the
program by pressing the Start / Stand-by
button. Warning indicator turns off and program
resumes.
Filter drawer /Heat exchanger cleaning
When the programme is finished, the cleaning
symbol of the heat exchanger or filter drawer
may light up.
5.7 Starting the program
Press the Start/Pause button to start the
program.
Start/Pause and Drying indicators will illuminate
to indicate that program started.
5.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being
interrupted when the buttons are pressed
during a program. When the child lock is
activated, all buttons on the panel except
the On/Off/Program selection knob are
deactivated.
5.5 Auxiliary functions
Alarm / Duration
Drying machine makes an audible warning
when the program is completed. If you don’t
want the machine to make an audible warning,
press the “Alarm / Duration” button. When you
press the Alarm / Duration button, a light will
illuminate and no audible warning will be made
when the program ends.
CNOTE
• You can select this function before or
after the program starts.
Alarm/Duration button is used to adjust
program duration while the Rack/Time
programs are selected.
Dryness Level
Dryness Level button is used for adjusting to
desired dryness level. Program duration may
change depending on the selection.
CNOTE
• You can activate this function only prior
to start of program.
Delay Start
You can delay the end time of the program
upto 24 hours with Delay/Start function.
1. Open the loading door and place the
laundry.
2. Select the drying program.
3. Press the Delay/Start selection button
and set the delay time you wish. Delay/
Start LED will illuminate.
4. Press the Start / Pause. Delay/Start
countdown starts. “:” Separator in the
middle of displayed delay time flashes.
CNOTE
•You can add or remove laundry within
end time. Displayed time is the sum of
normal drying time and end time. Delay
Start LED will turn off at the end of
countdown, drying starts and drying LED
will illuminate.

18
Dryer / User Manual
Press the Dryness and Alarm buttons
simultaneously for 3 buttons to activate the
child lock.
The child lock has to be deactivated to be
able to start a new program after the current
program is finished or to be able to interfere
with the program. To deactivate the child lock,
keep the same buttons pressed for 3 seconds.
CNOTE
• When the child lock is activated, the child
lock warning indicator on the screen
turns on.
• Child lock deactivates when the drying
machine is turned off and on by the On/
Off/Cancel knob.
CNOTE
• When the drying machine runs and
the child lock is active, it beeps twice
when the program selection knob is
turned. If the child lock is deactivated
without returning the program selection
knob to its previous position, program
will terminate due to the change in the
program selection knob position.
5.9 Changing the program after it is
started
You can change the program you selected to
dry your laundry with a different program after
the drying machine starts running
•
•
For instance, select Extra Dry program
by turning the On/Off/Program selection
knob to select Extra Dry instead of Iron
Dry.
Press the Start/Pause button to start the
program.
Adding and removing whilst the dryer is
paused
If you want to add or remove clothes to/
from the drying machine after the drying
program starts:
• Press the Start/Pause button to pause the
dryer. The drying operation stops.
•Open the loading door whilst the unit is
paused and add or remove laundry
items.
• Press the Start/Pause button to start
the program.
CNOTE
• Adding laundry after the drying operation
starts may cause the dried laundry inside
the machine to mix with wet laundry and
leave the laundry damp at the end of
operation.
• Adding or removing laundry during drying
may be repeated as many times as you
wish. But this operation continuously
interrupts the drying operation, and thus
increases program duration and energy
consumption. So, it is recommended to
add laundry before the program starts.
• If a new program is selected by turning
the program selection knob while the
drying machine is in stand-by, the
running program terminates.
WARNING!
• Do not touch the inner surface of the
drum while adding or removing clothes
during a continuing program. The drum
surface is hot.
5.10 Cancelling the program
If you want to cancel the program and
terminate the drying operation for any reason
after the drying machine starts running, turn
the On/Off/Cancel knob, the program will be
cancelled.
AWARNING!
• The inside of the drying machine shall
be extremely hot when you cancel the
program during machine operation, so
run the refresh program to allow it to cool
down.

19
5.11 End of program
When the program ends, the Fibre Filter
Cleaning and Water Tank warning symbols
on the program observation indicator turn on.
Loading door may be opened and the dryer
machine becomes ready for another run.
Bring the On/Off/Program selection knob to
On/Off position to turn the drying machine off.
CNOTE
• If the laundry is not removed after the
program is completed, the wrinkle
prevention function activates for 2 hours
to prevent the laundry inside the machine
to get wrinkled. The program tumbles
the laundry with 10-minute intervals to
prevent them from wrinkling.

20
Dryer / User Manual
6 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced if it is
cleaned at regular intervals.
AWARNING!
• Please unplug your product before
performing maintenance and cleaning
instructions. (eg control panel, body, etc.)
6.1 Cleaning Lint Filter / Loading
Door Inner Surface
Lint and fiber released from the laundry to the
air during the drying cycle are collected in the
Lint Filter.
CNOTE
• You can clean the lint filter housing with a
vacuum cleaner.
AWARNING!
• Always clean the lint filter and the inner
surfaces of the loading door after each
drying process.
To clean the lint filter:
• Open the
loading door.
• Remove the
lint filter by
pulling it up
and open the
lint filter.
• Clean lint, fiber, and cotton raveling by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
A layer can build up
on the filter pores that
can cause clogging
of the filter after using
the dryer for a while.
Wash the lint filter with
warm water to remove
the layer that builds
up on the lint filter
surface. Dry the lint
filter completely before
reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
6.2 Cleaning the sensor
There are
dampness sensors
in the dryer that
detect whether
the laundry is dry
or not.
To clean the
sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is still
hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with vinegar
and dry them.
CNOTE
• Clean metal surfaces of the sensors 4
times a year.
• Do not use metal tools when cleaning
metal surfaces of the sensors.
AWARNING!
• Never use solvents, cleaning agents or
similar substances for cleaning due to the
risk of fire and explosion!
