Eurotherm 5100e User manual

ε
EUROTHERM
Model 5100e
100 mm graphics recorder
User guide

Declaration of Conformity
Eurotherm Limited hereby declares that the above products conform to the safety and EMC
specifications listed. Eurotherm Limited further declares that the above products comply
with the EMC Directive 89 / 336 / EEC amended by 93 / 68 / EEC, and also with the Low
Voltage Directive 73 /23 / EEC
Manufacturer's name: Eurotherm Limited
Manufacturer's address Faraday Close, Worthing, West Sussex,
BN13 3PL, United Kingdom.
Product type: Industrial graphics recorder
Models: 5100e Status level A1 and above
Safety specification: EN61010-1: 1993 / A2:1995
EMC emissions specification: EN61326
EMC immunity specification: EN61326
Signed for and on behalf of Eurotherm Limited
Peter de la Nouger de
(Technical Director)
Signed: Dated:
IA249986U580 Issue 1 Jan 2001
ε
EUROTHERM
© 2001 Eurotherm Limited
All rights are strictly reserved. No part of this document may be reproduced, modified, or transmitted in any form
by any means, nor may it be stored in a retrieval system other than for the purpose to act as an aid in operating the
equipment to which the document relates, without the prior written permission of Eurotherm limited.
Eurotherm Limited pursues a policy of continuous development and product improvement. The specifications in
this document may therefore be changed without notice. The information in this document is given in good faith,
but is intended for guidance only. Eurotherm Limited will accept no responsibility for any losses arising from
errors in this document.

100 MM GRAPHICS RECORDER: USER GUIDE
Page 1
HA027271
Issue 1 Feb 01
GRAPHICS RECORDER
USER MANUAL
LIST OF CONTENTS
Section Page
SAFETY NOTES ........................................................................ 5
SYMBOLS USED ON THE RECORDER LABELLING......................... 5
1 INTRODUCTION ......................................................... 6
1.1 UNPACKING THE RECORDER ............................................. 6
2 INSTALLATION ........................................................... 6
2.1 MECHANICAL INSTALLATION............................................. 6
2.2 ELECTRICAL INSTALLATION................................................. 8
2.2.1 Signal wiring ........................................................................ 8
CONNECTOR WIRING DETAILS ............................................ 8
2.2.2 Supply voltage wiring ............................................................. 9
AC SUPPLY........................................................................... 9
2.3 DISK INSERTION AND REMOVAL........................................ 9
3 PROCESS VARIABLE DISPLAY....................................... 10
TRUNCATION OF NUMERIC VALUES ..................................... 10
CURRENT TRACE ALARM ICONS........................................... 10
3.1 STATUS BAR ...................................................................... 11
3.1.1 Current access level ............................................................... 11
3.1.2 Page name ........................................................................... 11
3.1.3 Error/alarm indicators............................................................ 11
SYSTEM ERROR .................................................................... 12
CHANNEL ALARM................................................................ 13
CHANGE BATTERY ............................................................... 13
3.1.4 Disk icon .............................................................................. 13
3.1.5 FTP Icon ............................................................................... 13
3.2 NAVIGATION KEYS ........................................................... 14
3.2.1 Key functions ........................................................................ 14
3.3 FIRST SWITCH-ON............................................................. 15
3.3.1 Access to Configuration ......................................................... 15
TEXT STRING ENTRY............................................................. 16
3.4 DISPLAY MODES................................................................ 18
3.4.1 Vertical Trend display............................................................. 18
TREND REVIEW .................................................................... 18
3.4.2 Horizontal Trend display ........................................................ 20
3.4.3 Vertical bargraph ................................................................... 22
3.4.4 Horizontal bargraph .............................................................. 23
3.4.5 Numeric ............................................................................... 24
(Continued)

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 2
4 SETTING UP THE RECORDER ........................................ 25
4.1 ARCHIVE........................................................................... 26
4.1.1 Archive to disk ...................................................................... 26
4.1.2 Remote archiving (FTP transfer) ................................................ 27
4.2 SAVE / RESTORE ............................................................... 28
4.2.1 Save 29
4.2.2 Restore ................................................................................. 29
4.2.3 New 29
4.2.4 Text 29
4.3 CONFIGURATION .............................................................. 30
4.3.1 Options ................................................................................ 30
4.3.2 Channel/Alarm configuration ................................................. 32
CHANNEL NUMBER ............................................................. 33
INPUT TYPE.......................................................................... 33
LIN TYPE .............................................................................. 33
INPUT LOW ......................................................................... 33
INPUT HIGH......................................................................... 33
SHUNT ................................................................................ 33
RANGE LOW....................................................................... 34
RANGE HIGH ...................................................................... 34
RANGE UNITS ..................................................................... 34
SCALED ............................................................................... 34
OFFSET................................................................................ 34
FILTER .................................................................................. 34
INPUT BREAK RESPONSE...................................................... 34
COLD JUNCTION COMPENSATION (CJC) ............................. 34
DESCRIPTOR ........................................................................ 35
SPANNED............................................................................ 35
ZONE.................................................................................. 35
MAXIMUM DECIMAL DIGITS ................................................. 35
COLOUR ............................................................................. 35
ALARM NUMBER.................................................................. 35
ENABLE ............................................................................... 36
TYPE.................................................................................... 36
THRESHOLD/HYSTERESIS ..................................................... 36
EXAMPLE ............................................................................. 36
DWELL................................................................................. 36
JOB NUMBER....................................................................... 36
CATEGORY .......................................................................... 36
WHILE ................................................................................. 36
ALARM MESSAGES .............................................................. 36
4.3.3 Group configuration .............................................................. 37
TREND UNITS....................................................................... 37
DESCRIPTOR ........................................................................ 37
TREND SPEED/TREND INTERVAL............................................ 37
RECORDING SPEED/RECORDING INTERVAL.......................... 37
ALARM MESSAGE ................................................................ 37
ACK MESSAGE .................................................................... 37
GROUP CONTENTS ............................................................. 37
4.3.4 Event configuration ................................................................ 38
EVENT NUMBER................................................................... 38
SOURCE .............................................................................. 38
DESCRIPTOR ........................................................................ 38
JOB NUMBER....................................................................... 38
CATEGORY .......................................................................... 38
WHILE ................................................................................. 38
LIST OF CONTENTS (Cont.)
Section Page
(Continued)

100 MM GRAPHICS RECORDER: USER GUIDE
Page 3
HA027271
Issue 1 Feb 01
LIST OF CONTENTS (Cont.)
Section Page
4.3.5 Instrument configuration ......................................................... 39
INSTRUMENT NAME ............................................................ 39
NORMAL/SAVER DISPLAY ..................................................... 39
SAVE AFTER ......................................................................... 39
4.3.6 Archive configuration ............................................................. 40
COMPRESSION ................................................................... 41
FLASH SIZE .......................................................................... 41
TREND HISTORY DURATION ................................................. 41
SHOW ................................................................................ 41
ARCHIVE TO MEDIA ............................................................. 41
MEDIA FULL OPERATION ...................................................... 41
MEDIA SIZE ......................................................................... 41
DISK ARCHIVE CAPACITY ..................................................... 41
ARCHIVE TO REMOTE .......................................................... 42
REMOTE PATH ...................................................................... 42
PRIMARY REMOTE HOST ...................................................... 42
PRIMARY LOGIN NAME/PASSWORD .................................... 42
SECONDARY REMOTE HOST/LOGIN/PASSWORD ................ 42
4.4 SECURITY.......................................................................... 43
4.4.1 Access levels......................................................................... 43
SETTING PERMISSIONS ........................................................ 43
ACCESS WHEN: .................................................................. 44
NEW PASSWORD/RETYPE PASSWORD................................. 44
CONNECT FROM REMOTE................................................... 44
REMOTE USER NAME/PASSWORD ....................................... 44
LOGIN DISABLED ................................................................. 44
EDIT OWN PASSWORD ....................................................... 45
CHANGE ALARM SETPOINTS ............................................... 45
SET CLOCK.......................................................................... 45
ARCHIVING CONTROL......................................................... 45
SAVE/RESTORE .................................................................... 45
PASTE/DELETE FILES ............................................................. 45
FULL CONFIGURATION ........................................................ 45
FULL SECURITY ..................................................................... 45
4.4.2 Add user .............................................................................. 46
NEW USER/NEW PASSWORD/RETYPE PASSWORD .............. 46
BASED ON .......................................................................... 46
4.4.3 Remove user ......................................................................... 46
4.5 NETWORK CONFIGURATION ............................................ 47
4.5.1 Address................................................................................ 47
INSTRUMENT NUMBER/MAC ADDRESS ................................ 47
IP ADDRESS LOOKUP ........................................................... 47
BOOTP TIMEOUT ................................................................. 47
IP ADDRESS ......................................................................... 47
SUBNET MASK..................................................................... 47
DEFAULT GATEWAY .............................................................. 47
4.5.2 Name ..................................................................................48
LOCAL HOST ....................................................................... 48
DOMAIN ............................................................................. 48
DOMAIN NAME SERVICE (DNS) ........................................... 48
PRIMARY/SECONDARY DNS SERVER .................................... 48
4.6 STSTEM ............................................................................ 49
4.6.1 Setup ..................................................................................50
HOME TIMEOUT .................................................................. 50
4.6.2 Clock ..................................................................................50
4.6.3 Locale ..................................................................................50
4.6.4 Keycode............................................................................... 51
4.6.5 About ..................................................................................51
(Continued)

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 4
LIST OF CONTENTS (Cont.)
Section Page
5 FILE ........................................................................... 51
5.1 FILER OPTION MENU KEYS ................................................ 51
5.2 THE HIDE KEY ................................................................... 51
6 BRIDGE 5000 REMOTE VIEWER ................................... 53
6.1 INTRODUCTION................................................................ 53
6.1.1 Minimum PC requirements ...................................................... 53
6.2 CONNECTION DETAILS ..................................................... 53
6.2.1 Direct PC connection.............................................................. 53
6.2.2 PC To remote recorder............................................................ 54
6.2.3 Networked systems ................................................................ 54
6.3 SOFTWARE INSTALLATION ................................................. 54
6.4 RECORDER CONFIGURATION ............................................ 55
6.4.1 Network ............................................................................... 55
6.4.2 Options ................................................................................ 55
6.4.3 Access ................................................................................. 56
6.5 RUNNING THE PROGRAM................................................. 57
6.6 OPERATION ...................................................................... 58
6.6.1 Display Modes ...................................................................... 58
6.6.2 Alarm acknowledgement ........................................................ 58
6.6.3 Status line ............................................................................. 58
6.6.4 Error messages...................................................................... 58
NETWORK CONNECTION HAS TIMED OUT ......................... 58
UNABLE TO CONNECT TO HOST ........................................ 58
UNABLE TO RESOLVE HOSTNAME ........................................ 58
FAILED TO AUTHENTICATE THE USER NAME AND
/OR PASSWORD SUPPLIED .... 58
MAXIMUM REMOTE VIEWERS ALREADY CONNECTED TO ... . 58
7 REFERENCE................................................................. 59
7.1 DIAGNOSTICS DISPLAY...................................................... 59
7.1.1 Display details ...................................................................... 59
MAC ETHERNET ADDRESS .................................................... 59
COLOUR TEST BARS ............................................................. 59
SOFTWARE VERSION NUMBER............................................. 59
SELF-TEST STATUS BARS ........................................................ 59
CIRCUIT BOARDS FITTED ...................................................... 60
TOUCH CAL......................................................................... 60
DETAIL ................................................................................. 60
7.2 SCREEN CALIBRATION (OFFSET CORRECTION) ................... 61
7.3 PREVENTIVE MAINTENANCE ............................................. 61
7.3.1 Touch Screen Cleaning........................................................... 61
7.3.2 Maintenance schedule ........................................................... 62
7.3.3 Battery replacement procedure................................................ 62
7.4 MENU STRUCTURE ............................................................ 63
ANNEX A: SPECIFICATION ............................................. 67
RECORDER............................................................................... 68
UNIVERSAL INPUTS................................................................... 69
ETHERNET/RELAY OUTPUT BOARD OPTION ............................... 71
INDEX ........................................................................... 72

100 MM GRAPHICS RECORDER: USER GUIDE
Page 5
HA027271
Issue 1 Feb 01
SAFETY NOTES
WARNING
Any interruption of the protective conductor inside or outside the apparatus, or disconnection of the
protective earth terminal is likely to make the apparatus dangerous under some fault conditions. Inten-
tional interruption is prohibited.
Note: in order to comply with the requirements of safety standard BS EN61010, the recorder shall have one
of the following as a disconnecting device, fitted within easy reach of the operator, and labelled as the discon-
necting device.
a A switch or circuit breaker which complies with the requirements of IEC947-1 and IEC947-3
b. A separable coupler which can be disconnected without the use of a tool
c. A separable plug, without a locking device, to mate with a socket outlet in the building.
1. Before any other connection is made, the protective earth terminal shall be connected to a protective conductor.
The mains (supply voltage) wiring must be terminated within the connector in such a way that, should it slip in
the cable clamp, the Earth wire would be the last wire to become disconnected.
2. In the case of portable equipment, the protective earth terminal must remain connected (even if the recorder is
isolated from the mains supply), if any of the I/O circuits are connected to hazardous voltages*.
3. The mains supply fuse within the power supply is not replaceable. If it is suspected that the fuse is faulty, the
manufacturer's local service centre should be contacted for advice.
4. Whenever it is likely that protection has been impaired, the unit shall be made inoperative, and secured against
accidental operation. The manufacturer's nearest service centre should be contacted for advice.
5. Any adjustment, maintenance and repair of the opened apparatus under voltage, should be avoided as far as possi-
ble and, if inevitable, shall be carried out only by a skilled person who is aware of the hazard involved.
6. Where conductive pollution (e.g. condensation, carbon dust) is likely, adequate air conditioning/filtering/sealing
etc. must be installed in the recorder enclosure.
7. Signal and supply voltage wiring should be kept separate from one another. Where this is impractical, shielded
cables should be used for the signal wiring.
8. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment
might be impaired.
* A full definition of 'Hazardous' voltages appears under 'Hazardous live' in BS EN61010. Briefly, under normal op-
erating conditions, hazardous voltages are defined as being > 30V RMS (42.2V peak) or > 60V dc.
SYMBOLS USED ON THE RECORDER LABELLING
One or more of the symbols below may appear as a part of the recorder labelling.
!Refer to the manual for instructions
Protective earth
This recorder for ac supply only
This recorder for dc supply only
This recorder for either ac or dc supply
Risk of electric shock

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 6
USER GUIDE
1 INTRODUCTION
This document describes the installation, operation and configuration of a 100mm graphics recorder. The recorder
has the facility for FTP transfer and Remote viewer connection if the Ethernet option is fitted.
1.1 UNPACKING THE RECORDER
The recorder is despatched in a special pack, designed to give adequate protection during transit. Should the outer
box show signs of damage, it should be opened immediately, and the recorder examined. If there is evidence of dam-
age, the instrument should not be operated and the local representative contacted for instructions. After the recorder
has been removed from its packing, the packing should be examined to ensure that all accessories and documentation
have been removed. The packing should then be stored against future transport requirements.
2 INSTALLATION
2.1 MECHANICAL INSTALLATION
Figures 2.1a gives installation details.
Note: It is recommended that the rear face of the panel be centre-punched at suitable positions to locate the
tips of the case clamps. Otherwise, particularly on smooth surfaces, the clamps can 'wander' as they are
tightened, leading to inefficient clamping and possible damage to the recorder mounting slots.
The unit is inserted through the panel aperture from the front of the panel. With the weight of the recorder supported,
a panel clamp is inserted into each of the mounting slots (one each on the left- and right-hand sides). The jacking
screws are then tightened sufficiently to clamp the recorder into position. EXCESS FORCE SHOULD NOT BE
USED IN TIGHTENING THESE SCREWS.

100 MM GRAPHICS RECORDER: USER GUIDE
Page 7
HA027271
Issue 1 Feb 01
2 INSTALLATION (Cont.)
Figure 2.1a Mechanical installation details - small frame unit
ab
Vertical
MAXIMUM INSTALLED ANGLE
a = b = 15 degrees max
Panel clamping
138 x 138mm
(-0.0 + 1.0)
5.44 x 5.44 in
(-0.00 + 0.04)
y
x
Panel cutout
x = 15mm (0.6 inch)
y = 10 mm (0.4 in)
Minimum recommended spacing
Side clamps Top/bottom clamps
x = 10 mm (0.4 in)
y = 15mm (0.6 inch)
View on under side 137mm
(5.4in)
View on right hand
side
247.5mm (9.75in)
213mm (8.39in)
137mm
(5.4in)
103 mm (4.1 in)
25mm
(0.99 in)
Mounting slot
(Left hand side)
Panel thickness
(25.4mm (1 in) max)
Lift then pull to open
flap for mass storage
access
144mm (5.67in)
144mm (5.67in)
Gland {approx 4 mm (.1875 in)}

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 8
2.2 ELECTRICAL INSTALLATION
2.2.1 Signal wiring
Figure 2.2.1a shows connector locations for the input chan-
nel and for the optional relay output/ethernet board
CONNECTOR WIRING DETAILS
Maximum wire size (inputs) = 4.13mm2(11 AWG)
Maximum wire size (relay) = 1.5 mm2(16 AWG)
Minimum wire size = 0.081mm2(28 AWG)
Design torque = 0.8Nm.
Figure 2.2.1b shows details of input board wiring and figure
2.2.1c shows relay output wiring.
Figure 2.2.1a Connector locations - small frame units
Figure 2.2.1b Input board wiring details
1 8
Input channel connector
122
Supply
voltage
connector
1
Ethernet
connector
(option)
Relay
connector
(option)
com
nc
no
V+ V- I
+- +-
Shunt
assembly
V+ V- I
+-
V+ V- I
Attenuator
assembly
-20 to + 100 V dc
-2 to + 10 V dc
Thermocouples
dc millivolts DC milliamps
1 2 3 4 5 6 7 8 910111213141516171819202122
V+ V- I V+ V- I V+ V- I
Cold
junction
V+ V- I V+ V- I V+ V- I
V+ V- I V+ V- I
2-wire resistance
thermometer
3-wire resistance
thermometer Potentiometer
V+ V- I
Contact closure
(Not channel 1)
RTD RTD
V+ V- I
Potentiometer
Minimum contact = 60msec
Input board pinouts
Channel 6Channel 4 Channel 5Channel 1 Channel 2 Channel 3
nc
Contacts shown in
power off/alarm
state
1
com
1
(NC) 2 (Com) 3 (NO)
no
23
Figure 2.2.1c Relay wiring details

100 MM GRAPHICS RECORDER: USER GUIDE
Page 9
HA027271
Issue 1 Feb 01
2.2.2 Supply voltage wiring
AC SUPPLY
The supply voltage to the recorder is terminated using an IEC socket which is connected to the mating plug at the rear
of the recorder. The recorder is suitable for use with all ac voltages between 85 and 265 V RMS (47 to 63 Hz), and
requires 60 VA max. power.
The minimum recommended wire size is 16/0.2 (0.5mm2).
2.3 DISK INSERTION AND REMOVAL
The disk slot is located below the recorder screen, and is protected by a flap as shown in figure 2.1, above.
In order to access the disk slot, the bottom of the central part of the flap is lifted (figure 2.3a) and then used as a han-
dle to pull the main flap open.
If a disk is already fitted, it is removed by pressing on the eject button (figure 2.3b).
Note: Before disk removal, archiving should be suspended (section 4.1) (wait for the green LED on the disk
drive to be extinguished), otherwise data might be lost.
Figure 2.3a Disk access Figure 2.3b Disk eject

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 10
3 PROCESS VARIABLE DISPLAY
The operator interface consists of a touch-sensitive screen, showing either process variable values in one of a number
of formats, or, showing configuration or operational details for use in setting up the recorder. This section (3) de-
scribes the process variable displays. Section 4 describes the Configuration displays.
Figure 3, below, depicts a typical trend display and gives details of the various areas of the display page.
TRUNCATION OF NUMERIC VALUES
If the amount of space on the display page is insufficient to display the full width of the process variable or scale
value, then the displayed value is rounded down and the number of decimal places reduced.
CURRENT TRACE ALARM ICONS
In each of the different types of PV display, each channel's faceplate give the status of the channel's two alarms. This
status is shown by a red arrow head, pointing upwards if the alarm is absolute high, or downwards if absolute low. As
described in section 4.3.2 (Channel/alarm configuration) the alarms may be both high, or both low, or one may be
high and the other low. If the arrow head is flashing it is active and unacknowledged; if it is on continuously, the
alarm is active and acknowledged. See section 3.1.3, below, for a description of how to acknowledge alarms.
Figure 3 Trend display definitions
Engineer
Group Name
15:01:47
21/12/00
99%
Channel 1 21.2613
C
35.00000.0000
21/12/00 14:43:37 Alarm(s) off 2 (1)
14:40:17
21/12/00
14:53:37
21/12/00
21/12/00 14:41:39 Alarm(s) on 2 (1)
Root menu key with
Current access level
or user ID
Page Name
System error Channel alarm Battery warning
FTP activity
Current time/date
This channel's
alarm icons
Current channel's
descriptor and
trace colour
Current channel's
scale
Current channel's
value
Channel(s)
configured 'Off'
Disk icon
Non-current trace
icon
Current trace icon
(diamond shape)
Time/Date stamp
Channel 2 alarm 1
on / off messages

100 MM GRAPHICS RECORDER: USER GUIDE
Page 11
HA027271
Issue 1 Feb 01
3.1 STATUS BAR
This appears across the top of the display, and contains the items described below.
3.1.1 Current access level
There are four access levels available (Logged out, Operator, Engineer and Service), and the current level is displayed
in this key at the top left hand corner of the display. Touching this key calls the root menu as described in section
3.2.1 (Key functions) below. If 'user IDs' have been entered in the 'Add User' part of the Security setup, then the cur-
rent user Id is displayed instead of the access level.
3.1.2 Page name
Initially this shows the current group's descriptor. The name changes according to context for example 'Operator' or
'Config-Archive'.
3.1.3 Error/alarm indicators
This area of the display can contain up to four icons: System error, Channel alarm, Battery change, Disk status. Press-
ing this area of the screen calls a pop-up display (figure 3.1.3) giving the option to view messages or to acknowledge
channel alarms. Also incorporated in this display is a slider control allowing the user to optimise the display contrast
for the local environment.
Figure 3.1.3 Alarm acknowledgement /System error display / Display contrast pop-up
Alarm & Message options
View Messages Ack all Alarms
Display Contrast
View Messages
Ok
DD/MM/YY HH:MM:SS Error description
Ack all Alarms
Confirm acknowledge of alarms?
NoYes

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 12
3.1.3 ERROR/ALARM INDICATORS (Cont.)
SYSTEM ERROR
This indicator appears, flashing, if any of the following errors are active. The view messages page shows any active
errors:
Archive failed -(message) Message explains archive failure - due to disk being missing, write protected,
faulty, full etc.
Clock failure Internal clock was corrupt at power up, or the time has never been set. Can be
caused by battery failure, in which case the battery icon will also be visible. The
error is cleared by setting the time and date.
Battery-backed RAM cleared This message appears if the battery has failed, and the unit has been switched off.
Channel failure Indicates a hardware failure in the channel circuit
Channel error Indicates a hardware failure in the channel circuit or in the internal CJ tempera-
ture measurement
Failed to authenticate the user name and/or password supplied
Appears if an incorrect user name or password has been entered whilst trying to
establish remote viewer connection.
Floppy disk worn Appears if a number of attempts had to be made before write to the disk was suc-
cessful. No data is lost, but the disk should be replaced as soon as is practicable.
Floppy disk corrupt This appears if all attempts to write to the disk fail. In such a case, some data may
be lost. If the damaged area of the disk is in the system part of the disk, it might
appear to the recorder that it is unformatted, and the disk icon will disappear. The
disk should be replaced immediately.
Internal flash: \user\ required repair Error found (in the internal file system) at power-up, and corrected.
Internal flash: \system\ required repair Error found (in the internal file system) at power-up, and corrected.
Internal flash: \history\ required repair Error found (in the internal file system) at power-up, and corrected.
Maximum Remote Viewers already connected to ...
Appears if an attempt is made to connect more remote viewers to the recorder
than are configured in the Options menu.
Network connection has timed out Appears if no connection can be established between the remote viewer and the
recorder. This might be caused by, for example, cable failure, network hardware
failure, etc.
Unable to connect to host ... As for 'Network connection has timed out' message above, but with the addition
of 'incorrect host address' as a possible cause.
Unable to resolve hostname Message appears if an incorrect host address is entered or if there is a network
failure whilst trying to establish remote viewer connection.

100 MM GRAPHICS RECORDER: USER GUIDE
Page 13
HA027271
Issue 1 Feb 01
This area of the icon flashes
green/white during archive.
3.1.3 ERROR/ALARM INDICATORS (Cont.)
CHANNEL ALARM
This red 'bell' indicator appears if any channel is in alarm. The symbol is illuminated continuously if all alarms are
acknowledged or flashes if any active alarm is unacknowledged. To acknowledge all unacknowledged alarms, the
flashing indicator is touched, and the 'Ack all Alarms' key in the resulting 'pop-up' page is touched.
CHANGE BATTERY
This flashing indicator first appears when the battery voltage indicates that the battery is approaching the end of its
useful life. The indicator continues to flash until the battery is replaced (Section 7.3.2).
3.1.4 Disk icon
This shows the free space available on the disk. The disk icon appears soon after a disk is inserted.
Only archiving activity is indicated; during archiving, the central area of the disk icon flashes green, regularly. No
other disk activity is indicated.
Figure 3.1.4 Archive activity indication
3.1.5 FTP Icon
For those recorders fitted with Ethernet option, the File Transfer Protocol (FTP) icon appears to the right of the disc
icon position, whenever transfer activity is taking place.

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 14
3.2.1 Key functions
Close folder Used, where appropriate, to recall the previous (higher level) display page.
Open folder Used, where appropriate, to call a further (lower level) display page.
Left cursor Used to navigate backwards through a text string, when editing.
Right cursor Used to navigate forwards through a text string, when editing.
Root Calls the 'Root Menu' as shown.
ROOT MENU KEYS
Home Causes a return to the 'Home' page from any page in the recorder.
As delivered, the 'Home' page is the vertical trend display as de-
picted in figure 3, but this can be edited (in Operator/System -
Setup) to be any of the available display modes - Horizontal trend,
Vertical bargraph, Horizontal bargraph, Numeric etc.
Operator Causes the top level Operator page to appear. The appearance of this display is dictated by the security
level that the recorder is set to, and by the access level of the user. As despatched from the factory, the
recorder is in 'logged out' mode and the Operator page contains only the buttons labelled 'Archive', 'Secu-
rity' and System. Further details appear in 'Access to configuration' below.
File Allows the file system in that area of Flash memory that is accessible to the user, and the file system on
any floppy disk fitted to be viewed. See section 5 for details.
Cycle Causes the next display mode to be selected for process variable display. Initially, the sequence is Trace
(on white background), vertical bargraph, horizontal bargraph, numeric. Though the order in which these
displays appear cannot be changed, all modes can be enabled/disabled in the Operator/System-Setup con-
figuration page. Tracing on a dark background is an alternative mode to tracing on a white background,
not an additional mode.
Login Calls the login page described in section 3.3.1, below
Options Used for a number of functions depending on the context. For example, entering or exiting trend review
mode, or calling the filer option pop-up.
To quit the Root menu, touch the root key again.
3.2 NAVIGATION KEYS
These keys allow the user to perform various context-related tasks such as to access the recorder configuration, to
archive data etc. In addition to this, left and right arrow keys or open/close folder keys appear where relevant.
Root
Engineer
Close
folder Open folder Left
cursor Right cursor
File
Home Operator
Cycle
Login Options
Root Menu

100 MM GRAPHICS RECORDER: USER GUIDE
Page 15
HA027271
Issue 1 Feb 01
3.3 FIRST SWITCH-ON
There is no on/off switch associated with the recorder.
When power is applied the recorder initialises, and once this process is complete, the home page is displayed. It is
unlikely that this will contain any useful information because the input channels will not, as yet, have been configured
to suit the type of input signals being applied to them, as described in section 4.
The recorder has four security levels as follows
Logged out Initially, no access to recorder configuration is possible. Only Archive, Login/security and the System
'About' functions can be accessed - via the root menu. Limited or full access can be permitted from
'Engineer' level.
Operator No access to recorder configuration is possible until access permission has been set up. Limited or full
access can be permitted from 'Engineer' level, either with or without a separate password.
Engineer Accessed initially, by entering '10' as the password. Full access to all recorder functions is available.
The Engineer password can be edited and an Operator level password can be entered. Access permis-
sion to some or all of the recorder functions can be granted, or not, to the operator and/or logged out
security levels.
Service Full access to all recorder functions and to areas of recorder memory for diagnostic purposes. For use
only by Service Engineers.
3.3.1 Access to Configuration
1 Once the recorder has initialised, touch the Root key, followed by 'Login'. Touching the 'Logged out' field in the
resulting display, calls the access level picklist as shown in figure 3.3.1a.
2 Press 'Engineer' to call the Password request page.
3 Touching the blank Password area calls the keyboard display (see figure 3.3.1b).
4 Touch <Numeric><1><0><OK> to enter the password '10'. The screen reverts to the 'Home' page.
5 Operation of the Root key followed by a touch on the Operator key calls the top level page allowing access to the
Archive, Save/Restore, Config, Security, Network*, and System areas described in section 4 below.
Figure 3.3.1a Access to configuration
* Network configuration appears only if the Ethernet option is fitted.
Login
Select the required access level and enter the password if
required. User Logged out
Cancel
Operator
Engineer
Service
Logged out

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 1 Feb 01Page 16
3.3.1 ACCESS TO CONFIGURATION (Cont.)
TEXT STRING ENTRY
The keyboard which appears when the password area is touched is the same as that which appears when any non-
numeric text string entry is required (e.g. channel descriptor). Figures 3.3.1b and 3.3.1c below are an attempt, within
the limitations of the illustrating process, to depict the available keyboards and thus the available character set. Actual
entry of the text string is by touching the relevant key. For items which require only a numeric entry (e.g. channel
range) the numeric keyboard appears.
When editing existing text strings, the existing text string appears highlighted, and will be replaced in its entirety by
the first character entered. To avoid this, the left arrow key can be touched to 'unhighlight' it.
Immediately below the keyboard are six keys with the functions listed below. When active, the background colour
changes to yellow for as long as the key is active.
Shift* Once the shift key has been pressed, the next-entered letter appears as a capital; subsequent letters are in
lower case.
Caps* When pressed, all subsequent letters appear as capital letters until the Caps key is operated again
BSpc This backspace key deletes character to the left of the cursor.
Ovr If selected, the next-entered character replaces (overwrites) the existing character to the right of the cursor
position. If not selected, the next-entered character in inserted into the existing text string at the cursor posi-
tion.
Ok Used to save the new text string and to return to the page from which the keyboard was called.
Cancel Causes a return to the page from which the keyboard was called without saving the new string.
*Note: The character on each display key is always a capital letter, whether or not the actual character being
entered is in capitals or lower case.
SymbolsNumericAlphabet 2
**
Alphabet
Shift Caps BSpc Ovr Ok Cancel
Tabs show
active keyboard
Shift key Caps Lock Backspace Overprint
Text string
(all * for password)
QWE R T Y U I O P
ASD F G H J K L
ZXC V B N M \ .
Cursor keys
Figure 3.3.1b Alphabet 1 keyboard
