Eurotherm 5100e User manual

Model 5100e
100 mm graphics recorder
User guide
E UR O T H E R M

Declaration of Conformity
Manufacturer's name: Eurotherm Limited
Manufacturer's address Faraday Close, Worthing, West Sussex,
BN 3 3PL, United Kingdom.
Product type: Industrial graphics recorder
Models: 5 00e Status level A and above
Safety specification: EN6 0 0- : 993 / A2: 995
EMC emissions specification: EN6 326
EMC immunity specification: EN6 326
ε
EUROTHERM
Eurotherm Limited hereby declares that the above products conform to the safety and EMC
specifications listed. Eurotherm Limited further declares that the above products comply
with the EMC Directive 89 / 33 / EEC amended by 93 / 8 / EEC, and also with the Low
Voltage Directive 73 /23 / EEC
Signed for and on behalf of Eurotherm Limited
Peter de la Nouger de
(Technical Director)
Signed: Dated:
IA249986U580 Issue 1 Jan 2001
© 2004 Eurotherm Limited
All rights are strictly reserved. No part of this document may be reproduced, modified, or transmitted in any form
by any means, nor may it be stored in a retrieval system other than for the purpose to act as an aid in operating the
equipment to which the document relates, without the prior written permission of Eurotherm limited.
Eurotherm Limited pursues a policy of continuous development and product improvement. The specifications in
this document may therefore be changed without notice. The information in this document is given in good faith,
but is intended for guidance only. Eurotherm Limited will accept no responsibility for any losses arising from
errors in this document.

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 1
HA027271
Issue 12 Mar 04
GRAPHICS RECORDER
USER MANUAL
LIST OF SECTIONS
Section Page
1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 PROCESS VARIABLE DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 SETTING UP THE RECORDER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5 FILE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
ANNEX A SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
ANNEX B REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
EFFECTIVITY
This manual refers to recorders fitted with software version 3.3. To determine the software version fitted to the re-
corder, the 'About' screen in the System menu may be accessed as described in section 4. .5.
For details of Remote Viewer and Modbus Communications see HA028122.
For details of Software and Hardware options see HA028121.

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 2
GRAPHICS RECORDER
USER MANUAL
LIST OF CONTENTS
Section Page
Safety Notes ....................................................................................................... 7
SYMBOLS USED ON THE RECORDER LABELLING .................................................. 7
1 INTRODUCTION ................................................................................. 8
1.1 UNPACKING THE RECORDER....................................................................... 8
2 INSTALLATION ................................................................................... 8
2.1 MECHANICAL INSTALLATION ...................................................................... 8
2.2 ELECTRICAL INSTALLATION .......................................................................... 10
2.2.1 Signal wiring....................................................................................... 10
CONNECTOR WIRING DETAILS ........................................................... 10
2.2.2 Supply voltage wiring............................................................................ 11
LINE SUPPLY ........................................................................................ 11
LOW VOLTAGE SUPPLY OPTION .......................................................... 11
2.3 DISK INSERTION AND REMOVAL ................................................................. 11
3 PROCESS VARIABLE DISPLAY .............................................................. 12
TRUNCATION OF NUMERIC VALUES .................................................... 13
CURRENT CHANNEL ALARM ICONS .................................................... 13
3.1 STATUS BAR ................................................................................................ 13
3.1.1 Current access level ............................................................................. 13
3.1.2 Page name.......................................................................................... 13
3.1.3 Alarm indicators .................................................................................. 14
ALARM SUMMARY PAGE ..................................................................... 14
ALARM ACKNOWLEDGEMENT............................................................ 15
INSTRUMENT ALARMS ........................................................................ 16
CHANNEL ALARM............................................................................... 17
CHANGE BATTERY .............................................................................. 17
3.1.4 Disk icon............................................................................................. 17
3.1.5 FTP Icon .............................................................................................. 17
3.1.6 Configuration Locked indicator.............................................................. 17
3.2 NAVIGATION Keys ...................................................................................... 18
3.2.1 Key functions ....................................................................................... 18
MESSAGE LOG ................................................................................... 19
3.3 FIRST SWITCH-ON....................................................................................... 21
3.3.1 Access to Configuration........................................................................ 22
TEXT STRING ENTRY............................................................................ 23
3.4 DISPLAY MODES.......................................................................................... 25
3.4.1 Vertical Trend display ........................................................................... 25
TIME CHANGE RECORDS .................................................................... 26
TREND HISTORY.................................................................................. 26
3.4.2 Horizontal Trend display....................................................................... 28
3.4.3 Vertical bargraph.................................................................................. 30
3.4.4 Horizontal bargraph ............................................................................ 31
3.4.5 Numeric.............................................................................................. 32
3.5 OPERATOR NOTES ...................................................................................... 33

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 3
HA027271
Issue 12 Mar 04
4 SETTING UP THE RECORDER ............................................................... 34
4.1 ARCHIVE..................................................................................................... 35
4.1.1 Archive to disk..................................................................................... 35
4.1.2 Remote archiving (FTP transfer).............................................................. 36
4.2 SAVE / RESTORE ......................................................................................... 37
4.2.1 Save ................................................................................................... 38
SAVE FOR PRE VERSION 1.8................................................................ 38
4.2.2 Restore................................................................................................ 38
4.2.3 New ................................................................................................... 38
4.2.4 Text .................................................................................................... 38
4.2.5 Import User Linearisation ...................................................................... 39
4.2.6 Export User Linearisation ...................................................................... 39
4.3 CONFIGURATION ........................................................................................ 40
4.3.1 Instrument configuration........................................................................ 43
INSTRUMENT NAME ........................................................................... 43
NORMAL/SAVER DISPLAY .................................................................... 43
SAVE AFTER ........................................................................................ 43
MODBUS ADDRESS ............................................................................. 43
MODBUS SECURITY DISABLED ............................................................. 43
COMMS CHANNEL TIMEOUT.............................................................. 43
PRESET HOUR ..................................................................................... 43
PRESET MINUTE .................................................................................. 43
4.3.2 Group configuration............................................................................. 44
GROUP NUMBER ................................................................................ 44
TREND UNITS...................................................................................... 44
DESCRIPTOR ....................................................................................... 44
A/B SWITCHING ................................................................................ 44
TREND SPEED/TREND INTERVAL........................................................... 45
GRID TYPE .......................................................................................... 45
RECORDING ENABLE .......................................................................... 46
RECORDING SPEED/RECORDING INTERVAL ......................................... 46
TREND HISTORY DURATION ................................................................ 46
ARCHIVE TO MEDIA/ARCHIVE VIA FTP................................................. 46
ALARM MESSAGE ............................................................................... 46
ACK MESSAGE ................................................................................... 47
GROUP CONTENTS ............................................................................ 47
4.3.3 Channel/Alarm configuration................................................................ 48
CHANNEL NUMBER ............................................................................ 49
VALUE ................................................................................................ 49
INPUT TYPE ......................................................................................... 49
LIN TYPE ............................................................................................. 49
INPUT LOW ........................................................................................ 49
INPUT HIGH........................................................................................ 49
SHUNT ............................................................................................... 49
RANGE LOW ...................................................................................... 50
RANGE HIGH ..................................................................................... 50
RANGE UNITS .................................................................................... 50
SCALED .............................................................................................. 50
OFFSET............................................................................................... 50
SCALE TYPE ........................................................................................ 50
FILTER ................................................................................................. 51
BREAK RESPONSE............................................................................... 52
COLD JUNCTION COMPENSATION (CJC) ............................................ 52
DESCRIPTOR ....................................................................................... 52
A/B SWITCHING ................................................................................ 52
SPANNED........................................................................................... 52
ZONE................................................................................................. 53
PV FORMAT ........................................................................................ 53
LIST OF CONTENTS (Cont.)
Section Page
Cont...

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 4
LIST OF CONTENTS (Cont.)
Section Page
4.3.3 Channnel/Alarm Configuration (Cont.)
Cont...
MAXIMUM DECIMAL DIGITS ................................................................ 53
COLOUR ............................................................................................ 53
ALARM NUMBER................................................................................. 54
ENABLE .............................................................................................. 54
TYPE................................................................................................... 54
PARAMETERS ...................................................................................... 55
EXAMPLE ............................................................................................ 55
JOB NUMBER...................................................................................... 57
CATEGORY ......................................................................................... 57
WHILE/ON......................................................................................... 57
ALARM MESSAGES ............................................................................. 57
4.3.4 Views Configuration............................................................................. 58
HOME TIMEOUT ................................................................................. 58
HOME GROUP.................................................................................... 58
DARK TREND/DARK HISTORY BACKGROUND ...................................... 58
SCOPE ............................................................................................... 59
GROUP............................................................................................... 59
DISPLAY ENABLED ............................................................................... 59
HOME PAGE....................................................................................... 59
DISPLAY MODE ENABLING .................................................................. 59
4.3.5 Archive configuration ........................................................................... 60
COMPRESSION .................................................................................. 61
FLASH SIZE ......................................................................................... 61
SHORTEST TREND HISTORY / DURATION ............................................. 61
CSV CHECKBOXES, DATE/TIME FORMAT ............................................. 61
SHOW ............................................................................................... 61
ARCHIVE TO MEDIA ............................................................................ 61
MEDIA FILE FORMAT/FTP FILE FORMAT................................................. 61
MEDIA FULL OPERATION ..................................................................... 62
MEDIA SIZE ........................................................................................ 62
DISK ARCHIVE CAPACITY .................................................................... 62
MEDIA FULL EVENT LIMIT ..................................................................... 62
ARCHIVE TO REMOTE ......................................................................... 62
REMOTE PATH..................................................................................... 62
PRIMARY REMOTE HOST ..................................................................... 63
PRIMARY LOGIN NAME/PASSWORD................................................... 63
SECONDARY REMOTE HOST/LOGIN/PASSWORD ............................... 63
CSV OPTION ...................................................................................... 63
4.3.6 Event configuration .............................................................................. 65
EVENT NUMBER.................................................................................. 65
SOURCE TYPES ................................................................................... 65
SOURCE 1 SENSE ............................................................................... 66
OPERATOR.......................................................................................... 66
SOURCE 2 SENSE ............................................................................... 66
DESCRIPTOR ....................................................................................... 67
JOB NUMBER...................................................................................... 67
CATEGORY ......................................................................................... 67
WHILE/ON......................................................................................... 67
EVENT EXAMPLE ................................................................................. 67
4.3.7 Messages............................................................................................ 68
MESSAGE ENTRY ................................................................................ 68
CONFIGURABLE PARAMETERS ............................................................. 68
EXAMPLE ............................................................................................ 70
4.3.8 User Linearisation Tables....................................................................... 71
CONFIGURATION PARAMETERS .......................................................... 71
4.3.9 Options............................................................................................... 73

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 5
HA027271
Issue 12 Mar 04
4.4 SECURITY.................................................................................................... 74
4.4.1 Access levels ....................................................................................... 74
SETTING PERMISSIONS ....................................................................... 75
ACCESS WHEN: ................................................................................. 75
NEW PASSWORD/RETYPE PASSWORD................................................ 75
CONNECT FROM REMOTE.................................................................. 75
REMOTE USER NAME/PASSWORD ...................................................... 76
LOGIN DISABLED ................................................................................ 76
EDIT OWN PASSWORD ...................................................................... 76
CHANGE ALARM SETPOINTS .............................................................. 76
ACKNOWLEDGE ALARMS ................................................................... 76
EDIT MATHS CONSTANT ..................................................................... 76
PRESET TOTALISERS ............................................................................. 76
PRESET COUNTERS ............................................................................. 76
START/RESET TIMERS........................................................................... 76
SET CLOCK......................................................................................... 76
ADJUST INPUTS................................................................................... 77
ARCHIVING CONTROL........................................................................ 77
SAVE/RESTORE ................................................................................... 77
PASTE/DELETE FILES ............................................................................ 77
FULL CONFIGURATION ....................................................................... 77
FULL SECURITY .................................................................................... 77
EVENT PERMISSION 1 ......................................................................... 77
EVENT PERMISSION 2 TO 5 ................................................................ 77
FORCE CHANGE OF PASSWORD ........................................................ 77
4.4.2 Management (option) ........................................................................... 78
4.4.3 Add user ............................................................................................. 79
NEW USER ID ..................................................................................... 79
NEW FULL USER NAME ....................................................................... 79
NEW PASSWORD/RETYPE PASSWORD................................................ 79
BASED ON ......................................................................................... 79
4.4.4 Remove user ........................................................................................ 79
4.5 NETWORK CONFIGURATION...................................................................... 80
4.5.1 Address .............................................................................................. 80
INSTRUMENT NUMBER/MAC ADDRESS ............................................... 80
IP ADDRESS LOOKUP .......................................................................... 80
BOOTP TIMEOUT ................................................................................ 80
IP ADDRESS ........................................................................................ 80
SUBNET MASK.................................................................................... 81
DEFAULT GATEWAY ............................................................................. 81
SNTP ENABLE ..................................................................................... 81
SNTP SERVER ...................................................................................... 81
4.5.2 Name ................................................................................................. 82
LOCAL HOST ...................................................................................... 82
DOMAIN ............................................................................................ 82
DOMAIN NAME SERVICE (DNS) .......................................................... 82
PRIMARY/SECONDARY DNS SERVER ................................................... 82
4.6 SYSTEM ...................................................................................................... 83
4.6.1 Clock.................................................................................................. 84
4.6.2 Locale................................................................................................. 84
4.6.3 Keycode .............................................................................................. 84
4.6.4 Input adjust ......................................................................................... 84
ADJUST PROCEDURE ........................................................................... 86
4.6.5 About ................................................................................................. 87
INSTRUMENT VARIANT........................................................................ 87
CONFIG REVISION ............................................................................. 87
SECURITY REVISION ............................................................................ 87
SUPPORT FILE ...................................................................................... 88
CLEAN \USER FOLDER ........................................................................ 88
LIST OF CONTENTS (Cont.)
Section Page
Cont...

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 6
4.6.6 Copy .................................................................................................. 89
CONFIGURABLE PARAMETERS ............................................................. 89
COPY RULES ....................................................................................... 90
4.7 JOBS .......................................................................................................... 91
4.7.1 No Action ........................................................................................... 91
4.7.2 Drive relay .......................................................................................... 91
4.7.3 Totaliser category................................................................................. 91
4.7.4 Message category ............................................................................... 92
4.7.5 Maths Category................................................................................... 92
4.7.6 Clock category .................................................................................... 93
4.7.7 Counter category ................................................................................. 93
4.7.8 Timer jobs ........................................................................................... 94
4.7.9 Recording jobs .................................................................................... 94
4.7.10 Trend jobs ......................................................................................... 95
4.7.11 Alarm jobs ........................................................................................ 95
4.7.12 Archive jobs ...................................................................................... 96
4.7.13 Email category .................................................................................. 96
5. FILE .................................................................................................. 97
5.1 FILER OPTION MENU KEYS .......................................................................... 97
5.2 THE HIDE KEY ............................................................................................. 97
5.3 FILE STRUCTURE .......................................................................................... 99
5.3.1 Software versions prior to 3.1 ............................................................... 99
5.3.2 Software versions 3.1 onwards ............................................................. 99
Annex A: SPECIFICATION...................................................................... 101
TECHNICAL SPECIFICATION (Recorder) ................................................................ 102
TECHNICAL SPECIFICATION (Universal inputs) ...................................................... 104
TECHNICAL SPECIFICATION (Ethernet/Relay output board option) .......................... 106
Annex B: REFERENCE ............................................................................ 107
B1 DIAGNOSTICS DISPLAY ................................................................................ 107
B1.1 DISPLAY DETAILS................................................................................... 107
MAC ETHERNET ADDRESS ................................................................... 107
COLOUR TEST BARS ............................................................................ 107
SOFTWARE VERSION NUMBER............................................................ 107
SELF-TEST STATUS BARS ....................................................................... 107
CIRCUIT BOARDS FITTED ..................................................................... 108
TOUCH CAL........................................................................................ 108
DETAIL ................................................................................................ 108
B2 SCREEN CALIBRATION (OFFSET CORRECTION).............................................. 109
B3 PREVENTIVE MAINTENANCE ........................................................................ 109
B3.1 Touch Screen Cleaning .......................................................................... 109
B3.2 Maintenance schedule ........................................................................... 110
B3.3 Battery replacement procedure ............................................................... 110
B4 OPTION ENABLING...................................................................................... 111
B4.1 Instrument Number ................................................................................ 111
B4.2 Key Code............................................................................................. 111
B4.3 KeyCode File ........................................................................................ 111
B5 COLOUR SELECTION .................................................................................... 112
B6 TCP Port Numbers ......................................................................................... 114
B7 TIME ZONES ................................................................................................ 115
B8 MENU STRUCTURE ....................................................................................... 117
Index .................................................................................................... 123
LIST OF CONTENTS (Cont.)
Section Page

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 7
HA027271
Issue 12 Mar 04
!Refer to the manual for instructions
Protective earth
This recorder for ac supply only
This recorder for dc supply only
This recorder for either ac or dc supply
Risk of electric shock
SAFETY NOTES
WARNING
Any interruption of the protective conductor inside or outside the apparatus, or disconnection of the
protective earth terminal is likely to make the apparatus dangerous under some fault conditions. Inten-
tional interruption is prohibited.
Note: in order to comply with the requirements of safety standard BS EN 1010, the recorder shall have one
of the following as a disconnecting device, fitted within easy reach of the operator, and labelled as the discon-
necting device.
a A switch or circuit breaker which complies with the requirements of IEC947-1 and IEC947-3
b. A separable coupler which can be disconnected without the use of a tool
c. A separable plug, without a locking device, to mate with a socket outlet in the building.
1. Before any other connection is made, the protective earth terminal shall be connected to a protective conductor.
The mains (supply voltage) wiring must be terminated within the connector in such a way that, should it slip in
the cable clamp, the Earth wire would be the last wire to become disconnected.
2. In the case of portable equipment, the protective earth terminal must remain connected (even if the recorder is
isolated from the mains supply), if any of the I/O circuits are connected to hazardous voltages*.
3. The mains supply fuse within the power supply is not replaceable. If it is suspected that the fuse is faulty, the
manufacturer's local service centre should be contacted for advice.
4. Whenever it is likely that protection has been impaired, the unit shall be made inoperative, and secured against
accidental operation. The manufacturer's nearest service centre should be contacted for advice.
5. Any adjustment, maintenance and repair of the opened apparatus under voltage, should be avoided as far as possi-
ble and, if inevitable, shall be carried out only by a skilled person who is aware of the hazard involved.
. Where conductive pollution (e.g. condensation, carbon dust) is likely, adequate air conditioning/filtering/sealing
etc. must be installed in the recorder enclosure.
7. Signal and supply voltage wiring should be kept separate from one another. Where this is impractical, shielded
cables should be used for the signal wiring.
8. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment
might be impaired.
* A full definition of 'Hazardous' voltages appears under 'Hazardous live' in BS EN 1010. Briefly, under normal op-
erating conditions, hazardous voltages are defined as being > 30V RMS (42.2V peak) or > 0V dc.
SYMBOLS USED ON THE RECORDER LABELLING
One or more of the symbols below may appear as a part of the recorder labelling.

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 8
USER MANUAL
1 INTRODUCTION
This document describes the installation, operation and configuration of a 100mm graphics recorder. The recorder
has the facility for FTP transfer and Remote viewer connection if the Ethernet option is fitted.
The recorder instrument time can be updated from a unicast (i.e. point-to-point) Simple Network Time Protocol
(SNTP) server and is also itself an SNTP server. SNTP time is based on elapsed seconds since 00:00 hrs on 1st Jan
1900 GMT and is affected neither by time zones nor by daylight saving. The relevant TCP port number is 123. See
sections 4.3.1 (Instrument configuration), 4.5.1 (Network Address configuration) and B in Annex B, for more details.
1.1 UNPACKING THE RECORDER
The recorder is despatched in a special pack, designed to give adequate protection during transit. Should the outer
box show signs of damage, it should be opened immediately, and the recorder examined. If there is evidence of dam-
age, the instrument should not be operated and the local representative contacted for instructions. After the recorder
has been removed from its packing, the packing should be examined to ensure that all accessories and documentation
have been removed. The packing should then be stored against future transport requirements.
2 INSTALLATION
2.1 MECHANICAL INSTALLATION
Figure 2.1 gives installation details.
Note: It is recommended that the rear face of the panel be centre-punched at suitable positions to locate the
tips of the case clamps. Otherwise, particularly on smooth surfaces, the clamps can 'wander' as they are
tightened, leading to inefficient clamping and possible damage to the recorder mounting slots.
The unit is inserted through the panel aperture from the front of the panel. With the weight of the recorder supported,
a panel clamp is inserted into each of the mounting slots (one each on the left- and right-hand sides). The jacking
screws are then tightened sufficiently to clamp the recorder into position. EXCESS FORCE SHOULD NOT BE
USED IN TIGHTENING THESE SCREWS.

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 9
HA027271
Issue 12 Mar 04
2 INSTALLATION (Cont.)
Figure 2.1 Mechanical installation details - small frame unit
247.5mm (9.75in) (STC)
213mm (8.39in)
137mm (5.4in)
Mounting slot
(Left hand side)
View on right hand
side
284mm (11.18in) (LTC closed)
70 mm
(2.76 in)
399 mm (15.7in) (LTC open)
a˚ b˚
Vertical
Panel clamping
138 x 138mm
(-0.0 + 1.0)
5.44 x 5.44 in
(-0.00 + 0.04)
y
x
Panel cutout
x = 15mm (0.6 inch)
y = 10 mm (0.4 in)
Minimum recommended inter-unit spacing
Side clamps Top/bottom clamps
x = 10 mm (0.4 in)
y = 15mm (0.6 inch)
View on under side 137mm
(5.4in)
110 mm (4.33 in)
Max. 30mm
(1.2 in)
Panel thickness
(25.4mm (1 in) max)
Lift then pull to open
flap for mass storage
access
144mm (5.67in)
144mm (5.67in)
LTC = long terminal cover
STC = Short Terminal cover
MAXIMUM INSTALLED ANGLE
a = b = 15 degrees max

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 10
com
nc
no
V+ V- I
+- +-
Shunt
assembly
V+ V- I
+-
V+ V- I
Attenuator
assembly
±100 V dc
±10 V dc
Thermocouples
dc millivolts DC milliamps
1 2 3 4 5 6 7 8 910111213141516171819202122
V+ V- I V+ V- I V+ V- I
Cold
junction
V+ V- I V+ V- I V+ V- I
V+ V- I V+ V- I
2-wire resistance
thermometer
3-wire resistance
thermometer Potentiometer
V+ V- I
Contact closure
(Not channel 1)
RTD RTD
V+ V- I
Potentiometer
Minimum contact = 60msec
Input board pinouts
Channel 6Channel 4 Channel 5Channel 1 Channel 2 Channel 3
2.2 ELECTRICAL INSTALLATION
2.2.1 Signal wiring
Figure 2.2.1a shows connector locations for the input
channel and for the optional relay output/Ethernet board
CONNECTOR WIRING DETAILS
Maximum wire size (inputs) = 4.13mm2 (11 AWG)
Maximum wire size (relay) = 1.5 mm2 (1 AWG)
Max. wire size (non-isolated TRS) = 1.5 mm2 (1 AWG)
Minimum wire size = 0.081mm2 (28 AWG)
Design torque = 0.8Nm.
Figures 2.2.1b, c and d show details of input board wiring,
relay output option wiring and Non isolated Transmitter
Power supply option pinout, respectively. Wiring details
for other options is to be found in the relevant Option
description later in the manual.
Figure 2.2.1a Connector locations
Figure 2.2.1b Input board wiring details
1 8
Input channel connector
122
Supply
voltage
connector
1
Ethernet
connector
(option)
Relay
connector
(option)
1
Non-isolated
TRS (option)
nc
Contacts shown in
power off/alarm
state
1
com
no
23
1
(NC) 2 (Com) 3 (NO)
Figure 2.2.1c Relay wiring details Figure 2.2.1d Non-isolated TRS wiring details
1
(+V) 2 (0V)

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 11
HA027271
Issue 12 Mar 04
2.2.2 Supply voltage wiring
WARNING
DC supply voltages must never be applied to recorders fitted with isolated transmitter power supplies.
Note: The minimum recommended wire size is 1 /0.2 (0.5mm2).
LINE SUPPLY
The supply voltage to the recorder is terminated using an IEC socket which is connected to the mating plug at the rear
of the recorder. The recorder is suitable for use with all ac voltages between 85 and 2 5 V RMS (47 to 3 Hz), and
requires 0 VA max. power. For recorders without transmitter power supplies, supply voltages of between 110V dc
and 370V dc may also be used.
Figure 2.3a Disk access Figure 2.3b Disk eject
LOW VOLTAGE SUPPLY OPTION
Not suitable for recorders fitted with the isolated transmitter power supply
option.
The low voltage supply option is terminated at a three-pin connector (plug
mounted on recorder - socket on supply cable) as shown in figure 2.2.2.
The option allows the use of ac or dc supplies with the following charac-
teristics:
AC: 20 to 42V RMS (45 to 400 Hz)
DC: 20 to 54V (See warning above)
Power: 0VA max.
2.3 DISK INSERTION AND REMOVAL
The disk slot is located below the recorder screen, and is protected by a flap as shown in figure 2.1, above.
In order to access the disk slot, the bottom of the central part of the flap is lifted (figure 2.3a) and then used as a han-
dle to pull the main flap open.
If a disk is already fitted, it is removed by pressing on the eject button (figure 2.3b).
Note: Before disk removal, archiving should be suspended (section 4.1) (wait for the green LED on the disk
drive to be extinguished), otherwise data might be lost.
+V or ac Earth 0V or ac
Figure 2.2.2 Low voltage supply pinout

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 12
3 PROCESS VARIABLE DISPLAY
The operator interface consists of a touch-sensitive screen, showing either process variable values in one of a number
of formats, or, showing configuration or operational details for use in setting up the recorder. This section (3) de-
scribes the process variable displays. Section 4 describes the Configuration displays.
Figure 3, below, depicts a typical trend display and gives details of the various areas of the display page.
Note: Dialogue boxes, message boxes etc. cause Process Variable displays to 'freeze' for as long as the box is
on display. Root and Option menus (amongst others) time-out (i.e. are removed from the display) after
approximately one minute. Messages, however, are displayed until the operator takes action to remove them.
It should be noted, especially, that several message boxes may be active at one time, but only the oldest one is
visible, until it is removed to reveal the 'next oldest' message, and so on.
Figure 3 Trend display definitions
Frederick Bl...
Group Name
99%
Channel 1
˚C
35.00000.0000
11:44:49
29/01/04
Root menu key with Current
access level or user full name Page Name
Instrument alarm
Channel alarm
Battery warning Configuration Locked indicator
Current time/date
Current channel's
descriptor and
trace colour
Current channel's
scale
Channel(s)
configured 'Off'
Disk icon
Channel 2 alarm 1
on / off messages
An animated bar appears over the
date, when the recorder is busy.
Though normally pale blue, the bar
is gold-coloured when the record-
er configuration is being updated
via the Remote Viewer.
FTP activity
Time/Date stamp
Current trace
alarm icons
Non-current trace
icon Current trace icon
(diamond shape)
Alarm threshold
marker (Abs Hi)
11:31:29
29/01/04
29/01/04 11:33:37 Alarm(s) off 2 (1)
29/01/04 11:31:39 Alarm(s) on 2 (1)
11:52:59
29/01/04
Channel value

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 13
HA027271
Issue 12 Mar 04
3 PROCESS VARIABLE DISPLAY (Cont.)
TRUNCATION OF NUMERIC VALUES
If the amount of space on the display page is insufficient to display the full width of the process variable or scale
value, then the displayed value is rounded down and the number of decimal places reduced. If the available space is
still too restricted, the value is displayed in 'Scientific' format, or if this is still too wide, the final visible character of
the integer part of the display is replaced by a '?'.
CURRENT CHANNEL ALARM ICONS
In each of the different types of PV display, each channel's faceplate give the status of the channel's alarms. This
status is shown by one of the icons depicted in table 3, either off, flashing (if it is active and unacknowledged) or on
continuously (if it is active and acknowledged). See section 3.1.3, below, for a description of how to acknowledge
alarms, and section 4.3.3 for a description of the alarm types. Absolute alarm threshold icons and deviation-alarm
bars appear in any display which includes a scale. For deviation alarms, the bar stretches from (Reference - Devia-
tion) to (Reference + Deviation).
Notes
1. For software versions 2.3 onwards, 32MB versions of the recorder come with four alarms per point, in-
stead of two per point as supplied with previous software versions. The System/About display can be
used establish what size of DRAM s fitted - see section 4. .5.
2. 'Trigger' alarms do not display threshold marks or bars, or faceplate symbols.
Absolute High
Absolute Low
Deviation in
Deviation out
Rate-of-change Rising
Rate-of-change Falling
4-alarm units 2-alarm units
Table 3 Alarm symbols
3.1 STATUS BAR
This appears across the top of the display, and contains the items described below.
3.1.1 Current access level
There are four access levels available (Logged out, Operator, Engineer and Service), and the current level is displayed
in this key at the top left hand corner of the display. Touching this key calls the root menu as described in section
3.2.1 (Key functions) below. If a user has been added in the 'Add User' part of the Security setup (section 4.4.3), then
the 'Full User Name' is displayed (truncated if necessary) instead of the access level.
3.1.2 Page name
Initially this shows the current group's descriptor. The name changes according to context for example 'Operator' or
'Config-Archive'.
Scale symbols
Faceplate symbols
Absolute
low Absolute high Deviation In / Out
Horizontal
scales
Vertical
scales
Rate of
change
No
indication
No
indication
R
d d
dd
R
For Deviation alarms, R = Reference; d = deviation

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 14
Instrument Alarm Summary
Display Contrast
Alarm & Message options
Ack all Alarms
Alarm Summary
Message Log
Instrument Alarm Summary
Ok
Maths channel Failure
network boot failure
Ack all Alarms
Confirm acknowledge of alarms?
NoYes
1 (1) Water temp 1a 60.0000 68.5277 C
2 (1) Water temp 1b 30.0000 23.4531 C
2 (2) Water temp 1b 10.0000 15.7773 C
3 (1) 0il pressure 250.0000 260.3425PSI
4 (1) Transfer 15.3678
Channel no.(alarm no.)
Channel descriptor Alarm type symbol
Alarm Summary
Setpoint value
(Absolute alarms only) Current process value
Group 1 Group 2
Goto Group
The 'Goto Group' win-
dow does not appear
for single group
recorders.
Ack Alarm
Confirm acknowledge of alarm?
NoYes
Touch Alarm area
(e.g. channel alarm symbol)
Touch alarm to
call 'Acknowledge'
dialogue box.
See section 3.2.1 for
Message Log details
3.1.3 Alarm indicators
This area of the display can contain up to four icons: Instrument alarm, Channel alarm, Battery change, Disk status.
Pressing this area of the screen calls a pop-up display (figure 3.1.3a) allowing the user to view messages to acknowl-
edge all channel alarms, or to display the Alarm Summary page. Also incorporated in this display is a slider control
allowing the user to optimise the display contrast for the local environment. For channel alarm symbols, refer to 'Cur-
rent Trace Alarm Icons', above.
ALARM SUMMARY PAGE
As shown in figure 3.1.3a, below, the alarm summary page contains the following information:
1. Alarm identifier. This appears as a point ID, followed by the relevant alarm number in parentheses. For exam-
ple, Alarm 1 on maths channel would appear as: D (1). Maths channels are prefixed by 'D'. Totalisers are
prefixed by 'T' and Counters are prefixed by 'C'. Input channels are not prefixed.
2 Alarm threshold for absolute alarms only
3 The current process value for the point
4 An alarm symbol (see Table 3). Alarm symbols flash until acknowledged.
Notes:
1. Alarms are always listed in Point/Alarm order with input channels first, followed by derived chan-
nels, totalisers and counters, if these options are fitted.
2 When the alarm source returns to its non-alarm state: Unlatched alarms are removed from the list
whether or not they have been acknowledged; latched alarms remain displayed until acknowledged.
See section 4.3.3 for a description of alarm types and actions.
3. There are no time or history components associated with the Alarm Summary. If Alarm messages have
been enabled in the relevant group's configuration (section 4.3.2), then alarm initiation/acknowledgement
times and dates can be found from the trend and trend history displays, described in section 3.4, or in
Message log, described in section 3.2.1.
4. If an alarm is active on a channel which is not included in either group, then although the channel alarm
symbol will flash, the alarm will not appear in the alarm summary pages.
Figure 3.1.3a Alarm and message options display and contrast control

100 MM GRAPHICS RECORDER: USER GUIDE
User Guide
Page 15
HA027271
Issue 12 Mar 04
3.1.3 ALARM INDICATORS (Cont.)
ALARM ACKNOWLEDGEMENT
Alarms can be acknowledged globally (all alarms), individually or on a group basis.
ALL ALARMS
To acknowledge all active alarms, touch (e.g.) the channel alarm icon at the top of the screen. From the resulting pop-
up menu, select 'Ack all Alarms', then finally, touch 'Yes' in the resulting pop-up confirmation box. Figure 3.1.3a,
above, attempts to show this process.
INDIVIDUAL ALARMS
Individual alarms are acknowledged from the alarm summary page by touching the relevant item (highlights yellow),
then touching 'Yes' in the resulting pop-up confirmation box. Figure 3.1.3a, above, attempts to show this process.
GROUP ALARMS
For recorders with multiple groups, alarms can be acknowledged on a group basis by calling the alarm summary page
for the relevant group, then pressing the Root menu Options key (section 3.2), the 'Ack Group Alarms' key and finally,
'Yes' in the resulting pop-up confirmation box. Figure 3.1.3b, below, attempts to show this process.
Figure 3.1.3b Group Alarm acknowledgement
1 (1) Water temp 1a 60.0000 68.5277 C
2 (1) Water temp 1b 30.0000 23.4531 C
2 (2) Water temp 1b 10.0000 15.7773 C
3 (1) 0il pressure 250.0000 260.3425PSI
4 (1) Transfer 15.3678
Alarm Summary
Engineer
Options
Goto Group
Operator
Login
Goto View
Home
File
Root menu
Note
Ack Group Alarms
Option menu
Ack Group Alarms
Confirm acknowledge of alarm?
NoYes

100 MM GRAPHICS RECORDER: USER GUIDE
HA027271
Issue 12 Mar 04
User Guide
Page 16
3.1.3 ALARM INDICATORS (Cont.)
INSTRUMENT ALARMS
This indicator appears, flashing, if any of the following alarms are active. The Instrument alarm summary page, de-
scribed above, allows the user to view any such alarms.
Archive failed -(message) Message explains archive failure - due to disk being missing, write protected,
faulty, full etc.
Battery-backed RAM cleared This message appears if the battery has failed, and the unit has been switched off.
Channel failure Indicates a hardware failure in the input channel circuit
Channel error Indicates a hardware failure in the channel circuit or in the internal CJ temperature
measurement
Clock failure Internal clock was corrupt at power up, or the time has never been set. Can be
caused by battery failure, in which case the battery icon will also be visible. The
error is cleared by setting the time and date. Server time forced to 00:00 1/1/1900.
Floppy disk worn Appears if a number of attempts had to be made before write to the disk was suc-
cessful. No data is lost, but the disk should be replaced as soon as is practicable.
Floppy disk corrupt This appears if all attempts to write to the disk fail. In such a case, some data may
be lost. If the damaged area of the disk is in the system part of the disk, it might
appear to the recorder that it is unformatted, and the disk icon will disappear. The
disk should be replaced immediately.
FTP Primary Server Failure This error is set if the recorder fails, after two attempts, to establish communica-
tions with the primary server as defined in Archive Configuration (section 4.3.5).
After the second attempt has failed, the Secondary server is tried.
FTP Secondary Server Failure This error is set if the recorder fails, after two attempts, to establish communica-
tions with the secondary server as defined in Archive Configuration (section 4.3.5).
See also 'FTP Primary Server Failure, above.
Insufficient non-volatile memory... There is insufficient memory available for the configuration. Sometimes caused by
the use of the Rolling Average maths function.
Internal flash: \user\ required repair Error found (in the internal file system) at power-up, and corrected.
Internal flash: \system\ required repair Error found (in the internal file system) at power-up, and corrected.
Internal flash: \history\ required repair Error found (in the internal file system) at power-up, and corrected.
Maths Channel failure Appears, for example, if the divisor of a divide function passes through zero.
Network boot failure The recorder is unable to establish connection with the bootP server. This might be
caused by, for example, cable failure, network hardware failure, etc.
Recording failure - (message) Message explains recording failure e.g. file error, internal overflow etc.
Removable media failure This error is set if the disk is corrupt, wrongly formatted etc. Becomes active only
when an Archive is attempted.
Removable media full Floppy disk or PC card full. Becomes active only when an Archive is in progress.
SNTP server failure This alarm is set if:-
a) the year received from the server is < 2001 or > 2035 or
b) the configured SNTP server cannot be accessed
Time synchronisation failure Set if 5 or more 'Time change events' are caused by the SNTP server within 24 hrs.
A 'Time change event' is defined as occuring whenever the recorder time is found
to be more than 2 seconds different from the server time. The alarm does not ap-
pear until 24 hours after the first of the five-or-more Time Change events occurred.
