Roland BR-1600CD Operating and maintenance manual

SERVICE NOTES
Issued by RJA
Copyright © 2004 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of ROLAND CORPORATION.
Printed in Japan (0800) (NB)17058222E0
Jan.2004 BR-1600CD
TABLE OF CONTENTS
SPECIFICATIONS.............................................................2
LOCATION OF CONTROLS ..........................................3
LOCATION OF CONTROLS PARTS LIST ...................5
EXPLODED VIEW 1 .........................................................6
EXPLODED VIEW 2 .........................................................7
EXPLODED VIEW 3 .........................................................8
EXPLODED VIEW 4 .........................................................9
EXPLODED VIEW PARTS LIST ...................................10
PARTS LIST......................................................................11
CHECKING THE VERSION NUMBER.......................17
USERS DATA SAVE AND LOAD................................17
TEST MODE.....................................................................21
RESTORING THE FACTORY SETTINGS...................24
SYSTEM SOFTWARE UPDATE PROCEDURE .........26
BLOCK DIAGRAM.........................................................28
CIRCUIT BOARD (MAIN BOARD) .............................30
CIRCUIT DIAGRAM (MAIN BOARD ANALOG) ....32
CIRCUIT DIAGRAM
(MAIN BOARD DIGITAL IO).......................................34
CIRCUIT DIAGRAM (MAIN BOARD DIGITAL) .....36
CIRCUIT DIAGRAM (MAIN BOARD DSP)...............38
CIRCUIT DIAGRAM (MAIN BOARD POWER)........40
CIRCUIT BOARD (SWITCH SHEET) ..........................42
CIRCUIT DIAGRAM (GAIN BOARD) ........................44
CIRCUIT DIAGRAM (GUITAR BOARD) ...................45
CIRCUIT DIAGRAM (5V POWER BOARD) ..............45
CIRCUIT DIAGRAM (PHONES BOARD) ..................46
CIRCUIT DIAGRAM (SW BOARD).............................48
CIRCUIT DIAGRAM (XLR JACK BOARD)................50
ERROR MESSAGES ........................................................51

2
Jan.2004
SPECIFICATIONS
BR-1600CD: Digital Recording Studio
Tracks
Track: 16 V-Track: 256 (16 V-Tracks per each Track)
*Up to 8 tracks can be recorded simultaneously, and up to 16 tracks can be played
back simultaneously.
Maximum Useful Capacity/Recording Time
Internal Hard Disk:
40 G bytes (recording time; 120 hours) (conversion in one track)
* The above-listed recording time is approximate. Times may be slightly shorter
depending on the number of songs and size of imported loop phrase that were
created.
*The above-listed recording time is the total for all the tracks that are used. If each
of the sixteen tracks contain an equal amount of data, the length of the resulting
song will be approximately 1/16 of the above.
Signal Processing
AD Conversion: 24 bit, AF Method (Guitar/Bass)
24 bit, ∆∑ Modulation (VOCAL)
24 bit, ∆∑ Modulation (MULTI-TRACK)
24 bit, ∆∑ Modulation (STEREO TRACKS)
DA Conversion: 24 bit, ∆∑ Modulation
Internal Processing:24 bit (digital mixer section)
Recording Data: 16 bit linear
Sample Rate
44.1 kHz
Frequency Response
20 Hz–20 kHz (+1/-3 dB)
Total Distortion
0.025 % or less
(INPUT SENS : CENTER, 1 kHz at nominal output level)
Nominal Input Level (Variable)
GUITAR/BASS jack:-10 dBu
MIC 1–8 jacks (XLR):-40 dBu
INPUT 1–8 jacks: -10 dBu
Input Impedance
GUITAR/BASS jack:1 M Ω
MIC 1–8 jacks (XLR):12.5 k Ω (HOT-COLD)
6.5 k Ω (HOT-GND, COLD-GND)
INPUT 1–8 jacks: 22 k Ω
Nominal Output Level
LINE OUT jack: -10 dBu
Output Impedance
LINE OUT jack: 2 k Ω
PHONES 1, 2 jack:100 Ω
Recommended Load Impedance
LINE OUT jack: 20 k Ω or greater
PHONES 1, 2 jack:8–50 Ω
Residual Noise Level
LINE OUT jack: -90 dBu or less
(INPUT SELECT: GUITAR/BASS, input terminated with 1 k Ω , INPUT SENS:
CENTER, IHF-A, typ.)
Interface
DIGITAL IN: S/PDIF 16–24 bit (coaxial type)
DIGITAL OUT: S/PDIF 16–24 bit (coaxial type)
USB connector (B type)
Display
130 x 36 mm (Backlit LCD)
Connectors
MIDI IN connector
MIDI OUT connector
USB connector
DIGITAL IN connector (coaxial type)
DIGITAL OUT connector (coaxial type)
FOOT SW jack (1/4 inch phone type)
EXP PEDAL jack (Stereo 1/4 inch phone type)
LINE OUT jacks (RCA Phono type)
INPUT 1–8 jacks (unbalanced, 1/4 inch phone type)
MIC 1–8 jacks (balance, XLR type)
PHONES 1 jack (Stereo 1/4 inch phone type)
PHONES 2 jack (Stereo 1/4 inch phone type)
GUITAR/BASS jack (1/4 inch phone type)
Power Supply
DC 12 V; Supply AC Adaptor (Roland PSB-3U)
Power Consumption
3 A
Dimensions
494 (W) x 339 (D) x 99 (H) mm
19-1/2 (W) x 13-3/8 (D) x 3-15/16 (H) inches
Weight
4.9 kg / 10 lbs 13 oz (Excluding AC Adaptor)
Accessories
AC Adaptor: PSB-3U (#02900423)
AC Cord 120V (#00894378)
230V (#00894389)
240V (#23495124)
240VE (#00907001)
Owner’s Manual (“Basic Operation,” “Owner’s Manual”,”Data List”)
English (#72451356)
Japanese (#72450667)
CD-ROM “DISCRETE DRUMS” (#03563878)
Options
Expression Pedal: EV-5 (Roland)
Foot Switch: FS-5U
Pedal Switch: DP-2 (Roland)
*0dBu = 0.775 Vrms
In the interest of product improvement, the specifications and/or appearance
of this unit are subject to change without prior notice.

3
BR-1600CD
LOCATION OF CONTROLS
fig.panel1

4
Jan.2004
fig.panel2

5
BR-1600CD
LOCATION OF CONTROLS PARTS LIST
[PARTS]
[SCREW]
No. PART CODE CATEGORY NAME PART NAME DESCRIPTION Q'TY
1 03343501 CASING TOP CASE 1
2 01891801 KNOB,BUTTON U R-KNOB S1 LCG BLK 8
03459212 POTENTIOMETER 9M/M ROTARY POTENTIOMETER EVUF2KFK315D 100KRD 8
3 02679456 DIODE LED (RED) SLR-342VR3F 8
4 00900145 KNOB,BUTTON D S-KEYTOP SD1H BLK 8
01904112 DIODE LED SLR-342VCT32 N.P.Q RANK 8
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 8
5 00900189 KNOB,BUTTON D S-KEYTOP SX1H BLK 10
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 10
6 00904256 KNOB,BUTTON D S-KEYTOP SX4H BLK 1
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 4
7 00900156 KNOB,BUTTON D S-KEYTOP SD2H BLK 1
01904112 DIODE LED SLR-342VCT32 N.P.Q RANK 2
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 2
8 00904245 KNOB,BUTTON D S-KEYTOP SX3H BLK 2
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 6
9 01783945 KNOB,BUTTON N S-KEYTOP MD3H 1
01904112 DIODE LED SLR-342VCT32 N.P.Q RANK 1
15029348 DIODE LED (GREEN) SLR-342MCT32 1
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 3
10 00900190 KNOB,BUTTON D S-KEYTOP SX2H BLK 3
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 6
11 01670512 KNOB,BUTTON F C-KEYTOP SX1H BLK 3
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 3
12 03343434 DISPLAY UNIT LCD F-51405GNY-LY-AB 1
03343534 CASING DISPLAY COVER 1
15029347 DIODE LED (RED) SLR-342VC3F 1
15039237 DIODE LED (GREEN) SLR-342MCT32 1
13 01234090 KNOB,BUTTON D T-KEYTOP MX4B BLK 1
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 4
14 03343545 MISCELLANEOUS PANEL SHEET 1
15 02013090 KNOB,BUTTON F C-KEYTOP MX1H CLR 12
01904178 DIODE LED (CLR) SPR-505MVWT31 12
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 12
16 01902289 KNOB,BUTTON U S-KNOB M BLK LCG 13
01677312 POTENTIOMETER 45M/M SLIDE POTENTIOMERTER EWAP1AC10 B54 (50KB/MS) 13
17 22485303 KNOB,BUTTON D R-KNOB (ALPHA-DIAL) L BLK 248-303 1
01905467 ENCODER ROTARY ENCODER EVE GC1 F20 24B 1
18 02457512 KNOB,BUTTON J R-KNOB SFA BLK/LCG 5
02896712 POTENTIOMETER 9M/M ROTARY POTENTIOMETER EVUF2KFK4B54 50KB 5
19 01783923 KNOB,BUTTON N S-KEYTOP MD1H 1
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 1
20 01340412 KNOB,BUTTON P R-KNOB SF-A BLK/LCG 2
02900467 POTENTIOMETER 9M/M ROTARY POTENTIOMETER EVJC25FB6A54 50KAX2 2
21 00569278 JACK,EXT TERMINAL 6.5MM JACK LGR4609-7100 2
22 02782990 DISK DRIVE UNIT ATAPI CD-RW DRIVE UJDA340 1
23 13449258 JACK,EXT TERMINAL 6.5MM JACK HLJ4306-01-3080 1
24 00569278 JACK,EXT TERMINAL 6.5MM JACK LGR4609-7100 8
25 03459223 JACK,EXT TERMINAL XLR CONNECTOR JY-5033A 8
26 03453290 JACK,EXT TERMINAL RCA (PIN) YKC21-3488N 1
27 00569278 JACK,EXT TERMINAL 6.5MM JACK LGR4609-7100 2
28 03239512 JACK,EXT TERMINAL RCA (PIN) YKC21-4539N 1
29 02781189 JACK,EXT TERMINAL USB CONNECTOR YKF45-0021 1
30 13429825 JACK,EXT TERMINAL MIDI CONNECTOR YKF51-5054 2PZ 1
31 32490595 KNOB,BUTTON P S-KEY MX BLK 1
32 22360712 MISCELLANEOUS CORD HOOK 236-712 1
33 02900312 JACK,EXT TERMINAL DC JACK HEC0470-01-640 1
34 02013090 KNOB,BUTTON F C-KEYTOP MX1H CLR 7
01904112 DIODE LED SLR-342VCT32 N.P.Q RANK 7
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 7
35 00900156 KNOB,BUTTON D S-KEYTOP SD2H BLK 1
01904112 DIODE LED SLR-342VCT32 N.P.Q RANK 1
03122112 DIODE LED SLR-343BBT3F 1
01340290 SWITCH TACT SWITCH EVQ11A H=5.0 2
No. PART CODE PART NAME DESCRIPTION Q’TY
a 40233012 SCREW M2.6X8 BINDING TAPTITE P BZC 16
b 40012534 SCREW 3X6 BINDING TAPTITE S FE BZC 3
c 40011312 SCREW 3X8 BINDING TAPTITE P BZC 4
d 40011378 SCREW M4X8 BINDING TAPTITE S FE BZC 1
e 40127689 SCREW M3X10 BINDING TAPTIGHT S TYPE FE BZC 1

6
Jan.2004
EXPLODED VIEW 1
ffig.explo-2
39
41
38
42
40
36
37
*
* Exerise care to avoid becoming defromed.
* whe you exchange this panel sheet.
40122490
DOUBLE FACED TAPE
#500 W5MM 20M

7
BR-1600CD
EXPLODED VIEW 2
ffig.explo-2
k
19
d
45
44
e
h
b
34
29
23
22
20
21
m
m
35
47
d
n
n
32
32 33
33
31
30
d
28
27
26
24
25
d
46
d
c
b
43

8
Jan.2004
EXPLODED VIEW 3
fig.explo-1
17
d
a
2
18
12
12
12
12
14
14
14
14
14
9
10
10
13
13
11
11 11
15
8
88
4
a
3
e
g
f
16
1

9
BR-1600CD
EXPLODED VIEW 4
fig.explo-1
7
7
56
7
7

10
Jan.2004
EXPLODED VIEW PARTS LIST
[PARTS]
[SCREW]
No. PART CODE CATEGORY NAME PART NAME DESCRIPTION Q'TY
1 03343501 CASING TOP CASE 1
2 03343512 CHASSIS CHASSIS 1
3 03345956 CHASSIS LCD HOLDER 1
4 03343434 DISPLAY UNIT LCD F-51405GNY-LY-AB 1
5 01783945 KNOB,BUTTON N S-KEYTOP MD3H 1
6 01783923 KNOB,BUTTON N S-KEYTOP MD1H 1
7 02013090 KNOB,BUTTON F C-KEYTOP MX1H CLR 19
8 01670512 KNOB,BUTTON F C-KEYTOP SX1H BLK 3
9 00904256 KNOB,BUTTON D S-KEYTOP SX4H BLK 1
10 00904245 KNOB,BUTTON D S-KEYTOP SX3H BLK 2
11 00900190 KNOB,BUTTON D S-KEYTOP SX2H BLK 3
12 00900189 KNOB,BUTTON D S-KEYTOP SX1H BLK 10
13 00900156 KNOB,BUTTON D S-KEYTOP SD2H BLK 2
14 00900145 KNOB,BUTTON D S-KEYTOP SD1H BLK 8
15 01234090 KNOB,BUTTON D T-KEYTOP MX4B BLK 1
16 22360712 MISCELLANEOUS CORD HOOK 236-712 1
17 72450745 PWB ASSY GAIN BOARD ASSY 1
18 72450712 PWB ASSY SW BOARD ASSY 1
19 02782990 MISCELLANEOUS ATAPI CD-RW DRIVE UJDA340 1
20 02899401 CHASSIS DD HOLDER CDRW L 1
21 02899412 CHASSIS DD HOLDER CDRW R 1
22 02899434 CHASSIS DD HOLDER CDRW STOP 1
23 72017823 PWB ASSY PCB ASSY CDI-BR-1 1
24 72450690 PWB ASSY MAINBOARD ASSY 1
25 72563889 PWB ASSY 5V POWER BOARD ASSY 1
26 72458067 PWB ASSY XLR JACK BOARD ASSY 1
27 72450734 PWB ASSY PHONES BOARD ASSY 1
28 72450723 PWB ASSY GUITAR BOARD ASSY 1
29 03343523 CASING BOTTOM COVER 1
30 03345945 CHASSIS HDD HOLDER 1
31 03459634 DISK DRIVE UNIT HDD 2F040L0 1
32 03459645 MISCELLANEOUS HDD COLLAR COLLAR 4
33 03459656 MISCELLANEOUS HDD INSULATOR INSULATOR 4
34 22355334 MISCELLANEOUS FOOT MKS 235-334 4
35 01016223 MISCELLANEOUS FOOT 30X10X3 1
36 03343545 MISCELLANEOUS PANEL SHEET 1
37 03343534 CASING DISPLAY COVER 1
38 02457512 KNOB,BUTTON J R-KNOB SFA BLK/LCG 5
39 01902289 KNOB,BUTTON U S-KNOB M BLK LCG 13
40 01891801 KNOB,BUTTON U R-KNOB S1 LCG BLK 8
41 01340412 KNOB,BUTTON P R-KNOB SF-A BLK/LCG 2
42 22485303 KNOB,BUTTON D R-KNOB (ALPHA-DIAL) L BLK 248-303 1
43 32490595 KNOB,BUTTON P S-KEY MX BLK 1
44 40238434 MISCELLANEOUS CAUTION LABEL CANADA EMI 1
45 40124567 MISCELLANEOUS CAUTION SEAL FCC 20X40 1
46 03459378 MISCELLANEOUS FLAT CLAMP FCR-15 V0 2
47 02780345 MISCELLANEOUS FOOT 05468 4
No. PART CODE PART NAME DESCRIPTION Q’TY
a 40011278 SCREW 3X8 BINDING TAPTITE P FE ZC 29
b 40011312 SCREW 3X8 BINDING TAPTITE P BZC 10
c 40233012 SCREW M2.6X8 BINDING TAPTITE P BZC 16
d 40012512 SCREW 3X6 BINDING TAPTITE S ZC 26
e 40012534 SCREW 3X6 BINDING TAPTITE S FE BZC 12
f 40127689 SCREW M3X10 BINDING TAPTIGHT S TYPE FE BZC 1
g 40011378 SCREW M4X8 BINDING TAPTITE S FE BZC 1
h 40011490 SCREW M3X6 PAN MACHINE W/SW BZC 3
k 40233978 SCREW M2X8 PAN MACHINE W/SW+PW ZC 2
m 40455867 SCREW M2X2.5 PAN MACHNE W/SW 4
n 40563112 SCREW 6-32X1/2 UNIFY 4

11
BR-1600CD
PARTS LIST
fig.part1e
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CONSIDERATION ON PARTS ORDRING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
NOTE: The parts marked # are new. (initial parts) ******** mean the not available.
CASING Q'TY
#03343501 TOP CASE 1
# 03343523 BOTTOM COVER 1
# 03343534 DISPLAY COVER 1
CHASSIS
#03343512 CHASSIS 1
# 03345956 LCD HOLDER 1
# 03345945 HDD HOLDER 1
02899401 DD HOLDER CDRW L 1
02899412 DD HOLDER CDRW R 1
02899434 DD HOLDER CDRW STOP 1
KNOB, BUTTON
00900145 D S-KEYTOP SD1H BLK 8
02013090 F C-KEYTOP MX1H CLR 19
01783945 N S-KEYTOP MD3H 1
01783923 N S-KEYTOP MD1H 1
01670512 F C-KEYTOP SX1H BLK 3
01234090 D T-KEYTOP MX4B BLK 1
00904256 D S-KEYTOP SX4H BLK 1
00904245 D S-KEYTOP SX3H BLK 2
00900190 D S-KEYTOP SX2H BLK 3
00900189 D S-KEYTOP SX1H BLK 10
00900156 D S-KEYTOP SD2H BLK 2
32490595 P S-KEY MX BLK 1
02457512 J R-KNOB SFA BLK/LCG 5
01891801 U R-KNOB S1 LCG BLK 8
01340412 P R-KNOB SF-A BLK/LCG 2
22485303 D R-KNOB (ALPHA-DIAL) L BLK 248-303 1
01902289 U S-KNOB M BLK LCG 13
SWITCH
01899989 PUSH SWITCH SPUP19-2N-LB2 SW1 on MAIN 1
01340290 TACT SWITCH EVQ11A H=5.0 W32,SW33,SW34,SW35,SW36,SW1,SW2,
SW3,SW4,SW5,SW6,SW7,SW8,SW9,SW10,
SW11,SW12,SW13,SW14,SW15,SW16,SW17,
SW18,SW19,SW20,SW21,SW27,SW28,SW29,
SW30,SW31,SW37,SW38,SW39,SW40,SW41,
68
SW42,SW43,SW44,SW45,SW46,SW47,SW48,
SW49,SW50,SW51,SW57,SW58,SW59,SW60,
SW61,SW62,SW63,SW67,SW68,SW69,SW70,
SW71,SW22,SW23,SW24,SW25,SW26,SW52,
SW53,SW54,SW55,SW56, on SW
JACK, EXT TERMINAL
13429825 MIDI CONNECTOR YKF51-5054 2PZ JK1 on MAIN 1
03239512 RCA (PIN) YKC21-4539N JK4 on MAIN 1
# 03453290 RCA (PIN) YKC21-3488N JK9 on MAIN 1
02781189 USB CONNECTOR YKF45-0021 JK6 on MAIN 1
00569278 6.5MM JACK LGR4609-7100 JK2,JK3,JK18,JK19,JK20,JK21,JK22,JK23,JK24,
JK25, on MAIN, JK9,JK10, on PHONES
10+2
02900312 DC JACK HEC0470-01-640 JK17 on MAIN 1
13449258 6.5MM JACK HLJ4306-01-3080 JK11 on GUITAR 1
# 03459223 XLR JACK JY-5033A JK17,JK18,JK19,JK12,JK13,JK14,JK15,JK16, on
XLR
8
DISPLAY UNIT
# 03343434 F-51405GNY-LY-AB LCD 1
NOTE: Replacement F-51405GNY-LY-AB should be made on a unit base.

12
Jan.2004
DISK DRIVE UNIT
#03459634 2F040L0 HDD 1
NOTE: Replacement 2F040L0 should be made on a unit base.
PCB ASSY
#72450690 MAIN BOARD ASSY 1
NOTE: ‘MAIN BOARD ASSY’ includes the following parts.
# 03564401 WIRING GND CABLE A (LONG) on MAIN 1
# 03564412 WIRING GND CABLE B (SHORT) on MAIN 1
# 03563945 SHIELD COVER JACK on MAIN 1
72450701 SW SHEET ASSY 1
NOTE: ‘SW SHEET ASSY’ includes the following parts.
# ******** SW BOARD ASSY 1
NOTE: ‘SW BOARD ASSY’ includes the following parts.
40013334 SPACER PLASTIC PIPE 3.2X5X10 CLARYTY on SW 7
03239467 LED SPACER LH-3-9 on SW 1
# ******** GUITAR BOARD ASSY 1
NOTE: ‘GUITAR BOARD ASSY’ includes the following parts.
00789789 RIBON CABLE 4X400-P2.0 on GUITAR 1
# 03343889 JACK HOLDER GUITAR BOARD on GUITAR 1
# ******** PHONES BOARD ASSY 1
NOTE: ‘PHONES BOARD ASSY’ includes the following parts.
# 03343890 JACK HOLDER PHONES BOARD on PHONES 1
# ******** GAIN BOARD ASSY 1
NOTE: ‘GAIN BOARD ASSY’ includes the following parts.
40013334 SPACER PLASTIC PIPE 3.2X5X10 CLARYTY on SW 8
# ******** XLR JACK BOARD ASSY 1
# ******** 5V POWER BOARD ASSY 1
NOTE: ‘5V POWER BOARD ASSY’ includes the following parts.
# 03560845 WIRING WIRING 5V POWER CN101 on 5V 1
72017823 PCB ASSY CDI-BR-1 1
IC
# 03343645 UPD703106AGJ-076-UEN MASK IC (CPU) IC6 on MAIN 1
02900978 M66291GP IC (USB CONTROLLER) IC53 on MAIN 1
02231767 RA0A-101 (TC223C080AF-101) IC (DSP) IC32,IC33,IC34 on MAIN 3
02896745 S1L50753F27B000 IC (I/F) IC17 on MAIN 1
03017856 M11L16161SA-45T IC (DRAM) IC38 on MAIN 1
03341590 TC58FVM5B2ATG65BAH IC (FLASH MEMORY) IC3 on MAIN 1
# 03459123 M12L128168AP1L IC (SDRAM) IC8 on MAIN 1
02451434 AK4552VT IC (AD/DA) IC59,IC64,IC67,IC72 on MAIN 4
02892334 TC74LCX245FT (EL) IC (CMOS) IC9,IC5 on MAIN 2
03129934 TC7SET04FU (TE85L) IC (CMOS) IC41,IC52 on MAIN 2
02458090 TC4066BFT (EL) IC (CMOS) IC60 on MAIN 1
01672634 TC74HC4052AFT (EL) IC (CMOS) IC10,IC7 on MAIN 2
01569689 TC7W32FU (TE12L) IC (CMOS) IC2 on MAIN 1
01348912 TC7SH08FU (TE85L) IC (CMOS) IC11 on MAIN 1
01679023 TC74VHC157FT (EL) IC (CMOS) IC30,IC31,IC35,IC36 on MAIN 4
01897967 TC74VHC74FT (EL) IC (CMOS) IC48 on MAIN 1
01899156 TC74VHC32FT (EL) IC (CMOS) IC14 on MAIN 1
01899167 TC74VHC04FT (EL) IC (CMOS) IC1,IC27 on MAIN 2
01907689 TC7WH157FU (TE12L) IC (CMOS) IC39 on MAIN 1
02017045 TC74VHCT541AFT (EL) IC (CMOS) IC23 on MAIN 1
02124934 TC74VHC541FTEL IC (CMOS) IC18,IC13 on MAIN 2
02565723 TC74VHC161FT (EL) IC (CMOS) IC29,IC25 on MAIN 2
03016156 TC74VHC00FT (EL) IC (CMOS) IC28,IC47 on MAIN 2
03016167 TC74VHCT08AFT (EL) IC (CMOS) IC21 on MAIN 1
03120834 TC74VHCT00AFT (EL) IC (CMOS) IC19 on MAIN 1
# 03343367 TC74VHC163FT (EL) IC (CMOS) IC46,IC49 on MAIN 2
01908701 TC74VHC14FT (EL) IC (CMOS) IC16 on MAIN 1
01908689 TC74VHC21FT (EL) IC (CMOS) IC26,IC45 on MAIN 2
# 03453367 TC74LCX00FT (EL) IC (CMOS) IC42 on MAIN 1
# 03343334 TC75S51FU (TE85L) IC (OP LINEAR) IC12 on MAIN 1
15189261 M5218AFP-600E IC (BIPOLAR OP AMP) IC75,IC57,IC61,IC63,IC65,IC74, on MAIN 6
00346445 NJM2100M (TE3) IC (BIPOLAR OP AMP) IC58,IC62,IC66,IC70 on MAIN 4
00564690 TC9246F (ELP) IC (PLL) IC43 on MAIN 1
# 01014634 REGULATOR TA7809F (TE16L) IC (REGULATOR) IC80 on MAIN 1
01458445 UPC29M33T-T1 IC (REGULATOR) IC78,IC55 on MAIN 2
02235378 TA78M05F (TE16L) IC (REGULATOR) IC40 on MAIN 1
02904001 NJU7222U33 (TE1) IC (REGULATOR) IC50 on MAIN 1
02563467 NJM2374AM-TE1 IC (SWITCHING REGULATOR) IC81,IC71 on MAIN 2
# 03125089 PQ1CY1032ZP IC (SWITCHING REGULATOR) IC79 on MAIN 1

13
BR-1600CD
02563534 ICS512MT IC (PLL) IC44 on MAIN 1
03120356 AK4114VQ IC (DIGITALAUDIO TRANSCEIVER)
IC51 on MAIN 1
02903745 S-80930CNMC-G80 IC (RESET) IC83,IC15 on MAIN 2
15289124 PC-4007 IC (PHOTO COUPLER) IC4 on MAIN 1
15189147N0 UPC4072C IC (OP AMP) IC8 on GUITAR 1
02346123 NJM4556AD IC (OP AMP) IC6,IC7 on PHONES 2
# 03560856 PQ1CG3032FZ IC (REGULATOR) IC77 on 5V 1
IC
TRANSISTOR
15309105 2SA1587-GR (TE85L) TRANSISTOR Q24 on MAIN 1
01121289 2SC4081 T106 QRS TRANSISTOR Q26 on MAIN 1
03344078 2SC4738-GR (TE85R) TRANSISTOR Q2,Q3,Q6,Q7,Q12,Q13,Q17,Q18,Q19,Q20,
Q21,Q22,Q23,Q25,Q27,Q28,Q39 on MAIN
17
# 03010567 2SC3303-Y (TE16L) TRANSISTOR Q40 on MAIN 1
15319107 2SC4116-GR (TE85R) TRANSISTOR Q41,Q42,Q43,Q44,Q45,Q46,Q47,Q48,Q49,
Q50,Q51,Q52,Q53,Q54,Q55,Q56 on MAIN
16
03344589 2SK879-Y (TE85L) TRANSISTOR Q59,Q60,Q61,Q62 on MAIN 4
02900301 TPC8303 (TE12L) TRANSISTOR Q31 on MAIN 1
# 02909490 2SJ527STR TRANSISTOR Q36 on MAIN 1
00239801 DTA114EU T-106 TRANSISTOR Q10,Q15,Q30,Q34,Q57 on MAIN 5
02340645 RN1441-A (TE85L) TRANSISTOR Q5,Q8,Q37,Q38 on MAIN 4
00239812 DTC114EUT106 TRANSISTOR Q33,Q35,Q58,Q1,Q9,Q11,Q14,Q16,Q32, on
MAIN
9
02900234 M54585KP-200D TRANSISTOR IC22 on MAIN 1
01905089 TD62787AF (EL) TRANSISTOR IC82 on MAIN 1
15129152 2SC2878-A (TPE2) TRANSISTOR Q30,Q31,Q32,Q33 on PHONES 4
15129204 DTC343TS TP TRANSISTOR Q2,Q3,Q4,Q5 on PHONES 4
15129164 DTC114ESTP TRANSISTOR Q33 on 5V 1
DIODE
#03453356 1SS362 (TE85L) DIODE DA24,DA26,DA17,DA18,DA20,DA21,DA23,
DA9,DA11,DA12,DA14,DA15,DA1,DA2,
DA3,DA5,DA6,DA8, on MAIN
18
03343090 1SS387 (TPH3) SWITCHING DIODE D1,D6,D21,D22,D23,D24 on MAIN 6
01780045 RB051L-40 SCHOTTKY DIODE D14,D15,D16 on MAIN 4
15019126 1SS133 T-77 SWITCHING DIODE D45,D46,D47,D48,D49,D50,D1,D2,D3,D4,D5,
D6,D7,D8,D9,D10,D11,D12,D13,D14,D15,
D16,D17,D18,D19,D20,D21,D22,D23,D24,
D25,D26,D27,D28,D29,D30,D31,D32,
64+1
D39,D40,D41,D42,D43,D44,D51,D52,D53,
D54,D55,D56,D57,D58,D59,D60,D61,D62,
D66,D67,D33,D34,D35,D36,D37,D38, on SW,
D68 on GUITAR
01904112 SLR-342VCT32 N.P.Q RANK LED LED1,LED2,LED3,LED4,LED5,LED6,LED22,
LED23,LED24,LED25,LED26,LED27,LED28,
LED29,LED30,LED31,LED39,LED40,LED50,
LED51 on SW
20
03122112 SLR-343BBT3F LED LED38 on SW 1
15029348 SLR-342MCT32 LED (GREEN) LED36,LED35 on SW 2
02679456 SLR-342VR3F LED (RED) LED19,LED20,LED21,LED32,LED48,LED49,
on SW, LED33,LED34,LED37,LED43,LED44,
LED45,LED46,LED47, on GAIN
6+8
01904178 SPR-505MVWT31 LED (CLR) LED11,LED12,LED13,LED14,LED15,LED16,
LED17,LED18,LED7,LED8,LED9,LED10, on
SW
12
02454856 RB081L-20 TE25 SCHOTTKY DIODE D13 on 5V 1
02781301 RB160L-60 TE25 SCHOTTKY DIODE D20 on MAIN 1
RESISTOR
#00671789 RK73K2ETD 682 G MTL.FILM RESISTOR R646,R613,R614,R629,R630,R645,R566,R581,
R582,R598,R599,R534,R535,R549,R550,R565,
on MAIN
16
01454890 MCR50 JZH J 220 MTL.FILM RESISTOR R3 on MAIN 1
01566923 RR0816P-183-D MTL.FILM RESISTOR R174 on MAIN 1
01897878 RPC05T 512 J MTL.FILM RESISTOR on MAIN 1
02124645 RR0816R-473-D MTL.FILM RESISTOR R387 on MAIN 1
00566934 RPC05T 330 J MTL.FILM RESISTOR on MAIN 6
00566912 RPC05T 220 J MTL.FILM RESISTOR on MAIN 5
# 03453245 RR0816P-513-D MTL.FILM RESISTOR R435 on MAIN 1
15399945 MCR100 101J RESISTOR R124 on MAIN 1
03126234 RR0816P-822-D MTL.FILM RESISTOR R434 on MAIN 1
01011856 RPC05T 0R0 J MTL.FILM RESISTOR on MAIN 126
00567556 RPC05T 105 J MTL.FILM RESISTOR on MAIN 5
00567412 RPC05T 104 J MTL.FILM RESISTOR on MAIN 42
00567390 RPC05T 683 J MTL.FILM RESISTOR on MAIN 16
00567378 RPC05T 473 J MTL.FILM RESISTOR on MAIN 49
00567289 RPC05T 103 J MTL.FILM RESISTOR on MAIN 61
03343067 RR0816P-302-D MTL.FILM RESISTOR R427 on MAIN 1
# 03453267 RR0816P-182-D MTL.FILM RESISTOR R429 on MAIN 1

14
Jan.2004
00567267 RPC05T 682 J MTL.FILM RESISTOR on MAIN 16
00567245 RPC05T 472 J MTL.FILM RESISTOR on MAIN 1
00566967 RPC05T 470 J MTL.FILM RESISTOR on MAIN 80
00566867 RPC05T 100 J MTL.FILM RESISTOR on MAIN 6
15399989 MCR50JZH680 1/2W CHIP RESISTOR R373 on MAIN 1
00567134 RPC05T 681 J MTL.FILM RESISTOR on MAIN 7
# 03453289 MCR25 JZH JL R51 MTL.FILM RESISTOR R432,R533 on MAIN 2
# 03564278 RR0816P-334-D MTL.FILM RESISTOR R380 on MAIN 1
# 03564312 RR0816P-393-D MTL.FILM RESISTOR R375 on MAIN 1
00567256 RPC05T 562 J MTL.FILM RESISTOR on MAIN 1
00567178 RPC05T 152 J MTL.FILM RESISTOR on MAIN 3
00567167 RPC05T 122 J MTL.FILM RESISTOR on MAIN 1
00567156 RPC05T 102 J MTL.FILM RESISTOR on MAIN 12
00567045 RPC05T 151 J MTL.FILM RESISTOR on MAIN 1
02239612 RR0816P-472-D MTL.FILM RESISTOR R519,R521,R523,R524,R525,R526 on MAIN 6
00566923 RPC05T 270 J MTL.FILM RESISTOR on MAIN 2
02122623 RR0816R-104-D MTL.FILM RESISTOR R388,R398 on MAIN 2
00567001 RPC05T 750 J MTL.FILM RESISTOR on MAIN 2
00567012 RPC05T 820 J MTL.FILM RESISTOR on MAIN 2
00567034 RPC05T 121 J MTL.FILM RESISTOR on MAIN 1
00567023 RPC05T 101 J MTL.FILM RESISTOR on MAIN 16
00567212 RPC05T 332 J MTL.FILM RESISTOR on MAIN 1
01905001 RR0816P-103-D MTL.FILM RESISTOR R215,R219,R233,R236,R291,R297,R307,R312,
R334,R343,R352,R355,R382, on MAIN
13
00567323 RPC05T 223 J MTL.FILM RESISTOR on MAIN 8
00567401 RPC05T 823 J MTL.FILM RESISTOR on MAIN 8
00567456 RPC05T 224 J MTL.FILM RESISTOR on MAIN 1
00567501 RPC05T 474 J MTL.FILM RESISTOR on MAIN 1
00909590 EXBV8V330JV RESISTOR ARRAY RA4,RA5,RA13,RA16 on MAIN 4
01011845 EXBV8V0R000V RESISTOR ARRAY RA43,RA45,RA47 on MAIN 3
01013578 EXBV8V470JV RESISTOR ARRAY RA48,RA25,RA26,RA37,RA38,RA39,RA8,
RA9,RA11,RA12,RA14,RA18,RA19,RA20,
RA21,RA24, on MAIN
16
01457145 EXBE10C103J RESISTOR ARRAY RA23,RA35,RA36,RA1,RA2,RA3,RA10,RA22,
on MAIN
8
15409113 EXBV8V103JV RESISTOR ARRAY RA30,RA31,RA41 on MAIN 3
00126112 EXBV8V101JV RESISTOR ARRAY RA34,RA6,RA7,RA15,RA17,RA33, on MAIN 6
00344289 EXBV8V333JV RESISTOR ARRAY RA29,RA32 on MAIN 2
01897723 RD16ST26A 105 J CARBON RESISTOR R134 on GUITAR 1
01897645 RD16ST26A 103 J CARBON RESISTOR R133,R135,R136, on GUITAR, R422 on 5V 3+1
01788378 RD16ST26A 153 J CARBON RESISTOR R108,R117,R124,R137 on PHONES 4
01897578 RD16ST26A 331 J CARBON RESISTOR R106,R113,R122,R129 on PHONES 4
01897712 RD16ST26A 104 J CARBON RESISTOR R104,R105,R111,R112,R120,R121,R127,R128
on PHONES
8
01788312 RD16ST26A 222 J CARBON RESISTOR R100,R107 on PHONES 2
01788301 RD16ST26A 102 J CARBON RESISTOR R425,R426,R427,R428, on GAIN, R5,R86,R89,
R92,R93,R98,R101,R102, on PHONES
4+8
01897745 RD16ST26A 472 J CARBON RESISTOR R116,R123 on PHONES 2
13749761T0 SR25TRE 330 J CARBON RESISTOR R431,R432,R125,R126,R138,R429,R430,R103,
R109,R110,R118,R119, on PHONES
12
# 03560878 MRS25CTR 3001 F MTL.FILM RESISTOR R421 on 5V 1
13799754T0 MR16 TR KF 1K METAL FOIL RESISTOR R423 on 5V 1
03454890 EEE1HA100SP CHEMICAL CAPACITOR C726 on MAIN 1
RESISTOR
POTENTIOMETER
02896712 EVUF2KFK4B54 50KB
9M/M ROTARY POTENTIOMETER VR1,VR2,VR3,VR4,VR5 on SW 5
01677312 EWAP1AC10 B54 (50KB/MS) 45M/M SLIDE POTENTIOMERTER VR16,VR17,VR18,VR6,VR7,VR8,VR9,VR10,
VR11,VR12,VR13,VR14,VR15, on SW
13
02900467 EVJC25FB6A54 50KAX2 9M/M ROTARY POTENTIOMETER VR28,VR29 on PHONES 2
# 03459212 EVUF2KFK315D 100KRD 9M/M ROTARY POTENTIOMETER VR25,VR26,VR27,VR20,VR21,VR22,VR23,
VR24, on GAIN
8
CAPACITOR
01674212 ECUV1H220JCV CERAMIC CAPACITOR on MAIN 3
00568456 ECJ1VF1C474Z CERAMIC CAPACITOR on MAIN 1
01674190 ECUV1H150JCV CERAMIC CAPACITOR on MAIN 4
01674701 ECJ1VF1E104Z 0.1UF/16VK CERAMIC CAPACITOR on MAIN 191
01674390 ECUV1H271JCV CERAMIC CAPACITOR on MAIN 1
01674556 ECJ1VB1H472K CERAMIC CAPACITOR on MAIN 8
01674712 ECJ1VF1A105Z CERAMIC CAPACITOR C143,C144,C145,C146,C147,C167,C169 on
MAIN
7
01674423 ECUV1H471JCV CERAMIC CAPACITOR on MAIN 30
01674356 ECUV1H151JCV CERAMIC CAPACITOR on MAIN 1
02568812 ECJ2FB1C474K CERAMIC CAPACITOR C243 on MAIN 1
01674312 ECUV1H820JCV CERAMIC CAPACITOR on MAIN 6
01674278 ECUV1H470JCV CERAMIC CAPACITOR on MAIN 17
01674167 ECUV1H100DCV CERAMIC CAPACITOR on MAIN 9
01674389 ECUV1H221JCV CERAMIC CAPACITOR on MAIN 26
01674334 ECUV1H101JCV CERAMIC CAPACITOR C189,C191,C245,C282,C394,C398,C449,C492,
C498,C528,C529,C7,C9,C20,C69,C75,C187, on
MAIN
23

15
BR-1600CD
#03564389 ECJ1VB1E563K CERAMIC CAPACITOR on MAIN 4
01674612 ECJ1VB1H103K CERAMIC CAPACITOR on MAIN 41
01674467 ECUV1H102JCV CERAMIC CAPACITOR on MAIN 1
01120301 ECEV1CA221P 220UF CHEMICAL CAPASITOR C364,C532,C533,C541 on MAIN 4
02897045 ECEV1CA220WR CHEMICAL CAPACITOR C310,C314,C369,C374,C416,C421 on MAIN 6
02897056 ECEV1CA471UP CHEMICAL CAPACITOR C538,C486,C508,C524,C534,C537, on MAIN 6
15369262 ECEV1HA010SR CHEMICAL CAPACITOR C471,C507,C296,C320,C334,C353,C381,C390,
C412,C427,C440,C462, on MAIN
12
# 03454967 EEE1JA220P CERAMIC CAPACITOR C466 on MAIN 1
# 03560934 EEE1VS3R3SR CERAMIC CAPACITOR C597 on MAIN 1
02897034 ECEV1HA101UP CHEMICAL CAPACITOR C451,C450 on MAIN 2
# 03454834 EEE1EA100SR CERAMIC CAPACITOR on MAIN 1
15369152 ECEV1CA100SR CHEMICAL CAPACITOR C468,C472,C589,C606,C611,C631,C634,C636,
C641,C644,C615,C616,C621,C624,C626,C417,
C425,C430,C431,C433,C389,C402,C405,C413,
C415,C646,C651,C654,C656,C661,C452,C455,
C457,C458,C460,
72
C367,C368,C370,C379,C386,C335,C336,C342,
C360,C363,C312,C317,C324,C327,C329,C300,
C303,C307,C309,C311,C257,C259,C260,C266,
C267,C36,C43,C155,C162,C235,C664,C666,
C671,C673,C674,C679,C691 on MAIN
# 03454945 EEE1HA470UP CERAMIC CAPACITOR C613,C622,C623,C632,C633,C560,C561,C602,
C603,C612,C663,C642,C643,C652,C653,C662,
on MAIN
16
02014356 ECEV1CA101WP CHEMICAL CAPACITOR on MAIN 17
01904856 ECEV1CA470WR CHEMICAL CAPACITOR C685,C686,C687,C680,C681,C682,C683,C684,
C240,C255,C287,C527,C544, on MAIN
13
13529132 RPE132-901F104Z50 CERAMIC CAPACITOR C1 on SW, C107,C105,C104, on GUITAR,
C127,C129,C131,C72,C101,C102, on
PHONES, C523 on 5V
1+3
+6
+1
13639550M0 ECEA1CKA101B 100UF/16V CHEMICAL CAPACITOR C2,C3 on SW 2
03018545 RPE2C1H101J2M1A01A CERAMIC CAPACITOR C106 on GUITAR 1
01900823 RA2-16V100M-T2 CHEMICAL CAPACITOR C108,C134, on GUITAR, C77,C84,C90,C97,
C100,C130, on PHONES
2+6
# 03344323 RPE2C1H470J2M1Z01A CERAMIC CAPACITOR C75,C82,C88,C95 on PHONES 4
# 03232178 RPE2C1H151J2M1A01A CERAMIC CAPACITOR C78,C85,C91,C98 on PHONES 4
01900834 RA2-16V101M-T2 CHEMICAL CAPACITOR C96,C128,C73,C76,C83,C89, on PHONES 6
00679089 16MV2200HC CAPACITOR C522 on 5V 1
02239623 RA2-16V102M-T2 CHEMICAL CAPACITOR C521 on 5V 1
CAPACITOR
INDUCTOR, COIL, FILTER
01676023 SBCP-87331H CHOKE COIL L64,L62 on MAIN 2
02451367 ZCYS51R5-M3PAT CHOKE COIL L36 on MAIN 1
02780378 ELL6SH2R7M CHOKE COIL L60,L52 on MAIN 2
# 03561623 RCR1616-331K CHOKE COIL L53 on MAIN 1
# 03457790 TSL1315S-221K1R7-PF CHOKE COIL L61 on MAIN 1
# 03457056 ELC10D331E CHOKE COIL L63 on MAIN 1
00237212 SH-202 CHOKE COIL FL1 on MAIN 1
12449386 SBT-0180W EMI FILTER L85 on MAIN 1
01565578 N1608Z601T01 FERRITE-BEAD L1,L2,L3,L4,L5,L6,L7,L8,L9,L10,L11,L12,L13,
L14,L27,L28,L29,L30,L37,L66,L21,L22,L23,
L24,L25,L26,L84,L15,L16,L17,L18,L19,L20, on
MAIN
33
01340834 EXCML20A390 FERRITE-BEAD L65 on MAIN 1
12449268 BL02RN2-R62T2 FERRITE-BEAD L61,L60 on SW 2
02780389 ELC10D470E CHOKE COIL L58 on 5V 1
# 03560867 RCR1616-101K CHOKE COIL L59 on 5V 1
CRYSTAL, RESONATOR
02781412 CX-49G 6.000MHZ CRYSTAL X2 on MAIN 1
# 03459089 CX-49G 5.00976MHZ CRYSTAL X1 on MAIN 1
ENCODER
01905467 EVE GC1 F20 24B ROTARY ENCODER EN1 on SW 1
CONNECTOR
01908656 18FE-BT-VK-N CONNECTOR CN6,CN16,CN17 ,CN11,CN12 on MAIN, on
XLR
3+2
01908667 22FE-BT-VK-N CONNECTOR CN7 on MAIN 1
01908645 16FE-BT-VK-N CONNECTOR CN13,CN14 on MAIN 2
02120056 24FE-BT-VK-N CONNECTOR CN4,CN12 on MAIN 2
02237512 75501-0X0-B CONNECTOR P/N CN5 on MAIN, on CDI-BR1 1
02349545 P/N 75401-0X0-B CONNECTOR CN1 on MAIN 1
13369570 B2B-PH-K-S (2P) CONNECTOR CN10 on MAIN 1
13369594 B4B-XH-A CONNECTOR CN2 on MAIN 1
13369599 52147-0410 (4P) WIRE TRAP CN11 on MAIN 1
# 03340278 B7B-PH-K-S (PB FREE) CONNECTOR CN18 on MAIN 1
# 03343101 52559-3692 CONNECTOR CN8,CN9 on MAIN 2

16
Jan.2004
02010878 18FE-ST-VK-N FOR WIRING CONNECTOR CN3 on SW 1
02016956 22FE-ST-VK-N CONNECTOR CN2 on SW 1
02122467 24FE-ST-VK-N CONNECTOR CN1 on SW, CN6 on GAIN 1+1
13429293 51048-0400 (4P) CABLE HOLDER CN4 on GUITAR 1
02010867 16FE-ST-VK-N CONNECTOR CN8 on PHONES, CN7 on GAIN 1+1
02782645 24 5600 050 100 883 CONNECTOR on CDI-BR1 1
CONNECTOR
WIRING, CABLE
02904623 WIRING HDD IDE 1
02900412 WIRING HDD POWER 1
# 03562567 WIRING BNCD-P=1.25-K-24-220 1
03348023 BAN CARD BNCD-P=1.25-K-22-90 1
02673523 BAN CARD BNCD-P=1.25-K-16-130 1
02673245 BAN CARD BNCD-P=1.25-K-16-220 1
# 02789367 WIRING BNCD-P=1.25-K-18-80 2
02459734 BAN CARD BNCD-P=1.25-K-18-200 1
02019834 BAN CARD BNCD-P=1.25-K-24-120 1
02902156 WIRING IDE 1
TRANSFORMER
02563501 PT-10 (2280-T008) PULSE TRANS FL2 on MAIN 1
SCREW
40011278 SCREW 3X8 BINDING TAPTITE P FE ZC 29
40011312 SCREW 3X8 BINDING TAPTITE P BZC 10
40233012 SCREW M2.6X8 BINDING TAPTITE P BZC 16
40012512 SCREW 3X6 BINDING TAPTITE S ZC 26
40011378 SCREW M4X8 BINDING TAPTITE S FE BZC 1
40012534 SCREW 3X6 BINDING TAPTITE S FE BZC 12
40127689 SCREW M3X10 BINDING TAPTIGHT S TYPE FE BZC
1
40011490 SCREW M3X6 PAN MACHINE W/SW BZC 3
# 40563112 SCREW 6-32X1/2 UNIFY 4
40233978 SCREW M2X8 PAN MACHINE W/SW+PW ZC 2
40455867 SCREW M2X2.5 PAN MACHNE W/SW 4
PACKING
#72451012 PACKING CASE SET 1
NOTE: ‘PACKING CASE SET’ includes the following parts.
#03343467 PACKING PAD UPPER 1
# 03343478 PACKING PAD LOWER 1
# 03343489 PACKING PAD SIDE PAD L 1
# 03343490 PACKING PAD SIDE PAD R 1
# 03343456 PACKING CASE 1
# 03456101 OUTER PACKING CASE 1
MISCELLANEOUS
#03459378 FLAT CLAMP FCR-15 V0 2
22360712 CORD HOOK 236-712 1
22355334 FOOT MKS 235-334 4
40238434 CAUTION LABEL CANADA EMI 1
40124567 CAUTION SEAL FCC 20X40 1
# 03343545 PANEL SHEET 1
# 03343556 INSULATING SHEET 1
# 03459645 HDD COLLAR COLLAR 4
# 03459656 HDD INSULATOR INSULATOR 4
02782990 ATAPI CD-RW DRIVE UJDA340 1
01016223 FOOT 30X10X3 1
40456956 CD R/W LABEL 1
# 03343856 WARNING LABEL ADAPTOR TAG 1
ACCESSORIES (STANDARD)
02900423 AC ADAPTOR PSB-3U DC 1
00894367 AC CORD SET 100V SP18A+IS14 VCTF2X0.75 1
00894378 AC CORD SET 120V SP301+IS14 SJT18/3 1
00894389 AC CORD SET 230V SP22+IS14 H05VV-F3G1.0 1
23495124 AC CORD SET 240VA SC-144-JO1 ES303-10HMA 1
00907001 AC CORD SET 240VE KP-610 GTTBS-3 KS-31A 1
40232389 WARRANTY CARD FOR BOSS JAPAN ONLY 1
# 03563878 DISCRETE DRUMS CD-ROM MEDIA 1
# 40563145 LEAFLET MANUL (NOTE HDD/CD-R)
JAPANESE/ENGLISH 1
# 72450667 OWNER’S MANUAL JAPANESE 1
# 72451356 OWNER’S MANUAL ENGLISH 1

17
BR-1600CD
CHECKING THE VERSION
NUMBER
1. With the unit in normal operating mode, simultaneously press the [Left]
and [Right] page scroll buttons.
2. The version is indicated in the display.
3. Press [ENTER/YES] (or [EXIT/NO]) to return to the normal screen.
* The version number can be checked in Test mode as well.
For more detailed information, check the Test mode categories.
USERS DATA SAVE AND
LOAD
The BR-1600CD’s built-in CD-R/RW drive can be used to exchange data in the
following ways:
• Storing of songs and other hard-disk data to CD-R/RW discs (Backup)
• Reading songs and other backup data back into the hard disk (Recover)
• Swapping of audio data with a PC
Storing of songs and other hard-
disk data to CD-R/RW discs
(Backup)
Although the songs you’ve recorded and created are stored on the BR-
1600CD’s internal hard disk, all of this data would be lost in the unlikely event
that the hard disk was damaged. For this reason, we recommend that you also
save your songs on CD-R/RW discs (Backup).
Once songs have been backed up in this way, it will also be possible to read
them from the CD-R/RW discs into another BR-1600CD.
Backing up a song (Song Backup)
1. Insert an empty CD-R/RW disc into the BR-1600CD’s CD-R/RW drive.
The drive’s access indicator will begin to flash. Wait until this indicator
stops flashing and turns off before proceeding.
2. Press CD-R/RW [DATA SAVE/LOAD].
The Data CD screen will appear.
fig.41-05d
3. Press [F1] (BACKUP) or move the cursor to BACKUP, and then press
[ENTER/YES].
The Backup screen will appear.
fig.41-01d
4. Press [F1] (SONG) or move the cursor to SONG, and then press [ENTER/
YES].
The Song Backup screen will appear.
fig.41-02d
5. Move the cursor to the song you want to back up and press [F1]
(SELECT).
The song will be selected for backup.
fig.41-02ad
A number of songs can be selected in this way for backup, and an
asterisk (*) will be displayed for each selected song. To cancel this
selection, press [F1] once again.
If you would like to back up all songs on the hard disk in a single
operation, press [F2] (ALL). All songs will be selected for backup.
To cancel this selection, press [F2] once again. This deselects all songs.
6. When you have selected all of the songs you want to back up, press [F4]
(GO).
The message “Write Speed?” will appear.
fig.41-03d
7. Use the TIME/VALUE dial to set the write speed.
Write Speed:
x2 (352 Kbps)Writes twice as fast.
x4 (704 Kbps)Writes four times as fast.
x8 (1408 Kbps)Writes eight times as fast.
Precautions for backup
• If a CD-R disc selected for backup already contains data, the
message “Not Blank Disc!” will appear and backup will not be
possible. Always use an empty disc for this operation. If, on the
other hand, you are using a CD-RW disc that already contains data,
the message “Erase Disc?” will be displayed. If you then press
[ENTER/YES], the BR-1600CD will begin erasing data from this
disc.
• If the current song contains newly recorded audio data or newly
modified settings, the message “Save Current?” may be displayed
during the backup procedure. If you want to save your song before
starting the backup, press [ENTER/YES]; if this will not be
necessary, press [EXIT/NO]. Remember that if you do not save a
modified song at this time, all newly recorded audio data, edited
data, modified mixer settings, etc. will be lost.
• If the total size of the songs and other data you intend to back up
exceeds the capacity of a single CD-R/RW disc, you will be able to
perform a backup using as many discs as necessary. In this case,
you will need to have a number of blank CD-R/RW discs on hand,
and during the backup process, you should insert and remove them
as requested on-screen.
• To cancel writing to a CD-R/RW disc, press [EXIT/NO]. When the
message “Cancel?” appears, press [ENTER/YES] to confirm
cancellation. (A certain amount of time may pass between pressing
of [EXIT/NO] and display of the confirmation message.) Please
note, however, that no guarantee can be made regarding the state of
the data written before cancellation.

18
Jan.2004
•The range of available write speeds can sometimes be limited by the type
of disc being used. In such cases, the BR-1600CD will allow you to select
only the supported speeds using the TIME/VALUE dial.
• If you are using CD-R/RW discs intended for highspeed writing, the
frequency of write errors may increase if the x2 or x4 speed is selected. It
is recommended that you use the x8 speed for high-speed discs.
8. Press [ENTER/YES].
If you want to cancel the backup, press [EXIT/NO].
The message “Write Sure?” will appear.
fig.41-04d
9. Press [ENTER/YES] once again.
The BR-1600CD will begin writing data to the CD-R/RW disc.
When the message “Complete!” appears, it indicates that the backup has
been successfully completed.
Backing up user data (User Backup)
The BR-1600CD allows you to back up the following types of user data to CD-
R/RW discs.
• Insert effect patches
• Mastering Tool Kit patches
• Speaker Modeling patches
• Vocal Tool Box patches
• Rhythm arrangements, drum patterns, bass patterns, and loop phrases
1. Insert an empty CD-R/RW disc into the BR-1600CD’s CD-R/RW drive.
The drive’s access indicator will begin to flash. Wait until this indicator
stops flashing and turns off before proceeding.
2. Press CD-R/RW [DATA SAVE/LOAD].
The Data CD screen will appear.
fig.41-05d
3. Press [F1] (BACKUP) or move the cursor to the BACKUP icon, and then
press [ENTER/YES].
The Backup screen will appear.
fig.41-01d
4. Press [F2] (USER) or move the cursor to USER, and then press [ENTER/
YES].
The User Backup screen will appear.
fig.41-07d
5. Move the cursor to the type of data you want to back up and press [F1]
(SELECT).
The data will selected for backup.
fig.41-07ad
A number of types of data can be selected in this way for backup, and an
asterisk (*) will be displayed for each selected type. To cancel a selection,
simply press [F1] once again.
Data that can be backed up:
Effects/Arrange./Drums&Bass Ptn.:
• Insert Effects User Patches
• Vocal Tool Box User Patches
• Mastering User Kit User Patches
• Speaker Modeling User Patches
• User Rhythm Arrangement
• User drum pattern
• User bass pattern
The data described above will all be saved.
Loop Phrase:
User loop phrases will all be saved.
If you would like to back up all such data on the hard disk in a single
operation, press [F2] (ALL). All data types will be selected for backup.
To cancel this selection, press [F2] once again. This deselects all data
types.
6. When you have selected all of the data you want to back up, press [F4]
(GO).
The message “Write Speed?” will appear.
fig.41-08d
7. Use the TIME/VALUE dial to set the write speed.
Write Speed:
x2 (352 Kbps)Writes twice as fast.
x4 (704 Kbps)Writes four times as fast.
x8 (1408 Kbps)Writes eight times as fast.
•The range of available write speeds can sometimes be limited by the type
of disc being used. In such cases, the BR-1600CD will allow you to select
only the supported speeds using the TIME/VALUE dial.
• If you are using CD-R/RW discs intended for high-speed writing, the
frequency of write errors may increase if the x2 or x4 speed is selected. It
is recommended that you use the x8 speed for high-speed discs.

19
BR-1600CD
8. Press [ENTER/YES].
If you want to cancel the backup, press [EXIT/NO].
The message “Write Sure?” will appear.
fig.41-09d
9. Press [ENTER/YES] once again.
The BR-1600CD will begin writing data to the CD-R/RW disc. When the
message “Complete!” appears, it indicates that the backup has been
successfully completed.
Backing up all data on the hard
disk (HDD Backup)
The BR-1600CD allows you to back up all of the data on the internal hard disk
onto CD-R/RW discs, regardless of the type of data or the song in which it is
used. Data that’s been backed up this way can later be recovered whenever
needed.
Note, however, that this type of backup is limited to the data contained in the
currently selected drive or partition. If you would also like to back up data
from another drive or partition, you will need to change the current drive first.
Note also that recovered data will be stored on the currently selected drive.
1. Insert an empty CD-R/RW disc into the BR-1600CD’s CD-R/RW drive.
The drive’s access indicator will begin to flash. Wait until this indicator
stops flashing and turns off before proceeding.
2. Press CD-R/RW [DATA SAVE/LOAD].
The Data CD screen will appear.
fig.41-05d
3. Press [F1] (BACKUP) or move the cursor to BACKUP, and then press
[ENTER/YES].
The Backup screen will appear.
fig.41-01d
4. Press [F3] (HDD) or move the cursor to HDD, and then press [ENTER/
YES].
The message “HDD Backup OK?” will appear.
fig.41-12d
5. Press [ENTER/YES].
The message “Write Speed?” will appear.
fig.41-13d
6. Use the TIME/VALUE dial to set the write speed.
Write Speed:
x2 (352 Kbps)Writes twice as fast.
x4 (704 Kbps)Writes four times as fast.
x8 (1408 Kbps)Writes eight times as fast.
•The range of available write speeds can sometimes be limited by the type
of disc being used. In such cases, the BR-1600CD will allow you to select
only the supported speeds using the TIME/VALUE dial.
• If you are using CD-R/RW discs intended for high-speed writing, the
frequency of write errors may increase if the x2 or x4 speed is selected. It
is recommended that you use the x8 speed for high-speed discs.
7. Press [ENTER/YES].
If you want to cancel the backup, press [EXIT/NO].
The message “Write Sure?” will appear.
fig.41-14d
8. Press [ENTER/YES] once again.
The BR-1600CD will begin writing data to the CD-R/RW disc. When the
message “Complete!” appears, it indicates that the backup has been
successfully completed.
Reading songs and other backup
data back into the hard disk
(Recover)
Notes concerning recovery
• You will not be able to select any songs or data types that have not been
saved to the CD-R/RW disc.
• If the current song contains newly recorded audio data or newly
modified settings, the message “Save Current?” may be displayed during
the recovery procedure. If you want to save your song before starting the
recover process, press [ENTER/YES]; if this will not be necessary, press
[EXIT/NO]. Remember that if you do not save a modified song at this
time, all newly recorded audio data, edited data, modified mixer settings,
etc. will be lost.
• To cancel reading from a CD-R/RW disc, press [EXIT/NO]. When the
message “Cancel?” appears, press [ENTER/YES] to confirm cancellation.
(A certain amount of time may pass between pressing of [EXIT/NO] and
display of the confirmation message.)
• If the total size of the songs and other data to be recovered exceeds the
amount of space available on the hard disk, the message “HDD Full!”
will be displayed and the reading of data will not be possible. In such a
case, you should reduce the number of songs or the volume of data to be
recovered, or alternatively, you should free up some hard disk space by
deleting unneeded data and/or songs.

20
Jan.2004
Reading backup songs back into
the hard disk (Song Recover)
1. Insert a CD-R/RW disc containing backup songs into the BR-1600CD’s
CD-R/RW drive.
The drive’s access indicator will begin to flash. Wait until this indicator
stops flashing and turns off before proceeding.
2. Press CD-R/RW [DATA SAVE/LOAD].
The Data CD screen will appear.
fig.41-05d
3. Press [F2] (RECOVER) or move the cursor to RECOVER, and then press
[ENTER/YES].
The Recover screen will appear.
fig.41-16d
4. Press [F1] (SONG) or move the cursor to SONG, and then press [ENTER/
YES].
A list of the CD-R/RW disc’s backup songs will be displayed.
fig.41-17d
5. Move the cursor to the song you want to recover and press [F1]
(SELECT).
The song will selected for recovery.
A number of songs can be selected in this way for recovery, and an
asterisk (*) will be displayed for each selected song. To cancel this
selection, press [F2] once again.
If you would like to recover all of the songs on the CD-R/RW disc in a
single operation, press [F2] (ALL). All songs will be selected for recovery.
To cancel this selection, press [F2] once again. This deselects all songs.
6. When you have selected all of the songs you want to recover, press [F4]
(GO).
The BR-1600CD will start the recovery process. When the message
“Complete!” appears, it indicates that the recovery has been completed
successfully.
Reading backup user data back
into the hard disk (User Recover)
1. Insert a CD-R/RW disc containing backup user data into the BR-
1600CD’s CD-R/RW drive.
The drive’s access indicator will begin to flash. Wait until this indicator
stops flashing and turns off before proceeding.
2. Press CD-R/RW [DATA SAVE/LOAD].
The Data CD screen will appear.
fig.41-05d
3. Press [F2] (RECOVER) or move the cursor to RECOVER, and then press
[ENTER/YES].
The Recover screen will appear.
fig.41-16d
4. Press [F2] (USER) or move the cursor to USER, and then press [ENTER/
YES].
fig.41-20d
5. Use the TIME/VALUE dial to select the data you want to recover.
If you select the data that has no backup data, “*EMPTY” will be
displayed.
Data that can be recovered:
ALL
All of the user data on the CD-R/RW disc
EFFECTS
All insert effects patches from the user bank will be recovered.
MASTERING TOOL KIT
The Mastering Tool Kit’s user bank will be recovered.
SPEAKER MODELING
The Speaker Modeling user bank will be recovered.
VOCAL TOOL BOX
The Vocal Tool Box’s user bank will be recovered.
ARRANGEMENT/DRUMS/BASS/LOOP PHRASE
User rhythm arrangements, user drum patterns, user bass patterns, and
user loop phrases will all be recovered.
ARRANGEMENT
Only user rhythm arrangements will be recovered.
DRUM&BASS PATTERN
Only user drum patterns and user bass patterns will be recovered.
LOOP PHRASE ALL
User loop phrases from banks A through H will be recovered.
LOOP PHRASE A–H
Only user loop phrases from the selected bank will be recovered.
The recovered songs will be saved in sequence on the hard disk using the
available song numbers.
