Evenflo EveryFit User manual

To reduce the risk of serious injury or death, read
this owner’s manual prior to installing and using
this child restraint.
WARNING!
Para instrucciones en Español,
llamar al: 1-800-233-5921
* See "Child Requirements" on pages 4 - 5.
REAR-FACING*
1.8 - 18.1 kg
(4 - 40 lbs)
43 - 102 cm
(17 - 40 in.)
FORWARD-FACING
WITH HARNESS*
10 - 29.5 kg
(22 - 65 lbs)
71 - 124 cm
(28 - 49 in.)
At least 2 years old
HIGH-BACK
OR BACKLESS
BOOSTER*
18 - 54.4 kg
(40 - 120 lbs)
112 - 145 cm
(44 - 57 in.)
At least 4 years old
EveryFit
4-in-1 Car Seat Owner’s Manual
Keep instructions for future use.
© 2019 Evenflo Company, Inc. 25701528 10/19

More children are killed every year as passengers
in car crashes than by any other type of injury.
To reduce the risk of SERIOUS INJURY or DEATH, read
this owner’s manual and your vehicle owner’s manual
before installing and using this child restraint. Using a
child restraint makes a big difference. By properly using
this child restraint and following these instructions (and
the instructions that accompany your vehicle), you will
greatly reduce the risk of serious injury or death to your
child from a crash. Do not be misled by the commonly
used term “safety seat”; no restraint system can prevent
all injuries in all crashes. Many properly restrained
adults and children are injured in motor vehicle crashes,
including relatively minor crashes. A properly used child
restraint is the best way to minimize injuries to your
child and to increase the chances for survival in most
crashes.
FEDERAL STANDARD NO. FMVSS213 -
Child Restraint Systems
This child restraint conforms to all applicable Federal
motor vehicle safety standards.
CANADIAN REGULATORY NOTICE
(Model numbers ending in “C.”)
This child restraint meets all applicable requirements
of Canadian Motor Vehicle Safety Standards CMVSS
213, 213.1, and 213.2.
Airbag Symbol – Alerts you to important
information about airbag safety.
LATCH Symbol – Alerts you to important
information about LATCH safety.
Tether Anchor Symbol – Alerts you to
important information about Tether Anchor safety.
Aircraft Symbol – Alerts you to important
information about aircraft safety.
Symbol Legend
2

ImportantRear-facingForward-FacingBoosterGeneral
3
Table of Contents
Important Information
Child Requirements .......................................................... 4
Premature Infant Use ........................................................ 6
Warnings .......................................................................... 7
Safe Practices.................................................................. 18
Recall Information for U.S. Customers............................. 18
Public Notice for Canadian Customers............................ 19
Motor Vehicle/Aircraft Usage .......................................... 19
Child Restraint Features .................................................. 20
Rear-facing
Using the Child Restraint Rear-facing .............................. 26
Rear-facing Installation with Lower Anchor (UAS)
Connectors ................................................................. 27
Rear-facing Installation with Vehicle Seat Belts ................ 33
Rear-facing Installation Checklist..................................... 37
Forward-facing with Harness
Using the Child Restraint Forward-facing with Harness ............. 38
Forward-facing Installation with Lower Anchor (UAS)
Connectors ................................................................... 39
Forward-facing Installation with Vehicle Seat Belts .......... 46
Forward-facing Installation Checklist............................... 52
Booster Mode
Using the Child Restraint as a Booster Seat ..................... 53
Using Your Booster Seat in High-Back Mode ................... 55
High-Back Booster Installation Checklist.......................... 58
Using Your Booster Seat in Backless Booster Mode .......... 59
Backless Booster Installation Checklist ............................. 62
General Information
Reattaching the Booster Back.......................................... 63
Reattaching Booster Back................................................ 64
Adjusting the Headrest/Harness Position......................... 65
Reclining Child Restraint ................................................. 66
Adjusting the Crotch Buckle Position .............................. 67
Securing the Child in the Child Restraint......................... 68
Removing the Child from the Child Restraint .................. 70
Removing the Tether Strap ............................................. 71
Installing Child Restraint Rear-facing in Aircraft ............... 72
Installing Child Restraint Forward-facing in Aircraft ......... 74
Removing the Seat Cover ............................................... 76
Reattaching the Seat Cover............................................. 79
Care and Cleaning.......................................................... 81
Recording Model Information......................................... 82
Storing Your Instructions................................................. 82
Proper Disposal............................................................... 82
Replacement Parts .......................................................... 83
Limited Warranty ............................................................ 84

4
This child restraint is designed for use by children in both
rear-facing and forward-facing orientations. To use
this child restraint properly, children MUST meet the
size and age requirements below. In addition, Evenflo
recommends consulting with your child’s physician before
allowing your child to transition from rear-facing to
forward-facing use of this child restraint.
The American Academy of Pediatrics (AAP) recommends
keeping children rear-facing for as long as possible, until
they reach the maximum height or weight for their child
restraint in rear-facing orientation. Additionally, some
states’ laws require children to be rear-facing until age
2. Accordingly, you will see this guidance reflected in the
Child Requirements below. Please review any applicable
local, state or provincial laws related to child passenger
safety before installing and using this child restraint.
Rear-facing
• 1.8 - 18.1 kg
(4 - 40 lbs)
• 43 - 102 cm
(17 - 40 in.)
• Top of child’s head is at least
2.5 cm (1 in.) or more below
the top of the child restraint
headrest
IMPORTANT: Once your child exceeds any of the size
requirements above, they MUST use this child restraint
in the forward-facing orientation, if possible. If your child
exceeds any of the size requirements above and is less
than 2 years old, however, you MUST discontinue use of
this child restraint.
Child Requirements
Failure to follow these Child Requirements could
result in serious injury or death.
WARNING

Important
5
Forward-facing with Harness
• 10 - 29.5 kg
(22 - 65 lbs)
• 71 - 124 cm
(28 - 49 in.)
• Tops of the child’s ears are at
or below the top of the child
restraint headrest
• At least 2 years old
IMPORTANT: Once your child exceeds any of the size
requirements for forward-facing use above, you MUST
discontinue use of this child restraint with its internal
harness and begin using it in booster mode, if possible.
If your child exceeds any of the size requirements for
forward-facing use above and is less than 4 years
old, however, you MUST discontinue use of this child
restraint.
Booster Mode
• 18 - 54.4 kg
(40 - 120 lbs)
• 112 - 145 cm
(44 - 57 in.)
• Tops of the child’s ears are at or
below the top of the booster seat
headrest (high-back mode) or
vehicle seat headrest (backless
mode)
• At least 4 years old
IMPORTANT: Once your child exceeds
any of the size requirements above for
booster mode, you MUST discontinue
use of this seat. Your child may be ready
for use of the vehicle belt system only at
this time.
Child Requirements

6
Before using this child restraint for preterm or low
birth weight infants, ensure the Child Requirements
are met and follow the guidelines in this section.
According to the U.S. National Highway Traffic Safety
Administration, a properly installed child restraint reduces
the risk of death by over 70 percent for infants involved in
crashes. Federal Motor Vehicle Safety Standard (FMVSS)
213 establishes design and dynamic performance
requirements for child restraint systems. However, the
standard has no minimum weight limit and does not
address the special medical needs of preterm or low-
birth weight infants. To ensure that preterm and low-
birth weight infants are transported safely, the guidelines
published by the American Academy of Pediatrics (AAP) in
Pediatrics 2009; 123:1424–1429 must be followed.
All children should ride rear-facing in the vehicle as long
as possible. Preterm and low-birth weight infants are at
additional risk of breathing difficulties and heart problems
when placed in a child restraint. Evenflo requires that the
evaluation recommended by the AAP be conducted for all
infants born earlier than 37 weeks and all newborn infants
who weigh less than 2.26 kg (5 pounds) at birth before
their first car trip to check for breathing difficulties or heart
rate problems when traveling in a rear-facing child restraint.
The AAP recommends that appropriate hospital staff observe
your infant in the child restraint for a period of 90 - 120
minutes or the duration of travel, whichever is longer. This
period of observation must be performed with the infant
properly positioned as described in these instructions and
with the child restraint placed at an angle that is approved
for use in the vehicle. The hospital staff will check for any
breathing difficulties or heart rate problems. Your child’s
pediatrician will let you know if there are any special
considerations for travel. The number of trips and the
duration of time the infant is seated in the child restraint
should be minimized. A caregiver should ride in the back
seat to monitor the infant during travel.
You can learn more about the AAP’s recommendations
for observation of newborns and the guidelines for safe
transportation of preterm and low-birth weight infants,
as well as other resources for parents and medical
professionals, at
https://www.healthychildren.org/english/safety-prevention/
on-the-go/Pages/default.aspx
Premature Infant Use

Important
7
• DO NOT use this child restraint in the front seat of a
vehicle equipped with an air bag, unless the air bag
has been deactivated. Interaction between a rear-
facing restraint and air bags may cause serious injury
or death. Air bags may cause serious injury or death to
children 12 years of age and under. If your vehicle has
an air bag, refer to your vehicle owner’s manual for
child restraint installation.
• DO NOT place any objects between the restraint and
the side air bag, as an expanding air bag may cause
the items to strike your child.
• If the rear seat of your vehicle is equipped with side
air bags, refer to the following information for proper
usage:
Vehicles built prior to the 2002 model year:
DO NOT use this restraint in a vehicle seating position
equipped with a side air bag unless authorized by the
vehicle manufacturer.
Model year 2002 and newer vehicles:
Refer to your vehicle owner’s manual before placing
this restraint in a seating position equipped with a side
air bag.
Airbag Warnings
The forward facing back seat is the safest
place for children 12 and under.
NE PAS placer un dispositif de retenue pour
enfant en orientation face à l’arrière sur un siège
avant doté d’un sac gonflable.
RISQUE DE DÉCÈS OU DE GRAVES BLESSURES.
Le siège arrière offre le plus de sécurité pour les
enfants âgés de 12 ans ou moins.
DO NOT place rear-facing child seat on front
seat with air bag.
DEATH OR SERIOUS INJURY CAN OCCUR.
The back seat is the safest place for children
12 and under.
WARNING / MISE EN GARDE
WARNING!DEATH or SERIOUS
INJURY can occur.

8
• Failure to follow the Child Usage Requirements for
rear-facing, forward-facing and booster mode
for this child restraint could result in serious injury or
death. (See "Child Requirements" on pages 4 - 5).
• Failure to follow installation instructions and the
instructions and warning labels on product can result
in the child striking the vehicle’s interior during a
sudden stop or crash. Serious injury or death may
result. These instructions and the instructions in your
vehicle owner’s manual must be followed carefully.
If there is a conflict between the two, the vehicle
owner’s manual regarding child restraint installation
must be followed.
• NEVER leave child unattended.
• DO NOT use child restraint if it is damaged, broken, or
missing parts.
• DO NOT use this restraint if it has been involved in a
crash. It must be replaced.
Children have STRANGLED in loose or partially buckled
harness straps. Fully restrain the child even when carrier is
used outside the vehicle.
WARNING/MISE EN GARDE
Des enfants se sont ÉTRANGLÉS dans des sangles de harnais
desserrées ou mal serrées. Attacher complètement l’enfant
même lorsque le porte-bébé est utilisé hors du véhicule.
General Warnings
WARNING!DEATH or SERIOUS
INJURY can occur.

Important
9
• ALWAYS read and follow exactly the instructions that
accompany your vehicle and child restraint.
• According to accident statistics, children are safer
when properly restrained in the rear seating positions
than in the front seating positions. Generally, the
center rear position is safest and should be used if
available.
• Some child restraints do not fit all vehicles or all
seating locations. There are many thousands of
combinations of vehicle makes, models, child restraint
configurations, vehicle seat belt designs, and seat
cushion shapes. The easiest way to determine whether
your child restraint is suitable for a particular seating
position is to check for a tight installation. If the child
restraint cannot be properly installed, DO NOT use
the child restraint. Consult vehicle owner’s manual, try
a different seating location, or call Evenflo for further
assistance.
• ONLY use this child restraint on forward-facing
vehicle seats. DO NOT use this restraint with vehicle
seats that face the rear or side.
• ONLY use this child restraint on vehicle seats with
backs that lock into place.
• VEHICLE TYPES IN WHICH THE RESTRAINT
SYSTEM CANNOT BE USED:
This child restraint is not to be used in vehicles that do
not have vehicle seat belts or UAS lower anchorages.
WARNING!DEATH or SERIOUS
INJURY can occur.
Location Warnings

10
• When using this restraint rear-facing, DO NOT loosen
the vehicle seat belt to provide more leg room, as
this may keep the child restraint from protecting your
child.
• Fold-down armrests could pose a hazard to a rear-
facing child in certain types of collisions. Consult your
vehicle owner’s manual before installing any rear-
facing child restraint in front of a fold-down armrest.
• DO NOT use the tether strap when the child restraint
is installed rear-facing.
• The headrest on the vehicle seat that the child faces
when sitting rear-facing should be placed in the lowest
position. The vehicle seat back that the child faces
must be fully padded and free of any hard objects.
• Cup holders MUST remain attached to the restraint
AT ALL TIMES in rear-facing mode.
• IMPORTANT: Infants may have difficulty breathing
when in an upright seated position. Make sure they
recline enough for their head to lie back comfortably
and safely. Failure to properly recline the child restraint
could increase the child’s risk of serious injury or
death.
• Adjust or remove the vehicle headrest in the
seat where the child restraint is to be installed,
so the back of the child restraint rests against the
vehicle seat back.
• The headrest on the vehicle seat in front of the child
should be put in its lowest position. The vehicle seat
back that the child faces must be fully padded and
free of any hard objects.
WARNING!DEATH or SERIOUS
INJURY can occur.
Rear-Facing Warnings
Forward-Facing Warnings

11
• DO NOT use this booster seat rear-
facing.
• Use ONLY the vehicle’s lap
AND shoulder belt system when
restraining the child in this booster
seat. Never use a booster with
only a lap belt, as this could
cause serious injuries.
• The shoulder belt MUST cross
midway between the child's
shoulder and neck.
- In high-back booster mode,
thread shoulder belt through the
shoulder belt guide.
- In backless booster mode,
thread shoulder belt through the
shoulder belt clip if needed. (See
"Using the Shoulder Belt Clip" on
pg. 61.)
• DO NOT use this booster seat if the tops of the child’s
ears are above:
- In high-back booster mode, the top of the
booster seat headrest
- In backless booster mode, the top of the vehicle
headrest.
• The shoulder belt MUST NOT cross the child’s neck
or fall off the child’s shoulder. If you cannot adjust
the shoulder belt to properly lay midway between
the child’s shoulder and neck AND at or above the
shoulder, try another seating location or do not use
the booster seat.
• IMPORTANT: Always secure the booster seat with the
vehicle seat belt or lower anchors when not occupied.
An unsecured booster seat can fly into and injure other
occupants in the event of a crash.
WARNING!DEATH or SERIOUS
INJURY can occur.
Booster Mode Warnings
Important

12
• ALWAYS read your vehicle
owner's manual to determine
what vehicle belts and retractors
are used in your vehicle.
Lock your retractors if available in
your vehicle.
• DO NOT use this child restraint
if it moves more than 2.5 cm (1 in.) side to side or
front to back at the belt path in use. Serious injury or
death may result from loose installation. If you cannot
tightly secure the child restraint, try again or move it
to another location.
• DO NOT use this child restraint in a
seating position with door-mounted seat
belts.
• DO NOT use this child restraint
in a vehicle with seat belts that
automatically move along the vehicle
frame when the door is opened.
• DO NOT use this child restraint in a
vehicle equipped with lap belts that
only lock during a sudden stop or
crash (Emergency Locking Retractor –
ELR). You must use a seating location
with a lap/shoulder belt or a locking
lap belt. Check your vehicle owner’s
manual to see if you have lap belts
with ELRs.
• DO NOT use on vehicle seats when
both portions of the vehicle belts are
positioned forward of the seat crease.
Retractor
WARNING!DEATH or SERIOUS
INJURY can occur.
Seat Belt Warnings

13
• DO NOT use with lap/shoulder belts with
two retractors. If the vehicle seat belts are
not routed and fastened correctly, the child
restraint may not protect the child in a crash.
• DO NOT use with inflatable seat belts.
• Check your vehicle owner’s manual to
determine how to lock your seat belt for child restraint
installation.
• DO NOT allow the vehicle seat belt release button to
touch the child restraint. Accidental contact may cause
the seat belt to release. If necessary, turn the seat belt
release button away from the child restraint or move the
child restraint to a different location.
• Failure to adjust the harness or vehicle seat belts snugly
around the child may result in the child striking the
vehicle’s interior during a sudden stop or crash. Serious
injury or death may occur.
• This child restraint must be securely belted to the vehicle,
even when it is unoccupied, since in a crash an
unsecured child restraint system may injure other occupants.
WARNING!DEATH or SERIOUS
INJURY can occur.
Seat Belt Warnings
Important

14
If you have any of these types of vehicle belt systems
listed, these are SAFE to use to install your child restraint
in the vehicle. Review vehicle owner’s manual for specific
instructions on child restraint installation.
LATCH can be used IN PLACE OF these vehicle belt types.
Refer to the Rear-facing and Forward-facing weight limits
on LATCH use on pages 28 and 40. Refer to your vehicle
owner’s manual for LATCH locations.
Lap Belt with Locking Latch Plate
Once buckled, the vehicle belt is
tightened by pulling on the free end of
the strap until the belt is tight.
Lap Belt with Automatic Locking Retractor
(ALR)
The automatic locking retractor does
not allow the lap belt to get longer
once it is buckled. The vehicle belt is
tightened by feeding seat belt webbing
into retractor.
Lap/Shoulder Belt with Locking Latch Plate
The lap portion of this belt does not
loosen once the belt is buckled.
The vehicle belt is tightened by pulling
up hard on shoulder belt and feeding the extra webbing
into the retractor.
Lap/Shoulder Belt with Sliding Latch Plate
with Locking Retractor
The latch plate slides freely along the
lap/shoulder belt. Vehicle belts with
sliding latch plates are typically locked at
the shoulder belt retractor by buckling
the belt and pulling all of the webbing out slowly to
switch the retractor.
Check vehicle owner’s manual for specific instructions.
The vehicle belt is tightened after switching the retractor
by pulling up on shoulder belt and feeding the webbing
into the retractor.
Free end
WARNING!DEATH or SERIOUS
INJURY can occur.
Seat Belt Warnings

15
LATCH/UAS Warnings
What is LATCH?
LATCH is an acronym for
(Lower Anchors and Tethers
for CHildren) and refers to a
pair of fixed Lower Anchors
(or bars) and a Top Tether
anchor that are built into
your vehicle, in vehicles built
after September 1, 2002.
The lower LATCH anchors
are located in the crease,
or bight, between the
vehicle seat back and seat
cushion, and if not visible,
will typically be indicated by the symbol. Top tether
anchors are located in various places behind the rear
vehicle seat.
Center installation in a non-standard LATCH
position:
Center installation of this child restraint is permitted
using inner Lower Anchor Bars from the outside seating
positions if:
1. your vehicle manual allows such installation; and
2. the inner Lower Anchor Bars from the outside seating
positions are 28 - 51 cm (11 - 20 in.) apart.
LATCH typically offers an easier and more consistent
installation. However, this child restraint can be safely
installed using either LATCH or vehicle belts and meets
the requirements of Federal Safety Standard FMVSS 213
with either installation method. Either method is safe for
your child when installed correctly. When using either
method, it is best practice to ALWAYS USE tether when
installing in the forward-facing position.
DO NOT install this child restraint with LATCH and
the vehicle’s seat belts at the same time. Your vehicle
owner’s manual may refer to this system as ISOFIX,
Universal Anchorage System (UAS), or Lower
Universal Anchorage System.
The LATCH system is intended to be used ONLY as
described in these instructions. Serious injury or death
may result from misuse. Refer to your vehicle Owner’s
Manual for lower anchor bar positions in your vehicle.
Vehicle
Lower
Anchors
Vehicle Top Tether
Anchor Points
Vehicle
Seat
Crease
WARNING!DEATH or SERIOUS
INJURY can occur.
Important

16
• DO NOT use the lower anchors of the child restraint
anchorage system (LATCH system) to attach this child
restraint when restraining a child weighing more than
18 kg (40 lbs) with the internal harnesses of the child
restraint. ONLY USE VEHICLE BELT INSTALLATION.
• In addition to these instructions, read and follow your
vehicle owner’s manual regarding installation of the
child restraint and LATCH. If there is a discrepancy,
follow your vehicle owner’s manual.
• ONLY use for securing child restraint to vehicle lower
anchor bars.
• NEVER attach two lower anchor connectors to one
vehicle lower anchor bar.
• NEVER use the vehicle seat belts when using the lower
anchor connector assembly. Using both together can
cause slack in a sudden stop or crash.
• To avoid strangulation, you must store the unused
LATCH straps, with all slack removed, in the storage
areas on the sides of your seat. Roll or fold the excess
LATCH strap and secure with a rubber band to
prevent serious injury to vehicle occupants.
• ALWAYS be sure that the lower anchor connectors
are attached to the vehicle lower anchor bars by
pulling hard on the lower anchor connectors. If
they are not attached, the lower anchor connector
assembly will not secure your child restraint. Serious
injury or death may result.
• DO NOT use this child restraint if it moves more than
2.5 cm (1 in.) side to side or front to back at the belt
path in use. Serious injury or death may result from
poor installation. If you cannot tightly secure the child
restraint, try again or move it to another location.
WARNING!DEATH or SERIOUS
INJURY can occur.
LATCH/UAS Warnings

17
Tether Strap Warnings
• To avoid a strangulation hazard, you MUST tightly roll
or fold excess of unused tether strap and secure with
a rubber band. Attach the tether hook to the storage
clip when not in use. (See "Removing the Tether Strap
on pg. 71). This will keep an unused tether or tether
hook from hitting someone during a crash.
• DO NOT use the cup holder to store cans or hard
cups. DO NOT place any cups that contain hot liquids
in the cup holder.
• DO NOT attach additional padding, toys, or other
devices not made by Evenflo or described in these
instructions for the child restraint. Items not tested
with the child restraint could injure the child.
Additional pads or pillows may interfere with the
function of the harness system, or cause breathing
problems if the child’s head falls forward, increasing
the risk of serious injury or death.
• In hot or sunny weather, ALWAYS check the areas of
the child restraint that may contact your child (e.g.,
buckle, buckle tongues, etc.) for hot areas before
placing him/her into the child restraint. The child
could be burned. Cover the child restraint with a light
colored blanket when you leave the vehicle.
• In cold weather, DO NOT dress the child in bulky
clothing like snowsuits if the child is riding in a child
restraint. Bulky coats/snowsuits make it difficult to
properly tighten the harness to the child, which
may allow the child to be ejected from the restraint
during a crash. If necessary, place a blanket over the
harnessed child without interfering with the child
restraint harness system.
WARNING!DEATH or SERIOUS
INJURY can occur.
Additional Warnings
Important

18
• Everyone rides buckled up or the vehicle does
not go. Make no exceptions for adults or children. If
someone unbuckles, stop the vehicle. Being firm and
consistent from the start will mean fewer discipline
problems as children get older. An unrestrained person
can be thrown into and injure other passengers.
• NEVER try to tend to a crying baby’s needs while
driving. NEVER take a baby out of a child restraint for
comforting while the vehicle is moving.
• DO NOT allow a child in a vehicle to have objects such
as lollipops or ice cream on a stick. The object can
injure the child if the vehicle swerves or hits a bump.
• DO NOT feed an infant who is riding in a child
restraint.
• Put sharp or heavy items in the trunk. Anything loose
can be deadly in a crash.
• Child restraints could be recalled for safety reasons. You
must register this restraint to be reached in a recall.
Send your name, address, email address if available,
and the restraint’s model number and manufacturing
date to:
Evenflo Company, Inc.
1801 Commerce Dr.
Piqua, OH 45356
or call 1-800-233-5921
or register online at
www.evenflo.com/registercarseat
• For recall information, call the U.S. Government’s Vehicle
Safety Hotline at 1-888-327-4236 (TTY:1-800-424-9153),
or go to http://www.NHTSA.gov
IMPORTANT
In case of a recall, we can reach you only if we
have your name and address. You MUST send in
the attached card or register online to be on our
recall list.
We've already paid the postage.
Do it today.
26000186 8/15
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
BUSINESS REPLY MAIL
FIRST-CLASS MAIL PERMIT NO. 325 PIQUA OH
POSTAGE WILL BE PAID BY ADDRESSEE
CHILD RESTRAINT REGISTRATION
EVENFLO COMPANY INC
1801 COMMERCE DR
PIQUA OH 45356-9960
FOR YOUR CHILD'S CONTINUED SAFETY
Please take a few moments to promptly fill out and return the
attached card (or register online using the direct link to the
manufacturer’s registration website provided).
Although child restraint systems undergo testing and evaluation,
it is possible that a child restraint could be recalled.
In case of a recall, we can reach you only if we have your name
and address, so please send in the card (or register online) to
be on our recall list.
The card is already addressed and we've paid the postage.
Tear off and mail this part
Consumer: Just fill in your name and address and e-mail address.
Your Name
CHILD RESTRAINT REGISTRATION CARD
Please fill this card out using blue or black ink
and mail it NOW,
(or register online at: www.evenflo.com/registercarseat)
while you are thinking about it.
Your Street Address
State Zip Code
City
E-mail Address
Safe Practices
Recall Information for U.S. Customers

19
Motor Vehicle/Aircraft Usage
• Child restraints could be recalled for
safety reasons. You must register this
restraint to be reached in a recall. Send
your name, address, and the restraint’s
model number and manufacturing
date to:
Evenflo Company, Inc.
1801 Commerce Dr.
Piqua, OH 45356
or call 1-937-773-3971
or register online at:
www.evenflo.com/registercarseatcanada
• For public notice information, call Transport Canada at
1-800-333-0510 (1-613-993-9851 in Ottawa region).
CANADIAN RESIDENTS ONLY
DOMICILIES DU CANADA SEULEMENT
PRODUCT REGISTRATION CARD
CARTE D'ENREGISTREMENT DU PRODUIT
1. Name
Nom
2. Street Address
Adresse
3. City
Ville 4. Prov. Prov
5. Postal Code
Code postal
6. Telephone Number (with Area Code)
Num. de téléphone (et indicatif régional) ( )
8. Date of Purchase
Date d'achat
ATTENTION: This card may be important to the safety of your child.
Please complete using blue or black ink and mail this card so that
you can be contacted in the event of a safety defect notice on this
product. The information you provide must be complete.
Or register online at www.evenflo.com/registercarseatcanada.
ATTENTION : Cette carte pourait être importante
à la sécurité de
votre enfant. Veuillez remplir cette carte à l’encre bleue ou noire
et la poster afin de pouvoir être contacté en cas d’un avis de
défaut lié à la sécurité de ce produit. Les informations
fournies doivent être complètes. Ou enregistrez-vous en
ligne à www.evenflo.com/registercarseatcanada.
PLACE DATE/MODEL # LABEL HERE.
AFFIXER L'ÉTIQUETTE DE LA DATE ET
DU NUMÉRO DE MODÈLE ICI.
7. Email Address
Adresse électronique
Public Notice for Canadian Customers
Check with
your airline before
departure to make sure
this restraint meets
their requirements.
Tip!
Tip!
Important
When used with the internal
harness and properly installed
pursuant to these instructions,
this restraint is certified for use only
in passenger and multi-purpose
passenger motor vehicles, buses
and trucks equipped with either
lap belts only or lap/shoulder belt
systems and in aircraft.
Refer to pages 72 - 75 for instructions on installing your
child restraint in aircraft.
When used WITHOUT the internal harness
system (in booster mode) and properly installed
pursuant to these instructions, this restraint is
certified for use only in passenger and multi-purpose
passenger motor vehicles, buses, and trucks equipped
with lap/shoulder belt systems only. In booster mode,
this restraint is NOT certified for aircraft use. A belt-
positioning booster requires the use of a lap/shoulder
belt system, which is not available in aircraft.

20
Description
1. Headrest Adjustment Handle
2. Adjustable Headrest
3. Shoulder Belt Guide
4. Chest Clip
5. Harness Straps
6. Cup Holder (both sides of seat)
7. Harness Release Button (under flap)
8. Recline Handle (under front edge of seat)
9. Harness Adjust Strap
10. Head Pillow*
11. Harness Covers*
12. Headrest Pad
13. Buckle Tongue Pocket (both sides of seat)*
14. Body Pillow
15. Crotch Buckle and Strap
Front
Child Restraint Features
q
w
e
r
t
y
u
i
o
1!
1@
1#
1$
1%
a
