Evenflo REVOLVE 360 SLIM User manual

Rotational Convertible Car Seat
Owner's Manual
Keep for future use.
© 2022 Eveno Company, Inc. 25701759 11/22
WARNING:
! To reduce the risk of serious
injury or death, read this owner’s manual prior to
installing and using this car seat.
ADVERTENCIA:
!Para reducir el riesgo
de lesiones graves o la muerte, lea este manual
del propietario antes de instalar y usar este
asiento infantil.
Asiento de bebé para el
automóvil convertible giratorio
Manual del propietario
Guarde para uso futuro.

According to the U.S. National Highway Trafc Safety Administration
(NHTSA), car seats and boosters provide protection for infants and children
in a crash, yet car crashes are a leading cause of death for children.
To reduce the risk of SERIOUS INJURY or DEATH, read this owner’s manual
and your vehicle owner’s manual before installing and using this Car Seat. Using
a Car Seat makes a big difference. By properly using this Car Seat and following
these instructions, the instructions on the Car Seat, and the instructions that
accompany your vehicle, you will greatly reduce the risk of serious injury or death
to your child from a crash. Do not be misled by the commonly used term “safety
seat”; no restraint system can prevent all injuries in all crashes. Many properly
restrained adults and children are injured in motor vehicle crashes, including
relatively minor crashes. A properly used Car Seat is the best way to minimize
injuries to your child and to increase the chances for your child’s survival in most
crashes.
FEDERAL MOTOR VEHICLE SAFETY STANDARD NO. 213 (FMVSS 213)
Child Restraint Systems
This Child Restraint conforms to all applicable Federal motor vehicle safety
standards. CANADIAN REGULATORY NOTICE
(Model numbers ending in “C”)
This Child Restraint meets all applicable requirements of Canadian Motor
Vehicle Safety Standards CMVSS 213, 213.1, and 213.2.

4
IMPORTANT INFORMATION
Child Requirements........................................................................................................................... 7
Rear-Facing Mode................................................................................................................... 10
Forward-Facing Mode.............................................................................................................. 12
Warnings ......................................................................................................................................... 14
Motor Vehicle/Aircraft Usage ........................................................................................................... 33
Registration and Recall Information ................................................................................................ 34
Car Seat Features ........................................................................................................................... 36
Revolve360 Seat Rotation....................................................................................................... 40
Adjustable Buckle Strap .......................................................................................................... 42
Body Pillow.............................................................................................................................. 43
Cup Holders ............................................................................................................................ 44
Harness Covers....................................................................................................................... 45
Head Pillow ............................................................................................................................. 46
Height Adjustable Headrest..................................................................................................... 47
Lower Anchor Connectors....................................................................................................... 48
Quick Clean Cover and Seat Protector Insert ......................................................................... 50
SensorSafe Chest Clip ............................................................................................................ 51
Tether Strap............................................................................................................................. 52
USING THE REVOLVE360 SLIM
Removing and Installing the Seat Shell from the Base ................................................................... 53
Removing the Seat Shell from the Base ................................................................................. 53
Installing the Seat Shell to the Base........................................................................................ 54
Lap/Shoulder Belt (Rear-Facing and Forward-Facing).................................................................... 55
Installing Lap/Shoulder Belt (Preferred Method) ..................................................................... 55
Removing Lap/Shoulder Belt................................................................................................... 63
Table of Contents

5
Lap Belt Only (Rear-Facing and Forward-Facing)........................................................................... 65
Installing Lap Belt .................................................................................................................... 65
Removing Lap Belt .................................................................................................................. 72
LATCH/UAS (Rear-Facing and Forward-Facing) ............................................................................. 74
Installing LATCH/UAS.............................................................................................................. 74
Removing LATCH/UAS............................................................................................................ 81
Aircraft Installation........................................................................................................................... 83
Installing a Child Restraint in an Aircraft.................................................................................. 83
Installing the Revolve360 Slim in an Aircraft ........................................................................... 84
GENERAL INFORMATION
Securing the Child ........................................................................................................................... 88
Removing/Replacing the Seat Cover............................................................................................... 96
Standard Seat Cover ............................................................................................................... 96
Quick Clean Seat Covers ...................................................................................................... 105
Care and Cleaning......................................................................................................................... 113
Proper Disposal............................................................................................................................. 114
Recording Model Information and Storing Your Instructions.......................................................... 115
Replacement Parts........................................................................................................................ 116
Table of Contents

6
Symbol Legend
Air bag Symbol Alerts you to important information about air
bag safety.
LATCH/UAS Symbol Alerts you to important information about
LATCH/UAS safety.
Tether Anchor Symbol Alerts you to important information about Tether
Anchor safety.
Aircraft Symbol Alerts you to important information about
aircraft safety.

7
Child Requirements
This Car Seat is designed for use by children in both REAR-FACING and
FORWARD-FACING mode. To use this Car Seat properly, children MUST meet
the size and age requirements on the following pages. In addition, Eveno
recommends consulting with your child’s physician before allowing your child to
transition between modes.
The American Academy of Pediatrics (AAP) recommends keeping children
REAR-FACING for as long as possible, until they reach the maximum height or
weight for their Car Seat in REAR-FACING orientation.* Additionally, some states’
laws require children to be REAR-FACING until age 2. Accordingly, you will see
this guidance reected in the Child Requirements on the following pages. Please
review any applicable local, state or provincial laws related to child passenger
safety before installing and using this Car Seat.
!WARNING! DEATH or SERIOUS INJURY can occur.
*Pediatrics. 2018;142(4):e20182460

8
Before using this Child Restraint for preterm or low birth weight infants, ensure
the Child Requirements are met and follow the guidelines in this section.
According to NHTSA, a properly installed Child Restraint reduces the risk of death
by over 70% for infants involved in crashes. Federal Motor Vehicle Safety Standard
(FMVSS) 213 establishes design and dynamic performance requirements for
Child Restraint systems. However, the standard has no minimum weight limit and
does not address the special medical needs of preterm or low birth weight infants.
To ensure that preterm and low birth weight infants are transported safely, the
guidelines published by the American Academy of Pediatrics (AAP) in Pediatrics
2009;123:1424–1429 (reafrmed June 2018) must be followed.
Preterm and low birth weight infants are at additional risk of breathing difculties and
heart problems when placed in a Child Restraint. Eveno requires that the evaluation
recommended by the AAP be conducted for all infants born earlier than 37 weeks
and all newborn infants who weigh less than 2.26 kg (5 lbs) at birth before their
rst car trip to check for breathing difculties or heart rate problems when traveling
in a REAR-FACING Child Restraint. Newborn infants should NEVER travel in a
FORWARD-FACING Child Restraint.
Premature Infant Use

9
The AAP recommends that appropriate hospital staff observe your infant in the
Child Restraint for a period of 90 to 120 minutes or the duration of travel, whichever
is longer. This period of observation must be performed with the infant properly
positioned as described in these instructions and with the Child Restraint placed at
an angle that is approved for use in the vehicle. The hospital staff will check for any
breathing difculties or heart rate problems. Your child’s pediatrician will let you know
if there are any special considerations for travel. The number of trips and the duration
of time the infant is seated in the Child Restraint should be minimized. A caregiver
should ride in the back seat to monitor the infant during travel.
You can learn more about the AAP’s recommendations as well as other resources for
parents and medical professionals, at https://www.healthychildren.org/english/safety-
prevention/on-the-go/Pages/default.aspx.
Premature Infant Use

10
Child Requirements
CHILD REQUIREMENTS
• 1.8 - 22.6 kg (4 - 50 lbs)
• 43 - 122 cm (17 - 48 in)
• Top of child’s head is at least 2.5 cm (1 in) or more
below the top of the Car Seat Headrest or Shell
• Harness Straps must be adjusted to be AT or JUST
BELOW child's shoulders.
IMPORTANT: The American Academy of Pediatrics
(AAP) recommends keeping children REAR-FACING for
as long as possible, until they reach the maximum height
or weight for their Car Seat in REAR-FACING orientation
(see pg. 7). Once your child exceeds any of the size
requirements above, they MUST use this Car Seat in the
FORWARD-FACING orientation, if possible.
If your child exceeds any of the size requirements above
and is less than 2 years old, you MUST DISCONTINUE
use of this Car Seat.
Rear-Facing Mode

11
Child Requirements
Rear-Facing Mode
OPTIONAL: To ensure a better t for
smaller infants, the Body Pillow (pg. 43)
and/or Head Pillow (pg. 46) may be used
in REAR-FACING mode ONLY.
For REAR-FACING installation, Recline
Ball should be in correct zone for child
size:
• White Zone: 1.8 - 9 kg (4 - 20 lbs)
• Black Zone: 9 - 22.6 kg (20 - 50 lbs)
Chest Clip at armpit level
Shoulder straps
must be at or
just below
child’s
shoulders.
Top of head
MUST be 2.5
cm (1 in) or
more below top
of headrest or
shell.
Always use tether strap in rear facing
harness installation.
Ball must becompletely in proper zone for child size.
Vehicle MUST be on level ground.
Rear Facing
1.8 - 9 kg (4 - 20 lbs) Rear Facing
9 - 22.6 kg (20 - 50 lbs)
25809693 8/22

12
Child Requirements
Forward-Facing Mode
CHILD REQUIREMENTS
• 10 - 29.4 kg (22 - 65 lbs)
• 72 - 124 cm (28 - 49 in)
• Tops of the child’s ears are at or below the top of the
Car Seat headrest
• At least 2 years old
• Harness Straps must be adjusted to be AT or JUST
ABOVE child's shoulders.
IMPORTANT: Once your child exceeds any of the size
requirements for FORWARD-FACING use above, you
MUST discontinue use of this Car Seat.

13
Child Requirements
Forward-Facing Mode
When used FORWARD-FACING,
make sure the Car Seat is in the
UPRIGHT position as shown.

14
!WARNING! DEATH or SERIOUS INJURY can occur.
Air bag Warnings
• DO NOT use this Car Seat in the front seat of a vehicle equipped with an air
bag, unless the air bag has been deactivated. Interaction between a REAR-
FACING Car Seat and air bags may cause serious injury or death. Air bags
may cause serious injury or death to children 12 years of age and under. If
your vehicle has an air bag, refer to your vehicle owner’s manual for Car Seat
installation.
• The back seat is the safest place for children 12 and under.
• DO NOT place any objects between the Car Seat and the side air bag, as an
expanding air bag may cause the items to strike your child.

15
!WARNING! DEATH or SERIOUS INJURY can occur.
• If the rear seat of your vehicle is equipped with side air bags, refer to the
following information for proper usage:
Vehicles built prior to the 2002 model year:
DO NOT use this Car Seat in a vehicle seating position equipped with a side air
bag unless authorized by the vehicle manufacturer.
Model year 2002 and newer vehicles:
Refer to your vehicle owner’s manual before placing this Car Seat in a seating
position equipped with a side air bag.
Air bag Warnings
The FORWARD-FACING back seat is the safest place
for children 12 and under.

16
!WARNING! DEATH or SERIOUS INJURY can occur.
General Warnings
• Failure to follow the REAR-FACING and FORWARD-FACING Child Usage
Requirements for this car seat could result in serious injury or death. (See
"Child Requirements" on pgs. 10 - 13).
• Failure to follow installation instructions and the instructions and warning labels
on product can result in the child striking the vehicle’s interior during a sudden
stop or crash. Death or serious injury can occur. These instructions and the
instructions in your vehicle owner’s manual must be followed carefully. If there
is a conict between the two, the vehicle owner’s manual regarding Car Seat
installation must be followed.
• Children have STRANGLED in loose or partially buckled Harness Straps.
• NEVER leave child unattended.
• DO NOT use Car Seat if it is damaged, broken, or missing parts.
• DO NOT use this Car Seat if it has been involved in a crash. It must be
replaced.
• DO NOT install or use seat shell in vehicle without base. Seat Shell is NOT a
child restraint and will not restrain the child by itself.
• DO NOT use base in vehicle without seat shell. Base is NOT a child restraint
and will not restrain the child by itself.

17
!WARNING! DEATH or SERIOUS INJURY can occur.
Location Warnings
• ALWAYS read and follow exactly the instructions that accompany your vehicle
and Child Restraint.
• According to accident statistics, children are safer when properly restrained
in the rear seating positions than in the front seating positions. Generally, the
center rear position is safest and should be used if available.
• Some Car Seats do not t all vehicles or all seating locations. There are many
thousands of combinations of vehicle makes, models, Car Seat congurations,
vehicle seat belt designs, and seat cushion shapes. The easiest way to
determine whether your Car Seat is suitable for a particular seating position is
to check for a tight installation. If the Car Seat cannot be properly installed, DO
NOT use the Car Seat. Consult vehicle owner’s manual, try a different seating
location, or call Eveno for further assistance.
• NEVER use this Car Seat in a vehicle seating position where it cannot be
secured tightly. A loosely installed Car Seat will not protect your child in a crash.

18
!WARNING! DEATH or SERIOUS INJURY can occur.
Location Warnings
• ONLY use this Car Seat on FORWARD-FACING vehicle seats. DO NOT use
this Car Seat with vehicle seats that face the rear or side.
• ONLY use this Car Seat on vehicle seats with backs that lock into place.
• VEHICLE TYPES IN WHICH THE CAR SEAT SYSTEM CANNOT BE USED:
This Car Seat is not to be used in vehicles that do not have vehicle seat belts
or LATCH/UAS lower anchorages.
• NEVER use this Car Seat on boats, low speed vehicles (LSV), all-terrain
vehicles (ATV), golf carts, or any other non-certied application.

19
!WARNING! DEATH or SERIOUS INJURY can occur.
• Fold-down armrests could pose a hazard to a REAR-FACING child in certain
types of collisions. Consult your vehicle owner’s manual before installing any
REAR-FACING Car Seat in front of a fold-down armrest.
• The headrest on the vehicle seat that the child faces when sitting REAR-
FACING should be placed in the lowest position. The vehicle seat back that the
child faces must be fully padded and free of any hard objects.
• IMPORTANT: Infants may have difculty breathing when in an upright seated
position. Make sure they recline enough for their head to lie back comfortably
and safely.
• DO NOT USE this Car Seat if the top of your child’s head is less than 2.5 cm
(1 in) from the top of the Headrest or Shell, whichever is higher, when used
REAR-FACING.
• The Revolve360 Slim MUST BE LOCKED for proper use when the vehicle is
moving. This car seat is not designed to protect your child in a crash when the
seat is not locked.
• THE ROTATED POSITION IS FOR LOADING AND UNLOADING YOUR
CHILD ONLY! When properly installed, the Revolve360 Slim rotates in its base,
making it easy to safely load and unload your child.
Rear-facing Warnings

20
!WARNING! DEATH or SERIOUS INJURY can occur.
Forward-facing Warnings
• DO NOT USE this Car Seat FORWARD-FACING if your child is less than 2
years old.
• Adjust or remove the vehicle headrest in the seat where the Car Seat is to
be installed, so the back of the Car Seat rests against the vehicle seat back.
• The headrest on the vehicle seat in front of the child should be put in its lowest
position. The vehicle seat back that the child faces must be fully padded and
free of any hard objects.
• DO NOT USE the optional Body Pillow or Head Pillow with this Car Seat in
FORWARD-FACING mode.
• The Revolve360 Slim MUST BE LOCKED for proper use when the vehicle is
moving. This car seat is not designed to protect your child in a crash when the
seat is not locked.
• THE ROTATED POSITION IS FOR LOADING AND UNLOADING YOUR
CHILD ONLY! When properly installed, the Revolve360 Slim rotates in its base,
making it easy to safely load and unload your child.
