Ever SINLINE PRO 10000 User manual

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
2
TABLE OF CONTENTS
TABLE OF CONTENTS........................................................................................................................................ 2
INTRODUCTION .................................................................................................................................................. 3
GENERAL INFORMATION................................................................................................................................. 3
INTENDED APPLICATION............................................................................................................................. 3
GENERAL DESCRIPTION .............................................................................................................................. 4
STRUCTURE......................................................................................................................................................... 7
USER INTERFACE........................................................................................................................................... 8
SCREENS........................................................................................................................................................ 10
Main menu............................................................................................................................................................ 10
MEASUREMENTS submenu............................................................................................................................... 11
CONTROL submenu ............................................................................................................................................ 13
CONFIGURATION submenu .............................................................................................................................. 15
ALARMS submenu............................................................................................................................................... 17
STATISTICS submenu......................................................................................................................................... 18
PANEL SETTINGS submenu............................................................................................................................... 20
IDENTIFICATION submenu ............................................................................................................................... 20
INDUSTRIAL WORK SAFETY INSTRUCTIONS............................................................................................ 21
TRANSPORT .................................................................................................................................................. 21
ELECTRICAL SAFETY ................................................................................................................................. 21
INSTALLATION.................................................................................................................................................. 22
UNPACKING .................................................................................................................................................. 22
INSTALLATION OF THE POWER SUPPLY UNIT..................................................................................... 23
BATTERY MODULE ..................................................................................................................................... 23
Connecting modules.............................................................................................................................................. 24
Disconnecting modules......................................................................................................................................... 25
CONNECTING THE POWER SUPPLY UNIT................................................................................................... 26
Connecting elements............................................................................................................................................. 26
Electrical system................................................................................................................................................... 27
START-UP....................................................................................................................................................... 27
SWITCHING OFF AND DISCONNECTING THE POWER SUPPLY UNIT .............................................. 28
OPERATING MODES OF THE POWER SUPPLY UNIT ............................................................................ 29
OTHER FUNCTIONAL ELEMENTS ............................................................................................................ 30
PROTECTION...................................................................................................................................................... 30
AVR ................................................................................................................................................................. 33
EPO.................................................................................................................................................................. 33
Service BYPASS.............................................................................................................................................. 33
COOPERATION OF THE POWER SUPPLY UNIT WITH A PC ..................................................................... 34
RS232 AND USB COMMUNICATION......................................................................................................... 34
EVER SNMP/HTTP NETWORK MANAGEMENT CARD.......................................................................... 34
Installing a management card................................................................................................................................ 35
INSTALLING AND CONFIGURING POWERSOFT PERSONAL.............................................................. 36
Installing on a Windows system ........................................................................................................................... 36
Installing on a Linux/Unix system........................................................................................................................ 36
Updating software................................................................................................................................................. 37
COMMENTS REGARDING OPERATION........................................................................................................ 38
COOPERATION OF THE POWER SUPPLY UNIT WITH ELECTRICITY GENERATORS..................... 39
STORAGE, MAINTENANCE AND TRANSPORT....................................................................................... 39
RECYCLING................................................................................................................................................... 39
TECHNICAL PARAMETERS............................................................................................................................. 40
INSTALLATION GUIDELINES.................................................................................................................... 40
TECHNICAL DATA............................................................................................................................................ 41
INFORMATION CONCERNING LEGAL PROVISIONS AND THE GUARANTEE...................................... 42
DECLARATION OF CONFORMITY............................................................................................................ 42
GUARANTEE ................................................................................................................................................. 42
NOTES.................................................................................................................................................................. 42

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
3
INTRODUCTION
Thank you for purchasing the EVER SINLINE PRO 10000 power supply unit. It
belongs to a series of technologically advanced power supply units intended for
servers, computer networks and data processing systems.
The UPS EVER SINLINE PRO 10000 has been designed in such a way as to best
meet all your expectations regarding protection against the consequences of power
outages.
The present instruction manual contains information on operating the device and sets
forward the principles of safe usage. Please read the instruction manual thoroughly
before operating the EVER SINLINE PRO 10000 power supply unit, for this will
surely facilitate correct and trouble-free usage. The power supply unit has been
manufactured in Poland, in full accordance with requirements introduced for the CE
symbol.
GENERAL INFORMATION
INTENDED APPLICATION
Power supply unit of the SINLINE PRO 10000 series are class LINE-INTERACTIVE
(VI) devices, intended for cooperation with equipment powered from a single-phase
~230 V power grid.
NOTE! SINLINE PRO 10000 power supply units are not intended
for usage with medical life and/or health support systems.

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
4
GENERAL DESCRIPTION
•Sinusoidal output voltage, generated in battery operation mode;
•DPC (Digital Power Control) - Digital control of the power supply units
operating parameters, such as:
- output voltage shape,
- output voltage frequency,
- battery charge status,
- battery voltage and current,
- measurement of the capacity of a set of batteries,
- life of batteries,
- temperature of critical elements of the power supply unit;
•Digital measurement of external parameters, such as:
- mains voltage value,
- mains current value,
- mains voltage frequency,
- value of active and apparent power received from the mains,
- coefficient of mains-side power,
- value of active and apparent power connected to the power supply unit's
output,
- coefficient of output-side power,
•An automatic voltage regulation system (AVR), which increases and decreases;
•Mains voltage filtration;
•RS232 and USB serial ports for communication with a PC;
•Socket for adapter cards (e.g. a management card);
•Possibility of connecting additional battery packs;
•Possibility of browsing network event statistics;
•Calculating the current available emergency operation time;
•PowerSoft Personal software is used to control the power supply unit and
automatically close the system;

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
5
Figure 1: Simplified block diagram of the power supply unit
The SINLINE PRO 10000 power supply unit is a modern electronic device that
serves as an autonomous source of sinusoidal 230 V voltage. The device belongs to
the LINE–INTERACTIVE (VI) class of UPSs, which includes power supply units that
synchronize with the power grid. The unit is equipped with the unique CLEAR
DIGITAL SINUS (CDS) system that during battery operation generates a precisely
stabilised output voltage with a sinusoidal shape, which makes it possible to power
a broad range of loads that do not tolerate quasi-sinusoidal voltages. The application
of this system increases the reliability of the device, guaranteeing its stable
operation.
The Automatic Voltage Regulation (AVR) system allows the power supply unit to
immediately correct even small drops and rises in mains voltage, so as to ensure that
receivers enjoy the proper supply conditions without using up the power gathered in
batteries.
What is more, the unit has been fitted with an advanced DIGITAL POWER
CONTROL (DPC) system, which precisely shapes the course of the unit's output
voltage so as to generate a purely sinusoidal voltage. During mains operation, the
system filters the mains voltage in order to eliminate interferences and distortions
that could be potentially harmful to receivers.

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
6
The dedicated DPC system controls the operation of the power supply unit, and has
an extremely precise and rapidly acting system for detecting overloads and output
short-circuits during battery operation. In mains operation mode, short-circuit
protection is provided by fuses, with overloads being brought to the user's attention
both audibly and optically.
A special soft start mode has been introduced, which allows trouble-free start-up with
large loads that draw considerably start-up power, such as laser printers.
In addition, the DPC enables long-term battery operation of the power supply unit by
allowing the user to connect an additional battery pack and control the internal
temperature by means of an active cooling system, which is activated as required.
This method of cooling activation reduces the noise generated by the unit and helps
extend the life of fans.
The DPC system supports various methods of communication between the unit and
a PC over a communication link or a special link for the connection of an EVER
management card EVER (HTTP, telnet, SNMP).
The unit performs precise measurements of its basic parameters, including battery
voltage, power grid input voltage, unit output voltage, the power of connected loads,
temperature, and of advanced parameters, such as the available battery capacity or
backup mode operating time under current load.
The UPS utilises an innovative charging method, typically reserve for high-end power
supply units. which is known as CBC - COOL BATTERY CHARGING; this system
utilises elements of the internal converter for cold battery charging. In the mains
operating mode, this function charges the batteries, while in battery operation mode it
converts the internal energy of the battery to an alternating voltage that supplies the
protected devices.

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
7
STRUCTURE
1) BYPASS switch cover
2) Fans
3) Adapter card slot plug
4) USB communication link
5) RS232 communication link
6) EPO link
7) Fusible cut-out for internal
batteries
8) Connection links cover
9) AC input automatic fuses
10) Mechanical cable mounting grip
11) Service BYPASS switch/UPS
12) Connection link
13) Fusible cut-out for external
battery packs
14) Device earthing point
15) Mounting holders
Figure 2: Views of the rear panel

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
8
USER INTERFACE
The user interface consists of a four-button keypad located on the upper cover of the
power supply unit, an LCD, and three LEDs. They allow the user to monitor the unit's
operating parameters, and also modify some of them. The method of using the
interface and the meanings of individual parameters have been described hereunder.
Figure 3: View of the user interface
Table 1 Meanings of signalling diodes
Graphical symbol Designation Description
LED 1 LED indicating the unit's operation mode: NORMAL/BACKUP
AVR LED 2 LED signalling activation of the AVR system
LED 3 LED signalling activation of the EMERGENCY mode
Table 2 Optical (diode) signalling
LED 1 LED 2
LED 3 Operation mode
UNKNOWN
F NORMAL
BACKUP
STANDBY
READINESS
* EMERGENCY
INIT
STOP
F - the status may be configuration-dependent (none or red);
* - flashes
The unit is also equipped with an audible signalling system for its respective states
(cf. table).
Table 3 Audible signalling
Action Audible signalling
NORMAL mode None
BACKUP mode intermittent signal, rapidity dependent on the charge level of batteries
(the more rapid the signal, the lower the battery charge level)
Forced switch to the
STANDBY mode intermittent signal - two successive short signals followed by a pause
EMERGENCY mode Event dependent
Overload continuous signal
Short circuit rapid intermittent 50% / 50% signal
Overheat slow intermittent 50% / 50% signal
EPO activation intermittent sound/silence (1s / 5s) signal
All successive screens shown on the LCD are organised in a tree structure, as
presented in the following figure.

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
9
Figure 1: Organisation of screens

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
10
SCREENS
SCREENSAVER
Description: An information screen that is activated 5 minutes after the last press of
a button. This is accompanied by the switching off of the LCD panel's
backlight.
Type: read
Parameters Qak – charge level of batteries
Uak – battery section voltage
Owy – load handled by the power supply unit
Tau – anticipated autonomous time of the power supply unit
TrybPracy – operation mode of the power supply unit
i:, a: – additional information as per the table
Information Alarms
Abbreviation
Meaning Abbreviation
Meaning
L Charging ZW Short circuit
C Overload PC Overload
G Overheat PG Overheat
O Waiting following STANDBY AU Damaged battery
N 90 sec. of autonomous time
remaining EPO EPO
S Service BW Internal error
AP AVR - increasing voltage e.g.
a:PC
AO AVR - decreasing voltage
e.g.
i:S
Screen view:
Main menu

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
11
The main menu comprises tree screens. Switching between screens is effected by
means of the ▼▲ keys. A selection is confirmed by pressing the key, whereafter
a submenu may be selected in the chosen menu also by means of the ▼▲ keys.
The arrow on the left of the submenu name indicates the current position. Selections
are confirmed by the key. To proceed to a higher level, press the ESC key.
MEASUREMENTS submenu
The MEASUREMENTS submenu is divided into four topical groups: INPUT,
OUTPUT, BATTERY, TEMPERATURE.
INPUT 1/4
Description: Power supply unit input parameters
Type: read
Parameters U– input voltage of the power supply unit
I– input current of the power supply unit
f–input frequency of the power supply unit
PF – input coefficient of the power supply unit
P– input active power of the power supply unit
S– input apparent power of the power supply unit
Screen view:
OUTPUT 2/4
Description: Power supply unit output parameters
Type: read
Parameters U– output voltage of the power supply unit
I– output current of the power supply unit
f–output frequency
PF – output power coefficient
P– output active power
S– output apparent power

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
12
Screen view:
BATTERY 3/4
Description: Battery-related parameters
Type: read
Parameters U– battery section voltage
I– absolute battery current value
Q– charge level of batteries
(calculated for the current load)
Tau – anticipated autonomous time
StanAku. – indicates the degree of wear of the batteries; this value
is updated following the complete discharge of the
batteries if the TestAku parameter is switched on; 100%
(default value) means that the batteries are fully efficient
Screen view:
TEMPERATURE 4/4
Description: Temperature parameters
The temperature of unit's internal elements.
Type: read
Parameters T0 – temperature of internal elements of the unit
T1 – temperature of internal elements of the unit
Screen view:

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
13
CONTROL submenu
The CONTROL submenu is divided into three groups. The menu can be navigated in
the same way as described above. The user may alter the configuration of the power
supply unit only if individual items can be changed
under specific conditions. Cf. table hereunder.
Table. 4 Table of control flag changes
Operation mode
Control flag
UNKNOWN INIT NORMAL (MAINS) BACKUP STOP READINESS STANDBY EMERGENCY
AwaryjneWylaczenie X
●
●●
●
●
●
X
UPS X X
○○ ●
■
○ X
Buzzer X
□
□ □ □ □ □ □
Czas.Wyl.EPO X
□ □ □ □ □ □ □
UPS->STB/STB->UPS X X X
●
X X X X
KasujAwarie X X X X X X X
●
TestAku X
□ □ □ □ □ □ □
Screens are selected using the ▲▼ keys, and confirmation given by pressing . As
in the case of parameters, selections are made using the ▲▼ keys and confirmation
given by pressing the key. Two types of parameters have been included in the
CONTROL submenu. Some of them require repeated confirmation of an intended
change (by pressing ) or resignation without changing (pressing the ESC key), e.g.
AwaryjneWylaczenie. The modification of others consists in the appropriate
placement of a flag by selecting On or Off by means of the ▲▼ keys and
confirmation by pressing . Confirmation is followed by automatic passage to
a screen one level higher in the tree structure.
Once confirmed, a parameter is save in the unit's memory. The saving process itself
is signalled by the following messages:
-- Trwa zapis -- - saving in progress
-- Zapis OK -- - saving successfully completed
-- Blad zapisu -- - saving was unsuccessful, please try again
-- Zla wartość -- - a value outside the permitted range
The message appear briefly in the lower line of the screen, whereafter the system
automatically proceeds to a screen one level higher. This principle is used for all
modifiable parameters. An example of saving screens has been given hereunder.
X – change not allowed
●– only switch on
○– only switch off
□- switching
■– only switch on; switch off
possible only when waiting for a
minimal load

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
14
CONTROL 1/3
Description: Settings of power supply unit control flags.
Type: read/save
Parameters
AwaryjneWylaczenie – forced passage of the power supply unit to
the EPO mode from the user interface level
UPS – switching the power supply unit on/off
Buzzer – switching on/off of battery charge status
signalling for the BACKUP mode
Screen view:
CONTROL 2/4
Description: Settings of power supply unit control flags.
Type: read/save
Parameters Czas.Wyl.EPO – temporary deactivation (1 min.) of the EPO link.
UPS->STB – manual forcing of the STANDBY mode;
switching after a specified time
(CONFIGURATION 2/4; Opoz.STB)
KasujAwarie – deletion of EMERGENCY mode flags
Screen view:
CONTROL 3/3
Description: Settings of power supply unit control flags.
Type: read/save
Parameters
Test Aku – permission to update the battery status indicator
following the complete discharge of batteries
Screen view:

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
15
CONFIGURATION submenu
The CONFIGURATION submenu is divided into four groups. The menu can be
navigated in the same way as described above. The user may change the power
supply unit parameter values if the keypad is not locked.
Screens are selected using the ▲▼ keys, and confirmation given by pressing . As
in the case of parameters, selections are made using the ▲▼ keys and confirmation
given by pressing the key. The CONFIGURATION submenu contains numerical
parameters. Their modification consists in increasing or decreasing values by means
of the ▲▼ keys, and confirming by pressing . Confirmation is followed by
automatic passage to a screen one level higher in the tree structure. To resign from
modifying a parameter, press the ESC key.
CONFIGURATION 1/4
Description: Power supply unit parameters
Type: read/save
Parameters UWyjsciowe – output voltage of the power supply unit
UGornyProg – upper limit of the voltage correctness criterion for
the supply line
UDolnyProg – lower limit of the voltage correctness criterion for
the supply line
Screen view:
CONFIGURATION 2/4
Description: Power supply unit parameters
Type: read/save
Parameters AVRGornyProg – upper input voltage limit, at which the AVR system
(decreasing) is activated
AVRDolnyProg – lower input voltage limit, at which the AVR system
(increasing) is activated
Opoz.STB – delay time when switching to STANDBY mode
forced by the user
Screen view:

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
16
CONFIGURATION 3/4
Description: Power supply unit parameters
Type: read/save
Parameters Poj. z STB. – minimal charge level that the batteries
must attain in order for the power supply unit
to start up following a discharge
ProgKas.Prz. – load level at which the power supply unit
ceases to signal an overload
Screen view:
CONFIGURATION 4/4
Description: Power supply unit parameters
Type: read/save
Parameters Poj.Aku. – the capacity of batteries used
LiczbaSekcji – number of battery sections (the sum of
internal and external battery sections)
Pr.Ladowania – sum total of battery charging current
Screen view:

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
17
ALARMS submenu
The ALARMS submenu comprises two screens. The menu can be navigated in the
same way as described above. Screens are selected using the ▲▼ keys, and
confirmation given by pressing . Alarm screens inform about the type of alarm
which caused the power supply unit to switch to EMERGENCY mode.
ALARMS 1/2
Description: Power supply unit alarms.
Type: read
Parameters Zwarcie – short-circuit on the output of the power
supply unit
PrzeciąŜenie – excessive load connected to the output of
the power supply unit
Przegrzanie – excessive temperature of the internal
elements of the power supply unit
Screen view:
ALARMS 2/2
Description: Power supply unit alarms.
Type: read
Parameters AkuUszkodzony – damaged battery
EPO – signalling of the forced switch of the power
supply unit to the EMERGENCY (EPO) mode
BladWewnetrzny – internal device error, necessary to contact the
service shop
Screen view:

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
18
STATISTICS submenu
The STATISTICS submenu comprises four screens. The menu can be navigated in
the same way as described above. Screens are selected using the ▲▼ keys, and
confirmation given by pressing . The screens display information concerning the
operational history of the power supply unit.
STATISTICS 1/4
Description: Statistical data.
Type: read
Parameters Zanikow – the number of occurrences of events connected
with an input voltage decay
Spadkow – the number of events connected with a fall in
voltage to a value below the declared lower input
voltage
Wzrostow – the number of events connected with a rise in
voltage to a value above the declared upper input
voltage limit
Screen view:
STATISTICS 2/4
Description: Statistical data.
Type: read
Parameters PrzeciąŜen – the number of events connected with an overload
of the power supply unit
Przegrzan – the number of events connected with an overheat
of the power supply unit
Zwarc – the number of events connected with a short circuit
of the power supply unit's output
Screen view:

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
19
STATISTICS 3/4
Description: Statistical data.
Type: read
Parameters Rozładowan – the number of total discharges of the power supply
unit's batteries
AVR Podw. – the number of activations of the AVR system
resulting in an increase in voltage value
AVR ObniŜ. – the number of activations of the AVR system
resulting in a decrease in voltage value
Screen view:
STATISTICS 4/4
Description: Statistical data.
Type: read
Parameters Normalna – operating time of the power supply unit in NORMAL
mode
Rezerwowa – operating time of the power supply unit in BACKUP
mode
PrzeciąŜ. – operating time of the power supply unit in an
overload state
Screen view:

Instruction manual for SINLINE PRO 10000 series power supply units
2010/08/24 www.ever.eu
20
PANEL SETTINGS submenu
The PANEL SETTINGS submenu contains a single screen. The menu can be
navigated in the same way as described above. The user can change the values of
power supply unit parameters.
Confirm a screen by pressing , select a parameter by means of the ▲▼ keys and
confirm by pressing the key. The PANEL SETTINGS menu contains numerical
parameters. Their modification consists in increasing or decreasing values by means
of the ▲▼ keys, and confirming by pressing . Confirmation is followed by
automatic passage to a screen one level higher in the tree structure. To resign from
modifying a parameter, press the ESC key.
PANEL SETTINGS
Description: Settings of user interface parameters.
Type: read/save
Parameters: Kontrast – level of contrast of the LCD
Podswietlanie – level of backlight brightness of the display
Blok.Kl. – indicates that the keypad is locked; can be
changed only from the level of the control
programme; when the keypad is locked, parameters
cannot be changed
Screen view:
IDENTIFICATION submenu
The IDENTIFICATION submenu contains a single screen with information
concerning the device. To exit this screen, press the ESC key.
IDENTIFICATION
Description: Information about the device.
Type: read/save
Parameters: S– nominal output apparent power of the power supply unit
P– nominal output active power of the power supply unit
VH – hardware version
VF – firmware version
VP – communication protocol version
VFP – LCD panel firmware version
Screen view:
