Everdure DWF126SS Guide

INSTALLATION, OPERATION
& MAINTENANCE INSTRUCTIONS
FOR EVERDURE DISHWASHERS
Models Included:
DWF126SS
KIMBERLEY
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS

Compartment A:
Fill main-wash detergent.
Compartment B:
Fill pre-wash detergent.
(refer to instructions in section 3)
Mechanical indicator C.
Check the rinse aid level
Load the baskets
Select a programme
Close the door, t urn on the water tap and press the Start/Reset button. The machine will begin the cycle
in approximately 10 seconds.
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better. Unload the appliance, starting from the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions in section 4
Press the Programme button until the selected programme lights up.
( Refer to section “Operation instructions”)
When the working cycle has finished, the buzzer of the dishwasher will sound 8 times, then stop.
Turn off the appliance using the ON/OFF button.
If the appliance is switched
off during a wash cycle.
WARNING!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
as it was prior to being switched off.
Switch on the appliance
Press the On/Off button to switch on the appliance. Open the door.
1.Press the Start/Pause button to stop the dishwasher.
2.Wait 10 seconds before you open the door completely.
3.Add the forgotten dishes.
4.Close the door, press the the dishwasher willStart/PAUSE button,
continue its cycle in approximately 10 seconds.
Electric indicator on control panel.
Quick Operation Guide
For detailed operating instructions, please refer to the corresponding content under “Operating
Instructions” in section 2
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Hold down the Start/PAUSE button for more than 3 seconds to cancel the running programme.
3. Select a new programme.
4. Restart the dishwasher.
C
A B
Open the door carefully.
Hot steam may escape
when the door is
opened.

To review the section on troubleshooting Tips
will help you to solve some common problems
by yourself .
NOTE:
Dear Customer,
Please carefully read this manual before using the
dishwasher, it will help you to use and maintain the
dishwasher properly.
Pass it on to any subsequent
owner of the appliance.
This manual contains sections on safety Instructions,
Operating Instructions, Installation Instructions and
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development and updating of the product, may
make modifications without giving prior notice.
Read this Manual
Before Calling for Service
Keep it to refer to it at a later date.
If you can not solve the problems by yourself ,
please ask for the help of professional technicians.
Dishwasher Features......................................................3
5) Prior using for the first time...........................................7
6) Loading the Dishwasher Basket...................................10
Attention before or after loading the Dishwasher
Baskets........................................................................10
8) Maintenance and cleaning...........................................15
Filtering System..........................................................15
Caring for the Dishwasher..........................................17.
A. Fill the Rinse Aid Dispenser.................... .. .......7....... ...
B. Function of Detergent .................................8
............
Loading the upper Basket ........................ ..................11....
Loading the Lower Basket ...................... ...........11..
Cutlery Basket............................................................12
7) Starting a washing programe.......................................13
Wash Cycle Table.......................................................13
Turning on the Appliance.............................................14
Change the Programme...............................................14....
At the End of the Wash Cycle.....................................14
4) Installation instruction............................... .....................4..
Positioning the Appliance...............................................4..
Water Connection...........................................................5.
Power Connection..........................................................4.
Start of dishwasher.............................................................6..
9) Troubleshooting Tips........................................... .......18..
Before calling for service.............................................18.
Error codes................................................................19.
2) Safety Information.........................................................2
3) Operating Instructions....................................................3
Control Panel..................................................................3
1) Technical Information....................................................1
.......
.......
...
Anti Flood Device............................................................5

850
600
580
1175
Height : 850mm
Width : 600mm
Depth : 580mm
Voltage connected Load : see rating label
Water pressure: 0.04-1.0MPa
Hot water connection : max 60 degrees
Power supply: see rating label
Capacity: 12 Place settings
1
1. Technical Information

SAVE THESE INSTRUCTIONS
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY
WARNING! PROPER USE
2.IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING
WARNING!
WARNING! HYDROGEN GAS IS EXPLOSIVE
Under certain conditions, Hydrogen gas may be produced in a hot-water system that has not been used
for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been used
for such a period, before using the dishwasher turn on all hot-water faucets and let the water flow from
each for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable,
do not smoke or use an open flame during this time.
When using your dishwasher, follow the below basic precautions including the following:
· Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
· Do not operate your dishwasher unless all enclosure panels are properly in place. Ensure you press the
“START / RESET” button prior to opening the Dishwasher whilst it is operating to avoid water spray.
Please also ensure all care is taken whilst opening the door as hot steam may also be present.
· Do not place any heavy objects or stand on the door when it is open as this could overturn the
dishwasher.
· When loading items in to the dishwasher:
o Locate sharp items so that they are not likely to damage the door seal;
o Warning: knives and other utensils with sharp points must be loaded in the basket with their points down
or placed in a horizontal position.
· Do not wash plastic items unless they are marked dishwasher safe or the equivalent. Please check the
manufacturer’s recommendations for items that are not marked such as plastic, ceramic or pots.
· Use only detergent and rinse additives designed for an automatic dishwasher. Never use soap, laundry
detergent, or hand washing detergent in your dishwasher.
· Other means for disconnection from the supply must be incorporated in the fixed wiring with at least 3mm
contact separation in all poles.
• This Dishwasher is intended for single family domestic use only.
· The appliance is not intended for use by young children or infirm persons without supervision.
Ensure the dishwasher door is not open in full when unused to avoid potential tripping hazards.
· Warning: Dishwasher detergents can be extremely dangerous if swallowed as they are high in alkaline.
Avoid contact with skin and eyes and ensure children are not present when opening the door of the
dishwasher. Also check that the detergent receptacle is empty after completion of the wash cycle.
· If the supply cord is damaged, it must be replaced by the manufacturer or its service centre or a
similarly qualified person in order to avoid a hazard.
· Please dispose of the packing materials appropriately.
· Use the dishwasher only for its intended function.
· During installation, the power cord must not be excessively or dangerously bent or flattened.
· Do not tamper with controls.
· The appliance is to be connected to the water mains using the new hose set supplied. Do not reuse old
or existing hose sets.
2

10 11
Back View
Front view
3.Operation Instruction
3
Dishwasher Features
Control Panel
instructions before using it for the first time.
To maintain the best performance from your dishwasher, read all operating
IMPORTANT
Main Filter
Detergent Dispenser
Cup Shelf
Cutlery Basket
Coarse Filter
Rinse Aid Dispenser
Inlet pipe connector
Drain pipe connector
Lower Basket
Spray Arms
Upper Basket
1
5
6
7
8
9
10
11
3
2
4
1
2
3
4
5
6
7
8
9
56
2
1
3478
7
8Program selection knob: being used to select
desired wash program.
1Power button: To turn on/off the power supply.
2Power indicator: To show the power supply.
Delay time indicator :3, 6, or 9 hours can be selected.
4
5Delay button: press the button to select desired
delay time
3Rinse aid indicator: To come on when the
dispenser needs to be refilled.
6
Program indicator: To show washing program.
START/PAUSE button: being used to start or
pause machine.
3h
6h
9h

Electrical Requirements
Ensure the voltage and frequency of the power corresponds to
those on the rating plate. Only insert the plug into an electrical socket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate for the plug, replace the socket, rather than using adaptors or the like as
they could cause overheating and burns.
Electrical Connection
Ensure appropriate
ground is evident
prior to use
GROUNDING INSTRUCTIONS
4.Installation instruction
Please see the rating label to identify the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp, time delay fuse or circuit breaker recommended and provide separate circuit serving
only this appliance.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
electric shock by providing a path of least resistance for the electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and an earthing plug. The plug must be plugged into an
appropriate outlet that is installed and earthed in accordance with all local standards and requirements.
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides,
along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can
be positioned either to the right or the left sides to facilitate proper installation.
Levelling the Appliance
Once the appliance is positioned for leveling, the height of the dishwasher
may be altered via adjustment of the screwing level of the feet. In any case,
the appliance should not be inclined more than 2 DEGREES TO ENSURE
CORRECT OPERATION
Positioning the Appliance
Power Connection
WARNING!
For personal safety:
DO NOT USE AN EXTENSION LEAD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING
CONNECTION FROM THE POWER CORD.
n
n
n
for personal safety:
DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE
FROM THE POWER CORD.
EARTHING
CONNECTION
n
n
WARNING!
I mproper connection of the equipment earthing conductor can result in the risk of an
Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly earthed.
I f the plug does not fit properly. Do not modify the plug provided with the appliance.
n
n
n
4
electric shock.
Please have a qualified electrician to install a proper outlet.

To reduce the water remaining in the inlet hose, please close
the water connection after use.
WARNING!
5
A hose that attaches to a sink spray can burst if it is installed on the same water line as the dishwasher. If your sink has
one, it is recommended that the hose be disconnected and the hole plugged.
WARNING!
ABOUT THE ANTI FLOOD DEVICE
How to Connect the safety supply hose
Pull The safety supply hoses completely out from storage compartment located at rear of dishwasher.
Turn water fully on before starting the dishwasher.
1
Tighter the screws of the safety supply hose to the faucet with thread 3/4inch.
The safety supply hose consists of the double walls. The hose's system guarantees its intervention by blocking the flow of
water in case of the supply hose breaking and when the air space between the supply hose itself and the outer corrugated
hose is full of water.
Turn off the water.
Release the water pressure by depressing the pressure release button. This relieves water pressure and protects you, and the
room, from severe splashing.
Unscrew The safety supply hose from the faucet..
3
2
1
How to Disconnect the safety supply hose
2
3
The appliance must be connected to the water mains using new hose-sets.
The old hose-sets should not be reused.
Water pressure must be between 0,04 MPa and 1 MPa. If the pressure is below the minimum
consult our Service Department for advice.
COLD WATER CONNECTION
HOT WATER CONNECTION
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the
water is clear and free of impurities. If this precaution is not taken, there is a risk that the water inlet can get blocked and
damage the appliance.
The water supply to the appliance can also be connected to the house hot water line (centralized system, heating system),
as long as it does not exceed a temperature of 60 C. In this case, the wash cycle time will be shortened by about 15 minutes
and the wash efficiency slightly reduced.
The connection must be made to the hot water line following the same procedures as those for the connection to the
cold water line.

The following things should be checked before starting the dishwasher.
Start of Dishwasher
1 Whether the dishwasher is level and fixed in to position.
2 Whether the inlet valve is opened.
3 Drain hose connected has the plug in waste tee been opened for drainage
4 Whether there is leakage at the hose connections
5 Whether the power cord is connected and power switched on.
6 Whether the inlet and drain hoses are kinked (as per page 4).
7 All packing materials and printings should be taken out from the dishwasher.
8 Can the spray arms rotate freely
If the sink is 100cm higher from the floor, the excess water in hoses cannot be drained directly
into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable
container that is held outside and lower than the sink.
How to Drain Excess Water From Hoses
Water Outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water inlet hose is not kinked or squashed.
Syphon Connection
Extension Hose
If you need a drain hose extension, make sure to use a similar drain hose.
It must be no longer than 4 metres; otherwise the cleaning effect of the dishwasher could be reduced.
The waste connection must be at a height of between 40 cm (minimum) and 100 cm (maximum)
from the bottom of the dish. The water drain hose should be fixed by a hose clip. The free end of
the hose must not be immersed in water.
6
Drain hose Connection
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to
avoid bending or crimping. Use the special plastic support that comes with the appliance. The free end of the hose
must be at a height between 40 and 100cm and must not be immersed in water.
Max 1000mm
Min 400mm
FRONT VIEW
Inlet pipe connectorDrain pipe connector
POWER OUTLET
SINK
DISHWASHER
Min 100mm
WARNING!
DO NOT BEND IN ANY WAY !

Before using your dishwasher for the first time:
5.Prior using for the first time
7
A. Fill the rinse aid dispenser
B. Fill in detergent
A. Fill the Rinse Aid Dispenser
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave
spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to
use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent dispenser. To fill the
dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely black.
The volume of the rinse aid container is about 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean up any rinse aid spilled during filling with an absorbent cloth to avoid excessive foaming
NOTE:
You can estimate the amount of rinse aid required from the colour of the optical level indicator “C” located next to
the cap. When the rinse-aid container is full. the whole indicator will be dark. As the rinse-aid diminishes, the size
of the dark dot decreases. You should never let the rinse aid level fall 1 / 4 full. The front panel also has a LED
indicator that will illuminate once you reach below the 1/4 level.
C (Rinse-Aid indicator)
1 2 3

8
Adjusting Rinse Aid Dispenser
The rinse aid dispenser has six or four settings. Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "2".
(Factory setting is "2".)
NOTE:
Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish stains on your dishes or a bluish film on glassware or
knife blades.
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of the commercial quality detergents are suitable for this purpose.
B. Function of Detergent
Based on their chemical composition, detergents can be split in two basic types:
The use of the “normal” washing program in combination with concentrated detergents
reduces pollution and is good for your dishes; these wash programs are specifically matched
to the dirt-dissolving properties of the enzymes of the concentrated detergent. For this reason
normal wash programs in which concentrated detergents are used can achieve the same
results that can otherwise only be achieved using intensive programs.
Detergent tablets of different brands dissolve at different speeds. During shorter programes,
it is recommended that you use powder or liquid to ensure the detergent will dissolve and
perform as required. Tablets will often perform ideally during longer programs and higher
temperatures.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table. Generally , only one tablespoon of detergent is required for
a normal wash load. Heavily soiled items require more detergent. Always add the detergent
just before starting the dishwasher, otherwise it could get damp and will not dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Adjust lever
(Rinse)
MAX

Amount of Detergent to Use
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Do no add powdered detergent into the dispenser until you're ready to wash dishes.
Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
WARNING!
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
NOTE:
9
Your dishwasher is equipped with an All in 1 program that requires no salt and rinse aid. You simply
add the All in 1 tablet in the wash cycle detergent and select the All in 1 program. Only the All in 1
function (for the program: Intensive/Heavy/Normal/All in 1) can be used with All in 1 tablets. If you
use All in 1 tablets in other programs, the dishwasher may not perform as required.
NOTE:
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
Please observe the manufacturers dosing and storage recommendations as stated on the detergent packaging.
If the dishes are heavily soiled, place an additional
Close the lid and press until it locks in place.
Pre-wash cycle detergent.
B
Wash cycle detergent.
A
illustrated on the right:
The marking indicates the dosing levels , as
Fill the detergent dispenser with detergent.
Fill in Detergent
Push latch to open
1 2
Detergent tablet
Detergent powder
AB

To prevent water dripping from the upper basket into the lower basket, we recommend that you empty the lower basket
first and then the upper basket
6.Loading the Dishwasher Baskets
For washing in the dishwasher the following cutlery/dishes
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become
dull after a large number of washes
Silver and aluminium parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not touch.
Load large items which are most difficult to clean into the lower basket.
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
Recommendation
Consider buying utensils that are identified as dishwasher-proof.
Use a mild detergent that is described as. If necessary, seek further
information from the detergent manufacturers.
For particular items, select a program with as low a temperature as possible.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery baskets may vary from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded at a slant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
NOTE:
Very small items should not be washed in the dishwasher as they could easily fall out of the basket
Attention before or after loading the Dishwasher Baskets
Removing the Dishes
10

11
The upper basket is designed to hold more delicate and lighter dishware
such as glass cups, coffee and tea cups and saucers, as well as plates,
small bowls and shallow pans (as long as they are not overly soiled).
Position the dishes and cookware so that they will not be moved by the
spray of water.
Loading the Upper Basket
We suggest that you place large items and items that are the most difficult to clean into the lower basket
such as: pots, pans, lids, serving dishes and bowls, as shown in the figure below.
It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the
top spray arm.
Loading the Lower Basket
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
2
Glasses
1
Cups Saucers
3
6
Soup plates
5
Dinner plates
Dessert dishes
Cutlery basket
7
4
IN
IN
6
7
5
4
3
5
44
3
1
2
2
2
1
2
1
22
1
22
Saucers
3

12
Cutlery should be placed in the cutlery basket with the handles at the bottom. If the rack has side baskets, the
spoons should be loaded separately into the appropriate slots, especially long utensils should be placed in the
horizontal position at the front of the upper basket as shown in the picture.
Folding Spikes of Lower Basket
For better stacking of pots and pans,
the spikes can be folded down as
shown in the picture right.
Cutlery Basket
Ensure that no item extends through the bottom.
Always load sharp utensils with the sharp point down!
WARNING!
IN
both for the upper/lower basket. The height of the upper basket can be adjusted by placing the
wheels on different height of the rails. Long items, serving cutlery, salad servers and knives
should be placed on the shelf so that they do not obstruct the rotation of the spray arms.
The shelf can be folded back or be removed when not required for use.
Adjusting the Upper Basket
The height of the upper basket can be adjusted in order to create more space for large utensils
Teaspoons
4
Soup spoons
2
Forks
1
Knives
5
3Dessert spoons
For personal safety and a quality cleaning, place the silverware in the basket
making sure that:
They do not nest together.
Silverware is placed with the handles-down.
Ensure knives and other potentially dangerous utensils are placed with handles-up.
4
4
2
4
4
4
4
4
4
4
1
1
1
1
1
1
1
1
1
4
4
4
1
1
1
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
3
In

7.Starting a washing program
Wash Cycle Table
13
We recommend you open the door slightly 50mm to assist in drying of the dishes after every wash.
NOTE:
NOTE:
*AS/NZS 2007.1: This programe is the test cycle. The information for comparability test
in accordance with AS/NZS 2007.1 , as follows:
Capacity: 12 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
Meaning: need to fill Rinse-Aid Dispenser.
( )
(*AS/NZS 2007.1)
Intensive
Detergent
pre/main
Cycle Selection
Information
Program Running
time(min) Water
(L)
Energy
(Kwh)
Rinse
Aid
5/25g
5/25g
5/25g
For the heaviest soiled
loads, such as pots, pans,
casserole dishes and dishes
that have been sitting with
dried food on them for a
while.
A shorter wash for lightly
soiled loads that do not
need drying.
Pre-wash(50¡)
Pre
Wash (65¡)
Rinse
Rinse
Rinse (55¡)
Drying
Wash (40¡)
Rinse
Rinse (45¡)
20g.
160
110
130
30
1.2
0.82
1.4
0.45
22
16
12
12
Description
of Cycle
/
8
4
0.01
Pre-wash
12 155 1.2
3in1
1Pcs
For normally soiled loads,
such as pots, plates, glasses
and lightly soiled pans.
standard daily cycle.
Pre-wash 50¡
wash 50¡
rinse
rinse 70¡
drying
RAPID
SOAK
All in1
Heavy
Normal
For heavily soiled loads,
such as pots, plates, glasses
and lightly soiled pans.
standard daily cycle.
For normally soiled loads,
such as plates, glasses,
bowls and normally
soiled pans.
Pre-wash(50¡)
Wash (50¡)
Rinse
Rinse (65¡)
Drying
Wash (55¡)
Rinse
Rinse
Rinse (50¡)
Drying
To rinse dishes that you
plan to was later that day.

WARNING! It is dangerous to open the door when washing, as hot water could spray outside the
dishwasher and scald you.
When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Switch Off the Dishwasher
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turn off the water tap!
The buzzer of the dishwasher will sound for 8 seconds, only in this case the programme has ended.
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and will improve the drying process.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
Turning On the Appliance
Change the Program...
Forgot to Add a Dish?
the machine will resume after 10 seconds.
off the main power and water supply before calling for service assistance.
If you open the door during washing, the machine will pause. When you close the door ,
.
If all the lights begin to glimmer, that indicates the machine is out of order, please turn
.
NOTE:
NOTE:
At the End of the Wash Cycle
14
Premise:
You can modify the washing program in the initial stages of the cycle .
If the detergent has already been released, the appliance may have
already drained the wash water. If this is the case, the detergent dispenser must be
refilled (see the section entitled " Loading the Detergent " ).
Hold down
Entitled " Starting a wash cycle".
1
2 the button of desired program more than 3 seconds until it's Indicator is on , after
10 seconds the machine will resume.
The program lights show the state of the dishwasher:
a) All program lights off---------------stand by
b) One of the program lights on----------pause
c) One of the program lights blinking----- run
and press START/PAUSE button , the machine will resume after 10 seconds.
If you open the door , the machine will pause. When you close the door , during a wash cycle
NOTE:
Premise:
A cycle that is underway can only be modified if it has only been running for a short
time. Otherwise, the detergent may have already been released, and the appliance may
have already drained the wash water. If this is the case, the detergent dispenser must
be refilled (see the section 3(B) entitled “Function of Detergent” ).
When you hold the start/reset button more than 3 seconds, you can cancel the running
programme and select other programmes (see the section entitled " Starting a wash cycle. . . " ).
1
2
A forgotten dish can be added at any time before the detergent cup opens.
Load the forgotten dishes.
Close the door, press START/PAUSE button the dishwasher
will resume again after 10 seconds.
Wait 10 seconds before opening the door.
2
Press the Start/Pause button to stop the dishwasher.
13
4

8.Maintenance and Cleaning
The filter prevents larger remnants of food or other objects from getting inside the pump.
The residues may block the filter, in this case they must be removed.
The filter system consists of a coarse filter, a main filter,
and a micro filter (Fine filter).
Food and soil particles trapped in this filter are pulverized by a
special jet on the lower spray arm and washed down to drain.
Larger items, such as pieces of bones or glass, that could block
the drain are trapped in the coarse filter. To remove the items
caught by the filter, gently squeeze the tap on the top of this
filter and lift out.
This filter holds soil and food residues in the sump area and
prevents it from being redeposited on the dishes during wash cycle.
Main filter 1
Coarse filter 2
Fine filter 3
2
3
1
Filtering System
Filter assembly
The filter efficiently
For best performance and results, the filter must be cleaned regularly. For this reason, it is a good idea to
remove the larger food particles trapped in the filter after each wash cycle by rinsing the semicircular filter and
cup under running water. To remove the filter device, pull the cup handle in the upward direction.
removes food particles from the wash water, allowing it to be recycled during the cycle.
WARNING!
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the performance level of the appliance
and damage dishes and utensils.
n
n
Step 1 Turn the filter in anti-clockwise direction,
then lift it up.
Step 2 Lift the Main filter up
Step 3 Lift the Fine filter up
NOTE:
15
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.

or Holidays
How to Maintain Your Dishwasher
It is recommend that you run a wash cycle with the
dishwasher empty and then remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
seals to last longer and prevent odours from forming
within the appliance.
If the appliance must be moved, try to keep it in the
vertical position. If absolutely necessary, it can be
positioned on its back.
One of the factors that cause odours to form in the
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
After every wash, turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odours are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water an a little
vinegar, or a cleaning product made specifically for
dishwashers.
After Every Wash
Remove the Plug
No Solvents or Abrasive Cleaning Moving the Appliance
Seals
When not in Use for Extended Periods
16

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Protect Against Freezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottom of the tub and use a sponge to soak up water in the sump.
please take frost protection measures on the dishwasher in winter. Every time after washing cycles,
please operate as follows:
Caring for the Dishwasher
- Inspect the filters for blocking after every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and
clean the filters under running water.
Remarks:
Cleaning the Filter
Cleaning The Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble the filter parts as shown in the figures
on the last page and reinsert the entire assembly in the dishwasher, positioning it in its seat and pressing downwards.
The entire filter assembly should be cleaned once a week.
When cleaning the filters, be careful not to bend them as it will affect the
performance of the dishwasher
WARNING!
NOTE:
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
WARNING!
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
n
n
17
NOTE:
Please contact a professional service provider in the event your dishwasher cannot operate
due to ice formation.
Cleaning the Spray Arms
It is necessary to clean the spray arms regularly as water chemicals will clog the spray arm jets and bearings.
Screw the nut clockwise to take out the washer on top of the spray arm
and remove the arm.
Remove the upper spray arms
To remove the lower spray arm, pull out the spray arm upward.
Remove the lower spray arms
Wash the arms
Wash the arms in soapy and warm water and use a soft brush to clean the
jets. Replace them after rinsing them thoroughly.
