Everdure DWF146PS Guide

INSTALLATION, OPERATION
& MAINTENANCE INSTRUCTIONS
FOR EVERDURE DISHWASHERS
Models Include:
DWF146WE
DWF146PS
DWF146SS DESIGNED TO PERFECTION

Compartment A:
Fill main-wash detergent.
Compartment B:
Fill pre-wash detergent.
(Follow the user instructions!)
Mechanical indicator C.
Check the rinse aid level
Load the racks
Select a programme
Turn on the water tap and press the Start/Reset button. The machine will start working
after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the racks
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better. Unload the appliance, starting from the lower basket.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the racks. Refer to the dishwasher loading instructions.
Close the door, press the Programme button until the selected programme lights up.
(See the section entitled ”Operating instructions”)
When the working cycle has finished, the buzzer of the dishwasher will sound 8 times, then stop.
Turn off the appliance using the ON/OFF button.
Switch on the appliance
Press the On/Off button to switch on the appliance, Open the door.
Electric indicator on control panel (if provided).
Quick operation guide
For detailed operating method read the corresponding content on the instruction manual.
C
B
A
Changing the programme
Add forgotten dishes in the
dishwasher.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hot steam may escape
when the door is opened.
WARNING!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state.
1. Press start/stop button, wait 10 seconds & open the door a little.
2. After the spray arms stop working, you can open the door completely.
3. Add the forgotten dishes.
4.Close door, press start/stop button & the dishwasher will start running
again after 10 seconds.
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Reset button for more than 3 seconds to cancel the running programme.
3. Select a new programme.
4. Restart the dishwasher.

To review the section on troubleshooting Tips
will help you to solve some common problems
by yourself .
NOTE:
Dear Customer,
Please carefully read this manual before using the
dishwasher, it will help you to use and maintain the
dishwasher properly.
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions,
Operating Instructions, Installation Instructions and
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development and updating of the product, may
make modifications without giving prior notice.
Read this Manual
Before Calling for Service
Keep it to refer to it at a later date.
If you can not solve the problems by yourself ,
please ask for the help of professional technicians.
Dishwasher Features.................................... ...2
3) Prior using for the first time...............................3
4) Loading the Dishwasher Racks.........................6
Attention before or after loading the Dishwasher
Racks.............................................................6
6) Maintenance and cleaning...............................11
Filtering System.............................................11
Caring for the Dishwasher..................... .........12.
A. Fill the Rinse Aid Dispenser............... .. ..3..... ...
B. Function of Detergent ..........................4........
Loading the upper ................ ..............7Rack... ...
Loading the Lower ...................... ........7Rack... ..
Cutlery Basket................................................8
5) Starting a washing program..............................9
Wash Cycle Table............................................9
Turning on the Appliance..................................9
Changing the Program................ ................10....
At the End of the Wash Cycle...........................10
7) Installation instruction...................... ............13..
Positioning the Appliance................... ..........13..
Water Connection.................................. .......14.
Electrical Connection............................. .......13.
Before Starting the Dishwasher................ ......15..
8) Troubleshooting Tips................................ ....15..
Before calling for service........................... .....16.
Error codes.................................... ..............15.
Technical information.............................. .....15..
1) Safety Information..........................................1
2) Operating Instructions.....................................2
Control Panel...................................................2

KEEP THESE INSTRUCTIONS
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY
1.IMPORTANT SAFETY INFORMATION: READ ALL OF
THE INSTRUCTIONS BEFORE USING APPLIANCE
1
WARNING! HYDROGEN GAS IS EXPLOSIVE
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of an electric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
WARNING!
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance. If it does not fit
the outlet have a proper outlet installed by a
qualified electrician.
Under certain conditions, Hydrogen gas may be produced in a hot-water system that has not been
used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.
If the hot-water system has not been used for such a period of time, before using the dishwasher turn
on all the hot-water taps and let the water flow from each of them for several minutes. This will release
any accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame during
this time.
WARNING! PROPER USE
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. Please
c
heck th
e
manufacturer's recommendations for items that are
not marked such as plastic, ceramic or pots.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not operate your dishwasher unless all
enclosure panels are properly in place.
When loading items:
1) Locate sharp items so that they are not likely
to damage the door seal;
2) Warning: Knives and other utensils with
sharp points must be loaded in the basket
with their points down or placed in a
horizontal position.
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
The appliance is to be connected to the water
mains using new hose sets.
The maximum number of place settings to be
washed is 14.
The maximum permissible inlet water pressure is
1Mpa.
The minimum permissible inlet water pressure is
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by person
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
s
When using your dishwasher, follow the precautions listed below:
WARNING!
Do not place heavy objects, or stand on the door
when it is open.
Other means for disconnecting from the supply
must be incorporated in the fixed wiring with at
least 3mm contact separation in all poles.
This dishwasher is intended for single family
domestic use only.

10 11
Back View
Front view
2
Dishwasher Features
Main Filter
Detergent Dispenser
Cup Shelf
Cutlery Basket
Coarse Filter
Rinse Aid Dispenser
Inlet pipe connector
Drain pipe connector
Lower Rack
Spray Arms
Upper Rack
1
5
6
7
8
9
10
11
3
2
4
1
2
3
4
5
6
7
8
9
2.Operation Instructions
Control Panel
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
IMPORTANT
31
6542
78
2
3
4
1Power indicator light: To show the power supply.
Start /Reset button: To start the selected
washing program or reset the washing program
when the machine is working.
Rinse aid warning light: To show
when the dispenser needs to be refilled.
Power switch: To turn on/off the power supply.
5Washing Program Selector
the six washing programs.
: To select one of
7
8
6Program indicator lights: To show the washing
program that has been selected.
Delay Button : Press the button to delay start.
Delay time/Washing Phases indicator light:
When you delay time(3, 6, 9, or 12 hours), the
indicators light will be on to show one of the
delay time. When the machine is working, the
indicators will be on to show one of the washing
phases of cycle.
1 HOUR
HEAVY
Finish light: To show when program has
finished

Before using your dishwasher for the first time:
3.Prior to using the appliance for the first time
3
A. Fill the rinse aid dispenser
B. Fill in detergent
A. Fill the Rinse Aid Dispenser
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave
spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to
use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent dispenser. To fill the
dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely black.
The volume of the rinse aid container is about 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinse aid for the dishwasher. Never fill the rinse aid dispenser with any
(e.g. Dishwasher cleaning agent, liquid detergent) as this would damage the appliance.
other substances
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with the "open" arrow and turning it to the closed (right) arrow.
1 2 3
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
Additionally to the rinse-aid warning light, you can estimate the amount from the colour
of the optical level indicator “ C” located next to the cap. When the rinse-aid container is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot will decrease. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean any excess rinse aid spilled while filling with an absorbent cloth to avoid excessive foaming
NOTE:
C (Rinse-Aid indicator)

4
Adjusting Rinse Aid Dispenser
The rinse aid dispenser has six settings. Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory setting is "4".)
Adjust lever
(Rinse)
NOTE:
MAX
Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish stains on your dishes or a bluish film on glassware or
knife blades.
Detergents with their chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Use only detergent specifically made for the use in dishwashers.
B. Function of Detergent
Based on their chemical composition, detergents can be split in two basic types:
The use of the “normal” washing program in combination with concentrated detergent
is specifically designed to dissolve the enzymes within the concentrated detergent to
help reduce the intensiveness of your wash. A “normal” wash with concentrated
detergent will give you the same results as an “intensive”wash with normal detergent.
Detergent tablets of different brands dissolve at different speeds. During shorter programs,
it is recommended that you use powder or liquid to ensure the detergent will dissolve and perform
as required. Tablets will often perform ideally during longer programs and higher temperatures.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table.
Generally, only one tablespoon of detergent is required for a normal wash load.
More heavily soiled items require more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes

Amount of Detergent to Use
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser until you're ready to wash dishes.
Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
WARNING!
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwashers.
If the lid is closed, press the release button and the lid will spring open.
NOTE:
5
Push latch to open
1 2
Detergent tablet
Detergent powder
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels, as
illustrated on the right:
Main wash cycle detergent.
Pre-wash cycle detergent.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
AB

4.Loading the Dishwasher Racks
For washing in the dishwasher the following cutlery/dishes
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery items or dishes
Pewter or copper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become
dull after a large number of washes
Silver and aluminium parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Not suitable Limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not touch.
Load large items which are most difficult to clean into the lower rack.
The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Do not wash dishes soiled with cigarette ash, candle wax, laquer or paint. Please ensure new dishware
is dishwasher approved when purchased.
Load hollow items such as cups, glasses, pans etc. with the opening facing downwards so that
water cannot collect in the container or a deep base.
Recommendations
Consider buying utensils which are identified as dishwasher-proof.
Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further
information from the detergent manufacturers.
For particular items, select a program with as low a temperature as possible.
To prevent damage, take glass and cutlery out of the dishwasher as soon as possible
after the program has ended.
(For the best performance of the dishwasher, please follow these loading guidelines.
Features and appearance of racks and cutlery baskets may vary with your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Place dishes in the dishwasher in following manner:
1.Items such as cups, glasses, pots/pans, etc. are placed upside down.
2.Curved items, or ones with recesses, should be loaded angled so that water can run off them.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in a way that the spray arms can rotate freely during washing.
NOTE:
Very small items should not be washed in the dishwasher as they could easily fall out of the rack.
Attention before or after loading the Dishwasher Racks
To prevent water dripping from the upper rack into the lower rack it is recommended that the lower rack is
emptied first, and then the upper rack last.
Removing the Dishes
6

7
The upper rack is designed to hold more delicate and lighter dishware such as glass cups, coffee
and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not overly spoiled).
Position the dishes and cookware so that they will not be moved by the spray of water.
Loading the Upper Rack
We suggest that you place large items and items that are the most difficult to clean into the lower rack
such as: pots, pans, lids, serving dishes and bowls, as shown in the figure below.
It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the
top spray arm.
Loading the Lower Rack
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be angled to allow water to flow out.
Please be reminded that:
The Bottom rack features folding spikes so that more or larger pots and pans can be loaded.
3
GlassesSaucers
2
1
Cups
IN
1
1
1
1
1
3
3
3
3
2
6
6
Dinner plates
5
5
5
Soup plates
Dessert dishes
4
Cutlery basket
7
IN
4
4
4
7

8
Cutlery should be placed in the cutlery basket with the handles at the bottom. If the rack has side baskets, the
spoons should be loaded separately into the appropriate slots. Especially long utensils should be placed in the
horizontal position at the front of the upper rack as shown in the picture.
Folding Spikes of Lower Rack
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture to the right.
Cutlery Basket
both for the upper & lower racks. The height of the upper rack can be adjusted by placing the
wheels on different rails. Long items, serving cutlery, salad servers and knives should be
placed on the shelf so that they do not obstruct the rotation of the spray arms.
The shelf can be folded back or be removed when not required for use.
Adjusting the Upper Rack
The height of the upper rack can be adjusted in order to create more space for large utensils,
Upper wheels
Lower wheels
Shelf
Ensure that no items extend
through the bottom.
WARNING!
Teaspoons
4
Soup spoons
2
Forks
1
Knives
5
3Dessert spoons
IN
5
4 4
5
5 5 5
5 5
2
3
2
3
2
3
2
3
2
3
23
2
3
4
1
1
1
1
1
1
14
4
4
4
4
4
4
41
1
1
1
1
1
2
3
2
3
2
3
2
3
2
3
2
3
2
43
1
5
5
5
5
5
5
4 4
5

5.Starting a washing program
9
Wash Cycle Table
15.0
Detergent
pre/main
Cycle Selection
Information
Heavy
Program
Intensive
Normal
Running
time(min) Water
(L)
155
Energy
(Kwh)
1.20
Rinse
Aid
3in1
3in1
For heaviest soiled crockery,
and normally soiled pots/
pans/dishes etc with dried
on soiling.
A shorter wash for lightly
soiled loads and .quick wash
For lightly soiled loads that
do not need excellent
drying efficiency.
Rapid
1 Hour
Pre-wash (50C)
Pre-wash
Wash (65C)
Rinse
Rinse
Rinse (55C)
Drying
Pre-wash (50C)
Wash (50C)
Rinse
Rinse (65C)
Drying
Wash (55C)
Rinse
Rinse
Rinse (50C)
Drying
Wash (40C)
Rinse (40C)
Rinse (45C)
20g.
20g.
Wash(55C)
Rinse
Rinse (50C)
Drying
Pre-wash (50C)
Wash (50C)
Rinse
Rinse (70C)
Drying
160
125
130
30
60
1.20
0.88
1.40
0.45
0.60
22.0
15.0
13.7
11.0
12.0
Description
of Cycle
NOTE:
NOTE:
Means: need to fill rinse into the Rinse-Aid Dispenser.
( )
Turning On the Appliance
Starting a cycle wash
1 lower & upper racks, load the dishes and push the racks back into place. It is recommended
that the lower rack be loaded first & then the upper rack. See these section entitled “loading the
dishwasher”.
2 Pour in the section entitled (see the section entitled “Detergent and Rinse Aid”).
3 Make sure power is connected and is turned on.
Make sure the water supply is turned onto full pressure.
4 Close the door, press the ON/OFF button, and the ON/OFF light will turn on.
5 Press the program button until the required setting is indicated. The wash program cycles through
in the following sequence:
3in1->Intensive->Heavy->Normal->1 Hour->Rapid;
If a program is selected, the appropriate program indicator will light. Then press the Start/Reset button & the
dishwasher will start.
Draw out the
(*AS/NZS 2007.1)
Standard daily cycle f
normally soiled loads, such
as pots, plates,glasses .
or
For heavily soiled loads,
such as pots, plates, glasses
and lightly soiled pans.
* : This program is the test cycle. The information for comparability test
in accordance with 2007.1 as follows:
AS/NZS 2007.1
AS/NZS
Capacity: 14 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
Open the door slightly 50mm to assist in drying of the dishes after every wash
For commonly soiled
loads, use multi-functional
detergent.

10
WARNING! It is dangerous to open the door when washing, because the hot water & steam may scald you.
When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloading the dishwasher
It is normal for the dishwasher to be wet inside.
Empty the lower rack first and then the upper one. This will avoid water dripping from the upper rack onto
the dishes in the lower one.
Forgot to Add a Dish?
At the End of the Wash Cycle
Changing the Program
If you open the door , the machine will pause. The program light will
stop blinking and the buzzer will sound every minute unless you close the door. Once
you close the door, press the start/restart button & the machine will restart working after
10 seconds.
during a wash cycle
NOTE:
Premise:
A cycle that is underway can only be modified if it has only been running for a short time. Otherwise, the
detergent may have already been released, and the appliance may have already drained the wash water.
If this is the case, the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent”).
Press the start/reset button for more than 3 seconds & the machine will go into the standby state. You can then
change the program to the desired cycle setting (see the section entitled " Starting a wash cycle. . ." ).
The program lights show the state of the dishwasher:
a) All program lights off--------------------------------------------------stand by
b) One of the program lights on-----------------------------------------pause
c) One of the program lights blinking-----------------------------------run
c) Some of the up three program lights blinking fast----------------error
1
2
3
NOTE:
When you press the Start/Reset button to pause during washing, the program light will
stop blinking and the dishwasher will sound every minute unless you press the
Start/Reset button to start again.
A forgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Wait 10 seconds for the spray arm to stop spraying &
then open the door a little.
14
5
6
Press the start/reset button
Press the start/reset button, the dishwasher will run
after 10 seconds.

6.Maintenance and Cleaning
The filter prevents larger remnants of food or other objects from getting into the pump.
This residue can occasionally clog up the filters.
The filter system consists of a coarse filter (flat main filter)
and a microfilter (Fine filter).
Food and soil particles trapped in this filter are pulverized by a
special jet on the lower spray arm and washed down to drain.
Larger items, such as pieces of bones or glass, that could block
the drain are trapped in the coarse filter. To remove the items
caught by the filter, gently squeeze the tabs on the top of this
filter and lift out.
This filter holds soil and food residues in the sump area and
prevents it from being redeposit on the dishes during wash cycle.
Main filter 1
Coarse filter 2
Fine filter 3
2
3
1
Filtering System
Filter assembly
The filters efficiently
For best performance and results, the filters must be cleaned regularly. For this reason, it is a good idea to
remove the larger food particles trapped in the filters after each wash cycle by rinsing the semicircular filter and
cup under running water. To remove the filter device, pull the cup handle in the upward direction.
remove food particles from the wash water, allowing it to be recycled during the cycle.
WARNING!
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the performance level of the appliance
and damage dishes and utensils.
n
n
1
2
Open
Step 1:£Turn the filter in anti-clockwise direction,
then lift it up.
Step 2:£Lift the Main filter up
3Step 3: Lift the Fine filter up
NOTE:
11
The filter system is replaced by following the same sequence in reverse.

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance cleaner.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Protect Against Freezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottom of the tub and use a sponge to soak up water in the sump.
Please take frost protection measures on the dishwasher in winter where temperatures drop below freezing.
Every time after use, please ask a service technician to:
Caring for the Dishwasher
- Inspect the filters for blockages every time after the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and
clean the filters under running water.
Remarks:
Cleaning the Filter
Cleaning The Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble the filter parts as shown in the figures
on the last page and reinsert the entire assembly in the dishwasher, positioning it in its seat and pressing downwards.
The entire filter assembly should be cleaned once a week.
NOTE:
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
n
n
n
Cleaning the Spray Arms
12
NOTE:
If your dishwasher cannot work because of ice, please contact professional a service technician.
To remove the spray arms, screw the nut off clockwise to
take out the washer on top of the spray arm and remove the
arm.
Wash the arms in warm soapy water and use a soft brush
to clean the jets.
Replace the parts after rinsing them thoroughly.
2
1
1
2

How to Keep Your Dishwasher in Shape
It is recommend that you run a wash cycle with the
dishwasher empty and then remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
seals to last longer and prevent odours from forming
within the appliance.
If the appliance must be moved, try to keep it in the
vertical position. If absolutely necessary, it can be
positioned on its back.
One of the factors that cause odours to form in the
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
Electrical Requirements
Ensure the voltage and frequency of the power being corresponds to
those on the rating plate. Only insert the plug into an electrical socket which is earthed
properly. Do not use adaptors to manipulate incompatible sockets.
Electrical Connection
Grounding is evident
prior to use
GROUNDING INSTRUCTIONS
7.Installation instructions
Please look at the rating label to identify the rating voltage and connect the dishwasher to the appropriate power supply.
Please use the required fuse 10 amp, time delay fuse or circuit breaker recommended and provide a separate circuit
serving this appliance only.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
electric shock by providing a path of least resistance for the electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and an earthing plug. The plug must be plugged into an
appropriate outlet that is installed and earthed in accordance with all local codes and ordinances.
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides,
along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can
be positioned either to the right or the left sides to facilitate proper installation.
Levelling the Appliance
Once the appliance is positioned for levelling, the height of the dishwasher
may be altered via adjustment of the screwing level of the feet. In any case,
the appliance should not be inclined more than 2 to ensure correct operation.
Positioning the Appliance
Electrical Connection
WARNING!
For personal safety:
DO NOT USE AN EXTENSION LEAD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING
CONNECTION FROM THE POWER CORD.
n
n
n
After every wash, turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odours are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water an a little
vinegar, or a cleaning product made specifically for
dishwashers.
After Every Wash
Remove the Plug
No Solvents or Abrasive Cleaning
Moving the Appliance
Seals
When not in Use for a LongTime
13

for personal safety:
DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE
FROM THE POWER CORD.
EARTHING
CONNECTION
n
n
Cold Water Connection
Drain hose Connection
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to
avoid bending or crimping. Use the special plastic support that comes with the appliance. The free end of the hose
must be at a height between 40 and 100cm and must not be immersed in water.
WARNING!
Improper connection of the equipment earthing conductor can result in the risk of an
electric shock.
Check with a qualified electrician or Service technician if you are in doubt whether the
appliance is properly earthed.
Do not modify the plug provided with the appliance. If the plug does not fit properly to the
outlet, please have a qualified electrician to install a proper outlet.
n
n
n
Water Connection
14
Max 1000mm
Min 400mm
FRONT VIEW
Inlet pipe connector
Drain pipe connector
POWER OUTLET
SINK
DISHWASHER
Min 100mm
WARNING!
DO NOT BEND IN ANY WAY !
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure
that it is fastened tightly in place.
If the water pipes are new or have not been used for an extended period of time, let the
water run to make sure that the water is clear. This precaution is needed to avoid the
risk of the water inlet to be blocked and damage the appliance.
When not being used for extended periods, please turn off the water supply tap.
WARNING!
Syphon Connection
The waste connection must be at a height of between 40 cm (minimum) and 100 cm (maximum)
from the bottom of the dish. The water drain hose should be fixed by a hose clip.
Extension Hose
If you need a drain hose extension, make sure to use a similar drain hose.
It must be no longer than 4 metres, otherwise the cleaning effect of the dishwasher could be reduced.
Water Outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water inlet hose is not kinked or squashed.
If the sink is more than 1000mm above the floor, the excess water in hoses cannot be drained directly
into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable
container that is held outside and lower than the sink.
How to Drain Excess Water From Hoses

15
The following things should be checked before starting the dishwasher.
Before Starting the Dishwasher
1 The dishwasher is level and fixed correctly into position
2 The water inlet valve is open
3 There is no leakage at the hose connections
4 The power is correctly connected & turned on
5 The spray arms can move freely
6 The inlet and drain hoses are not knotted and drain hose outlet is not blocked
7 All packing materials and printings have been taken out from the dishwasher
8.Troubleshooting Tips
WARNING!
If overflow occurs, turn off the main water supply before calling a service.
If there is water in the base pan because of an overfill or small leak,
the water should be removed before restarting the dishwasher.
n
n
Error Codes
When some malfunctions come on, the appliance will display error codes to warn you:
Overflow.
Codes Issue Possible Causes
Longer inlet time.
Tap is not opened, or water intake is restricted,
or water pressure is too low.
The Rapid light
flickers fleetly
The Normal light flashes fast
Dishwasher leaking.
Technical Information
850
600
600
1195
Height : 850mm
Width : 600mm
Depth : 600mm
Voltage connected Load : see rating label
Water pressure: 0.04-1.0MPa
Power supply: see rating label
Capacity: 14 Place settings

Problem Possible Causes What To Do
Fuse blown, or the
circuit breaker tripped
Replace fuse or reset circuit breaker. Remove any other
appliances sharing the same circuit with the dishwasher
Suds in the tub
Spilled rinse-aid Always wipe up rinse-aid spills immediately.
Review the charts on the following pages may save you from calling for service.
White film on
inside surface
There are rust
stains on cutlery
Knocking noise
in the wash cabinet
Rattling noise
in the wash cabinet
Knocking noise
in the water pipes
Hard water minerals
The affected items are
not corrosion resistant.
The lid of the softer
is loose
A sp ay arm is
knocking against
an item in a basket
r
Items of crockery
are loose in the
wash cabinet
This may be caused
by on-site installation
or the cross-section of
the piping.
A program was not
run after dishwasher
salt was added.
Traces of salt have
gotten into the wash cycle.
To clean the interior, use a damp sponge with
dishwasher detergent and wear rubber gloves.
Never use any other cleaner than dishwasher
detergent for the risk of foaming or suds.
Always run the quick wash program
without any crockery in the dishwasher and
without selecting the Turbo function (if present),
after adding dishwasher salt.
Check the lid is closed.
Interrupt the programme, and rearrange the items
which are obstructing the spray arm.
Interrupt the programme,
and rearrange the items of crockery.
This has no influence on the dishwasher function.
if in doubt, contact a suitably qualified plumber.
Stained tub interior Detergent with
colourant was used
Make sure that the detergent is the one without
colourant.
Improper detergent
Dishwasher doesn t
start
'
Make sure the dishwasher is turned on and the door is
closed securely.
Check that the water supply is connected properly and
the water is turned fully on.
Make sure to close the door properly and latch it.
Make sure the power cord is properly plugged into the
wall socket.
Power supply is not
turned on
Water pressure is low
Door of dishwasher
not properly closed.
water not pumped
from dishwasher
Kink in drain hose
Filter clogged
Kitchen sink clogged
Check drain hose. Check outlet is clear.
Check the coarse filter
(see section titled " Cleaning The Filter ")
Check the kitchen sink to make sure it is draining well.
If the problem is with the kitchen sink not draining, you may
need a plumber rather than a serviceman for dishwashers.
Use only the specialist dishwasher detergent to avoid
suds. If this occurs, open the dishwasher and let suds
evaporate. Add 4 litres of cold water to the tub. Close
and latch the dishwasher, then Start the "Rapid" wash
cycle to drain out the water. Repeat if necessary.
Before Calling for Service
16
problems
Technical
problems
General
Noise
Use corrosion resistant cutlery.

Problem Possible Causes What To Do
The dishes were not
loaded correctly.
See notes in " Loading the Dishwasher Baskets ".
The dishes
are not clean
Cloudiness
on glassware
Black or gray
marks on dishes
Detergent left in
dispenser cups
The dishes
are not drying
Select a more intensive programme.
See" Wash Cycle Table ".
Use more detergent, or change your detergent.
Rearrange the items so that the sp ay can rotate freely.r
Clean and/or fit the filter combination correctly.
Clean the spray arm jets. See "Cleaning the Spray
Arms".
Use less detergent if you have soft water and select
a shortest cycle to wash the glassware and to get
them clean.
Use a mild abrasive cleaner to eliminate those marks.
Re-loading the dishes properly.
Load the dishwasher as suggested in the directions.
Increase the amount of rinse-aid/refill the rinse-aid
dispenser.
Do not empty your dishwasher immediately after
washing. Open the door slightly so that the steam can
escape. Begin unloading the dishwasher only once
the dishes are barely warm to the touch. Empty the low
rack first. This prevents water form dropping off
dishes in the upper rack.
In short program the washing temperature is lower.
This also lowers cleaning performance. Choose
a program with a long washing time.
Water drainage is more difficult with these items.
Cutlery or dishes of this type are not suitable for
washing in the dishwasher.
The programme was
not powerful enough.
Not enough detergent
was dispensed.
Items are blocking
the path of spray arms.
The filter combination
in the base of wash
cabinet is not clean or
is not correctly fitted.
This may cause
the spray arm jets
to get blocked.
Combination of soft
water and too much
detergent.
Aluminum utensils
have rubbed against
dishes.
Dishes block
detergent cups.
Improper loading
Too little rinse-aid
Dishes are removed
too soon
Wrong program
has been selected
Use of cutlery with
a low-quality coating
17
Unsatis
-factory
washing
result
Unsatis
-factory
drying
result
A division of Shriro Australia Pty Ltd
104 Vanessa St Kingsgrove NSW 2208
In Australia: 1300 355 541
In New Zealand: [phone]
www.everdure.com
IM Ref: DWF146 12/2012/02FC
F OR I NDO O R U SE O NLY
