EverFocus EM900F EZ.HD SERIES User manual

EM900F eZ.HD Series
1080p Full High Definition
Micro Mini Metal Camera
User’s Manual
Copyright © EverFocus Electronics Corp.
Release Date: February 2016

2
Precautions
1. Do not install the camera near electric or magnetic fields. Install the camera away from
TV/radio transmitters, magnets, electric motors, transformers and audio speakers since the
electromagnetic fields generated from these devices may distort the video image or
otherwise interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor introduce
materials other than those recommended herein. Improper disassembly or introduction of
corrosive materials may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun. In some circumstances, direct sunlight may
cause permanent damage to the sensor and/or internal circuits, as well as creating
unbalanced illumination beyond the capability of the camera to compensate.
4. Keep the power cable away from water and other liquids and never touch the power cord
with wet hands. Touching a wet power cord with your hands or touching the power cord
with wet hands may result in electric shock.
5. Never install the camera in areas exposed to oil, gas or solvents. Oil, gas or solvents may
result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning. For cameras with interchangeable lenses, do not touch the surface of the sensor
directly with the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean
the sensor and the camera lens. Use a damp soft cloth to remove any dirt from the camera
body. Please do not use complex solvents, corrosive or abrasive agents for cleaning of any
part of the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power source
ratings. This camera is suitable for indoor operation only. Use the camera at temperatures
within -10°C~50°C (14°F~112°F) and humidity less than 80%; this device is not rated as
submersible. The input power source is 12VDC. Be sure to connect the proper + / - polarity
and voltage, as incorrect polarity or too high a voltage will likely cause the camera to fail,
and such damage is not covered by the warranty.
8. Mounting. Use care in selecting a solid mounting surface which will support the weight of
the camera plus any wind, snow, ice or other loading, and securely attach the camera to the
mounting surface using screws and anchors which will properly support the camera. If
necessary (e.g. when mounting to drop ceilings) use a safety wire to provide additional
support for the camera.

3
Safety Notice
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

4
Contents
1. Introduction...................................................................................................................... 5
1.1 Packing List .....................................................................................................................6
1.2 Features ..........................................................................................................................6
2. Overview .......................................................................................................................... 7
3. Installation and Adjustment .............................................................................................. 8
4. Configuration in the OSD Menu........................................................................................10
5. Specifications...................................................................................................................14

EM900F eZ.HD Micro Mini Metal Camera
５
1. Introduction
The EverFocus eZ.HD Series EM900F provides incredible performance in bright light or low light
environments and the resolution listed in the specification from the actual camera you install. To
take full advantage of the amazing resolution available from this advanced imaging technology, the
EM900F uses a fixed focal lens together with 1/2.8" SONY 2.43M pixels CMOS to deliver 1080p high
resolution.This camera truly provides HD images without compromising its 1080p video quality,
Digital Wide Dynamic Range for clear color images in the most challenging of bright or unbalanced
scene lighting conditions. The EM900F supports both NTSC and PAL scanning systems, which can be
switched via OSD.
Model
Sensor and
Lens
Resolu
tion Housing Lens Type Lens size Environmen t
EM900FP1 1/2.8” SNOY
2.43M pixels
CMOS
1080p Mini Metal
Case
Conical type 3.7mm
Indoor
EM900FP3 Flat face type 3.7mm
EM900FP4 Supercone type 3.7mm

EM900F eZ.HD Micro Mini Metal Camera
６
1.1 Packing List
Camera Body x 1 Power Pigtail Cable x 1
User Manual x 1
Warning Paper x 1
Power / Video Cable x 1
1.2 Features
1080p full HD with high flexibility and performance for astounding image
1/2 . 8 ” Sony 2.43M pixels CMOS sensor, delivering amazing high sensitivity
Astounding image quality from the 3.7mm conical/3.7mm flat/3.7mm cone lens
D-WDR to improve the visibility under high contrast scene
3D-Noise Reduction ensures less blurry moving subjects, vivid and high SN ratio images
even under low light environments
Supports 1080p, 720p & 960H analog signal output, which can be easily switched using
OSD Joystick
Compact metal case design is suitable for convert place, such as ATM
eZ.Controller function: Control camera OSD settings and PTZ operation directly from DVR
end

EM900F eZ.HD Micro Mini Metal Camera
７
2. Overview
Cable Description:
No. Name Descriptions
1 Power Input Connect to a 12 VDC
2 Video Output 1080p, 720p and 960H output, using a 75 Ohm BNC-type
coaxial cable.
3 DC Power Pigtail Cable Optional power pigtail cable. The red wire is positive (+);
while the black wire is negative (-).

EM900F eZ.HD Micro Mini Metal Camera
８
3. Installation and Adjustment
1. Connect the camera to a 12 VDC power source by using the supplied Power / Video Cable,
you can optionally use the supplied Power Pigtail Cable or a power adapter. (Refer to the
connection diagram as below )
2. Take the camera and turn it around, then configure the OSD menu by using the Joystick.
OSD indication as shown in the figure:
•Push the Joystick up / down to select
among menu items.
•Push the Joystick left / right to adjust the
level of the selected item.
•Press the Joystick to enter the submenu or
exit the OSD Setup Menu.

EM900F eZ.HD Micro Mini Metal Camera
９
Note: The function button is using to control direction, and also to switch video format and
video output. Please follow the detailed instruction as below to switch the camera to:
Switch between 1080p and 720p (Default, 1080p): Press Upward for 5 Seconds
Switch from HD (1080p / 720p) to 960H: Press Left for 5 Seconds
Switch from 960H to HD (1080p / 720p): Press Right for 5 Seconds
Switch between NTSC and PAL: Press Downward for 5 Seconds
3. Drill three holes on the position where you want to attach the camera. Unscrew the bracket
which located at the back of the camera, then screw the bracket to these holes.

EM900F eZ.HD Micro Mini Metal Camera
１０
4. Configuration in the OSD Menu
You can use the Joystick on the rear panel of the camera to configure camera settings in the OSD
menu. For details on the OSD menu structure as below:
No. Main Sub
Menu Sub Menu / Function
1 Lens DC Mode
Indoor
Outdoor
Min Shu. NTSC: 1/30
PA L : 1/2 5
Max. Shu.
NTSC: 1/60,FLK,1/240,
1/480,1/1000,
1/2000,1/5000,
1/10000, 1/50000
PAL: 1/50,FLK,1/200,
1/400,1/1000,
1/2000*,1/5000,
1/10000, 1/50000
Iris Speed 0 – 15
Manual
2 Exposure
Shutter
NTSC: 1/30, 1/60, FLK, 1/240, 1/480, 1/1000, 1/2000,
1/5000, 1/10000,
1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto
PAL: 1/25, 1/50, FLK, 1/200, 1/400, 1/1000, 1/2000, 1/5000, 1/10000,
1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto
AGC 0 – 15
Sens-up Off
Auto Sens-up X2, X4, X6, X8, X10, X15, X20, X25, X30
Brightne
ss 1-100
D-WDR
Off
On Level 0-8
Auto
Defog
Off
Auto
Pos/Size Position, Size,↑,↓,→,←
Gradation 0-2
Default
3 Backlight Off

EM900F eZ.HD Micro Mini Metal Camera
１１
BLC
Level Middle, High, Low
Area Position, Size,↑,↓,→,←
Default
HSBLC
Select Area1, Area2, Area3, Area4
Display Off
On Position, Size,↑,↓,→,←
Black Mask On/Off
Level 0-100
Model All Day
Night AGC Level 0-255
Default
4White
Balance
ATW
AWC→SET
Indoor
Outdoor
Manual Blue 1-500
Red 0-100
AWB
5
Day &
Night
Ext D→N(Delay) 0-60
N→D(Delay) 0-60
Auto
D→N(AGC) 1-255
D→N(Delay) 0-60
N→D(AGC) 1-255
N→D(Delay) 0-60
Color
B/W
Burst Off/On
IR Smart
Off
On
Level 0-15
Area Position, Size,↑,
↓,→,←
IR PWM Off
0-100
6 NR 2DNR Middle/Low/Off/High
3DNR Middle/Low/Off/High
7 Special Cam Title
Off
On 0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ▶→
←↑↓()ˉ-_▊/=&:~,.

EM900F eZ.HD Micro Mini Metal Camera
１２
D-effect
Freeze Off/On
Mirror Off, Mirror, V-flip, Rotate
Neg. Image Off/On
Motion
Off
On
Select Area1,Area2,Area3,Area4
Display On Position, Size,↑,↓,→,←
Off
Sensitiv
ity 0-100
Color Green, Blue, White, Red
Trans 1.00,0.75,0.50,
0.25
Alarm
View Type Off, Block, Outline, All
OSD View On/Off
Alarm Out On/Off
Time 1-15
Default
Privacy
Off
On
Select Area1,Area2,Area3,Area4
Display
Off
Color Position, Size,↑,↓,→,←
Mosaic Position, Size,↑,↓,→,←
Inv Position, Size,↑,↓,→,←
Color White, Black, Red, Blue, CYAN, Yellow,
Green
Trans 1.00,0.75,0.50,
0.25
Default
Language ENG/CHN1/CHN2/GER/FRA/ITA/SPA/POL/RUS/POR/NED/TUR
Defect
Live DPC
Off
On AGC level 0-255
Level 0-100
White DPC
Off
On
Pos/Size Position, Size,↑,↓,→,←
Start Close the iris then press
DPC View Off/On
Level 0-60

EM900F eZ.HD Micro Mini Metal Camera
１３
AGC 0-14
Sens-up x2, x4, x6, x8,x10, x15, x20,
x25, x30
Black DPC
Off
On
Pos/Siz Position, Size,↑,↓,→,←
Start Press Enter
DPC View Off/On
Level 0-255
RS485
CAM ID 0-255
ID Display Off/On
Baud Rate 2400,4800,9600,19200 ,38400
8 Adjust
Sharpness
Off
Auto
Level 0-10
Start AGC 0-255
End AGC 0-255
Monitor
CRT Blue Gain 0-100
Red Gain 0-255
LCD
Gamma
User,0.45,0.50,0.55,0.60,0.6
5,0.70,0.75,0.80,0.85,0.90,
0.95,1.00
Blue Gain 0-100
Red Gain 0-100
LSC Off/On
Video. Out PAL/NTSC
9 AF
AF Mode
Semi.
Auto
Manual
One Shot AF
TDN AF On
Off
Lens Init.
10 Exit Save& END /Reset/Not Saved

EM900F eZ.HD Micro Mini Metal Camera
１４
5. Specifications
Specifications and designs are subject to change for improving the functionality of this product
without notice.
Part Number EM900FP1 EM900FP3 EM900FP4
Lens Type
3.7mm Conical
3.7mm Flat
3.7mm cone
Pickup Device 1/2.8” Sony 2.43M pixels CMOS
Video Format NTSC/PAL(can be switched via OSD)
Effective Pixels 1920(H) x 1080(V)
Scanning System Progressive Scan
Sensitivity 0.2 Lux
Electronic Shutter Auto/Manual(x30~1/50,000)/FLK
Gamma Correction 0.45
BLC OFF/BLC/HSBLC Selectable
AGC 0~15 Levels
White Balance ATW/AWC-SET/Indoor/Outdoor/
Manual/AWB
Sync. Mode Internal
Day/Night Ext, Auto, Color, B/W
UTC Function Supported
OSD Languages English/Simplified Chinese/Traditional Chinese/German/French/Italian/
Spanish/Polish/Russian/Portuguese/Netherlands/Turkish
DNR 2DNR/3DNR,Off
Defog Off/Auto
D-WDR On/Off/Auto
Sens-up Off/Auto(x2~x30)
Mirror Off/Mirror/V-Flip/Rotate
Motion Detection Off/On for 4 selectable zones
Privacy Mask Off/On for 4 selectable zones
Power Source 12VDC
Power Consumption 1.08W max.
Operating Temperature -10℃~50℃/ 14℉~122℉
Humidity Less than 80%
Dimensions 30x18mm/1.18”x0.71”30x19mm/1.18”x0.74”
Weight 60g/0.132lbs
Certifications CE/FCC/RoHS

EM900F eZ.HD Micro Mini Metal Camera
EverFocus Electronics Corp.
EverFocus Taiwan:
12F-1, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, New Ta ip ei City, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
[e-mail]
EverFocus Europe - Germany:
Albert-Einstein-Strasse 1, D-46446
Emmerich, Germany
TEL: [phone]
FAX: [phone]
www.everfocus.de
[e-mail]
EverFocus China - Beijing:
Room 609, Technology Trade Building,
Shangdi Information Industry Base,
Haidian District, Beijing 100085, China
TEL: [phone]~39
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus China - Shenzhen:
4F, No. 2, D4 Building, Wan Yelong
Industrial Park, Tangtou Road, Shiyan,
Baoan, Shenzhen, Guangdong 518101, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus USA - California:
1801 Highland Avenue, Unit A, Duarte, CA 91010,
USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus Japan:
3F Kuramochi, Buildingll 2-2-3 Koto-Bashi,
Sumida-Ku Tokyo, 130-0022, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.co.jp
[e-mail]
Your EverFocus product is designed and
manufactured with high quality materials
and components which can be recycled
and reused.
This symbol means that electrical and
electronic equipment, at their end-of-life,
should be disposed of separately from
your household waste.
Please, dispose of this equipment at your
local community waste
collection/recycling centre.
In the European Union there are
separate collection systems for used
electrical and electronic product.
Please, help us to conserve the
environment we live in!
Ihr EverFocus Produkt wurde
entwickelt und hergestellt mit
qualitativ hochwertigen Materialien
und Komponenten, die recycelt und
wieder verwendet werden können.
Dieses Symbol bedeutet, dass
elektrische und elektronische Geräte
am Ende ihrer Nutzungsdauer vom
Hausmüll getrennt entsorgt werden
sollen.
Bitte entsorgen Sie dieses Gerät bei
Ihrer örtlichen kommunalen
Sammelstelle oder im Recycling
Centre.
Helfen Sie uns bitte, die Umwelt zu
erhalten, in der wir leben!
