EverFocus EAN3200 User manual

EAN3200_db_en_rev01
EAN 3200 – 2.0 megapixel full HD H.264 day/night
network camera, automatic IR Cut filter
Features
2.0 megapixel full size HD CMOS image sensor with full 1080p
(1920 x 1080) resolution
H.264 encoding / decoding at real time HD resolution up to
1080p @ 25 fps
High performance noise reduction
Supports digital video stabilization funtion
Video encoder includes line driver for PAL TV signal
Dual codec for H.264 and MJPEG
Local storage through built-in SDHC slot for optional SDHC card
Day/night switching with automatic IR cut filter
Motion detection with 3 zones
Bidirectional audio function
Integrated player for playback of SD card recordings
ONVIF / PSIA compliant
Power supply included
Technical data
Sensor type 2.0 megapixel full HD network camera
Pickup device 10 mm (1/2,5”) progressive scan CMOS
Effective pixels 1920 x 1080
Sensitivity 0,4 lux / F = 1.2
Day/night switching Automatically swiveling IR cut filter
Electronic shutter Automatic / manual
Lens CS-mount / C-mount, DC drive, backfocus adjustment, lens not included
Video output 1 Vp-p composite BNC (test video output), switchable between video out and IP streaming
Video compression H.264 / MJPEG
Independent streams 2
Video frame rate Single stream: 25 IPS @ 1080p // Dual stream: up to 2x 25 IPS @ lower resolutions
Video resolution Max. 1920 x 1080 (1080p)
Compression setting CBR (constant bit rate): 14 steps // VBR (variable bit rate): 7 steps
Audio 1 audio input, 1 audio output
Audio operation mode Bidirectional, half-duplex
Network interface 10 Base-T / 100 Base-TX auto-negotiation, RJ-45 socket, supports MDI/MDI-X auto crossover function
Supported protocols HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, UPnP, PSIA, ONVIF
Alarm 1 alarm input, 1 alarm output
Motion detection 3 adjustable motion areas
Event trigger alarm input, manual trigger, motion detection
Event reaction trigger alarm output, send mail notification, upload video to FTP, record video to SD card, send HTTP
notification and network alarm
Local storage SD card interface for optional SD card, supports SDHC host specification
Power 12 V DC (230 V AC via included power supply), 5W max., or PoE 802.3af
Ambient temperature 0°C ~ +40°C
Humidity 20% ~ 80%
Dimensions (WxHxL) 68 x 57 x 143 mm (w/o socket & lens)
Weight 550 g
Ordering information
EAN 3200 2.0 Megapixel full HD H.264 day/night network camera, autom. IR cut filter, incl. 230 VAC PS, 12 VDC/PoE
EFV 412 MP 4 ~ 12 mm megapixel DC varifocal lens, format: 12,7 mm (1/2”)
EFV 246 MP 2,4 ~ 6 mm / F = 1.2 megapixel DC lens, format: 8,5 mm (1/3”)
EFV 308 MP 3 ~ 8 mm / F = 1.0 megapixel DC lens, format: 8,5 mm (1/3“)
EFV 550 MP 5 ~ 50 mm / F = 1.4 megapixel DC lens, format: 8,5 mm (1/3“)

EHN3200_db_en_rev01
EHN 3200 – 2.0 megapixel full HD H.264 day/night
network outdoor dome camera, automatic IR Cut filter
Features
2.0 megapixel full size HD CMOS image sensor with full 1080p
(1920 x 1080) resolution
H.264 encoding / decoding at real time HD resolution up to
1080p @ 25 fps
High performance noise reduction
Supports digital video stabilization funtion
Video encoder includes line driver for PAL TV signal
Dual codec for H.264 and MJPEG
Local storage through built-in SDHC slot for optional SDHC card
Day/night switching with automatic IR cut filter
Integrated varifocal lens
Motion detection with 3 zones
Bidirectional audio function
Vandal-proof IP66 outdoor housing
Integrated player for playback of SD card recordings
PoE (Power over Ethernet) supported
ONVIF / PSIA compliant
Power supply included
Technical data
Sensor type 2.0 megapixel full HD network camera
Pickup device 10 mm (1/2,5”) progressive scan CMOS
Effective pixels 1920 x 1080
Sensitivity 0,4 lux / F = 1.2
Day/night switching Automatically swiveling IR cut filter
Electronic shutter Automatic / manual
Lens 2,8 ~ 10 mm / F = 1.2 DC varifocal lens
Video output 1 Vp-p composite BNC (test video output), switchable between video out and IP streaming
Video compression H.264 / MJPEG
Independent streams 2
Video frame rate Single stream: 25 IPS @ 1080p // Dual stream: up to 2x 25 IPS @ lower resolutions
Video resolution Max. 1920 x 1080 (1080p)
Compression setting CBR (constant bit rate): 14 steps // VBR (variable bit rate): 7 steps
Audio 1 audio input, 1 audio output
Audio operation mode Bidirectional, half-duplex
Network interface 10 Base-T / 100 Base-TX auto-negotiation, RJ-45 socket, supports MDI/MDI-X auto crossover function
Supported protocols HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, UPnP, PSIA, ONVIF
Alarm 1 alarm input, 1 alarm output
Motion detection 3 adjustable motion areas
Event trigger alarm input, manual trigger, motion detection
Event reaction trigger alarm output, send mail notification, upload video to F
T
P, record video to SD card, send HTTP
notification and network alarm
Local storage SD card interface for optional SD card, supports SDHC host specification
Power 12 V DC (230 V AC via included power supply), 5W max., or PoE 802.3af
Ambient temperature -10°C ~ +40°C
Humidity 20% ~ 80%
Dimensions (diameter x H) 123 x 108 mm
Weight 740 g

EHN3200_db_en_rev01
Accessories
ED WMA – wall mount bracket
Material: aluminium
Dimensions (WxHxD): 150 x 110 x 170 mm
Weight: 600 g
Max. load: 4 kg
Application: with ED 610 T, EDN 850 H, EDN 800 T and EHN 3200
Ordering information
EHN 3200 2.0 Megapixel full HD H.264 day/night network outdoor dome camera, automatic IR cut filter,
incl. 230 VAC PS, 12 VDC/PoE
ED WMA Wall mount bracket

EDN3240_db_en_rev01
EDN 3240 – 2.0 megapixel full HD H.264 day/night
network indoor dome camera with IR LED,
automatic IR Cut filter
Features
2.0 megapixel full size HD CMOS image sensor with full 1080p (1920 x 1080) resolution
H.264 encoding / decoding at real time HD resolution up to 1080p @ 25 fps
High performance noise reduction
Supports digital video stabilization funtion
Video encoder includes line driver for PAL TV signal
Dual codec for H.264 and MJPEG
Local storage through built-in SDHC slot for optional SDHC card
Day/night switching with automatic IR cut filter
Integrated varifocal lens
Motion detection with 3 zones
Bidirectional audio function
Integrated player for playback of SD card recordings
ONVIF / PSIA compliant
Power supply included
Technical data
Sensor type 2.0 megapixel full HD network camera
Pickup device 10 mm (1/2,5”) progressive scan CMOS
Effective pixels 1920 x 1080
Sensitivity 0,4 lux / F = 1.2 (IR LED off) / 0 lux (IR LED on)
Day/night switching Automatically swiveling IR cut filter
Electronic shutter Automatic / manual
Lens 2,8 ~ 10 mm / F = 1.2 DC varifocal lens
Video output 1 Vp-p composite BNC (test video output), switchable between video out and IP streaming
Recommended object distance Approx. 20 m* (depending on reflections in scenery)
IR wavelength 850 nm
Video compression H.264 / MJPEG
Independent streams 2
Video frame rate Single stream: 25 IPS @ 1080p // Dual stream: up to 2x 25 IPS @ lower resolutions
Video resolution Max. 1920 x 1080 (1080p)
Compression setting CBR (constant bit rate): 14 steps // VBR (variable bit rate): 7 steps
Audio 1 audio input, 1 audio output
Audio operation mode Bidirectional, half-duplex
Network interface 10 Base-T / 100 Base-TX auto-negotiation, RJ-45 socket, supports MDI/MDI-X auto crossover function
Supported protocols HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, UPnP, PSIA, ONVIF
Alarm 2 alarm inputs, 1 alarm output
Motion detection 3 adjustable motion areas
Event trigger alarm input, manual trigger, motion detection
Event reaction trigger alarm output, send mail notification, upload video to FTP, record video to SD card, send HTTP
notification and network alarm
Local storage SD card interface for optional SD card, supports SDHC host specification
Power 12 V DC (230 V AC via included power supply), 6W max.
Ambient temperature 0°C ~ +40°C
Humidity 20% ~ 80%
Dimensions (diameter x H) 140 x 108 mm (surface mounting) / 140 x 68 mm (flush mounting)
Weight 660 g
Ordering information
EDN 3240 2.0 Megapixel full HD H.264 day/night network indoor dome camera with IR LED, automatic IR cut filter,
incl. 230 VAC power supply, 12 VDC

EZN3240_db_en_rev01
EZN 3240 – 2.0 megapixel full HD H.264 day/night
network bullet camera with IR LED and motorized
varifocal lens, automatic IR Cut filter
Features
2.0 megapixel full size HD CMOS image sensor with full 1080p (1920 x 1080) resolution
H.264 encoding / decoding at real time HD resolution up to 1080p @ 25 fps
High performance noise reduction
Supports digital video stabilization funtion
Video encoder includes line driver for PAL TV signal
Dual codec for H.264 and MJPEG
Remote zoom & focus adjustment by webbrowser
Local storage through built-in SDHC slot for optional SDHC card
Day/night switching with automatic IR cut filter
Integrated varifocal lens
Motion detection with 3 zones
Bidirectional audio function
Integrated player for playback of SD card recordings
ONVIF / PSIA compliant
Power supply included
Technical data
Sensor type 2.0 megapixel full HD network camera
Pickup device 10 mm (1/2,5”) progressive scan CMOS
Effective pixels 1920 x 1080
Sensitivity 0,4 lux / F = 1.2 (IR LED off) / 0 lux (IR LED on)
Day/night switching Automatically swiveling IR cut filter
Electronic shutter Automatic / manual
Lens 2,8 ~ 10 mm / F = 1.2 DC varifocal lens
Video output 1 Vp-p composite BNC (test video output), switchable between video out and IP streaming
Recommended object distance Approx. 20 m* (depending on reflections in scenery)
IR wavelength 850 nm
Video compression H.264 / MJPEG
Independent streams 2
Video frame rate Single stream: 25 IPS @ 1080p // Dual stream: up to 2x 25 IPS @ lower resolutions
Video resolution Max. 1920 x 1080 (1080p)
Compression setting CBR (constant bit rate): 14 steps // VBR (variable bit rate): 7 steps
Audio 1 audio input, 1 audio output
Audio operation mode Bidirectional, half-duplex
Network interface 10 Base-T / 100 Base-TX auto-negotiation, RJ-45 socket, supports MDI/MDI-X auto crossover function
Supported protocols HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, UPnP, PSIA, ONVIF
Alarm 1 alarm input, 1 alarm output
Motion detection 3 adjustable motion areas
Event trigger alarm input, manual trigger, motion detection
Event reaction trigger alarm output, send mail notification, upload video to FTP, record video to SD card, send HTTP
notification and network alarm
Local storage SD card interface for optional SD card, supports SDHC host specification
Weatherproof rating IP 66
Power 12 V DC (230 V AC via included power supply), 12W max. (IR LED on)
Ambient temperature -40°C ~ +50°C
Humidity 20% ~ 80%
Dimensions (WxHxD) 88 x 74 x 235 mm
Weight 1,15 kg
Ordering information
EZN 3240 2.0 Megapixel full HD H.264 day/night network bullet camera with IR LED and motorized varifocal lens,
automatic IR cut filter, incl. 230 VAC power supply, 12 VDC
