Operation Instruction
HDcctv 1080p
Indoor 3-Axis Dome Camera
EDH5210B
EDH5210W
EDH5210B(W)-002
EDH5201WEDH5201B
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

EVERFOCUS ELECTRONICS CORPORATION
Operation Instruction
© 2013 EverFocus Electronics Corp
Please read this manual rst for correct installation and operation. This manual should be
retained for future reference. The information in this manual was current when published.
The manufacturer reserves the right to revise and improve its products. All specications are
therefore subject to change without notice.
All rights reserved. No part of the contents of this manual may be reproduced or transmitted in
any form or by any means without written permission of the EverFocus Electronics Corporation.
3
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

4
PRECAUTIONS
1. Do not install the camera near electric or magnetic elds.
Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio speakers
since the electromagnetic elds generated from these devices may distort the video image or otherwise
interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor
introduce materials other than those recommended herein. Improper disassembly or
introduction of corrosive materials may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun. In some circumstances, direct sunlight may
cause permanent damage to the sensor and/or internal circuits, as well as creating unbalanced illumination
beyond the capability of the camera to compensate.
4. Keep the power cord away from water and other liquids and never touch the power
cord with wet hands. Touching a wet power cord with your hands or touching the power cord with wet
hands may result in electric shock.
5. Never install the camera in areas exposed to oil, gas or solvents.
Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, re.
6. Cleaning
For cameras with interchangeable lenses, do not touch the surface of the sensor directly with the hands. Use
lens tissue or a cotton tipped applicator and ethanol to clean the sensor and the camera lens. Use a damp
soft cloth to remove any dirt from the camera body. Please do not use complex solvents, corrosive or abrasive
agents for cleaning of any part of the camera.
7. Do not operate the camera beyond the specied temperature, humidity or power source ratings.
This camera is suitable for indoor operation. Use the camera at temperatures within -10°C~50°C (14°F~122°F) and
in an indoor environment; this device is not rated as weather proof. The input power source is 12VDC. The use of
properly fused or Class 2 power limited type supplies are highly recommended.
8. Mounting
Use care in selecting a solid mounting surface which will support the weight of the camera plus any wind,
snow, ice or other loading, and securely attach the camera to the mounting surface using screws and anchors
which will properly support the camera. If necessary (e.g. when mounting to drop ceilings) use a safety wire to
provide additional support for the camera.
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

5
ATTENTION! This is a class A product which may cause radio interference in
a domestic environment; in this case, the user may be urged to take adequate
measures.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one of the following measures :
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modications not expressly approved by the
party responsible for compliance could void the users’ authority to operate this
equipment.
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

Table of Contents
1. PRODUCT OVERVIEW ................................................................. 7
1.1 FEATURES .............................................................................................. 7
1.2 ACCESSORY PARTS LIST ..................................................................... 8
1.3 SPECIFICATIONS ................................................................................... 9
1.4 DIMENSIONS .......................................................................................... 10
2. CAMERA COMPONENT DESCRIPTION ...................................... 11
3. INSTALLATION ............................................................................. 12
4. OSD Structure.............................................................................. 14
6
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

1. Product Overview
The EDH5201 is an HDcctv indoor 3-axis dome camera with Day/Night capability available in your choice of white or black
plastic housing to match or contrast with the décor. Based on a 1/2.8” Sony 2.43 megapixel progressive scan sensor and
varifocal 3.6~16mm megapixel lens for HD 1080p resolution 100% digital images, it delivers vastly superior video quality
compared to traditional CCTV images. This superior resolution not only captures more critical evidentiary information, but
the inherent ability for megapixel video also extends the area of coverage, expedites completion of investigations, resolves
complaints and reduces both capital and operational costs. Designed with SENS-UP up to 8X low light enhancement
technology, the EDH5201 can capture color images in very low light without ghosting, or it can switch to monochrome
mode automatically in low light environments.
This highly advanced imaging system also incorporates state of the art optical enhancement technologies: Lens Shading
Correction compensates to eliminate articial shadows caused by attenuation of light as it traverses the outer portions of
the lens; Digital Slow Shutter light enhancement technology combines with Digital Noise Reduction (3D DNR) to maximize
image clarity while conserving DVR disk storage space; digital WDR to handle challenging lighting conditions; digital zoom
with electronic PTZ to ne tune eld of view; Highlight Suppression (HSBLC) to handle imbalance due to bright spots in
the scene; image ip/rotate, and much more.
No major upgrade to the IT network is required to deploy this powerful technology; HDcctv cameras communicate at
digital speeds up to 1.5Gb/s over existing or new coaxial cable (RG59 or other types for longer distances), using industry
standard BNC connectors. With its NTSC/analog secondary output to allow convenient aim and focus using a standard
hand held test monitor, full OSD controls, 3-axis positioning and 94° wide horizontal viewing angle megapixel lens the
EDH5201 delivers exible, robust coverage in a wide range of low light surveillance applications while delivering stunning
HD image quality.
1.1 Features
• HDcctv 2.1 Megapixel real time 1920x1080/1280x720 HD video over coax for superlative image detail
• Supports video outputs of 1080p30/25 and 720p60/50 (eld select)
• Varifocal 3.6~16mm megapixel lens
• Choice of Day/Night operation or Full Color Images in Low Light
• Provides 3-D DNR to improve picture clarity while enabling DVRs to improve disk storage utilization
• 3-Axis Gimbal for Flexible mounting and positioning
• Easy to use OSD setup menu with an array of options
• Enhanced low light sensitivity increase of up to 8x
• Lens Shading Compensation to oset diminished light transmission through lens periphery for uniform image
illumination
• Electronic WDR and HSBLC [Highlight Suppression Back Light Compensation] to handle lighting imbalance and bright
areas in the scene
• Digital zoom increases eective lens magnication up to 20X
• Up to 24 Privacy Zones
• Dead pixel compensation for increased clarity and extended service life
• SD TV Out for aim and focus using a standard hand held test monitor
7
Chapter
1
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

8
1.2 Accessory Parts List
Please be careful when you unpack the box due to the electronics devices inside.
Check and make sure that you have all the items listed below inside the original box:
Camera Manual
Pigtail Cable(Power) Mounting Template Screws Service Video Cable
Please Note: If an item appears to have been damaged in shipment, replace it properly in its carton and notify the
shipper. If any items are missing, notify your EverFocus Electronics Corp. Sales Representative or Customer Service. The
shipping carton is the safest container in which the unit may be transported. Save it for possible future use.
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

9
1.3 Specications
Pickup Device 1/2.8” Sony 2.43 Megapixel Color Progressive CMOS sensor
Image Pixels 1920(H)x1080(V) with 2.8μx 2.8μ pixel size
HDcctv Image Area Dimensions 5.38mm (H) x 3.02 mm(W); ø 6.17 mm area diagonal
Sensitivity 0.1lux/F=1.2 (Sens-Up OFF)
S/N Ratio More than 50dB
Video Format Main Output HDcctv
Video Resolution/Mode Main Output Field select 1080p30/25, 720p60/50
Main Output Connector BNC-F
Video Format Test Output NTSC/PAL selectable
Test Output Connector Pin connector on board; adapter cable to BNC-F supplied
Lens Type 3.6~16mm Megapixel DC Iris Lens
FOV Angle 72°~19° Horizontal
Shutter Speed Auto/Manual selectable
OSD Yes (5-axis joystick control)
D/N Mode Auto, Color, B/W (Electronic D/N)
Exposure Control Automatic Electronic Shutter
Digital WDR Weight Level Adjustable 0~4
DSS Low light boost up to 8X
Lens Shading Compensation On / Off
HSBLC (Highlight Suppression Back Light
Compensation) Off/On
Auto Gain Control Variable relative level 0~10
White Balance ATW / Push / Manual
DNR - 3D Low / Medium / High
Digital Zoom 1X~20X
Image Flip Off /V Flip/H flip/H+V flip (rotate)
Programmable Privacy Zones 24 areas independently adjustable for size, location, color
Language English
Dead Pixel Compensation Manual Off/On
Power Source & Consumption DC12V (+/-10%) @ 220mA
Mounting/Positioning 3-Axis gimbal
Dimensions Body: 95.3mm / 3.75“ (Max. H)
x Ø136.4mm / Ø5.37“ Base Diameter (W)
Weight 343g / 12.1oz
Housing Color Choice of black or white
Operating Temperature 20%~80% humidity, non-condensing
Operating Humidity Up to 80%
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

10
1.4 Dimensions
Inches:
Ø 5.31"
Ø 3.94"
Ø 4.27"
1.77"
3.81"
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

11
2. Camera Component Description
Chapter
2
OSD Menu Switch
Service Video Connector
OSD Menu Switch
• UP,DOWN :
Menu up / down
• LEFT,RIGHT : Change Values
• MENU : MENU(SELECTION KEY) / Enter
LEFT
UP
RIGHT
DOWN
MENU
Far/Near Adjustment Knob
Tele/Wide Adjustment Knob
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

12
3. Installation
Chapter
3
PART NAME
1 Mounting Template
2 Base
3 Pan Adjust
4 Tilt Adjust
5 Rotate Adjust
6Cover
7 Housing Cover
8 Dome Cover
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

When installing the camera, make sure that all cable ends and connectors
are protected from humidity and other outdoor environments.
13
* NOTE
Connections
DC12V In (Black)
BNC Female
(HDcctv Jack)
EDH5210
DC12V
Adapter
HDcctv DVR or other
HDcctv Signal Equipment
NTSC Video In
*Service Video Connector Handheld
Monitor
Test Cable
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

14
Chapter
4
4. OSD Structure SETUP
EXPOSURE
WHITE BALANCE
WDR / BLC
DNR
DAY & NIGHT
SPECIAL
SYSTEM
Reset Date All
EXT
Main Sub Menu Sub Menu
EXPOSURE
BRIGHTNESS 0 ~ 20
AE MODE NORMAL AE / INDOOR
LENS(IRIS) MANUAL / AUTO
SHUTTER MANUAL /
AUTO
LEVEL 1/30(25), 1/60(50), 1/120(100), 1/240, 1/500,
1/1K, 1/2K, 1/4K, 1/8K, 1/16K, 1/30K, 1/60K.
RETURN BACK / EXIT
DSS OFF, X2, X3, X4, X5, X6, X7, X8
AGC 0 ~ 10
BASE FREQ 60Hz / 50Hz
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
WHITE BALANCE
WB MODE
AUTO
/AUTOext /
PUSH
/MANUAL
COLORTEMP. LOW / MIDDLE / HIGH
R-GAIN 0 ~ 20
B-GAIN 0 ~ 20
RETURN BACK / EXIT
SATURATION 0 ~ 20
RESET DATE BACK / DEF.
RETURN BACK / EXIT.
DWDR / BLC
MODE OFF, BLC, DWDR
WDR WGT 0 ~ 4
BLC OSD OFF ~ ON
BLC POS-X 0 ~ 20
BLC POS-Y 0 ~ 20
BLC SIZE-X 0 ~ 20
BLC SIZE-Y 0 ~ 20
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
DNR OFF, LOW, MIDDLE, HIGH
DAY & NIGHT COLOR/B&W/
AUTO
D&N DETECT AGC / SENSE
DELAY 1sec, 3, 5, 10, 15, 20, 25, 30, 40, 50, 60sec
D->N LEVEL 0 ~ 20(AGC) / 0 ~ 10(SENSE)
N->D LEVEL 0 ~ 20(AGC) / 0 ~ 10(SENSE)
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

15
Main Sub Menu Sub Menu
SHARPNESS 0 ~ 10
FLIP OFF, H FLIP, V FLIP, HV FLIP
LENS SHADING OFF, ON
DZOOM 1x, 2x, 4x, 6x, 8x, 10x, 12x, 14x, 16x, 18x, 20x
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
SPECIAL
PRIVACY OFF/ ON
ZONE NO. 0 ~ 23
ZONE OP. OFF/ ON
X-POS 0 ~ 60
Y-POS 0 ~ 40
X-SIZ 0 ~ 40
Y-SIZ 0 ~ 40
COLOR BLK, WHI, YEL, CYN, GRN,
MAG, RED, BLU
TRANS. 0 ~ 4
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
HLMASK OFF/ ON
LEVEL 0 ~ 20
COLOR BLK, WHI, YEL, CYN, GRN,
MAG, RED, BLU
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
PATTERN OFF, 1, 2
DISPLAY INFO.
CAMERA ID. OFF/ ON
MOTION CHECK OFF/ ON
RETURN BACK / EXIT.
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
SYSTEM
SDI FORMAT 1080p / 720p
SDI FPS 30 / 25 (when 1080p), 60 / 50 (when 720p)
CVBS FORMAT NTSC / PAL
APPLY OK
SYSTEM INFO S/W VERSION
SET VERSION
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
4. OSD Structure
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html

EverFocus Electronics Corp.
EverFocus Taiwan:
12F, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, Taipei, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
[email protected]
EverFocus Europe - Germany:
Albert-Einstein-Strasse 1, D-46446
Emmerich, Germany
TEL: [phone]
FAX: [phone]
www.everfocus.de
[email protected]
EverFocus China - Beijing:
Room 609, Technology Trade Building,
Shangdi Information Industry Base,
Haidian District, Beijing 100085, China
TEL: [phone]~39
FAX: [phone]
www.everfocus.com.cn
[email protected]
EverFocus China - Shenzhen:
4F, No. 2, D4 Building, Wan Yelong
Industrial Park, Tangtou Road, Shiyan,
Baoan, Shenzhen, Guangdong 518101, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[email protected]
EverFocus USA - California:
1801 Highland Avenue, Unit A, Duarte, CA 91010, USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[email protected]
EverFocus USA - New York:
415 Oser Avenue, Unit S, Hauppauge, NY 11788, USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[email protected]
EverFocus Japan:
5F, Kinshicho City Building, 2-13-4 Koto-Bashi,Sumida-Ku,
Tokyo, 130-0022, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.co.jp
[email protected].jp
EverFocus Europe - UK:
Unit 12, Spitfire Business Park,
Hawker Road, Croydon Surrey, CR0 4WD, UK
TEL: [phone]
FAX: [phone]
www.everfocus.com
[email protected]
EverFocus India:
Suite 803, Housen Bhavan, C-21,
Bandra Kurla Complex, Bandra (East),
Mumbai 400051, India
TEL: [phone]
FAX: [phone]
www.everfocus.in
[email protected]
Your EverFocus product is designed
and manufactured with high quality
materials and components which can
be recycled and reused.
This symbol means that electrical and
electronic equipment, at their end-of-
life, should be disposed of separately
from your household waste.
Please, dispose of this equipment at
your local community waste
collection/recycling centre.
In the European Union there are
separate collection systems for used
electrical and electronic product.
Please, help us to conserve the
environment we live in!
Ihr EverFocus Produkt wurde
entwickelt und hergestellt mit qualitativ
hochwertigen Materialien und
Komponenten, die recycelt und wieder
verwendet werden können.
Dieses Symbol bedeutet, dass
elektrische und elektronische Geräte
am Ende ihrer Nutzungsdauer vom
Hausmüll getrennt entsorgt werden
sollen.
Bitte entsorgen Sie dieses Gerät bei
Ihrer örtlichen kommunalen
Sammelstelle oder im Recycling Centre.
Helfen Sie uns bitte, die Umwelt zu
erhalten, in der wir leben!
This Manual:http://www.manuallib.com/everfocus/edh5210-mini-dome-camera-manual.html
